Atomic DRZ2 User manual

DRZV2 Instruction Manual
Version 1.1
1

DRZV2 Instruction Manual
Version 1.1
2
○1 Steering Post (open Bag 1,2,3,4)
M2 * 7
M2 * 7
M2 * 16
Main Chassis Plate
Arm Mount
Steering Post
○2 Steering Crank
M1.4*4 Flat Head
Glass Fiber Plate
Plastic Crank
Make sure there is no gap between
these 2 parts

DRZV2 Instruction Manual
Version 1.1
3
○2 Steering Crank
3*6*2 Bearing
3*6*2 Bearing
2.5mm Ball Head
With M1.4 Thread
1.5mm Hole Steel Washer
2.5mm Ball Head with M2.0 Thread
(Apply instant glue to secure it)
Steel Collar
Plastic Lock Nut
Do not over tighten the lock nut, adjust the nut to
make sure the steering crank is moving smoothly
and no wobble.
Make sure the leg of ball head is
not exceeding the surface of fiber
plate.

DRZV2 Instruction Manual
Version 1.1
4
○3 Front Lower Arms
(open Bag 5)
Pivot Ball 3.0mm
1.5 * 8 steel pin
1.5 *2.5*0.3mm White Plastic Spacer
Pivot Ball
Front Lower Arm
○4 Front Bulkhead
Front Body Mount
Front Bulkhead
M2*7 Flat Head
Use M2*8 if using Brass Chassis

DRZV2 Instruction Manual
Version 1.1
5
YouTube Scan this QR Code to see how to make the ball link Smooth
and no wobble.
https://www.youtube.com/watch?feature=youtu.be&v=RMhkoIUS_og
Youku Scan this QR Code to see how to make the ball link Smooth and
no wobble.
https://v.youku.com/v_show/id_XNDMzMDU5NzI4NA==
2.5 Ball Cap
M2.5 Link Rod
Normal Thread
Reverse Thread
7.0mm
1.0mm Gap
Make 2 Turnbuckles
○5 Steering Linkages
How to Make Steering Linkages Ball Cap Smooth and no wobble:

DRZV2 Instruction Manual
Version 1.1
6
○6 Front Upper Arms
1.5*11 pin
Upper Arm
M2*2 set screw
1.5*3.5*0.3mm white
spacer x 2 pcs
Upper Arm Mount
0.3mm white spacer x 2 pcs at rear side, it is maximum caster angle
(around 15 degree). Each 0.3mm step move result in 1 degree changes.
Front
Arms install in this
direction

DRZV2 Instruction Manual
Version 1.1
7
2.0mm Gap
M2.0 Camber Link Rod
M2*5 Flat Head
○7 Upper Arms Assemble
○8 Front Knuckles
Firstly, we need to identify Right and Left Knuckle
Left Knuckle has a Notch
Right Knuckle has No Notch

DRZV2 Instruction Manual
Version 1.1
8
○
8 Left Front Knuckle
Wheel Shaft
M1.4 * 6mm Flat Head
2.5 Ball Head
1.5mm hole Steel Spacer (2 pcs)
3*6*2 Bearing
3*6*2 Bearing
2.5 Ball Head
Repeat for the Right Side
3*6*2 Bearing
3*6*2 Bearing
2.5 Ball Head
2.5 Ball Head
M1.4 * 6mm Flat Head
Wheel Shaft
1.5mm inner hole Spacer (2 pcs)

DRZV2 Instruction Manual
Version 1.1
9
Attach the knuckle to the arms
○
1
○2
○3
○
9 Chassis Bridge Mount
M2 * 3 Flat Head
M2 * 3 Flat Head
Aluminium Bridge Mount

