ATZ ATZ VC-HDMI4K-VGA User manual

pg. 1 All specifications are subject to change without prior notice.
© Copyright ATZ 2015
Model : ATZ VC-HDMI4K-VGA
Description: HDMI 4Kx2K to VGA Converter Box

pg. 2 All specifications are subject to change without prior notice.
© Copyright ATZ 2015
Model : ATZ VC-HDMI4K-VGA
Description: HDMI 4Kx2K to VGA Converter Box
Introduction:
The 4Kx2K HDMI to VGA converter which will convert digital HDMI video and audio
signal to VGA and FL / FR stereo audio signal, while support DVI system sideline signals.
So that can play on CRT/LCD/LED monitor, HDTV or projector.
Features:
1. No need to install drivers, portable, flexible, plug and play.
2. High quality scaling technology for input resolutions.
3. Multiple output resolution setting in OSD menu.
4. Compatible with HDMI1.4.
5. Support HDMI input resolution up to 4Kx2k@30Hz.
Package:
1. 4Kx2K HDMI to VGA Converter 1 pcs
2. 5V1A DC Power Supply Adaptor 1 pcs
3. Operation Manual 1pcs
Specification:
Input ports
1xHDMI, 1 x Min- USB
Output ports
1xVGA, 1xEarphone
Dimensions(mm)
93(D)x84(W)x28(H)
Wight (g)
162g
HDMI input resolutions
480i to 4Kx2K@30Hz
VGA output resolutions
800x600@60Hz,1024x768@60Hz,1280x720@60Hz,
1360x768@60Hz,1366x768@60Hz,1600x1200@60Hz,
1680x1050@60Hz,1920x1080@60Hz.
Operating Temperature
0°C ~ 40°C / 32°F ~ 104°F
Storage Temperature
-20°C ~ 60°C / -4°F ~ 140°F
Elative Humidity
20 ~ 90% RH (Non-
condensing)
Power Consumption (Max)
2W
ESD Protection
Human Body Model:
± 8kV (air-gap discharge)
± 4kV (contact discharge)

pg. 3 All specifications are subject to change without prior notice.
© Copyright ATZ 2015
Model : ATZ VC-HDMI4K-VGA
Description: HDMI 4Kx2K to VGA Converter Box
Operation Controls and Functions:
1. HDMI IN: This slot is where you connect the HDMI source output from DVD, PC or
Laptop.
2. UPDATE: System software update.
3. Power LED: This red LED illuminate when the device is connected with power supply.
4. Resolution Button: Press this button to select the output resolutions.
5. ENTER Button: Press this button is used to determine the resolution of the selected.
6. RATIO Button: Press this button to switch output ratio (16:9 or 4:3).
7. Audio Output: This slot is where you connect to the audio amplifier with 3.5mm
earphone cable.
8. VGA Output: Through the VGA cable is connected to the TV or monitor.
9. DC 5V IN:Connect the 5V DC power supply into the Converter.
Connection and Installation:
i.Connect a source such as a PC or DVD to the Converter HDMI input.
ii.Connect a display such as a monitor, TV or Projector to the VGA output on the Converter.
iii.The stereo output is connected an audio amplifier.
iv.Power on the device and display.
