Introduction
Thank you for purchasing the K011. Before using your K011, be sure to read the K011 Basic Manual (this PDF manual)
to ensure correct usage. After you have finished reading this manual, store this PDF manual and the printed manuals and
keep it with your care so you can retrieve them whenever you need them.
Manuals for the K011
There are three manuals for the K011: the Basic Manual, printed Instruction Manual (Japanese) and full Instruction Manual
(Japanese).
●For learning the basics:
Read the K011 Basic Manual (this manual) or printed K011 Instruction Manual (Japanese).
●For learning details of each function:
The full Instruction Manual (Japanese) gives detailed instructions on using each function and can be downloaded from
the au homepage: http://www.au.kddi.com/torisetsu/index.html
To ensure proper usage of the K011, be sure to read the Safety Precautions “安全上のご注意” in the Instruction Manual.
The keyword searchable au Online Manual is also available on the au homepage:
http://www.au.kddi.com/manual/index.html
To access from EZweb (free of packet communication charge):
R⇒au Customer Support ⇒
オンラインマニュアル (Online Manual)
Scan this QR code to access the au Online Manual. ▶
•
H32BasicManual.indbiiH32BasicManual.indbii 2012/06/2010:16:252012/06/2010:16:25

1
Illustrations and Screenshots in This Manual
Illustrations and Screenshots in This Manual
Note on Illustrations
The illustrations in this manual may look different from the actual cell phone in shape, color and typeface.
The key illustrations are also simplified as shown below.
Key Illustration Key Illustration
①cjs ⑦w
②&⑧%
③L⑨R
④C⑩F
⑤N⑪T
⑥
123
456
789
*0#
⑫+
Note on Screenshots
The screenshots in this manual are simplified and may look different from the actual cell phone screens.
The display design themes of the K011 vary by model color. The operations and the screenshots for the Pearl White
models are used in this manual.
■
■
•
⑫
④
①
②
③
⑦
⑥
⑤
⑧
⑨
⑩
⑪
⑫
④
①
②
③
⑦
⑥
⑤
⑧
⑨
⑩
⑪
H32BasicManual.indb1H32BasicManual.indb1 2012/06/2010:16:252012/06/2010:16:25

2
Safety Precautions/Notes on water resistance
Safety Precautions/Notes on water resistance
Exemptions
The Company is not liable for any damages arising from
earthquakes, lightning, storms, floods or other natural
disasters, as well as fires, actions by third parties, other
accidents, intentional or mistaken misoperation by the
customer, or use under other unusual conditions outside
the responsibility of the Company.
The Company is not liable for any incidental damages
(change/disappearance of saved content, loss of
business income, disruption of business, etc.) arising
from use of or inability to use the product.
The Company is not liable for any damages arising from
failure to observe the described content of the "Instruction
Manual".
The Company is not liable for any damages arising,
for example, from malfunction caused by combination
with connected devices or software not related to the
Company.
Captured image data or downloaded data may
sometimes be altered or lost due to faults, repair or other
handling of the product. The Company is not liable for
any damage or lost income resulting from recovery of
these data.
It is recommended you keep a copy of important data
in your PC's hard disk, etc. Whatever the cause of
fault or malfunction may be, the Company assumes no
responsibility for alteration or loss of saved information.
※"The Company" as appears on the product refers to the following companies:
Sold by: KDDI CORPORATION, Okinawa Cellular Telephone Company
Manufactured by:KYOCERA Corporation
•
•
•
•
•
•
Safety Precautions (Observe Strictly)
Before using this product, thoroughly read these
safety precautions for proper use. After reading,
store the precautions in a safe place.
These "Safety Precautions" describe instructions that
should be observed to prevent damage to property or
injury to the customer or others using the product.
These instructions are divided into the following
categories.
Explanation of indications used in this
manual
DANGER This symbol indicates the potential and
imminent danger of death or serious
injury (*1) to a person.
WARNING
This symbol indicates the possibility of
death or serious injury (*1) to a person.
CAUTION
This symbol indicates the possibility of
personal injury (*2) to a person or physical
damage (*3).
*1 Serious injury: This refers to loss of sight, injury, burns (high- and low-
temperature), electric shock, broken bones, injuries with residual aftereffects
from poisoning, etc., or injuries requiring hospital admission for treatment or
long-term hospital attendance as an outpatient.
*2 Injury: This refers to injuries, burns (high- and low-temperature), electric
shock, etc. that do not require hospital admission for treatment or long-term
hospital attendance as an outpatient.
*3 Physical damage: This refers to extended damage to buildings, furniture,
livestock, or pets.
■
•
•
■
H32BasicManual.indb2H32BasicManual.indb2 2012/06/2010:16:252012/06/2010:16:25

