AU G'zOne TYPE-XX Installation guide

Basic Manual
濡れた状態での充電は、
異常な発熱・焼損などの原因となり
大変危険です。
衝撃や過度な外圧を加えると、電池
の破損・変形等により発煙・発火等
の原因となり大変危険です。
In case above numbers are not available (toll free).
0120-925-314
In case above numbers are not available (toll free).
0120-977-033
For inquiries, call:
Customer Center
From non-au mobile phones/
general subscriber phones
From au mobile phones
without area code 157
For general information (toll free)
Repair and Delivery Support Center
From au mobile phones
without area code 113
From non-au mobile phones/
general subscriber phones
For theft, loss, or malfunction (toll free)
Business hours 9:00－20:00 (7 days a week)
(Repair and Delivery Service for members)
Business hours 9:00－20:00 (7 days a week)
Business hours : 24 hours live support (7 days a week)
From au mobile phones/non-au mobile phones/general subscriber phones
0120-925-919
For repair or replacement cell phone delivery service
(toll free)
0077-7-111
0077-7-113
December 2021, 1st Edition
Sold by: KDDI CORPORATION, OKINAWA CELLULAR TELEPHONE COMPANY
Manufactured by: KYOCERA Corporation
Cell phone and PHS operators collect and recycle
unused telephones, batteries and battery chargers at
stores bearing the logo regardless of brand and
manufacturer to protect the environment and reuse
valuable resources.


Thank you for buying the "G'zOne TYPE-
XX (simply called the "product" or "main
unit" from here on).
Before using the product, be sure to read
the supplied "Basic Manual" (this manual)
to ensure correct use.

Before you start using the product, make
sure that you have all the following
packaged items with the product.
Main unit
Battery Pack
(KYY31UAA)
LOCK Rotating Tool
(sample)
•取扱説明書 (Basic Manual) (Japanese)
ii

The following items are not included in the
package.
•Desktop holder (KYY31PUA)
•microSD memory card
•AC adapter
•Earphone
•USB Type-C™ cable
◎Purchase a specified charger (sold
separately).
◎Illustrations of the products in this manual
are only for reference. They may look
different from the actual product.

■
Handles only basic operations for main
features.
■

For detailed descriptions of various
functions, refer to "取扱説明書 詳細版 (Full
Instruction Manual)" (Japanese) available
on the au homepage:
(https://www.au.com/support/service/
mobile/guide/manual/) (Japanese)
1



■
In this manual, the key illustrations are
simplified as shown below.
uo
jl
m,.
1 2 3
4 5 6
7 8 9
- 0 ^
qa
v
k
e
c
s f
Pressing e or c ............. w
Pressing s or f ............. x
Pressing e, c, s, f
... d
■

In this manual, step descriptions for
selecting a menu item/icon/on-screen
button, etc. with w or d and then
pressing k (OK/Check/Set/Commit/
Done) are abbreviated as [Operation].
Example: To edit phone book contacts
1
uu
Indicates to select "Edit" with w and
commit with k.
2

◎For details on key operations, refer to "Basic
Key Operations" (▶P. 97).
■
Screenshots and operation instructions
in this manual are based on the product
with the SIM card is inserted.
The illustrations and screenshots in this
manual may look different from the actual
product or screens. Also, please note
that the contents of the screen may be
partially omitted.
Notations used
in this manual
Actual screen
In this manual,
part of the
screen such as
icons are
omitted.
◎In this manual, keys, screenshots and icons
are described based on default settings of
the product with the body color "GREEN".
However, actual keys, screenshots and
icons may differ or be partially omitted.
◎Contents at the bottom of the screen that
can be operated by pressing k/u/o/j/
l are indicated in parentheses, such as u
(Menu).
* However, k (OK)/k (Check)/k (Set)/k
(Commit)/k (Done) are abbreviated as k only.
◎Menu items, layers and icons described in
this manual may be different according to
functions and conditions to use.
◎In this manual, "microSD™ memory card
(commercially available)" and "microSDHC™
memory card (commercially available)" are
abbreviated as "microSD memory card" or
"microSD".
◎
Company names and product names referred
to in this manual are trademarks or registered
trademarks of the respective companies. TM
or ® may be omitted in this manual.
3

