ATN TTWS Series User manual

TTWS Series
THERMAL WEAPON SIGHTS
operator’s manual
OPERATOR’S MANUAL (TTWS Series) REVISION 4 – APRIL, 2014
Important Export Restrictions! Commodities, products,
technologies and services contained in this manual are
subject to one or more of the export control laws and
regulations of the U.S. Government and they fall under the
control jurisdiction of either the US Department of State or the
US BIS-Department of Commerce. It is unlawful and strictly
prohibited to export, or attempt to export or otherwise transfer
or sell any hardware or technical data or furnish any service to
any foreign person, whether abroad or in the United States, for
which a license or written approval of the U.S. Government is
required, without first obtaining the required license or written
approval from the Department of the U.S. Government having
jurisdiction. Diversion contrary to U.S. law is prohibited.

Register your product warranty online at
www.atncorp.com/warranty
Manual (TTWS Series) Revision 4 – April, 2014
The information in this manual furnished for information use only, is subject to
change without notice, is not to be construed as a commitment by ATN Corp.
ATN Corp. assumes no responsibility or liability for any errors or inaccuracies
that may appear in this book.
© 2014 ATN Corp. All right reserved.

a
THIS PRODUCT CONTAINS NATURAL RUBBER LATEX
WHICH MAY CAUSE ALLERGIC REACTIONS.
CAUTION:
SAFETY SUMMARY
STUDY CAREFULLY THIS MANUAL BEFORE TURNING ON
AND OPERATING THIS PRODUCT.
CAUTIONS
The TTWS Series Thermal Digital Riflescopes are precision
electro-optical instruments and requires careful handling. To pro-
vide safe use of the systems the following instructions should be
observed:
• Do not dismantle the device.
• Keep the device clean; protect it from moisture, sharp tem-
perature drops and shocks.
• Be careful not to touch the glass surfaces. If you put fin-
ger-prints on, or contaminate the glass surfaces, use only
clean and soft materials to clean it.
• Do not leave the device in on position during stops in opera-
tion.
• Remove the batteries from the device for the period of storage.

b
WARNING
Do not permanently attach the scope to dynamic-mount applica-
tions that continuously transmit vibration (such as on vehicles or
heavy machinery).
WARNING
Do not point the scope directly at any high-intensity objects that you
must not view with your eyes (such as the sun or a welding arc). If
you do, you will damage the scope.
WARNING
Operating TTWS Series outside of its specified operating tempera-
ture range or voltage range can cause permanent damage and will
void the warranty.
WARNING
Use the power button to turn the scope off before you remove power
(remove batteries or disconnect external power supply).
WARNING
TTWS Series operates over a wide operating temperature range
(-20°C to +60°C). Not all lithium batteries are specified over this
same temperature span. Check the manufacturer’s specifications
of your selected battery to verify the valid temperature range.
WARNING
Do not use any battery other than a CR-123A lithium battery. DO
NOT use any battery(ies) providing a (combined) voltage greater
than 12.0 volts.
WARNING
Do not install batteries of different types (lithium with lithium-ion
rechargeable). All batteries must be of the same type.
WARNING
Do not replace batteries in a possibly explosive environment, such
as a gas station (or any place where you must turn off your vehicle
engine). If you do, sparks can cause an explosion.

c
WARNING
Remove the batteries before you store the riflescopes for extended
periods (2 weeks or more).
WARNING
Do not carry batteries in pockets containing metal objects such as
coins, keys, etc. Metal objects can cause the batteries to short cir-
cuit and become very hot. In the case of lithium batteries, a short
circuit could cause them to explode.
WARNING
Observe battery manufacturer’s guidelines for safe handling and
proper disposal of batteries.
EQUIPMENT LIMITATIONS
• The TTWS Series detector spectral band (7 to 14 mkm) pro-
vides a better penetration through smoke, smog, dust, water
vapor etc.
• Infrared radiation does not travel through glass and therefore
the scope does not sense objects if they are behind a glass
window.

