Sony Ericsson Z600 User manual

3
Sony Ericsson
GSM 900/1800/1900
This manual is published by Sony Ericsson AB,
without any warranty.
Sony Ericsson Mobile Communications AB
reserves the right to make changes or
improvements to any of the products described in
this guide without prior notice.
Such changes will, however, be incorporated into
new editions of this manual.
All rights reserved.
© Sony Ericsson Mobile Communications AB,
2003
Publication number: 3-255-631-31(1)
Please note:
Some of the services in this manual are not
supported by all networks. This also applies to the
GSM International Emergency Numbers (for
example, 112).
Please read the guidelines for safe and efficient
use (%116 Safe and Efficient Use) and the
Limited warranty (%120 Limited Warranty)
chapters before you use your mobile phone.
T9™ text input is a registered trademark of Tegic
Communications Inc. and the T9™ text input
software is provided under license of Tegic
Communications Inc.
Bluetooth™ is a trademark owned by the
Bluetooth SIG, Inc.
Java™ and all Java™-based marks and logos,
including the coffee cup logo, are trademarks or
registered trademarks of Sun Microsystems, Inc.
in the United States and other countries.
Power consumption of charger during stand-by: below 0.3W
Halogenated flame retardant is not used in the cabinets.
Halogenated flame retardant is not used in the printed wiring boards in main portions.
Z600_A6.book Page 3 Thursday, August 21, 2003 2:30 PM

4
My Z600 information
Phone information for your reference.
For easy reference, please record the
identification numbers of your mobile phone
and SIM card. This information will assist
you in customer inquiries to your retailer,
manufacturer or network operator/service
provider. In case of loss or theft of your phone
and/or SIM card, call your network operator/
service provider immediately to prevent misuse.
My mobile phone number:
__________ ___ ___ ___ ___ ___ ____ ___ __
Operator customer service number:
__________ ___ ___ ___ ___ ___ ____ ___ __
My SIM card number:
(Printed on your SIM Card)
__________ ___ ___ ___ ___ ___ ____ ___ __
My phone’s ID number (IMEI):
(Printed on the label underneath the battery)
__________ ___ ___ ___ ___ ___ ____ ___ __
Z600_A6.book Page 4 Thursday, August 21, 2003 2:30 PM

5
About this manual
Composition of this manual, Icon explanation.
Composition of this manual
This manual is composed of the following
sections:
• Your Z600: your phone information.
• Getting started: start using your Z600.
• Basic operation: basic features of your Z600.
• Menu operation: how to use menu options.
• Appendix: additional information.
Note that the screen and icon in this manual may
vary slightly in font and/or color from the actual
screen.
Explanation of the icons
(Instruction purpose only.)
Icons Explanations
Important
Notes
Contact your network operator/
service provider for details
}Use the Soft/Navigation key to
select
%xx See also page xx
Press the center of the Navigation
key
Press the Navigation key down
Z600_A6.book Page 5 Thursday, August 21, 2003 2:30 PM

6
Contents
My Z600 information . . . . . . . . . . . . . . 4
Phone information for your reference.
About this manual . . . . . . . . . . . . . . . . 5
Composition of this manual, Icon explanation.
Your Z600
Included in your kit . . . . . . . . . . . . . . . 9
What’s in your kit.
Covers and the Hand Strap . . . . . . . . 10
Attaching covers and the Hand Strap.
Quick reference . . . . . . . . . . . . . . . . 11
An overview of the phone and its functions.
Basic features . . . . . . . . . . . . . . . . . . 12
Key functions, External display, Menu overview.
Getting started
SIM card and Battery . . . . . . . . . . . . . 16
SIM card and Battery information.
Using your Z600 . . . . . . . . . . . . . . . . . 19
Start using your phone.
Basic operation
Making Calls (Saving contacts) . . . . . 21
Use Phonebook, Voice dialing, Speed dialing.
Receiving calls . . . . . . . . . . . . . . . . . 25
Receiving/Answering/Ending calls.
During a call . . . . . . . . . . . . . . . . . . . . 27
Call options.
Voice control . . . . . . . . . . . . . . . . . . . 31
Using voice commands.
Z600_A6.book Page 6 Thursday, August 21, 2003 2:30 PM

