FastStream™SC 5500E/7500E
Embeddable FC to SAS/SATA RAID Controllers
MicroATX RAID Controller
OEM / System Integrators
Technical Highlights
• DVRAID™ and RAID 0, 1,
4, 5, 6, 10, 40, 50 and 60
• Celerity Multipathing
support for OS X,
Windows & Linux
• 5500E features two 4-Gb
Fibre Channel host ports
to provide performance
of up to 650 MB/sec
• 7500E features four 4-Gb
Fibre Channel host ports
to provide performance
of up to 1200 MB/sec
• Eight 3-Gb SAS/SATA
Device Lanes via two
four-port connectors
• Supports up to 32 SAS
and/or SATA disk drives
in a single enclosure
• Optional External four
lane connector for
capacity expansion
• 512MB ECC Protected
Cache Memory
• ExpressNAV™ Storage
Manager user interface
• Drive Verification and
Performance Metrics
• Email Alert Notification
• RoHS Compliant
Collaborative Workflow
• Multiple fibre channel ports
provided by the 7500 give small
workgroups the ability to share
storage without the need for an
expensive fibre channel switch
Instant Data Protection
• Integrate with inexpensive JBOD
storage to create a high perform-
ance parity protected solution
• When used with ATTO Celerity
Multipathing additional reliability
is provided in the event of a Fibre
Channel link failure
Blazing Fast Performance
• The FastStream SC provides the
performance to support 24fps 4K
digital film, 2K film or 10-bit un-
compressed high definition video
• Provides managed latency for
low block-sized data transfers
common in database and audio
editing applications
Smooth Data Streaming
• Supports multiple workstations
accessing data over a SAN
• Add additional storage with on-
the-fly capacity expansion and
expand existing RAID groups
while keeping all data intact
One-click Installation
• One button setup wizards
optimize storage for Video,
Audio, Database and General IT
environments
FastStream SC Embedded
Embeddable RAID Controllers
adds instant RAID protection and
ensures high storage availability
The ATTO FastStream SC 5500E and 7500E are
embeddable RAID controllers that deliver high
performance access to data and data protection
for applications in DVA and IT infrastructures
including: 4K and 2K digital film production, high-
definition video post, digital prepress, disk-to-disk
backup, medical imaging, email compliance, data
warehousing, data mining and transaction based
environments.
ATTO FastStream Storage Controllers provide
best of class performance and instant RAID parity
protection to any SAS or SATA storage device;
FastStream allows you to mix SAS and SATA
storage to integrate into a tiered storage solution
ATTO designed the FastStream to take advantage
of the latest in storage connectivity and processor
technology, these two benefits alone provide a
path for OEMs to provide products with the fastest
time to market. By embedding the FastStream SC
5500E or 7500E into a storage product and
private labeling the browser interface, Systems
Integrators and OEM customers can be sure to
lower development costs while creating a portfolio
which compliments existing product lines.
Designed as an embedded MicroATX RAID
Controller which integrates with SAS or SATA
storage to provide instant RAID protection and
advanced intelligence, FastStream RAID Control-
lers can be seamlessly integrated into standard
ATX or custom storage enclosures to provide a
high performance storage solution.
The FastStream SC 5500E and 7500E add
advanced intelligence features such as Phone
Home email alerts, real-time performance metrics,
N-way mirroring, global hot spares and more.
Users can add storage as needed, when needed
with the capacity expansion feature. Specific
OEM-only features are available to provide a more
synergistic look and feel to your product.

Rev 1/09
©2009 ATTO Technology, Inc. Specifications subject to change without notice.
Power Behind the Storage
Technical Specification
For More Information:
www.ATTOTech.com
or to Purchase:
www.ATTOStore.com
[phone]
Technical Features
RAID Levels • JBOD, DVRAID, 0, 1, 4, 5, 6, 10, 40, 50 and 60 plus N-way mirroring
Key Features
Hardware Specifications
Fibre Channel Interface • 4-Gigabit, auto-negotiates to 2/1 Gigabit devices
• Two Optical SFP (Small Form Factor Pluggable) Fibre Channel ports (5500E)
• Four Optical SFP (Small Form Factor Pluggable) Fibre Channel ports (7500E)
• Full support for direct connect for F-port fabric switches
• Class 3 and Intermix ANSI Fibre Channel Specifications
• PLDA, public loop login (NL-ports) and fabric connect (N-port)
SAS/SATA Interface • Eight 3-Gb SAS/SATA ports via two internal SFF-8484 SAS connectors
Management Interface • RJ-45 connector for Ethernet management port
• RS-232 serial header console port
Management
Setup and Monitoring • Simplified one-click setup allows for system setup in just minutes
• Built in read-only drive performance monitoring allows you to gauge
storage performance while host-based applications are in use
Local and Network Management • ExpressNAVTM storage manager browser-based user interface for remote
configuration, management and diagnostic capabilities
• Local diagnostics supported via CLI, Telnet and FTP
• Command line and menu-based ASCII text management access via the
Ethernet management port and ExpressNAV
Environmental & Physical Specifications
Dimensions • 177.80mm (w) x 1U* (h) x 244mm (l) (*Up to 3U depending on configuration)
Operating Environment • Temperature: 5 - 40° C ●Humidity: 10 - 90% non-condensing
Storage Environment • Temperature: -40 - 70° C ●Humidity: 5 - 95% non-condensing
Power • Input: 12 VDC +- 10%, 6A
Recommended Airflow • 11 CFM
• Ambient air not to exceed 40° C
RoHS Compliant • Yes
Ordering Information
Model Numbers
FastStream™ SC 5500E/7500E
RAID Storage Controllers
FastStream SC Embedded
• ATTO Celerity Multipathing Support • SCSI Enclosure Services (SES)
• Tunable RAID Rebuild Priority • Configurable Sector Sizes to 8kB
• Real-time Performance Metrics • Enclosure Aware RAID Group Creation
• Dedicated and Global Hot Spares • Hot Swap with Auto Rebuild
• Configuration Cloning • Battery Backed Event Log
• Drive Initialization and Verification • ECC Protected Memory
• Partitioning of RAID Volumes • Media Error Handling
• Port Mapping for LUN Isolation • Field Upgradeable Firmware
• FSSC-5500-E00 / 5500E • FSSC-7500-E00 / 7500E
