Panasonic ICX User manual

August, 1998

August, 1998
Name__________________________________________________
Personal ID _____________________________________________
Dial Voice Mail Code _____________________________________
Dial Voice Mail Code From Outside __________________________
System Administrator _____________________________________
System Administrator Extension _____________________________

Built-In Voice Mail Quick Reference

1
Contents
Getting Started . . . . . . . . . . . . . . . . . . 2
Security. . . . . . . . . . . . . . . . . . . . . . . . 3
Playback Options . . . . . . . . . . . . . . . . 3
Message Copy Services. . . . . . . . . . . 5
Leaving a Message. . . . . . . . . . . . . . . 6
Broadcast Messages . . . . . . . . . . . . . 7
Outside Access. . . . . . . . . . . . . . . . . . 8
Outside Notification. . . . . . . . . . . . . . . 9
ReturningtoVM fromOtherServiceMenus
10
Recording Conversations . . . . . . . . . 11
Advanced Recording . . . . . . . . . . . . 13
Welcome to ICX Built-In Voice Mail
Your new Built-In Voice Mail allows you to
record telephone calls and access many
basic voice mail (VM) features. You may
use your system to greet callers, retrieve
and leave messages, notify outside
telephones and pagers of messages, and
many other powerful options to improve
your productivity.
This system iseasy touse and customize.
The system has automated commands
which you can access via a system of
option menus. The system informs you
which buttons to press; all you have to do
is press them! Usually you will input
keypad characters like the “7” (seven) key
and the “#” (pound) key.
Contents

2
Entering Your Mail Box
There are three ways to enter your Voice
Mail (VM) box.
Accessing VM with Keys
Press the “RETRIEVE” key or “START
VM” key to access your mail box. The
system dials your mailbox number for you.
Accessing VM by Dialling
Enter the VM number, then your mailbox
number followed by the “#” (pound) key.
[123]
If you assigned a password to your
mailbox, enter the password code
followed by the “#” (pound) key.
[456]
The messages play automatically, newest
to oldest. (See
Playback Options for
additional message options.)
Your Personal Greeting
The system provides an automated
greeting, “
Welcome to the voice mail
system
.” You may set a personalized
message when you enter the mail box
(look to the left for instructions) by
pressing “*” (star) “#” (pound), then the
number “7” and “#”.
Only then can you perform the steps
outlined below. Services in Personal
Greetings:
1.To start recording, press
“1” then “#”. .
2.To stop recording, press
press “7” then “#”.
3.To repeat your greeting,
press “3” then “#”.
4.To delete the greeting,
press “5” then “#”.
You should set a personal security code
(password). (See Setting a Password.)
Only you know your code, so don’t forget
what it is!
Think About It!
Write your greeting herebefore you record
it; it’s easier to remember what you want
to say if it’s right in front of you.
*
#7 #
*
#
7
#
3
#
7
#
Gettin
g
Started
RETRIEVE
key
START VM
key
Dial VM extension.
#
#

3
Setting a Password
Enter VM then press “*” star, then “#”
(pound), then number “8” and “#” (pound).
1.Enter the new
password and “#”.
2.To accept, press “1” and
“#”.
3.If you want to modify the
password, press “2” and
“#”.
You can change your password as
frequently as you wish. The code can be
anywhere between 3 - 10 numbers. If it is
easier for you to remember letters than
numbers, don’t forget that you can spell it
with letters on the keypad. Longer codes
are more secure than shorter ones.
If you forgetyour code, you must ask your
ICX Telephone System distributor to
reprogram a new security code.
Basic Message Playback Options
By default, messages play back
sequentially from the newest one. Once
you have dialled your voice mailbox, you
can use several options, including:
•Repeat the message
•Delete, then hear the next mes-
sage
•Save, then hear the next message
•Go back in message
•Skip forward in message
•Message Copy
Note: The following commands may be
entered during the message.
*
#8#
[1234]
#
1#
2#
Quick Tip:
To speed the Message
up/down, toggle the
“4” “#” (pound) keys..
To adjust the Volume
up/down, toggle the
“6” “#” (pound) keys.
✶✭
✶✭✶✭
1234
 