3
Safety Precautions/Notes on water resistance
Explanation of graphic symbols used
in this manual
Indicates an action that is not allowed (prohibited).
Indicates that disassembly is not allowed
(prohibited).
Indicates that handling with wet hands is not
allowed (prohibited).
Indicates that allowing the product to get wet is
not allowed (prohibited).
Indicates an action that must be done
(prohibited).
Indicates that the power plug must be
disconnected from the power outlet.
■Precautions common to the K011 main
unit, battery pack, charging equipment,
au IC-Card, peripheral devices
DANGER Be sure to read the following
hazards before use.
Be sure to use only the exclusive peripheral devices. Use of other
peripheral devices might cause rupture, ignition, fire, or leakage of
liquid.
Exclusive peripheral devices for the K011
• Common AC Adapter 01 (0202PQA) (sold separately)
• Common AC Adapter 02 (0203PQA) (sold separately)
• Desktop Holder (KY011PUA) (sold separately)
• Battery Pack (KY009UAA)
• Earphone adapter 01 for external connection jack (0201QVA) (sold
separately)
• Common DC adapter 01 (0201PEA) (sold separately)
• AC Adapter MIDORI (0205PGA) (sold separately)
• AC Adapter AO (0204PLA) (sold separately)
• AC Adapter SHIRO (0204PWA) (sold separately)
• AC Adapter MOMO (0204PPA) (sold separately)
• AC Adapter CHA (0204PTA) (sold separately)
• AC Adapter REST (LS1P002A) (sold separately)
• AC Adapter RANGERS (LS1P003A) (sold separately)
• AC Adapter CHARGY (LS1P001A) (sold separately)
• AC Adapter WORLD OF ALICE (LS1P004A) (sold separately)
• AC Adapter KiiRoll (L01P005A) (sold separately)
• Portable charger 01 (0201PDA) (sold separately)
• USB cable WIN (0201HVA) (sold separately)
• USB cable WIN 02 (0202HVA) (sold separately)
• USB charging cable 01 (0201HAA) (sold separately)
AC Adapters MIDORI, AO, SHIRO, MOMO, CHA, REST, RANGERS,
CHARGY, WORLD OF ALICE and KiiRoll have the same specifications
with the Common AC Adapter 02.
Do not use, leave or store the product in hot places (e.g. by a fire, near
a heater, in the hot sun). Doing so might cause rupture, ignition, fire or
overheating.
■
H32BasicManual.indb3H32BasicManual.indb3 2012/06/2010:16:262012/06/2010:16:26

4
Safety Precautions/Notes on water resistance
Before entering an area where flammable gas is generated such as a
gas station, be sure to turn off the product. Do not charge the battery.
In addition, when using Osaifu-Keitai®at a gas station, be sure to turn
off the power in advance. (If FeliCa lock has been set, cancel the lock
before turning off the power.)
Do not throw the product into a fire or heat it. Doing so might cause
rupture, ignition, fire or overheating.
Do not put the product in a heating apparatus (microwave oven, etc.)
or a pressure vessel. Doing so might cause rupture, ignition, fire or
overheating.
Do not disassemble, modify or repair the product. Doing so might
cause rupture, ignition, fire, overheating, electric shock, or injury.
Modification of this cell phone is in violation of the Wireless Telegraphy
Act. Contact an au shop or Secure cell phone support center for
repairs due to malfunction. The Company is not liable even in the event
of any nonconformities arising on the K011 or peripheral devices as a
result of modification, etc.
Do not short-circuit the connection terminals. Do not allow conductive
foreign objects (metal fragments, pencil leads, etc.) to come into
contact with or get inside the connection terminals. Doing so might
cause rupture, ignition, fire, overheating or electric shock.
Do not drop from a high place or subject to strong impact, such as
throwing or stepping on the product. Doing so might cause rupture,
ignition, fire, overheating, or leakage of liquid.
Immediately discontinue use if there is smoke, abnormal odor or noise,
excessive overheating, or other abnormalities. If an abnormality occurs
while charging, immediately disconnect the specified charging
equipment (sold separately) from the power outlet or cigarette lighter
socket, make sure that the product is not overheating before turning
the power off, then remove the battery pack and contact an au shop or
Secure cell phone support center. Continued use in that state might
result in rupture, ignition, fire or overheating.
WARNING
Be sure to read the following
warnings before use.
Do not let your hands, fingers or other parts of the body touch the
connection terminals when power is on. Doing so might cause electric
shock or injury.
Do not charge the battery if the K011 is wet. Doing so might cause
electric shock or short circuit resulting in malfunction or fire.
Malfunction due to charging while wet is not covered by warranty and
exempt from repair.
Although the K011 has waterproof property, stop use if liquid such as
water gets inside the main unit from the external connection jack cover
or the battery pack cover. Continued use of the product in this state
might cause overheating, fire or a fault.
If you drop or break the cell phone, discontinue use and contact an au
shop or Secure cell phone support center.
Do not leave in places within the reach of small children. Small children
might swallow parts, the battery pack, etc. by mistake and choke on
them or be injured.
Do not store the product in places subject to direct sunlight (e.g. in
automobiles), places that get extremely cold, and in humid or dusty
places. Doing so might cause ignition or fire.
CAUTION
Be sure to read the following
cautions before use.
If you carry the K011 on you (in a pocket, etc.), it may cause low-
temperature burns depending on the manner and time it is in contact
with you and the surrounding environment. Be especially careful not to
let the K011 be in contact with your skin or in a pocket for a prolonged
period in conditions when the K011 will become warm such as when
near heating appliances (kotatsu, heater, electric blanket), under a hot
sun, while charging, etc. The K011 may become hot and cause low-
temperature burns (skin redness, itchiness, etc.) depending on your
physical constitution and health.
H32BasicManual.indb4H32BasicManual.indb4 2012/06/2010:16:262012/06/2010:16:26

5
Safety Precautions/Notes on water resistance
Do not leave on unstable places such as rocky stands or tilting
surfaces. Dropping the product may cause injury. Also, take care that
the K011 does not vibrate and fall if its vibrator is set.
Do not touch the K011, battery pack or specified charging equipment
(sold separately) for a long time while power is being supplied from an
external source. Doing so might cause low-temperature burns.
Do not place near corrosive chemicals or in places where corrosive
gas is generated. Doing so might cause loss of internal data due to
malfunction.
Do not fold, bend or place a heavy object on the au IC-Card. Doing so
might cause a fault.
Do not touch the IC (metal) part of the au IC-Card or short-circuit it.
Doing so might cause loss of data or a fault.
Do not scratch the IC (metal) part of the au IC-Card. Doing so might
cause a fault.
Do not wet the au IC-Card. Doing so might cause a fault.
Do not use in humid places. When carried on you, humidity from
sweating may cause malfunction. Malfunction deemed to be caused
by wetting with water or humidity is not covered by warranty and
exempt from repair.
When adjusting the volume with an earphone, etc. inserted into the
K011, raise the volume a little at a time. If you raise the volume too
much from the outset, sudden loud noise from the earphone, etc.
might adversely affect your ears.
K011 main unit
DANGER Be sure to read the following
hazards before use.
Do not use a cell phone while driving/riding a car, motorbike, bicycle,
etc. or walking. It may cause a traffic accident. Use of a cell phone
while driving a car or motorbike is hazardous and prohibited by law.
Use of a cell phone while riding a bicycle may be punishable by some
regulations.
Do not light the Camera light/simple light toward a driver of a car, etc.
If dazzled or surprised by the light, the driver might cause an accident.
Use of the main unit in an automobile sometimes affects on-vehicle
electronic devices, though this rarely happens. If this happens, stop
use since this may impair safe travel.
Do not use the K011 while you are aboard an airplane. Use of electric
devices transmitting radio waves in airplane is prohibited by law. Some
airline companies, however, allow their passengers to use cell phones.
For details, contact the airline company you use.
■
H32BasicManual.indb5H32BasicManual.indb5 2012/06/2010:16:272012/06/2010:16:27