i
TABLE OF CONTENTS
CHAPTER 1. INTRODUCTION . . . . . . . . . . . . . . . . . 1-1
1.1. General Information . . . . . . . . . . . . . . . . . . . . 1-2
1.1.1. Scope . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2
1.1.2. Reports . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2
1.1.3. Storage . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2
1.1.4. Warranty Information . . . . . . . . . . . . . . . . . . . 1-2
1.2. Description and Data . . . . . . . . . . . . . . . . . . . 1-5
1.2.1. Description . . . . . . . . . . . . . . . . . . . . . . . . 1-5
1.2.2. TTWS Standard Components. . . . . . . . . . . . . . . 1-7
1.2.3. Specifications . . . . . . . . . . . . . . . . . . . . . . . 1-8
1.2.4. Mechanical Function . . . . . . . . . . . . . . . . . . 1-11
1.2.5. Optical Function. . . . . . . . . . . . . . . . . . . . . 1-11
1.2.6. Electrical Function . . . . . . . . . . . . . . . . . . . 1-12
CHAPTER 2. ASSEMBLY AND PREPARATION . . . . . . . . 2-1
2.1. Preparation. . . . . . . . . . . . . . . . . . . . . . . . . 2-2
2.1.1. Preparation for Use . . . . . . . . . . . . . . . . . . . . 2-2
2.1.2. Examination for Operation . . . . . . . . . . . . . . . . 2-3
2.2. Assembly. . . . . . . . . . . . . . . . . . . . . . . . . . 2-4
2.2.1. Remove/installation of Quick Release Mount (QRM) . . . 2-4
2.2.2. Video Output . . . . . . . . . . . . . . . . . . . . . . . 2-5
CHAPTER 3. OPERATION . . . . . . . . . . . . . . . . . . . 3-1
3.1. General Information . . . . . . . . . . . . . . . . . . . . 3-2
3.1.1. General . . . . . . . . . . . . . . . . . . . . . . . . . . 3-2
3.1.2. Controls and Indication . . . . . . . . . . . . . . . . . . 3-2
3.2. Operating procedure . . . . . . . . . . . . . . . . . . . 3-3
3.2.1. Turning On . . . . . . . . . . . . . . . . . . . . . . . . 3-3
3.2.2. Focusing . . . . . . . . . . . . . . . . . . . . . . . . . 3-4
3.2.3. ISM – Interactive Symbology Menu . . . . . . . . . . . . 3-5
3.2.4. Polarity . . . . . . . . . . . . . . . . . . . . . . . . . . 3-6
3.2.5. Brightness. . . . . . . . . . . . . . . . . . . . . . . . . 3-7

ii
3.2.6. Zoom . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-7
3.2.7. Color Modes . . . . . . . . . . . . . . . . . . . . . . . 3-8
3.2.8. Manual Image Refresh / Calibration . . . . . . . . . . . 3-9
3.2.9. Reticle Color . . . . . . . . . . . . . . . . . . . . . . 3-10
3.2.10. Reticle Pattern . . . . . . . . . . . . . . . . . . . . . 3-10
3.2.11. New Firmware Change Guide . . . . . . . . . . . . . 3-11
3.2.12. Shut Down Operations. . . . . . . . . . . . . . . . . 3-11
CHAPTER 4. MAINTENANCE INSTRUCTIONS . . . . . . . . 4-1
4.1. Preventive Maintenance Checks and Services (PMCS) . 4-2
4.1.1. Purpose of PMCS. . . . . . . . . . . . . . . . . . . . . 4-2
4.1.2. Frequency of Performing PMCS . . . . . . . . . . . . . 4-2
4.2. Troubleshooting . . . . . . . . . . . . . . . . . . . . . . 4-4
4.2.1. General . . . . . . . . . . . . . . . . . . . . . . . . . . 4-4
4.2.2. Troubleshooting Procedures . . . . . . . . . . . . . . . 4-4
4.3. Maintenance Procedures . . . . . . . . . . . . . . . . . 4-5
4.3.1. Scope Maintenance. . . . . . . . . . . . . . . . . . . . 4-5
4.3.2. Cleaning Procedures . . . . . . . . . . . . . . . . . . . 4-5
4.3.3. Preparing for Extended Storage . . . . . . . . . . . . . 4-6

iii
HOW TO USE THIS MANUAL
• Usage
You must familiarize yourself with the entire manual before operat-
ing the equipment. Read and follow all warning notices.
• Manual Overview
The table of contents includes the paragraph number, paragraph
title, and page number. An index provides additional references to
the subject contents.

