Atomic 3000 LEDSTROBE User manual

please read this manual before connecting your equipment
ATOMIC 3000 LED STROBE
user manual

1
Introduction
Before turning on the equipment, it is essential that you read the manual of the
user. Following the instructions here will ensure your safety and easily achieve the best
effect, and you will also understand the correct way to maintain your equipment, therefore
prolong the life of the product.
1. Product Description
Thank you for purchasing products. Product has been thoroughly tested and shipped in
perfect operating conditions. Check carefully that the packaging where it is shipped does not
show any damage, this may have occurred during transport. If it appears damaged, carefully
inspect your equipment for any damage and make sure that all necessary accessories to
operate the unit have arrived intact.
The STROBE3000 RGB LED is a powerful strobe that can operate via DMX control,
manually or automatically with pre-recorded programs, its main function is to produce
flashes with full effects in white, it has a backgroundRGB effect that perfectly accompanies
the color scenarios.
There are no useful parts inside the unit, do not try to repair it yourself; If you do, you will
lose the warranty. In the unlikely event that your equipment requires service, please contact
an authorized dealer or the manufacturer.
2. caution
The manufacturer will not accept any responsibility for the resulting damages
caused by the breach of this manual or any unauthorized modification of the
equipment.
security information
To reduce the risk of electric shock or fire, secure the connections of your
electrical installationA different voltage or connecting it to a dimmer can cause
damage to the equipment.
Qualified personnel must be the person who transports, carries, installs and operates this equipment,
but should refer to the instructions in this manual.
Do not attempt to operate this unit if the power cord is damaged or broken.
Do not attempt to remove or break the physical ground tip of the power supply cord,
this tip is to reduce the risk of electric shock or fire in case of an internal short.
Do not attempt to operate the unit if it is damaged.
The cables connecting the unit could be damaged if they are in the passage
of people or vehicles.
The team may need service by qualified personnel when:
1. The power supply cable or the connections have been damaged
2. The equipment has suffered a fall or a blow.
3.The equipment does not work normally or shows a marked change
in its operation.
The equipment must be transported in safe conditions so that it does not suffer damage during
same.
The warranty will be lost if the equipment is not operated according to the manual, or if it presents
some anomaly like short circuit, blows due to fall or abuse,

2
2.1 prevent falls
When you hang up a device, please verify that it will be supported by the accessory
assembly, truss or stand, and that is not damaged. As well as the rest of the rigging accessories.
2.2 Prevention of concussion
The electrical connection must match the corresponding characteristics, before installing,
make sure that the voltage is adequate and that it is a power outlet with protection.Each
equipment must be properly grounded.
2.3 prevent burns or fire
1. For no reason should the equipment be mounted directly or near a surface or
flammable material.
You must consider a distance not less than 3.0 meters.
2. Do not short-circuit the fuse when you need to replace it, use a fuse with the value
suitable.
3. Avoid directly seeing the light source
4. During operation, the equipment case becomes very hot, allow the equipment to cool for
at least 20 minutes before handling.
6. Never cover the equipment with any items, this could cause overheating and fire.
3. PACKING AND TRANSFER
3.1 unpacked
Note: Before unpacking, check that the box is not damaged, this could mean that the
equipment has had some damage as well, make sure the equipment is in good condition
before switching it on, in case of being damaged put the complaint before your parcel service
or freight