Preface .........................................................................ii
List of Packaged Items ..........................................ii
Operating Instructions ..........................................1
Illustrations and Descriptions in
This Manual ...............................................................2
Contents ...................................................4
Safety Precautions ...............................9
Safety Precautions...............................................9
When Using the Product ......................................9
Safety Precautions (Observe Strictly) ........ 12
Material List ........................................................... 28
Handling Precautions .........................................29
Notes on Waterproof/Dustproof/
Shockproof Properties ....................................... 37
Important Items to Remember before Use . . 39
How to Clean the Product ................................. 43
Precautions on Charging ................................... 45
Draining the Product ........................................... 45
Notes on Using Bluetooth®/Wireless LAN
(Wi-Fi®) Function ................................................... 47
Cautions on Using 2.4 GHz Band ................... 48
Security Code/PIN Code ................................... 49
Notes on Security Code ..................................... 49
Notes on PIN Code ..............................................50
Notes on Data Communication Charges .... 51
Notes on Call Charges ....................................... 51
Notes on Applications ........................................ 52
Cell Phone Etiquette ........................................... 52
Basic Operations ................................54
Basic Operations ................................................54
Names and Functions of Parts ....................... 54
Charging/Notification Indicator ....................... 58
How to Attach a Strap ........................................ 58
Installing/Removing the Battery Pack ........ 59
Installing the Battery Pack ............................... 59
Removing the Battery Pack ..............................62
SIM Card .................................................................. 63
When SIM Card is Not Inserted ....................... 63
Installing/Removing the SIM Card.................64
Inserting the SIM Card ........................................ 64
Removing the SIM Card ......................................66
Inserting/Removing the microSD Memory
Card ........................................................................... 68
Inserting the microSD Memory Card ............. 68
Removing the microSD Memory Card ........... 69
Contents
4

Charging .................................................................. 71
Charging with the AC Adapter ......................... 72
Charging with the Desktop Holder and the
Specified AC Adapter .......................................... 74
Turning the Power On/Off.................................76
Turning the Power On ......................................... 76
Turning the Power Off ......................................... 76
Forcing the Product to Shut Down and
Restart ...................................................................... 76
Initial Settings ....................................................... 77
Using the Pointer ................................................. 79
Pointer Operation.................................................. 79
Switching to English Display ........................... 81
Using the Standby Screen ............................... 81
Using Widgets and Indicators .......................... 82
Editing Widgets in the Standby Screen ....... 82
Monitoring the Product's Status ....................83
Viewing Icons ......................................................... 83
Notification Panel ................................................. 84
Setting Manner Mode ......................................... 86
Setting Airplane Mode ........................................ 87
Checking Your Phone Number ........................ 87
Checking Your Profile .......................................... 87
Editing Your Profile .............................................. 88
Using the Sub-display ......................................... 88
Using the Main Menu .......................................... 90
Using Applications/Services ............................ 94
Changing the Main Menu ................................... 95
Using the Custom Menu .................................... 95
Registering Applications to the Custom
Menu .......................................................................... 95
Using the Custom Menu to Activate
Applications ............................................................ 95
Rearranging Applications ..................................95
Deleting Applications .......................................... 96
Using Custom Keys ............................................ 96
Common Operations ...........................................97
Basic Key Operations .........................................97
Using Checkboxes ...............................................98
Disabling Manner/Shutter Key Operation
when the Product is Folded (Key Lock) ...... 98
Character Input ...................................99
Character Input ...................................................99
How to Enter Characters .................................. 99
Phone ...................................................103
Phone ...................................................................103
Making a Call ......................................................103
Entering a Phone Number and Making
a Call ....................................................................... 103
5

