ATN MARS6-21A User manual

MARS6 with remote control
NIGHT VISION WEAPON SIGHT
ATN Night Vision Weapon sights – the world’s most complete line of
professional night vision sights – has a new flagship – the ATN MARS
Series. Inspired by ATN’s quest for technical perfection and named after the
Roman God of War, the ATN MARS NV riflescopes represent the absolute
latest in the world of night vision equipment. Similar to all ATN scopes the
ATN MARS features only the purest grades of heavy glass and computer-
aided optical designs to create multi-element, high-speed, multi-coated
lenses for ultra-fast light transmission and resolution beyond current
military standards. All optical lenses on the MARS scopes are individually
fitted and calibrated to achieve optimum performance.
The ATN MARS uses the highest quality MX10160 type hand-selected
image intensifier tubes (IIT) based on the latest night vision technologies.
Compact, lightweight and rugged one-piece construction is CNC milled
from solid aerospace-quality aluminium billet and fitted with titanium
inserts. The ATN MARS gives the weapon operator 50% more (45mm!) of
eye relief than Raptor (4X and 6X) and ITT F7001 (A) and offers superior
performance over other manufacturer’s models in regard to step of windage
and elevation precision as well as in other characteristics and features.
ATN MARS is the only night vision scope with new ATN proprietary
feature – Two-Color Manual Brightness control of the aiming reticle. This
feature allows for a choice of color (red or amber) of the projected reticle
depending on operator’s preference and tactical situation.
Powerful 6x magnification
Superior quality Multi-coated all-glass optics
Precision windage and elevation adjustments
Tactical digital remote control
Waterproof and submersible to 66 feet for 1 hour
Included mount for Piccatiny or 7/8” Weaver-style rail
Unit accepts either, (1) 3V CR123A or (1) AA battery
Nitrogen-purged for resistance to internal fogging
Free Pelican Hard case included
Limited Two-Year Warranty
Export Warning: These products are subject to one or more of the export control laws and regulations of the U.S. Government. Pending the model these products are under the control jurisdiction of
either the US Department of State or the US Bureau of Industry and Security US Department of Commerce. Export without proper licensing or consent is strictly prohibited.
1341 San Mateo Ave,
South San Francisco, CA 94080.
Tel: [phone],
fax: [phone]
www.atncorp.com
e-mail: [email protected], [email protected]
IR-450 Infra-red
Illuminator
HIGH QUALITY 2IA GEN IMAGE INTENSIFIER TUBE
DESCRIPTION Alpha
GENERATION 2+
PHOTOCATHODE TYPE Multi - Alkali
RESOLUTION, lp/mm* 40-50
FIGURE OF MERIT <1000
MTTF - MEAN TIME BEFORE FAILURE, hours 5,000
EXPORT Dual-use: subject to EAR
* Specifications are provided for informational purposes only. Actual values may vary
TUBE SPECIFICATIONS
MARS6-2IA
Magnification 6x
Lens System F 2.0; 160 mm
FOV 6°
Exit Pupil 7mm
Eye Relief 45 mm
Range of Focus 25 m to infinity
Diopter Adjustment -5 to +5
Controls Direct
Remote Control Yes
Automatic Brightness Control Yes
Bright Light Cut-off Yes
IR Indicator Yes
Low Battery Indicator Yes (in FOV)
Power Supply 1 x 1.5 V AA type battery or
1 x 3 V CR123A type battery
Battery Life 55 hours (3V) / 40 hours (1.5V)
Environmental Rating Waterproof
Operating Temperature -51 to +45 °C
Storage Temperature -55 to +70 °C
Dimensions 295x90x100 mm/11.6x3.7x3,9”
Weight 1.55 kg / 3.4 lbs
SPECIFICATIONS