3
4. DMX operation MENU
Choice
Function
Display
Explain
FEATURES
SETTING
Run Mode
DMX, Auto, Sound
Modes of operation
Channel Mode
3, 4 and 14 channels
DMX, 3, 4, 14 channel modes
Singl Clear
On, Off
ECO MODE
On, Off
Power attenuation
Success
Leave
Handbook
TEST RUN
car
Automatic mode
SOUND
Rhythmic Audio Mode
SIMULATE DMX
Beam intensity
Manual Function Control
Beam duration
Beam rate
Beam effect
Setting
FX select
FX adjustement
Reserved
Background shuter
Background dimming
Background R
Background G
Background B
syste info
DMX VALUE
CH 1
DMX value of each channel at the
moment
…
CH 14
REST INFO
No function
OTHER INFO
Temperature, time information
of equipment use, software version
DISPLAY
SETTING
Light Set
Display brightness level
Light Off
Display off time
Menu Back
Background shutdown time
Light Flash
On, Off
Flashing display without signal
Touch Cali
On, Off
Touch calibration
Exit
Leave
DIMMER
SETTING
Dimmer Mode
In the purse
SW Balance
Off
Adjust maximum color level
Blance Red
0 – 255
Green Balance
0 – 255
Blue balance
0 – 255
White balance
0 – 255

4
LANGUAGE
In
English
Chinese
EXIT
Leave
DMX Modes
3 c a n a l e s D M X
Channel
Function
DMX Value
Description
1
Beam intensity (White
LED tube)
0
Off
1-255
LED tube intensity level
2
Flash duration (Beam)
0-255
7 - 650 ms
3
Flash rate
0-5
Strobe Speed   (Beam) Slow to Fast
4 DMX channels
Channel
Function
DMX value
Description
1
Beam Intensity (Tube
white of leds)
0
Off
1-255
LED tube intensity level
2
Flash duration (Beam)
0-255
7 - 650 ms
3
Flash rate
0-5
Strobe Rate (Beam) Slow to
Quick
4
Effect
0-5
No function
6-42
Ramp up
43-85
Ramp down
86-128
Ramp up, Ramp down
129-171
Random
172-214
Lightning
215-255
Spikes

5
14 DMX channels, Extended Mode
Channel
Function
DMX value
Description
1
Beam Intensity (Tube
white of leds)
0
Off
1-255
LED tube intensity level
2
Flash duration (Beam)
0-255
7 - 650 ms
3
Flash rate
0-5
Strobe Speed   (Beam) Slow to Fast
4
Effect
0-5
No function
6-42
Ramp up
43-85
Ramp down
86-128
Ramp up, Ramp down
129-171
Random
172-214
Lightning
215-255
Spikes
5
No function
6
Background Effects
0-255
Background Effects
7
Speed   Effects Background
0-255
Background Effect Rate
8
No function
9
Shutter Background
0-19
Shutter closed
20-49
Shutter open
50-200
Flash, slow to fast
201-210
Shutter open
211-255
Random flash, slow to fast
10
Dimmer Background
0-255
Dimmer background
11
Red background
0-255
Red Background Intensity
12
Green background
0-255
Green Background Intensity
13
Blue background
0-255
Blue Background Intensity
14
Background colors
0-255
Background colors
8. Technical specifications
Light source:240*5W white LEDs(strobe)
64*0.6W RGB LEDs(backlight)array
Minimu LED lifetime:50000 hours
Resolution:8 bits per color plus8-bit imming
Control systems:DMX
DMX channels:3/4/14channels(same as Martin Atomic)
Setting:Control panel with backlit monochrome display
NG:8.3kg/pcs
GW:9kg

6
4. control panel configuration
Menu
Function
Display
Description
DMX address
1-XXX
DMX address
Control mode
3 DMX channels
3-channel DMX mode
4 DMX channels
4-channel DMX mode
extend
Mode to 14 DMX channels, with
background functions in colors
Features
Dimmer
curve
linear
Linear dimmer curve
square-law
Square dimmer curve (Square-law)
Inverse
square-law
Inverse square dimmer curve (Square-law)
S curve
S curve dimming curve
Strobe
LED
Solid LED flash light
Xenon
Power frequency cycle of flashlight simulate
Xenon tube
Cooling mode
Regulating fan
Cooling fan speed thermostatic control
Constant fan
ultra low
Constant fan speed, ultra-low speed
Constant fan low
Constant fan speed, low speed
Constant fan
medium
Constant fan speed, medium speed
Constant fan
height
Constant fan speed, high speed