6
Safety Precautions/Notes on water resistance
When using the cell phone near an implanted pacemaker, implanted
cardioverter-defibrillator or other electronic medical device, radio
waves might affect these units and devices. So, please observe the
following.
1. Those with an implanted pacemaker or implanted cardioverter-
defibrillator should carry or use the cell phone at least 22 cm away
from the pacemaker or cardioverter-defibrillator.
2. Turn the cell phone off in crowded trains or other crowded places,
since there may be people with a cardiac pacemaker or implanted
cardioverter-defibrillator nearby.
3. Pay attention to the following points when using the cell phone
inside medical institutions.
• Do not bring the cell phone into operating theaters, intensive-
care units (ICU) and coronary care units (CCU).
• Turn the cell phone off in hospital wards. Cancel auto power-on,
alarm, and other automatic power-on functions before turning the
cell phone off.
• Even if you are in a lobby, etc., be sure to turn the cell phone off
when there are electronic medical devices nearby.
• When a medical institution has laid down designated areas where
use of the cell phone is prohibited or is not allowed to be brought
in, abide by the instructions of that medical institution.
4. When using electronic medical devices other than an implanted
pacemaker and implanted cardioverter-defibrillator outside a
medical institution (e.g. home medical treatment), check
individually with the manufacturer of the electronic medical device
regarding the influence of radio waves.
This content is based on “Guidelines on the Use of Radio
Communications Equipment such as Cellular Telephones and
Safeguards for Electronic Medical Equipment” (Electromagnetic
Compatibility Conference, March 1997 [current Electromagnetic
Compatibility Conference Japan]) with reference also to “Report of
Investigation of the Effects of Radio Waves on Medical Equipment,
etc.” (Association of Radio Industries and Businesses, March 2005).
An investigation regarding the CDMA system was carried out in
FY2004, and the above guidelines and report were deemed to be
reasonable in an announcement by the Ministry of Internal Affairs and
Communications in 2005.
The product sometimes affects high-precision electronic devices. So,
turn it off near such devices. (Examples of electronic devices that
might be affected by the product include cardiac pacemakers, hearing
aids, other electronic medical devices, fire alarms, and automatic
doors. If you are using an electronic medical device, contact the
device manufacturer or retailer for information about the possible
affect of radio waves.)
Stay alert to your surroundings when calling, messaging, browsing the
Internet, shooting photos, playing games, watching TV (1Seg) or
listening to music. Use without checking for safety might cause a fall
or traffic accident.
Take care with the volume if using an earphone (sold separately).
Difficulty hearing sounds around you might result in an accident.
Immediately stop using the K011 outside when you can hear thunder.
Failure to do so might risk lightning strikes and electric shock. Turn off
the K011 and move to a safe place.
WARNING
Be sure to read the following
warnings before use.
The K011 main unit is not completely waterproof. Failure to observe
items 1 to 4 below and “Notes on water resistance” on pages 17 to 20
may result in ignition, overheating, injury, electric shock, or
malfunction.
1. Do not use under water (including key operation).
2. Do not immerse in liquid other than room temperature fresh water/
tap water.
3. Do not subject to strong water flow exceeding specification (IPX5/
IPX7) (page 17) or leave under water for an extended time.
4. Do not place on a sandy beach or similar place.
Do not light the Camera light/simple light in front of a person's eyes.
Do not gaze at the light emitting part when the Camera light/simple
light is lighted. Doing so might cause impairment of eyesight, etc. Be
especially careful not to shoot small children from a very close
distance.
H32BasicManual.indb6H32BasicManual.indb6 2012/06/2010:16:272012/06/2010:16:27