  
Security/Playback Options
4 #
6#

4
Repeating the Message
1.Press “3” and “#” (pound).
Deleting the Message
2.Press “5” and “#” (pound). The
following message plays
automatically.
Saving the Message
1.Press “8” and “#” (pound). The next
message plays automatically.
Going Backward in a Message
You can go back in any message while
you are listening to it. The system default
is to go back 10 seconds, but system
programming can change it to any time
increment you want.
1.Press “1” and “#” (pound). The
message skips backwards the
amount of seconds you have
programmed.
Going Forward in a Message
You may skip over part of a message
while you are listening to it. Again, the
system default is 10 seconds.
1.Press “7” and “#”
(pound). The message
skips forward to the
specified time increment.
3 #
5#
8
#
1#
7#
X
✶✭
✶✭ ✶✭ ✶✭ ✶✭ ✶✭ ✶✭
✶✭ ✶✭ ✶✭ ✶✭ ✶✭ ✶✭
✶✭
Playback Options (Cont)

5
Copying Messages
You can copy a message to another
mailbox or multiple mailboxes while you
are listening to the message. You also
may copy it when you hear the
announcement,“
To Delete, press 5 and#.
To Save, press 8 and #
.”
Copying the Message to Another
Mailbox
1.Press the COPY key or “1” “9” and
“#” pound. The system announces:
“
Please enter the mailbox number
and press Pound
.”
2.Press the MAILBOX key or enter
the mailbox number and “#” (pound).
3.Press “1” and “#” to copy
the message.
•If you selected the wrong mailbox
number, press “2” and “#” (pound).
The system takes you back to Step
One above.
•To Cancel copying, press “*” “#”.
Copying to Multiple Mailboxes
Instead of entering the MAILBOX key or
mailbox numbers in Step Two above,
enter the broadcast code and “#” (pound).
1.Press the COPY key or “1” “9” and
“#”(pound). The system announces:
“
Please enter the mailbox number
and press # (pound)
.”
2.Press “*” BROADCAST CODE “#”
(pound) or press the pre-assigned
broadcast MAILBOX key.
3.Press “7” and “#” (pound).
✶✭
✶✭
✶✭
✶✭
cc:Ted cc:Connie cc:John
Original Message
to You
COPY
Softkey
or
19 #
MAILBOX
key
1
#
2
#
*
#
or
COPY
Softkey
1 9 #
7#
✶✭
Broadcast
Code
✶✭
✶✭
✶✭ ✶✭
✶✭
*
#
Messa
g
e Copy Services

6
You may want to leave a message in
another party’s mailbox. One message
can be recorded for up to 4 minutes.
(Recording time is set upon installation,
but can be changed.) One mailbox can
contain up to 30 messages. (This number
can also be changed.)
Calling Another Party’s Mailbox
1.Press the START VM key or dial the
Voice Mail number. Do not enter
your personal mailbox.
2.Press “*”, dial the mailbox number,
and press “#” (pound).
3.You will hear the other person’s
greeting. Leave a message after the
tone and press “7” “#” (pound) or
hang up to stop recording.
If you chose “7” “#” (pound), you may
then choose several options.
•Press “1” “#” (pound) to re-record
the message..
•Press “3” “#” (pound) to repeat the
message..
•Press “5” “#” (pound) to cancel the
message..
If the other party’s mailbox is full, you will
hear the announcement, “
Sorry, you
cannot leave a message in mailbox XXX
.”
*
#
Dial Mailbox
Number
1#
Re-Record
Messa
g
e
3#
Repeat
Messa
g
e
5#
Cancel
Messa
g
e
✶✭ ✶✭
✶✭
FULL
✶✭
“...And the eighteenth
reason I think it should be
done this way is... and
another consideration here
is...”
Leavin
g
a Messa
g
e

