Atomik RED 13019 User manual

2-3 Cell LiPO
Motor Diameter:
Motor Length:
Weight:
Shaft Diameter:
Rotor Diameter:
Wind Type:
36 mm
65.80 mm
8.5oz (242g)
5.0 mm
12.50 mm
Star (Y) wind
GEARING AND TIMING
Timing can be adjusted by loosening the three screws and
rotating the aluminum end cap. Rotating the end cap counter-
clockwise adds timing which increases the motor’s RPM. Be
aware that by adding timing, motor temperatures will increase
and battery duration will decrease. Those with limited motor
tuning experience should leave the timing at the factory setting.
INSTALLATION AND MAINTENANCE
•Solder the three leads from your Electronic Speed Control
(ESC) noting the A, B, and C connections. Do NOT allow
solder to bridge the gap between each connection.
•To clean your motor, lightly brush dirt away on a regular
basis paying particularly close attention to the area around
the ball bearing. Occasionally add a small drop of bearing
oil. DO NOT spray cleaners or solvents into the motor.
PRECAUTIONS & WARNINGS
•Avoid over gearing by monitoring motor temperature.
Operating temperatures should NOT exceed 80C (175F)
•Be sure to use the proper size motor mounting screws
•Do NOT over-tighten the motor mounting screws
Sensor Wire
Orange
Blue
ABC
WIRING DIAGRAM
Yellow
P/N
13019 50 0.014 No7.5
Winds
2650
K/v Max Current Resistance ROAR
®
Approved
Specifications:

This product contains chemicals known to the State of California to cause Cancer, Birth Defects and other
Reproductive Harm. Be responsible, dispose of properly.
Important Notice
Atomik®assumes sole responsibility for our products; therefore, dealers should not be involved in any
warranty issues. All warranty claims are to be directed to Atomik®Customer Service. Before returning any
defective product, please contact Atomik Customer Service at: [email protected] to receive a
Return Merchandise Authorization Number. A dated & itemized sales receipt must accompany any product
returned for warranty work.
General Warranty Policies
Atomik®warrants this product to be free of material and workmanship defects when new. Atomik®will at its sole
discretion repair or replace defective components free of charge within 90 days from date of purchase or within
30 days for all electronic components. This warranty does not cover wear and tear, crash damage,
modifications, failure to perform routine maintenance, or any damages arising as a result of improper use. All
warranty claims are to be directed to Atomik®Customer Service at: [email protected].
GUARANTEE
All products are inspected and adjusted individually before leaving the manufacturer and are guaranteed to
be free of material defects and manufacturing faults.