7
Safety Precautions/Notes on water resistance
Do not send data with the infrared port pointing toward eyes. Doing so
might cause vision impairment. Also, sending data with the infrared
port pointing toward some other infrared device might cause false
operation, etc.
If the K011 is damaged or internal parts are exposed, do not touch the
broken or exposed parts. Doing so might cause electric shock or
injury. Discontinue use and contact an au shop or Secure cell phone
support center.
If you have a weak heart, be careful when setting the level of vibration
and volume to prevent the possibility of adverse effects on your heart.
Do not gaze at bright or flickering light from the screen in a dark room.
Sometimes, very rarely some people demonstrate symptoms such as
muscle spasms, loss of consciousness, etc. by gazing at bright light
or watching repeatedly flickering screens. Those with a past history of
this should always consult with a physician beforehand.
Do not expose the camera lens to direct sunlight for an extended
period. Doing so might cause ignition or fire by the light-collecting
mechanism of the lens.
Use the product with the covers of external connection jack, battery
pack, etc. closed. If the covers are open, dirt or water may get inside
causing a fault due to electric shock or short circuit.
CAUTION
Be sure to read the following
cautions before use.
Never use modified au cell phones. Use of a modified device violates
the Radio Law.
This au cell phone has acquired the certification of conformity with
technical regulations for the specified radio station based on the Radio
Law, and the "Technical Conformity Mark " is printed on the
nameplate of the au cell phone as a certificate.
If the screws of the au cell phone are removed and modifications are
made to the internal components, the certification of conformity with
technical regulations will become invalid. Never use the au cell phone
without the valid certification. Doing so violates the Radio Law.
Pay attention to items becoming stuck to the receiver and speaker.
Since the receiver and speaker use magnets, thumbtacks, pins, craft
knife blades, staples, and other metal objects may sometimes become
stuck to them causing unexpected injury. Before using the product, be
sure to check that there are no foreign objects on the receiver and
speaker.
Do not swing the K011 around by holding the hand strap or shake the
main unit of the au cell phone excessively. Doing so might strike others
or things around you, causing damage or injury.
Be careful not to your pinch fingers/hand when closing the K011.
Doing so might cause injury.
Be careful not to your pinch fingers/hand in hinge (between display
and keypad) when opening the K011. Doing so might cause injury. Do
not leave in reach of infants or young children.
Do not listen for an extended period with loud volume that is hard on
the ears, either directly or with an earphone (sold separately). Doing
so might affect hearing.
Do not bring the product close to or fold the product to hold
magnetized objects such as cash cards, floppy disks, or credit cards,
or electronic devices and metal items. Doing so might result in loss of
magnetic information.
H32BasicManual.indb7H32BasicManual.indb7 2012/06/2010:16:272012/06/2010:16:27

8
Safety Precautions/Notes on water resistance
Use the K011 in temperatures between 5°C and 35°C (limited use
between 36°C and 40°C) and humidity between 35% and 90%.
Repairs are not covered by warranty if malfunction is deemed to be
due to use in extremely hot or cold conditions exceeding these
ranges.
Remove the protective sheet from display before use. Use with the
protective sheet applied may cause injury. Be careful not to cut your
fingers, etc. when removing.
Do not forcefully remove an inserted microSD. Doing so might result in
malfunction or loss of stored data.
Use only specified microSD. Failure to do so may result in malfunction
or loss of stored data. For details on au-specified items, contact an au
shop or the Customer Service Center.
The Bluetooth®function of the K011 conforms to the domestic
standards of Japan, FCC standards and EC directives, and has been
certified. Use of the Bluetooth®function may be restricted in some
countries/regions. If you are using the Bluetooth®function overseas,
check the relevant laws and regulations of the country/region you visit.
If you feel any abnormality with your skin, immediately consult a
dermatologist. Itching, rashes, eczema, etc. sometimes occurs
depending on your physical constitution and condition. See the
following table.
The materials of parts used in the K011 are as follows.
Location Material Finish
Outer case (LCD front case) PA + GF
resin
Evaporation + UV cured
acrylic coating
Outer case (LCD rear central panel) SUS Acrylic thermally cured
coating
Outer case (LCD key front case,
key rear case), battery cover
PA + GF
resin
UV cured acrylic coating
Outer case (Hinge cover,
LCD rear case), Manner key (Side
key)
PC resin UV cured acrylic coating
Answer key, Power/End key,
Clear/News key, Number keys,
Address book key, Application key,
Mail key, EZ key, Cursor key,
Center key, Self menu key, TV key,
Cushion (under number keys)
Acrylic
urethane
resin
UV cured coating
Key plate PET resin UV cured coating
Window panel (main),
Window panel (sub), Camera plate,
Camera light/Simple light,
Window panel (sub)
PMMA resin Chemical hardening
External connection jack cover PC resin +
TPE resin
UV cured acrylic coating
Charging terminals Phosphor
bronze
Gold plating (base layer:
nickel)
H32BasicManual.indb8H32BasicManual.indb8 2012/06/2010:16:282012/06/2010:16:28

9
Safety Precautions/Notes on water resistance
Battery pack
(The battery pack of this product is a lithium-ion
battery.)
The battery pack is not fully charged at the time of
purchase. Charge the battery before using the product.
DANGER
Mishandling is dangerous as it
might cause overheating,
leakage or rupture.
Be sure to read the following
hazards before use.
Do not short-circuit the (+) and (-) terminals of the battery pack. Doing
so might cause rupture, ignition or overheating.
Do not allow metal objects (such as necklaces and hairpins) to come
in contact with the connection terminals when carrying or storing the
battery pack. Doing so might cause the battery pack to short-circuit,
causing rupture, ignition, or overheating due to excessive current flow.
Do not connect the battery pack to the K011 or charging equipment
with (+) and (-) reversed. Connecting in an incorrect orientation might
cause rupture, ignition or overheating. Do not try to forcibly connect
the battery pack, instead thoroughly check the connection terminals
before connection.
Do not puncture the battery pack with a nail, hit it with a hammer or
step on it. Doing so might cause rupture, ignition, overheating or
leakage of liquid.
Do not directly solder or disassemble or modify the battery pack.
Doing so might cause spilling of the battery liquid resulting in an
accident such as loss of eyesight if it gets into eyes, or cause rupture,
ignition or overheating.
Discontinue use of a battery pack if it is leaking battery liquid or
emitting an odor. Do not touch liquid directly. Move the battery pack
away from any nearby fire. Failure to do so might cause the leaked
liquid to catch fire resulting in rupture or ignition.
■Never use the cell phone with wet hands.
WARNING
Mishandling might cause
overheating, fire, electric
shock, etc.
Be sure to read the following
warnings before use.
The battery pack is not waterproof. Do not wet the battery pack with
water, seawater, pet urine, etc. Do not charge a wet battery pack. A
wet battery pack might cause overheating, damage or ignition.
If the liquid gets into your eyes, do not rub but wash your eyes
thoroughly with clean water, and immediately seek treatment by a
doctor. If left unattended, there is a risk of losing your eyesight. If the
liquid gets on a device, wipe it off without touching it.
CAUTION
Mishandling might cause
overheating, fire, electric
shock, etc.
Be sure to read the following
cautions before use.
If internal fluid comes in contact with your skin or clothing, immediately
wash off thoroughly with clean water. Contact with skin might cause a
skin rash.
Do not discard an old battery pack together with regular trash. Please
cooperate in the collection of an old battery pack when it is no longer
needed to protect the environment and effectively use resources.
Used battery packs are collected at au shops and other places.
Do not remove the sticker from around the battery pack. Doing so
might result in malfunction.
H32BasicManual.indb9H32BasicManual.indb9 2012/06/2010:16:282012/06/2010:16:28

