Bushnell 71-3946 User manual

Congratulations on your choice of a Bushnell®riflescope. It is a precision instrument
constructed of the finest materials and assembledby highly skilled craftsmen fora lifetime
of trouble-free use under the most demanding conditions.
This booklet will help you achieve optimum performance by explaining how to use it’s
various features and how to care for it. Read the instructions carefully before mounting
and using yourscope.
The following photographs are guides to the nomenclature and location of the riflescope
parts mentioned throughout this text.
Elevation Adjustment
Shoulder Objective Lens
Windage Adjustment
Eyepiece
Power Change Ring
Fast
Focus
Objective
Adjustment Ring
EYEPIECE FOCUSING
The eyepiece is designed to provide a precise fast focus. The eyepiece will focus
faster than your eye can compensate for any inaccuracy in your adjustment.
Look at a distant object for several seconds without using your scope. Then, shift
your vision quickly, looking through the scope at a plain background. Turn the fast-
focus eyepiece clockwise or counter clockwise to adjust to your eyes. The reticle
pattern shouldbe sharp and clear beforeyour eye can refocus. After you have made
your adjustment, with a quick glance re-check the image.
WARNING: NEVER LOOK AT THE SUN THROUGH THE RIFLESCOPE (OR ANY
OTHER OPTICAL INSTRUMENT). IT MAY PERMANENTLY DAMAGE YOUR EYES.
CENTERING THE RETICLE
The reticle wascarefullysetat the opticalcenter ofyourriflescopeat our factory. This
setting provides you with the ideal adjustment range from the center position. The
riflescope’s adjustments are used to zero-in the riflescope.
It is wise to check the center of the optical axis before mounting. Do this by placing
the scope in a solid V-block (cardboard box with two slots). While looking through
the scope in a normal viewing position, carefully rotate the scope. If the target
moves in a circle larger than 1” from center (at 25 yards) in relation to intersection
of crosshairs, reset windage and elevation adjustments. Remove adjustment caps.
Set each adjustment to midpoint and recheck for centering. If target still rotates,use
adjustments to correct.
MOUNTING
To achieve the best accuracy from your rifle, your Bushnell scope must be mounted
properly. (We strongly recommend that those unfamiliar with proper procedures
have the scope mounted by a qualified gunsmith). Should you decide to mount
it yourself:
1. Use a high-quality mount with bases designed to fit your particular rifle. The
scope should be mounted as low as possible without touching either the barrel
or the receiver.
2. Carefully follow the instructions packed withthe scope mounts you have selected.
3. Before tightening the mount rings, look through the scope in your normal
shooting position. Adjust the scope (either forward or backward) until you find
the furthest point forward (to ensure maximum eye relief) that allows you to see
a full field of view.
WARNING: IF THE SCOPE IS NOT MOUNTED FAR ENOUGH FORWARD, IT’S
REARWARD MOTION MAY INJURE THE SHOOTER WHEN THE RIFLE RECOILS.
4. Rotate the scope in the rings until the reticle pattern is perpendicular to the bore
and the elevation adjustment is on top.
5. Tighten the mounting screws.
BORE SIGHTING
Bore sighting is a preliminary procedure to achieve proper alignment of the scope
with the rifle’s bore. It is best done using a Bushnell®Bore Sighter. If a bore sighter
is not available, it can be done as follows: Remove the bolt and sight through the
gun barrel at a 100 yard target. Then sight through the scope and bring the cross
hairs to the same point on the target. Certain mounts have integral windage
adjustments and, when bore sighting, these should be used instead of the scope’s
internal adjustments. If major elevation adjustments are needed, they should be
accomplished by shimming the mount base.
WINDAGE
ADJUSTMENT ELEVATION
ADJUSTMENT
RESETTING THE ADJUSTMENT SCALE RING
This step isnot necessary, but, for futurereference,you maywant torealign the zero
markson the Adjustment Scale Rings with the index dots.
1. Using a jeweler’s screwdriver, loosen the Phillips screw on the Adjustment Scale
about1/2 turn.Take carenotto disturbyourzeroby“losing” aclick ortwowhen
loosening the screws.
2. Rotate the Adjustment Scale Ring(which should nowturnfreely) to align the “O”
with the Index Dot.
3. Retighten the screw in the Adjustment Scale and reinstall the Elevation and
Windage Adjustment Knobs.
VARIABLE POWER ADJUSTMENTS
To change magnification, simply rotate the Power Selector Ring to align the desired
number on the power scale with index dot.