1-1
CHAPTER 1
INTRODUCTION

1-2
1.1. GENERAL INFORMATION
1.1.1. SCOPE
This manual contains instructions for use in operating and main-
taining the TTWS Series Thermal Digital Riflescopes. Throughout
this manual, the TTWS Series will be referred to as the scope or
TTWS.
1.1.2. REPORTS
Reports from the user on recommendations for improvements are
encouraged. Send reports to the address below.
American Technologies Network Corp.
1341 San Mateo Avenue
South San Francisco, CA 94080
[phone]
[phone]
[phone] fax
[e-mail]
www.atncorp.com
1.1.3. STORAGE
Storage of TTWS should be done in the factory packing and after a
thorough PMCS as outlined in Section 4.1 of this manual. This will
ensure the scope remains in mission ready condition during stor-
age. Batteries should be stored separately from the scope.
The scope should not be placed on the floor, in any area exposed to
high temperatures or direct sunlight. Presence of acid and alkaline
vapor, as well as of other aggressive admixtures in the air is unac-
ceptable.
1.1.4. WARRANTY INFORMATION
ONE YEAR PRODUCT WARRANTY
This product is guaranteed to be free from manufacturing defects in
material and workmanship under normal use for a period of 1 (one)
years from the date of purchase. In the event a defect that is covered

1-3
by the foregoing warranty occurs during the applicable period stated
above, ATN, at its option, will either repair or replace the product, and
such action on the part of ATN shall be the full extent of ATN’s liability,
and the Customer’s sole and exclusive remedy. This warranty does
not cover a product (a) used in other than its normal and customary
manner; (b) subjected to misuse; (c) subjected to alterations, modi-
fications or repairs by the Customer of by any party other than ATN
without prior written consent of ATN; (d) special order or “close-out”
merchandise or merchandise sold “as-is” by either ATN or the ATN
dealer; or (e) merchandise that has been discontinued by the manu-
facturer and either parts or replacement units are not available due to
reasons beyond the control of ATN. ATN shall not be responsible for
any defects or damage that in ATN’s opinion is a result from the mis-
handling, abuse, misuse, improper storage or improper operation,
including use in conjunction with equipment which is electrically or
mechanically incompatible with or of inferior quality to the product,
as well as failure to maintain the environmental conditions specified
by the manufacturer. This warranty is extended only to the original
purchaser. Any breach of this warranty shall be waived unless the
customer notifies ATN at the address noted below within the applica-
ble warranty period.
The customer understands and agrees that except for the foregoing
warranty, no other warranties written or oral, statutory, expressed or
implied, including any implied warranty of merchantability or fitness
for a particular purpose, shall apply to the product. All such implied
warranties are hereby and expressly disclaimed.
LIMITATION OF LIABILITY
ATN will not be liable for any claims, actions, suits, proceedings,
costs, expenses, damages or liabilities arising out of the use
of this product. Operation and use of the product are the sole
responsibility of the Customer. ATN’s sole undertaking is limited
to providing the products and services outlined herein in accord-
ance with the terms and conditions of this Agreement. The pro-
vision of products sold and services performed by ATN to the
Customer shall not be interpreted, construed, or regarded, either
expressly or implied, as being for the benefit of or creating any
obligation toward any third party of legal entity outside ATN and
the Customer; ATN’s obligations under this Agreement extend
solely to the Customer. ATN’s liability hereunder for damages,
regardless of the form or action, shall not exceed the fees
or other charges paid to ATN by the customer or custom-

1-4
er’s dealer. ATN shall not, in any event, be liable for special,
indirect, incidental, or consequential damages, including,
but not limited to, lost income, lost revenue, or lost profit,
whether such damages were foreseeable or not at the time
of purchase, and whether or not such damages arise out of a
breach of warranty, a breach of agreement, negligence, strict
liability or any other theory of liability.
PRODUCT WARRANTY REGISTRATION
In order to validate the warranty on your product, ATN must
receive a completed Product Warranty Registration Card
for each unit or complete warranty registration on our web-
site at www.atncorp.com. Please complete the included
form and immediately mail it to our Service Center: ATN
Corporation, 1341 San Mateo Avenue, South San Francisco, CA
94080.
OBTAINING WARRANTY SERVICE
To obtain warranty service on your unit, End-user must notify ATN
service department by calling 800-910-2862 or 650-989-5100 or
via e-mail [e-mail] to receive a Return Merchan-
dise Authorization number (RMA). When returning please take or
send the product, postage paid, with a copy of your sales receipt
to our service center, ATN Corporation at the address noted
above. All merchandise must be fully insured with the correct post-
age; ATN will not be responsible for improper postage or, miss-
ing or damaged merchandise during shipment. When sending
product back, please clearly mark the RMA# on the outside of the
shipping box. Please include a letter that indicates your RMA#,
Name, Return Address, reason for service return, Contact infor-
mation such as valid telephone numbers and/or e-mail address
and proof of purchases that will help us to establish the valid start
date of the warranty. Product merchandise returns that do not
have an RMA listed may be refused or a significant delay
in processing may occur. Estimated Warranty service time is
10-20 business days. End-user/customer is responsible for
postage to ATN for warranty service. ATN will cover return post-
age/shipping after warranty repair to end-user/customer only if
product is covered by aforementioned warranty. ATN will return
product after warranty service by domestic UPS ground and/
or domestic mail. Any other requested, required or international
shipping method the postage/shipping fee will be the responsibil-
ity of the end-user/customer.

