ATN PVS14-3 User manual

US Military design
Multi-Purpose unit
Handheld monocular
Hands-free goggle (optional helmet mount)
Mil-Spec headgear
Limited Two-Year Warranty
MULTI-PURPOSE SYSTEM
1341 San Mateo Ave,
South San Francisco, CA 94080.
Tel: [phone],
fax: [phone]
www.atncorp.com
e-mail: [email protected], [email protected]
ATNs PVS14 are rugged, lightweight and versatile night
vision monoculars, designed for the most demanding of
nighttime applications. The PVS14 can be handheld,
head/helmet-mounted for hands-free usage or adapted to
cameras/camcorders. Originally designed for the U.S. military,
these units are of the highest quality in optics, design and
functionality. The ATN PVS14 is an outstanding choice for
professional night vision applications.
INCLUDED
ACCESSORIES
HEAD MOUNT
ASSEMBLY
HELMET MOUNT
ASSEM BLY
Export Warning: These products are subject to one or more of the export control laws and regulations of the U.S. Government. Pending the model these products are under the control jurisdiction of
either the US Department of State or the US Bureau of Industry and Security US Department of Commerce. Export without proper licensing or consent is strictly prohibited.
THE PVS-14 BASIC KIT
Head Mount Assembly - Allows for hands-free operation
Brow Pad - Changeable pad for secure head mount fit
Helmet/Head Mount Adapter - Allows the user to position the monocular in
front of either eye
Eye Cup - Prevents the emission of stray light or facial reflections
Soft Carrying Case - Provides convenient storage of PVS14 and accessories
Shoulder Strap - Attaches to the PVS14 carrying case for easy portability
Lens Paper - Used to lightly clean the objective and eyepiece glass surfaces
Day Light Filter - Filters excessive light. Protects objective lens from the elements
Diopter Lens Cap - Protects diopter lens from the elements
Operator’s Manual - Instructional user’s guide
Batteries - One 1.5V AA size
SPECIFICATIONS
TOTAL DARKNESS IR SYSTEM
"SMART" TECHNOLOGY
MULTI-PURPOSE SYSTEM
IIT GENERATION
RESOLUTION
MAGNIFICATION
LENS SYSTEM
PROSHIELD LENS COATING
FOV
RANGE OF FOCUS
DIOPTER ADJUSTMENT
CONTROLS
AUTOMATIC BRIGHTNESS CONTROL
BRIGHT LIGHT CUT-OFF
AUTOMATIC SHUT-OFF SYSTEM
INFRARED ILLUMINATOR
IR INDICATOR
LOW BATTERY INDICATOR
POWER SUPPLY
BATTERY LIFE
ENVIRONMENTAL RATING
MIL-STD-810
OPERATING TEMPERATURE
STORAGE TEMPERATURE
DIMENSIONS
WEIGHT
Yes
No
Yes
3
64 lp/mm
1x
F1.2, 26 mm
Yes
40°
0.25 m to infinity
-5 to +2
Direct
Yes
Yes
Yes
Yes
Yes
Yes
1 x 1.5 V AA type battery
50 hrs
Waterproof
Complies
-40 to +50 °C
-50 to +70 °C
114x56x50 mm / 4.5”x2,2”x2”
0.3 kg / 0,68 lbs
TUBE SPECIFICATIONS
HIGH QUALITY 3 GEN IMAGE INTENSIFIER TUBE
* Specifications are provided for informational purposes only. Actual values may vary
DESCRIPTION
GENERATION
PHOTOCATHODE TYPE
RESOLUTION, lp/mm*
SIGNAL TO NOISE RATIO*
FIGURE OF MERIT
MTTF - MEAN TIME BEFORE FAILURE, hours
EXPORT
Standard
3
GaAs
64
22 Typical
1600 Typical
10,000
N/A for Export
PVS14–3