7
Text entry . . . . . . . . . . . . . . . . . . . . . 32
Standard and T9 text entry.
Menu operations
Phonebook . . . . . . . . . . . . . . . . . . . . . 35
Phonebook menu, Voice commands.
Messaging . . . . . . . . . . . . . . . . . . . . . 43
Chat, SMS, MMS, Email, etc.
My shortcuts . . . . . . . . . . . . . . . . . . . 58
Creating your own Shortcuts menu.
Calls . . . . . . . . . . . . . . . . . . . . . . . . . . 59
Call options (configuring call conditions).
Camera . . . . . . . . . . . . . . . . . . . . . . . 66
Using the integrated camera.
Pictures & sounds . . . . . . . . . . . . . . . 69
Selecting, Composing, Recording sounds and
pictures.
Connectivity . . . . . . . . . . . . . . . . . . . . 73
WAP, Bluetooth, Synchronization, etc.
Operator direct link . . . . . . . . . . . . . . 91
Accessing Operator defined direct links.
Internet services . . . . . . . . . . . . . . . . 91
Accessing an online web page.
Settings . . . . . . . . . . . . . . . . . . . . . . . 92
Personalizing your phone settings.
Organizer . . . . . . . . . . . . . . . . . . . . . . 99
Calendar, Notes, Alarms, Timer, Stopwatch,
Calculator and Code memo.
Entertainment . . . . . . . . . . . . . . . . . 106
Playing games and downloading an application.
Z600_A6.book Page 7 Thursday, August 21, 2003 2:30 PM

8
Appendix
Troubleshooting . . . . . . . . . . . . . . . 108
Security . . . . . . . . . . . . . . . . . . . . . . 111
PIN, PIN2, SIM card and Phone locks.
Icon glossary . . . . . . . . . . . . . . . . . . 113
Icons which may appear in the display.
Safe and Efficient Use . . . . . . . . . . 116
Please read this information before using your
mobile phone.
Z600_A6.book Page 8 Thursday, August 21, 2003 2:30 PM

9
Your Z600
Your Z600
Included in your kit
What’s in your kit.
The kit should include one mobile phone, one
standard battery, two sets of exchangeable
covers, one charger, one CD and this instruction
manual. If one of these items is missing, please
contact your retailer immediately.
Plug type differs from country to country.
Z600_A6.book Page 9 Thursday, August 21, 2003 2:30 PM

10
Your Z600
Covers and the Hand
Strap
Attaching covers and the Hand Strap.
The exchangeable cover
Your Z600 comes with 2 different colored
covers. Place the cover onto the phone as
illustrated below.
The Hand Strap
Attach the hand strap to the phone as illustrated
below.
1
2
The hand strap is not included in your kit.
Z600_A6.book Page 10 Thursday, August 21, 2003 2:30 PM

11
Your Z600
Quick reference
An overview of the phone and its functions.
1
2
9
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
1Earpiece 12 On/Off key
2Display 13 Camera
3Volume keys 14 Strap hole
4Return key 15 External antenna
connector
5Voicemail key 16 Camera key
6Charging/Network
indicator
17 Infrared port
7Operator key 18 Mirror
8Navigation key 19 External display
9Soft keys 20 Loudspeaker
10 Clear key 21 Battery cover
11 Keypad
(Alphanumeric keys)
22 Connector
Z600_A6.book Page 11 Thursday, August 21, 2003 2:30 PM

12
Your Z600
Basic features
Key functions, External display, Menu overview.
Key functions
On/Off Switch on/off the phone.
Soft Select an option that
appears above in the
display.
Return Exit the menu.
Operator Access Operator direct
link.
Clear Delete items from a list.
Delete text/digit before
the cursor.
Press and hold to turn
on/off mute (during calls)
or sound.
Voicemail Press and hold to access
your voicemail. %50 Call
voicemail
Camera Activate Camera function.
Take a picture.
, Volume Adjust the volume.
Z600_A6.book Page 12 Thursday, August 21, 2003 2:30 PM