1-5
1.2. DESCRIPTION AND DATA
1.2.1. DESCRIPTION
a. Purpose
The TTWS Series Thermal Digital Riflescopes combines the ergo-
nomic features of a handheld and the convenience of weapon
mounting. Based on the proven 324x256 or 336x256 or 640x512
microbolometer core, the TTWS is an ideal product for force pro-
tection, border patrol officers, police SWAT and special operations
forces providing them the tools they need to be successful in all
field conditions both day and night. Uncooled thermal imaging cuts
through dust, smoke, fog, haze, and other battlefield obscurants. Its
use cannot be detected as it emits no visible light or RF energy and
operates without the use of illuminators or IR lights.
b. Features
TTWS has the following important features:
• High resolution digital thermal imaging
• Compact, lightweight and durable housing
• True magnification
• High end OLED display
• Four-colors reticle system
• Rapid start-up in 3 seconds
• Up to 8 hours operation with three lithium batteries
• One-Year Warranty
• Aluminum constructed body with class 3 hard anodized coating
• Digital Tactical Menu with quick view icons
• Memory Recall preserves operational settings
• Power-off safety feature prevents accidental shut down
• Recoil rated up to .308 caliber
• Polarity: white hot / black hot / color
• Thermal images viewable in up to 12-tone color pallet.
• Five reticle patterns: duplex, post, post with dot, standard
crosshair, ballistic

1-6
• Four reticle colors: red, green, white, black
• Ten-step brightness control
• Flexible battery cartridge can run on 1, 2, or 3 batteries
• Batteries: (3) 3V lithium (CR123A) – AA optional (qty 4)
• Battery life: 8 hours (3V)

1-7
1.2.2. TTWS STANDARD COMPONENTS
The TTWS standard components are shown in Figure 1.3. and pre-
sented in Table 1.1.
FIGURE 1.3. TTWS STANDARD COMPONENTS
TABLE 1.1. TTWS STANDARD COMPONENTS
ITEM DESCRIPTION QTY
1Scope
The thermal imaging scope. 1
2Quick Release Mount
Used to mount scope to weapon. 1
3
Hard Storage Case
A protective case used for shipping/storing TTWS and
accessories.
1
4Lens Tissue
Uses for cleaning of lenses surface. 1
5Lithium Battery CR1223A
Three CR123A lithium batteries used to power the unit. 3
6
Operator’s Manual
Provides equipment description, use of operator con-
trols and preventative maintenance checks and service.
1

1-8
1.2.3. SPECIFICATIONS
The following tables provide information pertaining to the operational, electrical, mechanical, optical and environmental characteristics for the sights.
TABLE 1.2. SPECIFICATIONS
ITEM TTWS-320
1.25-5x
TTWS-336
1.5-6x
TTWS-336
3-12x
TTWS-320
3.5-14x
TTWS-320
4.5-18x
TTWS-320
9-36x
TTWS-640
1.1-9x
TTWS-640
1.5-12x
TTWS-640
2.5-20x
TTWS-640
5-40x
Sensor (microbolometer) 320x240 336x256 336x256 320x240 336x256 336x256 640x512 640x512 640x512 640x512 Frame rate 60 Hz 60 or 30 Hz 60 or 30 Hz 60 Hz 60 or 30 Hz 60 or 30 Hz 30 Hz 30 Hz 30 Hz 30 Hz
Material VoX Image Size (output resolution) 800x600 Video output Digital NTSC / PAL Display Color OLED matrix, SVGA< 800x600, Color background + color reticules Thermal Sensitivity, mK <50 mK Spectral Response, μm 7-14 Focal length of the lens, mm 19 19 30 50 50 100 19 30 50 100
Field of View (H x V), deg 24°x18° 21°x16° 12.5°x9.7° 9°x7° 6°x4.7° 3°x2.4° 21°x16° 21°x16° 12.5°x9.7° 6° x 4.7°
Eye Relief, mm 28 Optical Magnification 1.25 1.5 3 3.5 4,5 9 1.1 1,5 2,5 5
E-Zoom
2.5x, 5x 3x, 6x 6x,12x 7x, 14x 9x, 18x 18x, 36x 2.2x, 4.5x, 9x 3x, 6x, 12x 5x, 10x, 20x 10x, 20x, 40x