7
DMX Reset
off
Forbid Rest by DMX
on
Rest by DMX
Display
Sleeping display
mode
After 30 seconds, turn off the screen and press
any button to wake up
Not sleeping
Don’t turn off the screen
Error Mode
normal
Any errors detected are displayed on the reset
screen
silent
The error message is not displayed in the screen.
You need to see it in the error table.
Art Net Dmx
shutdown
After the shutdown, receive the control DMX512
signal
opening
After opening, the art net signal is received, and
the control DMX512 is not received
language
Chinese
Interface Language is Chinese
English
Interface Language is English
Default
setting
Factory
Default
Loading
Restore all settings to factory defaults
Info
Boot time
Total boot time
Displays the total operating time
despues de
manufacture
Current boot time
Current boot time displays
Reset Table X time
Counter clear→ Yes/ No Reset counter clear
Software
version
X.X.X
Displays the current program software version
RDM UID
4D50:XXXXXXXX
Display unique RDM ID
Fan speed
Basic fan X RPM
Displays the current speed of the basic fan 1,
NA,0-10000 RPM
temperature
LED temperature
Current temperature, last maximum
temperature, historical maximum temperature
DMX LIVE
Rate
XX Hz
DMX transmission speed，live , In seconds
Quality
0-100%
Percentage of error packets received，live
Start code
0-255
The decimal value of the DMX start code，live
Channel [Y] X
[Y] 0-255
Display DMX values   (x) on each channel (y)
TEST
LEDS test
Static beam
Test white LEDs at low intensity
Flash beam
White LED test
Beam close
White LEDs off
R AURA
Try red background LEDs
G AURA
Try green background LEDs
B AURA
Test Blue background LEDs
Handbook
control
Reboot
Reboot fixture
Channel [Y]X
Send DMX value [Y] on channel X
...
......
Service
Error table
Displays any valid errors
Fan clear
OFF / ON stop fan

8
DMX Modes
5. dmx operation
DMX Channels Mode：3/4/14 Channels
3- DMX channel mode
3 CH
Function
Value
Introductions
1
Beam flash intensity
Snap
blackout
0
Minimum to maximum intensity
1-255
2
Beam flash duration
Snap
7→650 ms
0-255
3
Beam flash rate
Snap
0.289→16.67 Hz
0-255
4- DMX channel mode
CH
Function
Value
Introductions
1
Beam flash intensity
Snap
blackout
0
Minimum to maximum intensity
1-255
2
Beam flash duration
Snap
7→650 ms
0-255
3
Beam flash rate
Snap
0.289→16.67 Hz
0-255
4
Beam effect
Snap
No effect
0-5
Ramp up
6-42
Ramp down
43-85

9
Ramp up, Ramp down
86-128
Random
129-171
Lightning
172-214
Spikes (flash over low light)
215-255
14-DMX Model (Extend)
CH
Function
Value
Introductions
1
Beam flash intensity
blackout
0
Minimum to maximum intensity
1-255
2
Beam flash duration
7→650 ms
0-255
3
Beam flash rate
0hz
0-5
Snap
0.289→16.67 Hz
6-255
Snap
4
Beam effect
Premise: 3 dmx channels
greater than 5 dmx channels
No effect
0-5
Ramp up
6-42
Ramp down
43-85
Ramp up, Ramp down
86-128
Random
129-171
Lightning
172-214
Spikes (flash over low light)
215-255
5
Control / setting
No function
0-9
Reset the entire fixture - 5 seconds
10-14
No function
15-22
Linear dimming curve - 1 sec. (menu override, setting
unaffected by power off/on)
23
Square law dimming curve - 1 sec. (menu override, factory
default setting, setting unaffected by power off/on)
24
Inverse square law dimming curve - 1 sec. (menu override,
setting unaffected by power off/on)
25
S-curve dimming curve - 1 sec. (menu override, setting
unaffected by power off/on)
26
No function
27-51
Turn on control panel display - 1 sec.
52
Turn off control panel display - 1 sec
53
Regulated fans speed, fixed light output intensity = full
54