13
Your Z600
Navigation Key External Display
Your Z600 has an external display for viewing
information (for example, date, battery status,
message indication) without opening the phone.
This display is deactivated when the phone is
opened.
External display key functions
Press center Open Main menu from
standby mode.
Select an option.
Press right Open Main menu from
standby mode.
Scroll through the menus,
list and texts.
Press left Access SMS (Write new)
from standby mode.
Scroll through the menus,
list and texts.
Press up Access Internet services
from standby mode.
Scroll through the menus,
list and texts.
Press down Access Phonebook from
standby mode.
Scroll through the menus,
list and texts.
Key Mode Explanation
Standby
Event
Sleep
Activate backlight.
Standby Activate backlight.
2nd press toggles
between status
items.
Event Activate backlight.
2nd press dismisses
screen or returns to
standby mode.
Z600_A6.book Page 13 Thursday, August 21, 2003 2:30 PM

14
Your Z600
Info/Help text
More information, explanation or tips about
some menus or functions are available in your
phone. Select the menu or function and press
Info.
More option
If you press More, a list of options is displayed.
The option list differs depending on which
menu you are in.
Pressing More in standby mode offers you
the following options: Turn On Silent,Turn On
Bluetooth,Turn On IR,Post Note,Status.
Sleep Activate backlight.
Go to standby/event
screen.
Incoming call Mute ringer.
2 x press in rapid
succession rejects
the call.
Press
and
hold
Standby
Event
Sleep
Activate backlight.
Z600_A6.book Page 14 Thursday, August 21, 2003 2:30 PM

15
Your Z600
Menu overview
to access the Main menu from standby mode
and move the Navigation key to scroll through
the menu options.
Some menus are operator, network dependent.
(* Only visible during calls.)
1
4
7
10
2
5
8
11
3
6
9
12
1 Operator
direct link
2 Internet
Services
3 My Shortcuts
Write New
Ring Volume
Select Profile
My Numbers
Edit Shortcuts
4 Camera 5 Messages
Tex t
Call Voicemail
Email
Chat
WAP Push
Area Info.
Options
6 Entertainment
Games & More
Other Games
7 Pictures &
Sounds
My Pictures
More Pictures
My Sounds
More Sounds
Themes
More Themes
Draw Picture
Music DJ
Record Sound
8 Phonebook
Call Contact
Find and Send*
Add Contact
Manage Contact
Pictures
Personal Rings
Voice Commands
Special Numbers
Advanced
Options
9 Calls
Missed Calls
Call List
Forward Calls
Manage Calls
Time & Cost
Next Call
Options
10 Connect
Online Services
Bluetooth
Infrared Port
WA P O pti on s
Synchronization
GSM Networks
Data Comm.
Accessories
11 Organizer
Calendar
Notes
Alarms
Timer
Stopwatch
Calculator
Code Memo
12 Settings
Sounds and Alerts
Display
Profiles
Language
Time and Date
Voice Control
Locks
Handsfree
Master Reset
Z600_A6.book Page 15 Thursday, August 21, 2003 2:30 PM

16
Getting started
Getting started
SIM card and Battery
SIM card and Battery information.
SIM card
Your SIM (Subscriber Identity Module) card
contains a computer chip with your service
details and phone numbers. Like a credit card, it
should be kept securely and handled carefully.
Do not bend, scratch or expose to moisture.
Avoid static electricity. To avoid corrupting the
memory of your SIM card, always switch off
your phone before removing or inserting your
SIM card.
Inserting the SIM card
1Remove the battery cover and the battery.
2Insert the SIM card into the holder.
3Replace the battery and the cover.
To remove the SIM card
Follow steps 1-3 above removing the SIM card
from the holder in step 2.
When you insert a new SIM card, your phone
prompts you to select whether or not you wish to
copy the SIM contents to the phone memory
%35 Phonebook.
Z600_A6.book Page 16 Thursday, August 21, 2003 2:30 PM

17
Getting started
Battery
Use only the Sony Ericsson-specified Z600
battery and charger. When supplied, your
battery will not be fully charged.
Both the status bar within the battery icon
in the display and the charging indicator (red)
display the charging status.
Charging (5 °C-45 °C) is complete when
appears.
Full charging can take up to approximately
3 hours, but may vary depending on certain
conditions (for example, if your phone is
switched on or if temperature is outside the
operating range).
When your battery is completely empty, it can
take some time until the battery icon appears
during charging.
As an energy-saving measure disconnect the
charger from both the mains socket and the
phone after charging.
On exposure to high temperatures your battery
may expand slightly. This has no influence on
your safety/health and will reduce to its original
size once re-exposed to a lower temperature.
Inserting the Battery
1Slide the battery cover down to remove.
2Align the claws on the battery terminal with
those of the phone and press battery down.
3Align the claws at the side of the cover with
slots of the phone and slide back into place
until the lock clicks.
2
1
Z600_A6.book Page 17 Thursday, August 21, 2003 2:30 PM