When still-hunting or stalking game, a variable scope should be set to the lowest
power. You then have the widest field of view for quick shots at close range. Higher
powersshould be reserved for precise long-range shots.
WARNING: A SCOPE SHOULD NEVER BE USED AS A SUBSTITUTE FOR EITHER A
BINOCULAR OR SPOTTING SCOPE. IT MAY RESULT IN YOUR INADVERTENTLY
POINTING THE GUN AT ANOTHER PERSON.
ADJUST ABLE OBJECTIVE LENS
This feature (if present onyour scope) permits precise focusing, whilesimultaneously
readjusting the parallax-free distance, for any range from 50 yards to infinity. To
change range focus, turn the Objective Adjustment Ring and align the number with
the distanceindex dot. Analternativemethod is to look through the scope and turn
theObjective AdjustmentRinguntil thetarget, at whateverrange, issharplyfocused.
MAINTENANCE
Your Bushnell riflescope, though amazingly tough, is a precision instrument that
deserves reasonable cautious care.
1. When cleaning the lenses, first blow away any dirt and dust, or use a soft lens
brush. Fingerprints and lubricants can be wiped off with lens tissue, or a soft
clean cotton cloth, moistened with lens cleaning fluid.
WARNING: UNNECESSARY RUBBING OR USE OF A COARSE CLOTH MAY
CAUSE PERMANENT DAMAGE TO LENS COATINGS.
2. All moving parts of the scope are permanently lubricated. Do not try to
lubricate them.
3. No maintenance is needed on the scope’s outer surface, except to occasionally
wipe off dirt or fingerprints with a soft cloth.
4. Use lens covers whenever convenient.
STORAGE
Avoid storing the scope in hot places, such as the passenger compartments of
vehiclesonhot days. Thehigh temperatures couldadversely affectthelubricantsand
sealants. A vehicle’s trunk, a gun cabinet or a closet is preferable. Never leave the
scope where direct sunlight can enter either the objective or the eyepiece lens.
Damage may result from the concentration (burning glass effect) of the sun’s rays.
Riflescope
Instruction Manual ZEROING
Final sighting-in of your rifle should be done with live ammunition, based on your
expectedshootingdistance. If most of your shotswill beat short range, zero-in at 100
yards. But, for long-range shooting at big game, most experienced shooters zero-in
aboutthree inches high at 100 yards. Three-shot groups are useful for averaging the
point of impact.
ELEVATION AND WINDAGE ADJUSTMENT
Most Bushnell®scopes feature finger-adjustable audible-click elevation and
windage adjustments.
1. Remove the covers from the Elevation and Windage Adjustments.
2. Grasp the Adjustment Bar and turn it in the appropriate “UP” (and/or “R”)
direction indicated by the arrows. Each “click” or increment on the Adjustment
Scale Ring will change bullet impact by 1/4" Minute of Angle . 1/4" MOA
corresponds to 1/4 inch at 100yards,1/2 inchat 200 yards, 3/4 inch at 300 yards
and so on(1/12" at 50 feet for air rifles).
1
Warranty information on page 2.
Lit. #: 91-0200/02-01

WARRANTY / REPAIR
LIFETIME LIMITED WARRANTY
Your Bushnell®riflescope is warranted to be free of defects in materials and
workmanship for the lifetime of the original owner. The Lifetime Limited
Warranty is an expression of our confidence in the materials and mechanical
workmanship of our products and is your assurance of a lifetime of dependable
service. In the event of a defect under this warranty, we will, at our option, repair
or replace the product, provided that you return the product postage prepaid.
This warranty does not cover damages caused by misuse or improper handling,
installation or maintenance of the product.
Any return made under this warranty
must be accompanied by the items listed below:
1) A check in the amount of $10.00 to cover the cost of handling
2) Name and address for product return
3) An explanation of the defect
4) Product should be well packed in a sturdy outside shipping
carton to prevent damage in transit and return postage prepaid to
the address listed below:
IN U.S.A. Send T o:
Bushnell Performance Optics
8500 Marshall Drive
Lenexa, Kansas 66214
For products purchased outside the United States and Canada please contact your local
dealer for applicable warranty information. This warranty gives you specific legal rights.
You may have other rights which vary from country to country.
©2001 Bushnell Performance Optics
2
IN CANADA Send To:
Bushnell Performance Optics
25A East Pearce Street, Unit 1
Richmond Hill, Ontario L4B 2M9