Using Call Histories and Making a Call ..... 107
Using Speed Dial ............................................... 107
Calling Overseas from au Phones (au
International Call Service) ............................... 108
Receiving a Call ................................................. 109
Answering an Incoming Call ........................... 109
Rejecting an Incoming Call............................. 110
Settings for Step-Up Ring Volume .............. 110
Settings for Snooze of Missed Call ............ 111
Using Auto Answering .................................... 111
Settings for Auto Answering ......................... 111
Playing Back Auto Answering ....................... 112
Phone Book ........................................113
Phone Book .......................................................113
Registering to the Phone Book.................... 113
Using the Phone Book List ............................ 114
Displaying the Phone Book List ................... 114
Using Information in Phone Book ................ 115
Registering the Frequently Used
Address to Pair Function ............................... 116
Using the Pair Function .................................. 117
Mail ........................................................118
Mail .......................................................................118
E-mail ....................................................................118
Initial Settings .................................................... 118
Checking E-mail .................................................119
Sending E-mail .................................................... 122
Adding/Deleting Recipients........................... 124
Receiving E-mail ................................................. 124
Inquiring for and Receiving New Mail ........ 125
Checking E-mail Address ............................... 125
Changing E-mail Address ............................... 126
+Message (SMS) ............................................126
Initial Settings .................................................... 127
Using +Message ............................................... 128
The Usages of +Message.............................. 128
How to Use +Message ................................... 128
Registering Recipients .................................... 129
Registering Recipients via QR Code .......... 129
Registering a New Recipient ......................... 130
Sending a Message .......................................... 130
Checking a Received Message ................... 131
PC Mail ................................................................131
Adding an Account of PC Mail ..................... 131
Sending PC Mail ................................................. 132
Receiving PC Mail ............................................. 132
Replying/Forwarding PC Mail ....................... 132
6

Internet ................................................133
Internet Access ...............................................133
Accessing the Internet ................................... 133
Using Data Communication ........................... 133
Browser...............................................................134
Displaying the Browser Menu ...................... 134
Using the Pointer .............................................. 135
Camera ................................................136
Camera ................................................................136
Viewfinder Layout .............................................. 137
Capturing Still Pictures/Video ...................... 138
Useful Functions ..............................140
OUTDOOR APPS .............................................140
Flashlight ............................................................141
Using the Buzzer Sound ...............................142
Alarm ....................................................................143
Using the Menu in the Alarm List ............... 143
Kanji Check .......................................................144
Screenshot ........................................................144
Radio ....................................................................145
Using FM Radio .................................................. 145
Data Transfer ...................................................146
Using the microSD Memory Card ............... 146
Using "Data Storage App" ............................. 147
Using Bluetooth® Function ............................ 148
Settings ...............................................149
Settings ..............................................................149
Displaying the Settings Menu ...................... 149
Wireless LAN (Wi-Fi®) Function .................150
Wireless LAN (Wi-Fi®) Function ................... 150
Using the Wireless LAN (Wi-Fi®)
Function ................................................................ 151
Enabling the Wireless LAN
(Wi-Fi®) Function ................................................ 151
Connecting to a Wi-Fi® Network ................... 151
Disconnecting from an Access Point ........ 151
Appendix .............................................152
Appendix .............................................................152
Updating Software ............................................ 152
Downloading and Updating Software ......... 153
Troubleshooting ................................................. 153
位置検索サポート (Find Missing Device
Service) ................................................................. 156
After-Sales Service .......................................... 157
7

SIM Unlock ........................................................... 159
Related Accessories ........................................ 160
Using an Earphone ............................................ 160
Main Specifications .......................................... 161
Specific Absorption Rate (SAR) of Cell
Phones................................................................... 164
FCC Notice ..........................................................165
Export Administration Regulations ............ 167
Intellectual Property Right ............................ 167
Trademarks .......................................................... 167
License .................................................................. 170
8