7
Recording Your Message in Multiple
Mailboxes
The same message can be left in up to 50
other mailboxes. To use this service, your
system administrator must set up
broadcast codes. Up to 30 broadcast
codes can be assigned in one system.
Ask your administrator for details
regarding broadcast codes.
1.Press the VOICE MAIL key or dial
the Voice Mail number.
2.When you hear the system
announcement
, press “*” enter the
broadcast code, and press “#”
(pound).
3.Record the message.
4.Press “7” “#” (pound) when you are
finished or hang up.
START VM
key
7 #
✶✭
✶✭
Record Message
✶✭ ✶✭ ✶✭
✶✭
✶✭
Broadcast Code *
#
Quick Tip:
My broadcast code is:
Broadcastin
g
Messa
g
es

8
Accessing Voice Mail from the Outside
If an outside access telephone number
has been assigned, you can access the
voice mail from the outside. Once
connected to voice mail, you can access
the voice mail features.
1.Call the Voice Mail outside access
telephone number.
2.Enter the box number and press #.
3.Enter your password and #.
Your messages play automatically,
newest to oldest. You can access the
voice mail features as if your were at
an extension.
Q
uick Tip:
The outside access phone number is:
Outside Access

9
Outside Notification Services
After a message is recorded in your
mailbox, you can be informed in one of the
following two methods:
•Calling a pager
•Calling an outside telephone or
extension
Calling a Pager
You can instruct VM to notify a pager.
1.Enter VM then press *and #
2. Press “9” “#” (pound)
to access outside
notification service.
3.Press “1” '#” to notify
pager.
4.Enter the phone
number (with trunk
access #).
5.Press “#” (pound).
6.If you are done, hang
up or press “1” and
“#”.
7.If you want to modify
the notification, press
“2” “#”.
Calling an Outside Phone or Extension
You can instruct VM to notify an outside
phone after you leave the message.
1.Enter VM then press *and #
2.Press “9” “#” (pound)
to access outside
notification service.
3.Press “2” '#” to notify
outside phone.
4.Enter the phone
number.
5.Press “#” (pound).
6.If you are done, hang
up or press “1” or “#”.
7.If you want to modify
the notification, press
“2” “#”.
Some systems are set up to perform these
services automatically. Large display
telephones show an notify option on the
soft key screen. Press the button beside
the appropriate display to execute the
command.
*
#
9#
1 #
9-555-1234
#
1 #
2 #
*
#
9#
2#
[ABC-WXYZ]
1#
2#
Outside Notification
#

10
Some other options which are available to
you with the ICX Voice Mail service are as
follows:
•Go back to message retrieve service
•Go backto message retrieve/retrieve
oldest message
•Successive message retrieve
Go Back
If you have gone into VM features other
than message retrieve, such as recording
your greeting or changing your password,
and you want to go back to message
retrieve, you can do so without exiting and
starting all over again.
1.Press *and #.
2.Press 3and #to go back to
message retrieve service.
Go Back and Listen
If you want to return to message retrieve
from other areas of VM, but you want to
listen to your message oldest-first, then
you may do so.
1.Press *and #.
2.Press “3” “0” “#”.
Successive Message Retrieve
You can go directly to Successive
Message Retrieve from any area of VM.
Retrieving messages successively plays
them from the most recent to the oldest.
1.Press *and #.
2.Press 3 1 #, then 3#.
*
#
3#
*
#
3 #0
*
#
3 #1 3 #
✶✭
✶✭
NEW
OLD
✶✭
LESS
OLD
Returning to VM from Other Service Menus
✶✭
✶✭
NEW
OLD
✶✭
LESS
NEW