10
Safety Precautions/Notes on water resistance
AC adapter
DANGER
Mishandling might cause
overheating, fire, electric
shock, etc.
Be sure to read the following
hazards before use.
Install and position in-car devices, such as the common DC adapter
01 (sold separately), where they do not hinder driving or safety
equipment such as airbags. Failure to do so might cause a traffic
accident. Install in-car devices following the instructions of their
manuals.
Do not use the desktop holder in a vehicle. Doing so might cause
accident by falling or hindering driving. The desktop holder assumes
use indoors on a stable surface.
If charging is not completed after the specified time, stop charging.
Failure to do so might cause leakage of liquid, rupture, ignition, fire or
overheating with regard to the battery pack.
Contact an au shop or Customer Service Center.
If you hear thunder, do not touch the specified charging equipment
(sold separately). Doing so might cause an electric shock as a result
of a lightning strike.
■
WARNING
Mishandling might cause
overheating, fire, electric
shock, etc.
Be sure to read the following
warnings before use.
Do not use at other voltages than the specified power supply voltage.
Doing so might cause fire, overheating or electric shock.
• Use domestic (Japan) household 100 V AC for Common AC Adapter
01 (0202PQA) (sold separately). Do not charge with single phase
200 V or with a travel converter.
• The following are compatible with 100 to 240 V AC, and can be used
for charging overseas: Common AC Adapter 02 (0203PQA) (sold
separately) / AC Adapter MIDORI (0205PGA) (sold separately) / AC
Adapter AO (0204PLA) (sold separately) / AC Adapter SHIRO
(0204PWA) (sold separately) / AC Adapter MOMO (0204PPA) (sold
separately) / AC Adapter CHA (0204PTA) (sold separately) / AC
Adapter REST (LS1P002A) (sold separately) / AC Adapter
RANGERS (LS1P003A) (sold separately) / AC Adapter CHARGY
(LS1P001A) (sold separately) / AC Adapter WORLD OF ALICE
(LS1P004A) (sold separately) / AC Adapter KiiRoll (L01P005A) (sold
separately).
• Use Common DC Adapter 01 (0201PEA) (sold separately) in a 12 or
24 V DC negative earth car.
When plugging a specified AC adapter (sold separately) into an outlet,
do not allow a metal strap or accessory come in contact with the
power plug. Doing so might cause ignition, fire, electric shock or injury.
Unplug the power plug from the outlet or cigarette lighter socket when
not charging. Failure to do so might result in ignition, fire, or electric
shock.
Firmly insert the power plug into the power outlet or cigarette lighter
socket down to the base of its pins. Incomplete insertion of the power
plug might result in ignition, fire, overheating or electric shock.
H32BasicManual.indb10H32BasicManual.indb10 2012/06/2010:16:292012/06/2010:16:29

11
Safety Precautions/Notes on water resistance
The specified charging equipment (sold separately) is not waterproof.
Do not use the product in places where it may be splashed with water,
pet urine or other liquids. Doing so might result in overheating, ignition,
fire, electric shock or short circuit. In the event that the product is
splashed with liquid, immediately disconnect the power plug from the
outlet or cigarette lighter socket.
Never use the cell phone with wet hands.
Never use in humid places such as bath areas. Doing so might cause
electric shock or a fault.
Do not charge the battery pack if wet.
While charging, do not cover or wrap the product with a cloth or
bedding. Doing so might cause ignition or fire.
Do not use power outlets or wiring apparatus beyond its rating. Also,
exceeding rating, for example, by connecting multiple devices to a
single power strip might cause ignition, fire or overheating.
Do not damage, modify, twist, pull, place a heavy object on, or use the
power cord while bundled. Do not use a damaged power cord. Doing
so might cause ignition, fire, electric shock or short circuit.
Unplug the power plug from the outlet or cigarette lighter socket
before you clean the charging equipment. If the plug remains plugged
in when you clean the equipment, it might cause electric shock or
short circuit.
Wipe off dust on the power plug. Leaving it dusty might cause ignition
or fire.
When unplugging the specified charging equipment's (sold separately)
power plug from the outlet or cigarette lighter socket, always hold and pull
the power plug. If you pull the power cord, the power cord might be
damaged, resulting in ignition, fire or electric shock.
Use a fuse of the specified type (250 V, 1 A) in the common DC
adapter 01 (sold separately). Using a different type of fuse might
cause ignition, fire or overheating.
CAUTION
Mishandling might cause
overheating, fire, electric
shock, etc.
Be sure to read the following
cautions before use.
Do not use the common DC adapter 01 (sold separately) with the car
engine stopped. Doing so might result in draining of the car battery.
H32BasicManual.indb11H32BasicManual.indb11 2012/06/2010:16:292012/06/2010:16:29