Safety Precautions
Safety Precautions

•Before you start using the product, be sure to
read "Safety Precautions" in this manual to
ensure correct use.
•Before you assume that the product is
malfunctioning, check "Troubleshooting" in this
manual.
Or, check for possible remedies in "トラブル診断
(trouble-check)" (Japanese) of au homepage:
https://www.au.com/trouble-check/
(Japanese)
•Communication is not possible even inside the
service area in places where the signal does
not reach (e.g. tunnels and basements). Also,
communication may not be possible in poor
reception areas. Communication may be
interrupted if you move into poor reception
areas during communications.
•Since this product uses radio waves, the
possibility of communication intercepts by
third parties cannot be eliminated (though the
LTE/UMTS/GSM system has highly secure
confidential communication features).
•VoLTE (LTE network) by au is used when
connecting with emergency call receiving
agencies within Japan. You cannot connect
using 3G (circuit-switched network).
•The product is compatible with au World
Service. Each network service described in
this manual varies depending on the area and
service content.
•Since the product is a radio station under the
Radio Law, you may be asked to temporarily
submit the product for inspection in
accordance with the Radio Law.
•The IMEI information of your cell phone is
automatically sent to KDDI CORPORATION for
maintenance and monitoring operational
status of your cell phone.
•If you are using the product overseas, check
the relevant laws and regulations of the
country/region you visit beforehand.
•The Company is not liable for any damages
arising from earthquakes, lightning, storms,
floods or other natural disasters, as well as
fires, actions by third parties, other accidents,
intentional or mistaken operation by the
customer, or use under other unusual
conditions outside the responsibility of the
Company.
9

Safety Precautions
•The Company is not liable for any incidental
damages (change/disappearance of saved
content, loss of business income, disruption
of business, etc.) arising from use of or
inability to use the product.
•The Company is not liable for any damages
arising from failure to observe the described
content of this manual.
•You cannot use information obtained from the
measuring sensor or GPS equipped with the
product for the purpose which requires high
reliability. Note that the Company is not liable
for any damage or lost income arising from the
difference caused by measurement.
•The Company is not liable for any damages
arising, for example, from malfunction caused
by combination with connected devices or
software not related to the Company.
•Captured image data or downloaded data may
sometimes be altered or lost due to faults,
repair or other handling of the product. The
Company is not liable for any damage or lost
income resulting from recovery of these data.
•
It is recommended you keep a copy of important
data on your PC's hard disk, etc. Whatever the
cause of the defect or malfunction may be, the
Company assumes no responsibility for
alteration or loss of saved data.
•Contents saved in the product, such as
contacts, mails and favorites might be altered
or lost by an accident, fault, repair or
mishandling. Be sure to keep a copy of
important contents. Note that the Company
assumes no responsibility for any damages or
lost profits resulting from altered or lost
contents.
•Note that content data (both charged or free
of charge) saved on the product cannot be
returned to the customer when the product is
replaced for repair of a fault, for example.
•The product uses liquid crystal for its main
display. The main display response speed may
become slow when the ambient temperature
is low, which is due to the characteristics of
liquid crystal and is not a malfunction. The
main display response speed will return to
normal at room temperature.
•
Although the display used on the product is
made using high-precision technology, some
pixels (dots) might be lit or out at all times.
This is not a malfunction.
10

Safety Precautions
•
You are recommended to store copies of
individual data such as photos/movies you took
and music in your PC by sending each file as mail
attachment, etc. Note, however, that you may
not be able to make copies of some copyrighted
data even by the above-mentioned means.
•Do not discard the old product together with
regular trash. Please cooperate in the
collection of the product (including optional
parts) when it is no longer needed to protect
the environment and effectively use resources.
Old products are collected at an au shop/au
Style and other places.
•If the confirmation screen such as terms and
conditions, etc. appears when you use
applications and functions of the product,
follow the on-screen instructions.
•If the confirmation screen of communication
charge appears when you use applications
and functions of the product, follow the
on-screen instructions.
* "The Company" as appears in this manual
refers to the following companies:
Sold by: KDDI CORPORATION, OKINAWA
CELLULAR TELEPHONE COMPANY
Manufactured by: KYOCERA Corporation
◎ Reproduction of the content of this manual in part
or in whole is prohibited.
◎
The content of this manual is subject to change
without notice.
◎ Due to the specification changes of the operating
system or termination of the services, some
features become unavailable.
◎ Every effort has been made in the preparation of
this manual. Should you notice any unclear points,
omissions, etc., feel free to contact us.
11