1-9
ITEM TTWS-320
1.25-5x
TTWS-336
1.5-6x
TTWS-336
3-12x
TTWS-320
3.5-14x
TTWS-320
4.5-18x
TTWS-320
9-36x
TTWS-640
1.1-9x
TTWS-640
1.5-12x
TTWS-640
2.5-20x
TTWS-640
5-40x
Diameter of exit pupil, mm 14 Distance of the human detection, m (w/o zoom)
500 750 1100 1250 1500 2500 750 1100 1500 2500
Distance of the human recognition, m (w/o zoom)
225 300 400 520 600 1100 300 400 600 1100
Distance of the human Identification, m (w/o zoom)
135 180 225 290 360 600 180 225 360 600
Distance of the vehicle detection, m (w/o zoom)
1100 1650 2425 2550 3300 5000 1650 2425 3300 5000
Distance of the vehicle recognition, m (w/o zoom)
495 660 875 1000 1320 2200 660 875 1320 2200
Distance of the vehicle Identification, m (w/o zoom)
300 400 525 650 800 1400 400 525 800 1400
Reticle Multiple Reticles to Choose From Reticle Color Red, Green, Blue, White & Black Smart Zoom TTWS’s Reticle will Automatically Adjust its position when using E-Zoom (Note: Most thermal scopes allow the user to use the scope for
observation only, in E-Zoom due to the lack of this feature.)
Brightness adjustment Manual Sharpness adjustment Automatic Polarity control White hot / Black hot / Multiple Color Modes

1-10
ITEM TTWS-320
1.25-5x
TTWS-336
1.5-6x
TTWS-336
3-12x
TTWS-320
3.5-14x
TTWS-320
4.5-18x
TTWS-320
9-36x
TTWS-640
1.1-9x
TTWS-640
1.5-12x
TTWS-640
2.5-20x
TTWS-640
5-40x
Start up time, sec <3 Waterproof Waterproof / Dustproof Battery type 3 x CR123A battery type Battery Life, h 8+ Weight, grams 850 1417 710 850 850 1417 710 710 850 1417
Dimensions (L x W x H), mm (without bracket)
203x69x73 262x94x73 171x69x73 203x69x73 203x69x73 262x94x73 171x69x73 171x69x73 203x69x73 262x94x73
Mounting bracket MIL-STD 1913 Picatinny (Quick) Output computer set up Yes Video output Yes Low Battery Indicator Yes Iconology Quick access, Icon driven feature controls Housing Aircraft Aluminum 6061 T6 w/ class III hard anodized coating Objective lens Janus, full MIL SPEC, DLC (Diamond Like Carbon) coating
* ATN reserves the right to change the above specifications at any time without notice.

1-11
1.2.4. MECHANICAL FUNCTION
The mechanical adjustments of the TTWS sights allow for physi-
cal differences between individual operators using the system. The
scope functions include the Keypad, Output Connector, Eyepiece
Diopter Adjustment Ring, Focusing Ring, Battery Module, Accessory
Rail, and Weapon Mount.The controls are identified in Figure 1.4.
FOCUSING
RING
BATTERY
MODULE
KEYPAD DIOPTER
ADJUSTMENT RING
WEAPON MOUNT
RELEASE WEAPON MOUNT
ADJUSTER
RUBBED
EYEGUARD OUTPUT
CONNECTOR WEAPON
MOUNT
ACCESSORY
RAIL
FIGURE 1.4. TTWS MECHANICAL CONTROLS
1.2.5. OPTICAL FUNCTION
The optical functions include an objective lens, thermal imaging
detector, display and eyepiece. Infrared energy is emitted propor-
tionally to the temperature of an object. The warmer the object,
the more energy it emits. The infrared energy from the objects is
focused by the optics, onto an infrared detector. The information

1-12
from infrared detector is passed to electronics for image process-
ing. The signal processing circuitry translates the infrared detector
data into an image that can be viewed on the built-in OLED display.
The image is observed through an eyepiece by operator.
1.2.6. ELECTRICAL FUNCTION
The electronic circuit is powered by replaceable four 3V lithium bat-
teries (CR123A). Power from the batteries is supplied to the compo-
nents through the Power button.