12
Safety Precautions/Notes on water resistance
Handling precautions
These precautions are provided to ensure that performance
can be fully demonstrated. Thoroughly read these
precautions to ensure correct use.
Stored content/mail/data/etc.
●Content stored on the au cell phone (phone book, Data Folder, e-mail, C-
mail, Bookmark, etc.) may be altered or lost due to accident, malfunction/
repair, or other handling. Keep a separate copy of important content. In the
event of alteration or loss, the Company bears no liability for damages or lost
earnings.
Precautions common to the main unit,
battery pack, charging equipment, au
IC-Card, peripheral devices
●Applying excessive force to the product might damage the display or internal
circuit board resulting in malfunction. Be sure not to sit on it in a pants/skirt
pocket or put it in a bag with heavy objects on top. Keeping an external
device connected to the external connection jack or earphone jack might
damage the connector resulting in a malfunction. Such damage and
malfunction are not covered by the warranty, even if there is no external
damage.
●Do not use the product in extremely hot, cold or humid places. (Use within an
ambient temperature range of 5°C to 35°C and humidity range of 35% to
85%.)
- Charging equipment
- Peripheral devices
●Do not use the product in extremely hot, cold or humid places. (Use within an
ambient temperature range of 5°C to 35°C (temporary use at 36°C to 40°C is
allowed) and humidity range of 35% to 90%.
- K011 main unit
- au IC-Card (when installed in K011)
- Battery pack (when installed in K011)
●Do not use in places subject to lots of dust or vibration.
■
■
●Clean the external connection jack/charging terminals with dry cotton swabs,
etc. every now and then. Soiled terminals might cause poor connection. Do
not exert a strong force to clean the connection terminals to prevent
deformation and scratching.
●Clean the product with a soft dry cloth. Do not wipe the product using
benzene, thinner, alcohol, detergent, etc., which might affect the outer casing
or printing.
●Use as far away as possible from land-line phones, TVs and radios. Use
nearby might affect them.
●The K011 may become warm while calling, watching TV (1Seg), connected
to EZweb, messaging, or while charging or during other operations,
depending on the situation, but this is not abnormal.
●Turn off the power before removing the battery pack. If you remove the battery
pack with the power on, saved data might be altered or lost.
●When the product is used by a child, to avoid hazards, parents or guardians
should thoroughly read the “Instruction Manual” (this manual) and teach the
child how to use it. Also make sure that the child is using it as instructed.
K011 main unit
●Do not remove the stickers printed with the serial numbers on the au cell
phone (visible when the battery pack is removed). These stickers prove that
the au cell phone is permitted under the Wireless Telegraphy Act and
Telecommunications Operations Act.
●Note that mail and downloaded data (both charged or free content) saved on
the au cell phone cannot be returned to the customer when the au cell phone
is replaced with another au cell phone for model upgrade, repair of a fault,
etc.
●Although the display used on the K011 is made using high-precision
technology, some pixels (dots) might be lit or out at all times. This is not a
malfunction.
●Take care not to inconvenience people around you when you use the product
in a public place.
●Do not exert force on the hinge (between display and keypad) when opening
or using the main unit. Exerting force by swinging or bending the main unit
backward might result in malfunction or damage. Use with care.
■
H32BasicManual.indb12H32BasicManual.indb12 2012/06/2010:16:302012/06/2010:16:30

13
Safety Precautions/Notes on water resistance
●Do not forcefully press, tap or intentionally subject the display to strong
impact. Doing so might cause scratching or damage.
●Take care that hard objects do not rub against and scratch the display or
camera lens.
●When you put the product in your pocket or bag, take care so that the
display does not come in contact with metal objects or other hard objects.
Also, be careful not to scratch or damage the display by using a strap whose
metal or other hard part comes in contact with the display.
●The display may appear dark or warped depending on the angle if viewed
while wearing polarized sunglasses or similar eyewear.
●When hearing the other party’s voice, make sure that the earpiece is placed
at the center of your ear. If the earpiece (audio output port) is closed by the
ear lobe, it may be hard to hear the voice.
●When suddenly brought into a warm indoors place from a cold outdoors
place, or when in a humid location, water droplets (i.e. condensation)
sometimes are formed inside the product. Note that when used under
conditions such as this, humidity might cause corrosion or a fault.
●Do not leave the cell phone near air conditioning vents. Condensation from a
sudden temperature change may corrode the inside of the cell phone and
cause malfunction.
●Do not place stickers on the display/key side of the cell phone. After closing
the main unit, the keys, etc. may be pressed and cause misoperation, or key
operations while closed may be unavailable or usable time may be
shortened. The K011 may also be damaged.
●Trying to press keys while data is playing back may cause unusual operation
such as data pausing.
●Continuously displaying the monitor screen during photography or
continuous video recording, use of EZweb, etc. for extended periods
repeatedly causes main unit components to become warm, and may result in
low-temperature burns with prolonged skin contact.
●Placing a strong magnet close to the product might cause malfunction.
●To prevent unauthorized use in case of theft or loss, the K011 is locked so that it
cannot be used unless the legitimate user's au IC-Card is inserted. If the user is
changed to some other person, the new user should bring the au IC-Card to an
au shop or PiPit. Note that a fee is charged for ownership change.
●Surrounding brightness is detected by the optical sensor (page 26). Take care
not to cover it with your fingers.
●Be careful not to scratch the surface coating by dropping the main unit, etc. If
adhesion of water, etc. to the damaged surface area is prolonged, the surface
coating might peel off.
●There may be some difficulty in viewing the sub-display of the K011 in bright
places such as in the open air or under fluorescent lights, but this is not a
malfunction.
●Do not discard the product together with regular trash. Please cooperate in the
collection of the product when it is no longer needed to protect the environment
and effectively use resources. Old products are collected at au shops and other
places.
●When using handsfree call, take care to keep the speaker at a safe distance
from your ears, as the speaker volume may be too loud.
Battery pack
●Use in very hot or cold environments, for example, when left in an automobile
with the windows closed in summer, will cause the battery capacity to drop
and shorten the available battery usage time. This will also shorten the
battery pack's service life. Try to use the battery pack as far as possible at
room temperature.
●When the battery pack is not to be used for a long time, remove the battery
pack from the main unit, and store it in a battery pack case away from hot
and humid places (a battery pack case is included with an additional battery
pack (sold separately)).
Data stored in the K011 may be lost if left uncharged for an extended time.
●Charge the battery pack before using the product for the first time after
purchase, or if you have not used the product for a long time (the battery
pack may become warm during charging, but this is not a malfunction).
●The battery pack is a consumable item. If the performance of a battery pack
does not recover after charge or is bulging, the battery pack is at the end of
service life, so buy a new one of the specified type. Note that the length of
service life varies depending on the usage condition, etc.
●Do not discard battery packs together with regular trash. Please cooperate in
the collection of used battery packs to protect the environment and
effectively use resources. au shops and other retailers collect used battery
packs.
●Battery packs sometimes swell up as they approach the end of their service
life. This is due to the properties of lithium-ion batteries, and is not a problem
in terms of safety.
■
H32BasicManual.indb13H32BasicManual.indb13 2012/06/2010:16:302012/06/2010:16:30