Safety Precautions


■Before using the product, thoroughly read
this "Safety Precautions" for proper use.
■These precautions describe instructions that
should be observed to prevent injury to the
customer and others, or damage to property
using the product.
■The signs below differentiate between the
levels of danger that can occur if the product
is not used within the specified guidelines.
DANGER
This sign denotes that
"death or serious injury*1
may directly result from
improper use".
WARNING
This sign denotes that
"death or serious injury*1
may result from improper
use".
CAUTION
This sign denotes that
"minor injury*2 or damage
to property*3 may result
from improper use".
*1 Serious injury: This refers to loss of sight, injury,
burns (high- and low-temperature),
electric shock, broken bones, injuries
with residual aftereffects from
poisoning, etc., and injuries requiring
hospital admission for treatment or
long-term hospital attendance as an
outpatient.
*2 Minor injury: This refers to injuries, burns (high- and
low-temperature), electric shock, etc.
that do not require hospital admission
for treatment or long-term hospital
attendance as an outpatient.
*3 Property damage: This refers to extended damage
to buildings, furniture, livestock
or pets.
■

Indicates an
action that is
not allowed.
Indicates that
handling with
wet hands is
not allowed.
Indicates that
disassembly
is not allowed.
Indicates an
action based
on instructions
that must be
done.
12

Safety Precautions
Indicates that
use in a place
where the
product is
likely to get
wet or
allowing the
product to get
wet is not
allowed.
Indicates that
the power
plug must be
disconnected
from the
power outlet.
■



DANGER
Do not use, store or leave the product
in hot places (e.g. by the fire, near a
heater, under a kotatsu or futon, in
direct sunlight, in a car in the hot sun).
Doing so may cause fire, burns, injuries,
or electric shock.
Do not put the product into or near a
heating cooking device such as a
microwave oven or IH cooker, or
high-pressure container such as a
pressure cooker.
Doing so may cause fire, burns, injuries,
or electric shock.
13

Safety Precautions
Do not put sand, dirt, or mud on the
product or put it on them directly. Do
not touch the product with hands to
which sand or others adhere.
Doing so may cause fire, burns, injuries,
or electric shock.
For details on water/dust resistance,
refer to the following.
▶P. 37 "Notes on Waterproof/Dustproof/
Shockproof Properties"
Do not charge when the product is wet
with water (drinking water, perspiration,
seawater, urine of pet animals, etc.).
Do not use it near water, such as in a
bathroom.
Doing so may cause fire, burns, injuries,
or electric shock.
For details on water resistance, refer to
the following.
▶P. 37 "Notes on Waterproof/Dustproof/
Shockproof Properties"
Do not subject the product to strong
pressure or break the product.
Especially when bringing the product
putting in a pocket of clothes, do not let
the product hit against surroundings or
being put between the objects.
Doing so may cause fire, burns, or injury
due to battery damage.
* Examples to avoid
•Sitting or squatting with the product
put in a pocket of trousers or skirt
•Putting the product in a pocket of
outer wear and catching them in a door
or a door of car
•Stepping on the product on a soft
object such as a sofa, bed, or bedding,
or on a floor
•Putting the product into a seat of train
or bus
Do not attempt to disassemble or
modify the product.
Doing so may cause fire, burns, injuries,
or electric shock.
14

Safety Precautions
Do not let the product get wet with
water (drinking water, perspiration,
seawater, urine of pet animals, etc.).
Doing so may cause fire, burns, injuries,
or electric shock.
For details on water resistance, refer to
the following.
▶P. 37 "Notes on Waterproof/Dustproof/
Shockproof Properties"
Do not put water (drinking water,
perspiration, seawater, urine of pet
animals, etc.) into the charging terminal
or the external connection terminal.
Doing so may cause fire, burns, injuries,
or electric shock.
For details on water resistance, refer to
the following.
▶P. 37 "Notes on Waterproof/Dustproof/
Shockproof Properties"
Use the optional products specified by
au.
Not doing so may cause fire, burns,
injuries, or electric shock.
WARNING
Do not drop, trample, or throw the
product or give a strong force or
vibration to it.
Doing so may cause fire, burns, injuries,
or electric shock.
Keep conductive materials (metal
pieces, pencil lead, etc.) from coming in
contact with the charging terminal or
the external connection terminal, and
prevent dust from getting inside.
Not doing so may cause fire, burns,
injuries, or electric shock.
Do not cover or wrap the product with
bedding, etc. while using or charging
the product.
Doing so may cause fire or burns.
When cleaning the product, be careful
not to allow disinfectant or moisture to
come into the gaps of the product,
charging terminal, external connection
terminal, microphone, or speaker.
The product is damaged and may cause
injuries or electric shock, etc.
15