DRZV2 Instruction Manual
Version 1.1
10
○
10 Gear Differential (open Bag 6)
M1.2*6 Button Head
M1.2*6
Button Head
M1.2*4 Button Head
Loose the screws a little bit if the gear diff is not smooth.
○
11 Gear Differential (open Bag 7)
3*6*2.5 Bearing
3*6*2.5 Bearing
1.5*4.5 pin
1.98 * 10 pin
2*5*2 Bearing
Plastic collar
12T Gear
18T Gear
Main Shaft
Right Bulkhead
Left Bulkhead

DRZV2 Instruction Manual
Version 1.1
11
Rear Chassis
M2*5 Flat Head
M2*4 Button Head
○
12 Attach Bulkhead to Chassis
○
13 Rear Arms and Down Stop
M1.2*4 Button Head Screw come out 0.5mm
Droop Screw setup
Left Rear Arm
Right Rear Arm
M1.2*4 Button Head

DRZV2 Instruction Manual
Version 1.1
12
○
14 Attach Rear Arms to Bulkhead
Right Rear Arm
Left Rear Arm
Rear Toe Mount
M2 *7 Flat Head
M2 *7 Flat Head
○
15 Motor Mount
M2 *3 Flat Head
Motor Mount

DRZV2 Instruction Manual
Version 1.1
13
○
14 Spur Gear
O-Ring
Spur Gear
Spur Gear Adapter
1.5x 6.5 Pin
M2x4
Button Head
○
15 Attach Gear Differential
M2x4 Button Head
6*10*3 Bearing
6*10*3 Bearing
Bulkhead Cover
Gear Differential

DRZV2 Instruction Manual
Version 1.1
14
○
16 Rear Wheel Hub Build 2 pcs
3*6*2 Bearing
3*6*2 Bearing
Universal Shaft
3.5 Ball Head
2*3.8*0.8 Brass Spacer
M1.2*3 Button
Head 1.5 x 13 pin Use sandpaper to polish the wheel hub if
it is not moving freely with arm.

DRZV2 Instruction Manual
Version 1.1
15
○
17 Camber Link
Cut the cap
2.5mm
M1.2*4 Button Head
Build 2 pcs
3.5 Ball Cap
Ball Head Cover
Steel Link
○
18 Shock Stay Tower
M2*4 button head
M2*4 button head
4.0 Ball Head
4.0 Ball Head
Front Tower
Rear Tower

DRZV2 Instruction Manual
Version 1.1
16
○
19 Shock Damper (open Bag 8)
Rear Damper is longer
Front Damper is shorter
Front Sprig has thicker wire
Rear Sprig has thinner wire
If the piston is not moving smooth along the tube. Please use sandpaper to Polish it. Use
#1000 paper to sand it first and then use #3000 for polish.
○
20 Attach Damper to Chassis – Rear Side
Rear Long Damper
M2x7 Flat Head
4.0 Ball Head

DRZV2 Instruction Manual
Version 1.1
17
○
20 Attach Damper to Chassis – Front Side
4.0 Ball Head
○
21 Attach Servo
3rd Hole
Servo Horn
M2x4
2.5 Ball – Thread M1.4
1.5mm hole spacer
M2x5 Flat Head

DRZV2 Instruction Manual
Version 1.1
18
○
22 Attach Servo Link Rod
2.5 Ball Cap 2.5 Ball Cap
M1.5 x 6 set screw
M2 x 5 Flat Head
M2 x 5 Flat Head
○
23 Battery and Body Mount

DRZV2 Instruction Manual
Version 1.1
19
○
24 Top Deck
M2 x 3 Flat Head
M2 x 4 Button Head
M2 x 4 Button Head
○
25 Wheelbase Adjustment
90mm WB
94mm WB
98mm WB

DRZV2 Instruction Manual
Version 1.1
20
○
26 Wheel and Tire
Front wheel, +1.5 or +2.0 offset is recommended
Rear wheel, +1.0 or +1.5 offset is recommended
2.0mm
2.2mm
○
27 Ride Height
Front: 2.0mm, Rear 2.2mm is a recommended basic setup