14
Safety Precautions/Notes on water resistance
AC adapter
●When not using the specified charging equipment (sold separately), remove
its power plug from the power outlet or cigarette lighter socket.
●Clean the K011’s charging terminals and the desktop holder (sold
separately) terminal periodically using a dry cotton swab. Soiled terminals
may result in poor connections.
●Do not wrap the specified charging equipment (sold separately) power cord
around the power plug or desktop holder (sold separately). Doing so might
cause electric shock, ignition or fire.
au IC-Card
●The au IC-Card is lent to you by au. In case of loss or damage, the card will
be replaced at your expense. When malfunction is suspected, or in case of
theft or loss, contact an au shop or PiPit.
●Do not forcibly remove or insert the au IC-Card.
●You are responsible for any damage caused by inserting your au IC-Card
into some other IC card reader/writer, etc.
●Keep the IC (metal) part of your au IC-Card clean.
●Clean usually by wiping with a soft, dry cloth. Take care not to wipe too hard
and deform or scratch terminals.
●Do not put stickers, etc. on the au IC-Card.
●The au IC-Card may become warm during use, but this is not a malfunction
and you can continue to use the card.
●
Do not disassemble or modify the au IC-Card. Doing so might cause loss of data
or a fault.
●Do not insert non-au IC-Cards in this cell phone. You cannot use cards other
than au IC-Cards inserted in this cell phone.
■
■
Camera
●Do not leave the camera lens exposed to direct sunlight. Imaging elements
might be discolored or burnt.
●When using the camera, follow common rules of etiquette regarding camera
use.
●When photographing important occasions (such as a wedding), take a trial
shot and check the shot image to make sure it is correctly shot, and audio to
make sure it is audible.
●Image data (below, “data”) might be altered or lost due to malfunction, repair
or other handling. The Company takes no responsibility for recovery of
altered or lost data, damages resulting from altered or lost data, and lost
profits.
●Do not use the camera for recording information in places, bookstores, etc.
where photographing is not allowed.
Copyrights and rights of portrait
●You are not allowed to copy, modify or edit the data you shot or recorded
using the K011 without consent of the copyright holder, except for personal
use, under the copyright law. In addition, do not use or modify portraits or
names of other individuals without their consent, as it might infringe on rights
of portrait.
●Also be careful about the copyright and portrait right when posting photos
you shot, etc. on Internet homepages. Restrictions may also be in place on
photography/recording, even for personal purposes, of performances,
entertainment, exhibitions, etc.
●You cannot transfer images or sound protected under copyright where such
use exceeds stipulations of copyright laws.
■
■
H32BasicManual.indb14H32BasicManual.indb14 2012/06/2010:16:302012/06/2010:16:30

15
Safety Precautions/Notes on water resistance
Notes on using Bluetooth®
functions
Frequency band
Bluetooth®functions of the au cell phones use frequencies
in the 2.4 GHz band ranging from 2.402 GHz to 2.480 GHz.
Bluetooth®function: 2.4FH1
The au cell phone main unit uses the
2.4 GHz band. FH-SS is used as the
modulation scheme. The interference
distance is about 10 m or less.
The bands of mobile unit identification
devices cannot be avoided.
•
Precautions about Bluetooth®
The Bluetooth®function of K011 conforms to the domestic
standards of Japan, FCC standards and EC directives,
and has been certified. Use of the Bluetooth®function
may be restricted in some countries/regions. If you
are using the Bluetooth®function overseas, check the
relevant laws and regulations of the country/region you
visit.
Bluetooth®precautions
The frequencies used by the Bluetooth®function of K011
are in the 2.4 GHz band. In this frequency band, other
similar wireless stations, in-plant wireless stations for
mobile unit identification that require a license for use,
such as factory production lines, specific smallpower
wireless stations that do not require licenses, amateur
wireless stations (collectively called “other wireless
■
■
•
■
stations” from here on) are operated in addition to home
electrical appliances such as microwave ovens, devices for
industrial, scientific and medical devices.
1. Before using K011, make sure that “other wireless
stations” are not in operation nearby.
2. In the event that instances of radio wave interference
have occurred between K011 and “other wireless
stations”, immediately either relocate K011 or stop
operation of the device (stop emission of radio waves).
3. If you are unclear on any points or are troubled by
anything, contact an au shop or Customer Service
Center.
Connections between K011 and all other Bluetooth®
devices have not been confirmed. Therefore,
connections with all Bluetooth®devices are not
guaranteed.
K011 supports security features for wireless
communications that are compliant with the Bluetooth®
standard specifications, but the security may not
be sufficient depending on the usage environment
and configuration. Be careful when making data
communication using Bluetooth®function.
KDDI CORPORATION, Okinawa Cellular Telephone
Company assumes no responsibility for leakage of
data or information that may occur during Bluetooth®
communication.
•
•
•
H32BasicManual.indb15H32BasicManual.indb15 2012/06/2010:16:302012/06/2010:16:30