10
(default setting, menu override, setting unaffected by power
off/on)
Fixed fan speed = full, regulated light output intensity
(menu override, setting unaffected by power off/on)
55
Fixed fan speed = medium, regulated light output intensity
(menu override, setting unaffected by power off/on)
56
Fixed fan speed = low, regulated light output intensity
(menu override, setting unaffected by power off/on)
57
Fixed fan speed = ultra low, regulated light output intensity
(menu override, setting unaffected by power off/on)
58
Strobe behavior = LED (menu override, setting unaffected by
power off/on)
59
Strobe behavior = Xenon (menu override, setting unaffected
by power off/on)
60
No function
61-255
6
FX select
Effect Select
（See Appendix FX, "preprogrammed effect.""）
0-255
7
FX adjustment
Synchronous speed adjust, zero to maximum
0-255
8
No function
0-255
Aura control channels
9
Aura flash / shutter effect
Snap
Shutter closed
0-19
Shutter open
20-49
Flash , slow→ fast
50-200
Shutter open
201-210
Random flash，slow→fast
211-255
10
Aura dimming
0-255
Fade
Closed→Open
11
Aura R
0-255
Fade
0%→100%
12
Aura G
0-255
Fade
0%→100%
13
Aura B
0-255
Fade
0%→100%
14
Aura Color preset（'color wheel 'effect）
OpenRGB color mixing enabled
0-10
Color 1 - LEE 790 - Moroccan pink
11-15
Color 2- LEE 157-pink
16-20
Color 3 - LEE 332- Special rose pink
21-25

11
Color 4 LEE 328- Follies pink
26-30
Color 5-LEE 345- Fuchsia pink
31-35
Color 6- LEE 194-Surprise pink
36-40
Color 7-LEE 181-Congo blue
41-45
Color 8-LEE 071- Tokyo Blue
46-50
Color 9 - LEE 120 - Deep Blue
51-55
Color 10-LEE 079- Just Blue
56-60
Color 11-LEE 132-Medium Blue
61-65
Color 12- LEE 200- Double CT blue
66-70
Color 13-LEE 161- Slate Blue
71-75
Color 14- LEE 201-Full CT Blue
76-80
Color 15- LEE 202-Half CT blue
81-85
Color 16-LEE 117 - steel blue
86-90
Color 17-LEE 353-Lighter blue
91-95
Color 18-LEE 118-Light Blue
96-100
Color 19-LEE 116- Medium Blue Green
101-105
Color 20-LEE 124-Dark green
106-110
Color 21-LEE 139- Primary Green
111-115
Color 22-LEE 089-moss green
116-120
Color 23-LEE 122- Fern Green
121-125
Color 24-LEE 738- JAS Green
126-130
Color 25-LEE 088-Lime Green
131-135
Color 26-LEE 100- Spring Yellow
136-140
Color 27-LEE 104-Deep Amber
141-145
Color 28-LEE 179-Chrome Orange
146-150
Color 29-LEE 105-Orange
151-155
Color 30-LEE 021-Golden Amber
156-160
Color 31-LEE 778- Millennium Gold
161-165
Color 32-LEE 135- Deep Golden Amber
166-170
Color 33-LEE 164- Flame red
171-175
34-Magenta Color
176-180
Color 35- Medium Lavender
181-185
Color 36- withe
186-190
Aura' color wheel rotation' Effect
clockwise，fast→slow
191-214
Stop (this will stop wherever the color is at the time）
215-219
Counter-clockwise, slow fast
220-243
Aura Random colors
Fast
244-247
Medium
248-251
Slow
252-255

12
