ATTO Technology Diamond Array V User manual

Enterprise Storage
155 CrossPoint Parkway • Amherst, NY 14068 • 716.691.1999
attotech.com
An Enterprise-class RAID storage array with industry-leading
density, reliability, performance and your choice of Fibre Channel
or SCSI connectivity all at a new level of affordability
ATTO Diamond Storage Array V-Class
• Highest Density Available
Up to 12 TB per 3U enclosure
• Outstanding Performance
Up to 240 MB/sec. sustained
data transfers
• Variable Host Connectivity
2-Gigabit Fibre Channel or
Ultra160 SCSI
• Fault-resiliant Design
Redundant, hot-swappable components,
hot Spares, ECC Memory
• Highly Configurable Hardware
RAID 0/1/5/10 or JBOD
• Advanced Features
Zoning / Mapping / Partitioning
• Excellent Manageability
SNMP, SES, CLI and In/Out
of Band
TECHNICAL
HIGHLIGHTS
The Diamond Array V-Class is designed
for storage consolidation, business
continuance, digital video, imaging
and near-line storage applications in
which high density, high performance
and affordability are driving factors
to implementation. The ATTO Diamond
Storage Array V-Class contains up
to 24 drives per 3U enclosure and
comes complete with a combination
Ethernet/Serial Management card,
redundant power supplies and cool-
ing assemblies, as well as redundant
pathways to the storage.
The Diamond Storage Array V-Class is
available in both rack mount and
deskside chassis designs. For added
flexibility, the ATTO Diamond Array V-Class
can be configured with either dual
Ultra160 SCSI or dual 2-Gigabit/sec.
Fibre Channel host interfaces.

Enterprise Storage
Performance
©2005 ATTO Technology, Inc. Specifications subject to change without notice. September 2005
attotech.com ATTO Diamond Storage Array V-Class
• Configurations: RAID 0/1/5/10, JBOD
• Capacity: Up to 12 TB per 3U form factor
• Max Data Rate: (2 port Array) 2-Gigabit FC
HIC: up to 400 MB/sec. full duplex per port;
Ultra160 SCSI: up to 160 MB/sec. per port
• Number of Drives: 24 (max)
• Drive Size: 500 GB Type ATA
• Overlapped Command & Command Queuing
Support (disk drive dependent)
• Buffer size: 256 MB ECC DRAM
• Hot spares supported
Management Services
• Integrated web server and browser-based
GUI for configuration, management and
diagnostics
• LEDs for Fibre Channel interface, disk
drive status, system management activity,
system faults and power supply status
• RS-232 serial port for monitoring and
configuration
• Ethernet connection for LAN/WAN
monitoring and configuration
• ATTO QuickRaid™ for RAID setup
• In-band management – SCSI, FC
• Field updateable firmware
• Thermal monitoring
• SMART environmental monitoring support
• Audible Alarm
• SES Support
• SNMP Trap support
• LUN Zoning / Mapping / Partitioning
• Hot Spare capability
Connectivity
• O/S and platform independent including
support for large LBAs and greater than
2 TB LUNs
• Dual independent, hot-pluggable Host
Interface Cards (HICs)
• Available Host Interface Cards
• 2-Gigabit Fibre Channel
400 MB/sec. full duplex
Fabric Ready
Compatible with 1-Gigabit
SFP based (Small Form-factor Pluggable)
Integrated FC-AL hub port
2nd port built-in hub for chaining
• Ultra160 SCSI
160 MB/sec.
VHDCI connectors
2nd port built-in for SCSI chaining
Environmental and Physical
Characteristics
• Operating Temperature: 5 - 40º C
• Storage Temperature: -25 - 60º C
• Humidity: 10 - 85%
(non-condensing)
• Rack Mount Dimensions:
Height: 131 mm
(5.16 inches / 3U)
Width: 447 mm
(17.60 inches)
Depth: 585 mm
(23.05 inches)
Weight: 39 kg
(86 lbs)
Designed for balanced center mount
• Acoustical Noise: < 69dBA
• Altitude: Operating 10,000 ft
at 35º C
• Operating Shock: 3G @ 11ms,
1/2 sine pulse
Certifications:
CE Mark
UL/CSA
TUV
ISTA packaging approved
• Safety Compliance:
UL 1950 3rd Edition
TUV EN 60950
CSA 22.2 No. 950-95
• Quality Standard:
Manufactured under ISO-9000 registered
quality system
• EMC Specifications:
FCC Class A
EN 55022: Class A
EN 50204: RF Immunity 900 MHz Pulse
EN 61000-4-8: Magnetic Immunity
EN 61000-4-2: ESD
EN 61000-4-3: Radiated Immunity
EN 61000-4-4: EFT
EN 61000-4-5: Surge
EN 61000-4-6: Conducted Immunity
EN 61000-4-11:Voltage Dips and
Interruptions
Additional Specifications
• Universal AC input voltage 100-240V
50/60 Hz nominal (90-264VAC range)
• Nominal power consumption (24 drives)
4.75 A @ 112V input, 532 W
• Dual 340 Watt power supplies
• Dual high volume blower assemblies
• Hot swappable:
Power supplies
Blower assemblies
Dual-drive disk sleds
• Hot pluggable:
Host Interface Cards (HICs)
System management card
• Warranty:
2 Years
Potential Applications
• Near-line Backup
• Storage Consolidation
• Business Continuance
• Disaster Recovery
• Imaging / Fixed Content
• Primary Storage SMB
• Email Archive
• HSM
• Broadcast / Video Editing
• CAD / CAM
• Web Page Delivery
• Rich Media on Demand
