ATN Mars4x-3P User manual

mars 4x-3p
mars 4x-3p
AMERICAN TECHNOLOGIES NETWORK, CORP.
www.atncorp.com
E-mail: [email protected], [email protected]
American Technologies Network Corp.
1341 San Mateo Avenue, South San Francisco, CA 94080
800-910-2862, 650-989-5100, FAX [phone]
• POWERFUL 4X MAGNIFICATION
• SUPERIOR QUALITY MULTI-COATED ALL GLASS OPTICS
• “SINGLE-ELEMENT” ADJUSTABLE FRONT FOCUS
• MIL-DOT RETICLE
• CRISP-CLICK PRECISION WINDAGE AND ELEVATION
ADJUSTMENTS
• TARGET TURRETS
• AUTOMATIC BRIGHTNESS CONTROL
• NITROGEN-PURGED FOR RESISTANCE TO INTERNAL FOGGING
• TACTICAL RAIL ENABLING MOUNTING OF IR ILLUMINATOR OR IR
LASER
• LOW BATTERY INDICATOR
• DIGITAL REMOTE CONTROL
• WATERPROOF AND SUBMERSIBLE TO 66 FEET FOR 1 HOUR
• PELICAN HARD CASE, BATTERIES, USER GUIDE, NV INSTRUCTIONAL
VIDEO AND ALL NECESSARY MOUNTING HARDWARE ARE INCLUDED
• INCLUDED MOUNT FOR PICCATINY, 7/8" WEAVER-STYLE RAIL OR
AK STYLE WEAPONS
• UNIT ACCEPTS EITHER, (1) 3V CR123A OR (1) AA BATTERY
• DAY TIME COVER WITH IR FILTER
4X
F1:1.5
9°
10M TO INFINITY
45MM
7MM
-6 / +2
120MOA
1/4MOA
ONE 3 V LITHIUM OR 1.5V(AA)
50 H (3V), 40 H (1.5V)
-40°C TO +50°C
-50°C TO +70°C
20M FOR 1 HOUR
MILDOT 2 COLORS
(RED AND AMBER)
235 X 90 X 95 MM
1.3 KG
MAGNIFICATION...........................................
LENS SYSTEM..............................................
FOV...............................................................
RANGE OF FOCUS.......................................
EYE RELIEF..................................................
EXIT PUPIL...................................................
DIOPTER ADJUSTMENT................................
WINDAGE & ELEVATION ADJUSTMENTS......
RETICLE ADJUSTMENT STEP SIZE..............
POWER SUPPLY...........................................
BATTERY LIFE.............................................
OPERATING TEMPERATURE, C.......................
STORAGE TEMPERATURE, C.........................
WATERPROOF.............................................
RETICULE ...................................................
DIMENSIONS................................................
WEIGHT........................................................
The ATN MARS4X-3P is a night vision weapon sight that utilizes a 3rd generation image intensifier tube
(IIT). The Figure of merit of the IIT for this unit is less then 1800.
Compact, lightweight and rugged one-piece construction is CNC milled from solid quality aluminum
billet and fitted with titanium inserts.
The ATN MARS series is equipped with a new ATN proprietary feature – Two-Color Manual Brightness
of the aiming reticle. This feature allows for a choice of color (red or amber) of the projected reticle depend-
ing on operator preference and lighting situation.
Export Warning: These products are subject to one or more of the export control laws and regulations of the U.S. Government. Pending the model these products are under the control
jurisdiction of either the US Department of State or the US Bureau of Industry and Security US Department of Commerce. Export without proper licensing or consent is strictly prohibited.
Pinnacle™
3
THIN FILM GaAs
64 - 72
24 TYPICAL
N/A FOR EXPORT
1800 TYPICAL
2000-2800
HIGH QUALITY 3P GEN IMAGE INTENSIFIER TUBE
* Specifications are provided for informational purposes only. Actual values may vary
DESCRIPTION ................................
GENERATION ................................
PHOTOCATHODE TYPE ................
RESOLUTION, LP/MM * ................
SIGNAL-TO-NOISE RATIO* ........
EXPORT ........................................
FIGURE OF MERIT ........................
PHOTOCATHODE SENSITIVITY.......
3P - ITT Pinnacle™ Intensifier Tubes
ATN night vision units with the 3P designation use
ITT Pinnacle™ Image Intensifier tubes. The industry
leading ITT Pinnacle image tubes utilize a gated power
supply providing truly outstanding performance in
high-light or light-polluted areas, such as urban
environments. The Pinnacle™ tube with gated power
supply minimizes any “halo” effects. “Halo” is often
associated with using night vision devices in an urban
area where random street lights are often an issue with
early Generation night vision devices. Night vision units
with Pinnacle™ tubes have a typical resolution of
64-72lp/mm and a typical signal to noise ratio of 24.
All night vision devices utilizing Pinnacle™ Image
Intensifier tubes come with ITT data record sheet.
*Pinnacle is a registered trademark of ITT Night Vision