18
Getting started
Removing the battery
First power off and wait until the display goes
blank. Remove the cover and then the battery.
Charging the battery
1Plug the charger into a mains socket.
2Connect the charger to the bottom (jack) of
the phone.
Removing the charger from the phone:
Usage time
When your battery is nearly empty, appears
and a beep indicates that approximately 1 minute
of talk time remains; however, if the Turn On
Silent option is activated there will be no tone.
If you insert a new battery, you must reset the clock.
Z600_A6.book Page 18 Thursday, August 21, 2003 2:30 PM

19
Getting started
Using your Z600
Start using your phone.
Switching on your phone
To switch on/off your phone, press and hold .
(The first time you turn on the phone it takes up
to 40 seconds to begin operating.)
Entering PIN
Enter your PIN (Personal
Identification Number)
using the number keys (the
PIN appears in code as ****)
and press OK or to
confirm. %111 PIN
(Personal Identification
Number).
Connecting to the network
After successfully entering your PIN, your
phone searches for an available GSM network.
The network search is automatic and may take
a few seconds. (To select the network manually
%87 GSM Networks.)
You are ready to make and receive calls when
the network operator’s name and the signal
strength icon appear in the display and the
network indicator (green) blinks.
The following indicates the strength of the
received network signal. If the signal is very
weak, there is a risk of losing service.
Strong
signal
Weak signal Network not
available
Z600_A6.book Page 19 Thursday, August 21, 2003 2:30 PM

20
Getting started
If you cannot obtain service
If you cannot obtain a network service the
reception strength may be too weak. Move to a
higher elevation, a window or an open space and
make sure that there is nothing obstructing the
internal antenna area (front cover).
Roaming
If you are out of range of your “Home” network
operator, especially when abroad, another network
operator may be selected automatically subject
to signal strength and roaming agreements
between network operators %87 GSM
Networks.
Z600_A6.book Page 20 Thursday, August 21, 2003 2:30 PM

21
Basic operation
Basic operation
Making Calls
(Saving contacts)
Use Phonebook, Voice dialing, Speed dialing.
Dialing a Number
1Dial the complete
number of the party
you wish to call
(including the area
code even if dialing
locally). In the case of
international calls,
press and hold
until +appears. Enter
the country code
followed by the area code and then the
number.
2Press to correct any mistakes.
3Press Call to dial the number displayed or
4}More }Add Number to save the number in
the Phonebook.
Select New Contact to create a new contact
entry or Add to Old to save the number to an
existing contact.
To hide/show your phone number when making a
call %65 Next call.
Automatic redialing: If connection fails, the message
Retry? is displayed. Press Yes to activate the automatic
redialing option (not available for fax or data calls).
The phone automatically redials the number up to
10 times until the call is connected, you press a key
or receive an incoming call. You will hear a tone
when the call is connected.
Z600_A6.book Page 21 Thursday, August 21, 2003 2:30 PM

22
Basic operation
Selecting a Phonebook entry
1In standby mode, press and hold an
alphanumeric key to advance to the first
letter on the key and then press the same
key repeatedly to go to the letter you wish
to find (for example, to advance to contacts
beginning with “L”, press and hold to
go to Jand then press again 3 times
to go to L).
2Highlight the contact you wish to call and
press Select.
3Select the number and press Call.
Making emergency calls
Your phone supports the international
emergency numbers, 112, 911 and 08.
This means that these numbers can be used
to make an emergency call in any country,
with or without a SIM card inserted (network
dependent), if a GSM network is within range.
In some countries, other emergency numbers
may also be promoted. Your operator may
therefore have saved additional local emergency
numbers on your SIM card.
To make an emergency call, enter an emergency
call number (112, etc.) and press Call.
You can also select a Phonebook entry from Call
Contact in Phonebook menu %36 Call contact.
To call a contact from the SIM card, %42 Call from
SIM.
Z600_A6.book Page 22 Thursday, August 21, 2003 2:30 PM