11
You can record normal CO trunk calls,
ISDN trunk calls, private lines, and
intercom calls. The recording is retained
as a voice mail message. Recording can
be either automatic or manual. Automatic
recording is set at installation. Phones set
for automatic recording record every
incoming/outgoing call. Ask your
administrator about your phone.
Precautions:
•Make sure the other person knows you
are recording the call. Without his or
her consent, you could be invading
privacy.
•Calls cannot be recorded if your
mailbox is full.
•You cannot record a call made with a
locally-supplied ISDN terminal adaptor.
•If Handset Mute is enabled for the
extension, the voice on the Mute
handset is still recorded on an intercom
call.
•While a conversation is being
recorded, key tones are not sent out
without first dialling “0” and “#”.
Manual Conversation Recording to
Your Mailbox
1.Receive or make a call.
2.Press the RECORD key to start
recording.
3.Replace the handset when the call is
terminated. The conversation is
stored in your mailbox.
Manual Conversation Recording to a
Designated Mailbox
1.Receive or make a call.
2.Press the VOICE MAIL key to start
recording.
3.Press the destination MAILBOX key
or input the destination mailbox
number and press #.
4.Replace the handset when the call is
terminated. The conversation is
stored in the designated mailbox.
Cancelling While Recording
1.Press CANCEL or 5 #.
Pausing Recording
1.Press PAUSE or 2 #.
2.To resume a paused recording,
press PAUSE or 2 #.
Re-Recording
1.Press Re-Record or 1 #. The
previous recording is cancelled and a
new recording is initiated.
!
RECORD VM
key
START VM
key
MAILBOX
key
CANCEL
OR
5
#
PAUSE
OR
2
#
PAUSE
OR
2
#
RE-RECORD
OR
1
#
Recording Conversations

12
Playing Back the Recorded
Conversation Before Hanging Up
1.Before hanging up, press the ADD
key, 8 #, or Soft Key 5. .
2.If prompted, press the destination
MAILBOX key or input the
destination mailbox number and
press #.
3.Press 3 # or Soft Key 10.
4.Replace the Handset.
Cancelling the Recorded Conversation
Before Hanging Up
1.Before hanging up, press the ADD
key, 8 #, or Soft Key 5. .
2.If prompted, press the destination
MAILBOX key or input the
destination mailbox number and
press #.
3.Press 5 # or Soft Key 5. The
recorded conversation is cancelled.
4.Replace the Handset.
Changing the Destination Mailbox After
Recording
1.Before hanging up, press the ADD
key, 8 #, or Soft Key 5. .
2.If prompted, press the destination
MAILBOX key or input the
destination mailbox number and
press #.
3.Press * # or Soft Key 9.
4.Choose a new recording destination.
5.Replace the Handset.
5
8#
key
ADD
MAILBOX
key
10
3#
5
8#
ADD
key
MAILBOX
key
5
5#
5
8#
key
ADD
MAILBOX
key
9
*
#
Can I record
that?!
I'm
g
oin
g
to
g
ive
y
ou a raise, Joe!
Advanced Recording

13
HOLDing During Recording
•If you place the callon HOLD while
you are recording it, then recording
is paused.
•If you place the call on HOLD for
more than 10 minutes, then record-
ing terminates automatically.
•If you resume a recorded call
which you placed on HOLD within
less than ten minutes, recording
resumes.
•If someone else retrieves the call
you placed on HOLD while record-
ing, then the person who picks up
can either continue recording or ter-
minate recording. The recorded
part of the conversation is still in the
designated mailbox.
Adding a Message to a Recorded
Conversation
After you have recorded a conversation,
you may want to add thoughts or
comments to the recording.
1.Before hanging up, press the ADD
key, 8 #, or Soft Key 5. .
2.If prompted, press the destination
MAILBOX key or input the
destination mailbox number and
press #.
3.Press Soft Key 4 or 1 #.
4.Add your message.
5.Press 7 # when you have finished.
6.You should hear, “
Message
recorded
,” before you hang up.
Outside Notification of Recorded
Conversations
You can notify outside phones and pagers
after recording a conversation. You may
also add a message to the recording
before notifying. (See “
Adding a Message
to a Recorded Conversation
.”)
NOTE: Prior to using outside notification,
you must firstset up outside notification as
described on page 10.
1.Before hanging up, press the ADD
key, 8 #, or Soft Key 5. .
2.If prompted, press the destination
MAILBOX key or input the
destination mailbox number and
press #.
3.Press Soft Key 1 or 9 #.
4.To cancel the notification, press Soft
Key 9, 9 #, or the Notify key.
5
key
ADD
8#
MAILBOX
key
4
4#
3#
5
key
ADD
8#
MAILBOX
key
1
9#
9
Notify
9#
Advanced Recordin
g

Notes

Built-In Voice Mail Quick Reference

Notes