16
Safety Precautions/Notes on water resistance
<Backup content on the product>
Please back up* important content received by
or downloaded to the K011 to an outside source.
Content recorded to memory on the K011 sometimes
disappears or is altered by unexpected factors, such
as static electricity or a fault, repair, mishandling, etc.
* How to make backups
Store important data such as phonebook data,
music (incoming ring tone, etc.), shot photos and
videos on microSD memory cards. You can also
send files as e-mail attachment or transfer to your
PC. Note, however, that there are some data that
cannot be copied by using these means.
Information
Reproduction of the content of this manual in part or in
whole is prohibited.
The content of this manual is subject to change
without notice.
Every effort has been made in the preparation of
this manual. Should you notice any unclear points,
omissions, etc., feel free to contact us.
●
•
■
•
•
•
H32BasicManual.indb16H32BasicManual.indb16 2012/06/2010:16:302012/06/2010:16:30

17
Safety Precautions/Notes on water resistance
Notes on water resistance
The K011 main unit has water resistance equivalent to IPX5 and IPX7 (with the
external connection jack cover and battery cover securely attached (based on in-
house testing). However, use regardless of the precautions on pages 17 to 20
may result in water seepage or intrusion of sand/foreign particles, resulting in
overheating, ignition, electric shock, scratching, malfunction, etc. Read the
precautions on pages 17 to 20 for safe use.
• IPX5 equivalent
Means that the product will maintain its operability as a phone even if it is
sprayed with water from a 6.3 mm diameter nozzle at a distance of about 3
meters for more than 3 minutes at a rate of about 12.5 liters per minute from any
direction.
• IPX7 equivalent
Means that the product will maintain its functionality as a phone with no water
getting inside the main unit even if it is gently submerged in a tank of still tap
water at room temperature to a depth of 1 meter for about 30 minutes.
• Specifically, you can use the product in the rain (less than 20 mm per hour)
without umbrella, as well as use the product in a place with water such as a
bathroom, kitchen or poolside.
Important items to remember before use
• Firmly close the external connection jack
cover and attach the battery cover to prevent
water seepage. Make sure that they are
securely closed so that they are not raised.
• Just a small particle (a hair, grain of sand, etc.) on the seals can cause water
leaks.
• Do not open/close the external connection jack cover or battery cover if the
main unit or your hands are wet.
• Do not place the product on sand at a beach, etc. Grains of sand or other
small particles might get into the microphone or speaker causing the volume to
drop.
• Do not use (including opening/closing and key operation) the product
underwater.
• Do not expose the product to or immerse it in liquids other than room
temperature fresh water/tap water (water with soap, detergent, bath salts, hot
spring, boiling water, sand/mud, seawater, a swimming pool, alcohol, etc.).
Soap, detergent,
bath salts
Hot spring Boiling water Sand, mud Seawater Pool water
How to close the external connection jack cover
After stowing the cover hinge, press on the external connection
jack cover ①evenly with the flat part of your finger.
Then, rub your finger over the cover in the direction of arrow ②to
ensure that the cover is not partially open.
②①
H32BasicManual.indb17H32BasicManual.indb17 2012/06/2010:16:302012/06/2010:16:30

18
Safety Precautions/Notes on water resistance
Closing the battery cover
Close firmly so that the battery cover is not raised.
󱫀Place the battery cover aligning its tabs with the grooves of the main unit.
󱫂Push the battery cover in the direction of the arrow.
󱫄Press and slide your finger over the circumference of the battery cover in the
direction of the arrow to firmly attach it.
Grooves
Tabs
󱫀󱫂󱫄
Precautions
■Notes on various usage scenes
<In the rain>
• Do not use in heavy rain (more than 20 mm per hour).
• Never open/close the external connection jack cover or battery cover if the
product is exposed to rain, or your hands are wet.
<Bathroom>
• Do not immerse or drop in tub. Do not use under water.
• Do not immerse the product in soap water, detergent water, water with bath
salts in it, or in hot spring water.
• Do not expose directly to warm shower.
• Do not splash the product with hot water.
• Do not use the product in a bathroom for an extended period of time.
• Use in temperatures between 5°C and 35°C (limited use between 36°C and
40°C) and humidity between 35% and 90%.
• Do not bring the desktop holder (sold separately) into a bathroom. Also, do not
use the desktop holder if it has condensation.
<In the kitchen>
• Do not splash the product with or immerse it in liquids such as soap water,
detergent water, seasonings, juices, etc. other than fresh water/tap water.
• Do not splash the product with or immerse it in hot water or chilled water.
• Do not place the product where it gets extremely hot or cold such as near a
stove or in a refrigerator.
• Do not expose to strong water flow (more than 6 L/min.).
• When viewing 1Seg, place the product on a stable surface.
<Poolside>
• Do not immerse or drop in pool water. Do not use under water.
• Pool water contains disinfecting chlorine. If exposed to pool water, immediately
wash off with room temperature tap water*. Do not use a brush.
* Rather weak water flow (less than 6 L/min.)
• When viewing 1Seg, place the product on a stable surface.
■Common precautions
• Firmly close the cover of the external connection jack, and firmly attach the
battery cover after checking that the rubber seal on the underside is positioned
correctly. A caught particle (lint, a hair, grain of sand, etc.), no matter how
small, may result in seepage.
• Do not insert pointed objects in gaps around the cover of the external
connection jack or battery cover. Doing so might damage the rubber seals and
cause seepage.
• Do not open/close the cover of the external connection jack or remove/attach
the battery cover while wearing gloves. A caught particle (lint, a hair, grain of
sand, etc.) on the gloves, no matter how small, may result in seepage.
• Before opening/closing the cover of the external connection jack or removing/
attaching the batter cover, check that there is no wetting, sand, soiling, etc. on
the cell phone or your hands. Wetting, sand, soiling, etc. on them may enter the
cell phone or become caught under the covers and cause malfunction or
seepage. If even a small amount is present, wipe cell phone and hands with a
lint-free, clean, dry cloth before working.
H32BasicManual.indb18H32BasicManual.indb18 2012/06/2010:16:312012/06/2010:16:31