Safety Precautions
If charging is not complete after the
specified charging time, stop charging.
Overcharging may cause fire, burns, or
injuries.
Make sure to turn off or stop charging
the product before you get close to
places where a flammable gas or dust
can be generated.
Using the product in places where a
flammable gas can be generated may
cause an explosion or fire.
Follow the instructions given by the
respective institution regarding the use
of the product in a gas station.
Do not charge the product in a gas
station.
Be careful not to drop the product in a
place like a gas station, especially when
you put gas into a vehicle.
Using the product in places where a
flammable gas can be generated may
cause an explosion or fire.
Perform the following operations
carefully while using, charging, or
keeping the product if there are odors,
noise, smoke, overheating, discoloring,
deformation, or other abnormalities.
•Remove the power plug from the wall
outlet.
•Turn the product off.
•Remove the battery pack from the
product.
Not doing so may cause fires, burns,
bodily injury, electric shock, etc.
CAUTION
Do not use the damaged product.
Doing so may cause fire, burns, or
injuries.
Do not leave the product on unstable or
sloping surfaces. Be careful especially
when the product is set to vibrate.
The product may fall and cause injuries.
16

Safety Precautions
Do not use or store the product in
humid or dusty places, or places that
get hot.
Doing so may cause fire, burns, or
electric shock.
For details on water/dust resistance,
refer to the following.
▶P. 37 "Notes on Waterproof/Dustproof/
Shockproof Properties"
When children use the product, do not
let them use incorrectly without
instruction by an adult for proper use.
Doing so may cause accidental swallow,
injuries, or electric shock.
Do not store the product within the
reach of small children.
Doing so may cause accidental swallow,
injuries, or electric shock.
Be careful when using the product
continuously for a long time or charging
as it gets hot. Be careful of contacting
with the product continuously by
putting the product in a pocket of
clothes or falling asleep etc.
The product, battery pack, or specified
charger (sold separately) may become
hot when using for a long time such as
applications, calling, data
communication, watching videos, or
while charging. Depending on your
physical predisposition and physical
condition, contacting with a high
temperature part may cause skin
redness, itching, rash, or low-
temperature burns.
■
DANGER
Do not throw the main unit into fire or
apply heat.
Doing so may cause fire, burns, or
injuries.
17

Safety Precautions
Do not apply excessive force such as
sticking a sharp-edged tool (nail, etc.)
into the product, hitting it with a hard
tool (hammer, etc.), or stepping on it.
Doing so may cause fire, burns, or
injuries.
If the substance inside the product
comes into contact with your eyes or
mouth, immediately rinse the area with
clean water, and then see a doctor
right away.
Not doing so may cause loss of sight or
poor physical condition due to the
influence of the substance, etc. inside
the product.
WARNING
Do not lighten or flash the lighting part
of the light close to person's eye. Be
especially careful to keep a sufficient
distance from small children.
Not doing so may cause vision
disturbance. Also, it may cause an
accident such as injuries due to
dizziness or shocks.
Do not lighten or flash the light to point
at the eyes of someone driving a car
etc.
Doing so may interfere with driving and
cause an accident.
Do not watch a repeatedly flickering
screen for a long time.
Doing so may cause muscle spasms or
loss of consciousness, etc.
Do not allow water or other liquids
(drinking water, perspiration, seawater,
urine of pet animals, etc.), metal pieces,
flammable material or foreign object
into the SIM card slot or the microSD
memory card slot on the product. Do
not mistake the place and direction of
the SIM card or the microSD memory
card.
Doing so may cause fire, burns, injuries,
or electric shock.
Do not expose the camera lens to
direct sunlight for an extended period.
Doing so may cause fire, burns, or
injuries by the light-collecting
mechanism of the lens.
18
