AUDAC IMEO2 User manual

User manual
1
2
3
IMEO2
audac.eu

IMEO2 - User manual02
ADDITIONAL INFORMATION
This manual is put together with much care, and is as complete as could be on the publication date. However,
updates on the specications, functionality or software may have occurred since publication. To obtain the latest
version of both manual and software, please visit the Audac website @ www.audac.eu.

IMEO2 - User manual 03
Table of contents
Introduction 05
Professional soundbar � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 05
Precautions 06
Chapter 1 08
Connections and connectors � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 08
Chapter 2 09
Overview IMEO2: Front � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 09
Overview IMEO2: Rear � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 010
Overview IMEO2: Remote control � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 011
Chapter 3 013
Placement and mounting � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 013
Chapter 4 015
Connecting � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 015
Chapter 5 017
Additional information � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 017
Technical specications 019
Notes 021

IMEO2 - User manual 05
Introduction
Professional soundbar
The IMEO2 Soundbar features a slim and elegant design and includes all required functions for expansion of any audiovisual
system with an impressive sound, while having a minimal hassle for installation. It’s perfectly suited for installations such
as classrooms, presentation rooms or meeting rooms where it can be used and installed in combination with screens,
smartboards or projectors.
The acoustics originate from a 3-way speaker construction, composed of two 1.5” high frequency drivers, two 2” mid frequency
drivers and a low frequency section with two 2.5” low frequency drivers with an RMS rating. The power handling reaches
an overall level of 60 Watt RMS. The Class-D amplier with integrated WaveSelect DSP processing and transmission line
conguration for the low-frequency drivers offers a crystal clear sound reproduction with stunning low-frequency response.
Selectable DSP presets offer optimization for applications such as presentations, music playback or video’s.
Various input possibilities such as an unbalanced line input, HDMI (ARC) input or SPDIF (optical and coaxial) allow compatibility
with a variation of input sources, while Bluetooth allows wireless connections with portable devices. In installations with multiple
IMEO’s installed throughout the area, it can be desirable to assign custom Bluetooth ID’s to distinguish them from each other.
Typical applications are hotels, conference rooms, schools, ... The hotel mode function in the rmware offers a solution for
these applications. An additional function is also implemented to dene a specic wake-up source, allowing the IMEO2 to
always turn-on with the same input source selected, no matter which input source was selected before power-down.
An included IR remote control allows input selection, volume control and EQ preset selection while the unique and clever
wall mounting bracket allows convenient mounting to walls on any kind of surface or location with an optimal guiding and
coverage for the cables.
The auto standby function ensures that the IMEO is automatically put in energy-saving mode after 15 minutes without input.
This way, no unnecessary energy is lost, while the IMEO remains ready to play at any moment.

IMEO2 - User manual06
Precautions
READ FOLLOWING INSTRUCTIONS FOR YOUR OWN SAFETY
ALWAYS KEEP THESE INSTRUCTIONS. NEVER THROW THEM AWAY
ALWAYS HANDLE THIS UNIT WITH CARE
HEED ALL WARNINGS
FOLLOW ALL INSTRUCTIONS
NEVER EXPOSE THIS EQUIPMENT TO RAIN, MOISTURE, ANY DRIPPING OR SPLASHING LIQUID. AND NEVER PLACE AN OBJECT FILLED WITH
LIQUID ON TOP OF THIS DEVICE
NO NAKED FLAME SOURCES, SUCH AS LIGHTED CANDLES, SHOULD BE PLACED ON THE APPARATUS
DO NOT PLACE THIS UNIT IN AN ENCLOSED ENVIRONMENT SUCH AS A BOOKSHELF OR CLOSET. ENSURE THERE IS ADEQUATE
VENTILATION TO COOL THE UNIT. DO NOT BLOCK THE VENTILATION OPENINGS.
DO NOT STICK ANY OBJECTS THROUGH THE VENTILATION OPENINGS.
DO NOT INSTALL THIS UNIT NEAR ANY HEAT SOURCES SUCH AS RADIATORS OR OTHER APPARATUS THAT PRODUCE HEAT
DO NOT PLACE THIS UNIT IN ENVIRONMENTS WHICH CONTAIN HIGH LEVELS OF DUST, HEAT, MOISTURE OR VIBRATION
THIS UNIT IS DEVELOPED FOR INDOOR USE ONLY. DO NOT USE IT OUTDOORS
PLACE THE UNIT ON A STABLE BASE OR MOUNT IT IN A STABLE RACK
ONLY USE ATTACHMENTS & ACCESSORIES SPECIFIED BY THE MANUFACTURER
UNPLUG THIS APPARATUS DURING LIGHTNING STORMS OR WHEN UNUSED FOR LONG PERIODS OF TIME
ONLY CONNECT THIS UNIT TO A MAINS SOCKET OUTLET WITH PROTECTIVE EARTHING CONNECTION
THE MAINS PLUG OR APPLIANCE COUPLER IS USED AS THE DISCONNECT DEVICE, SO THE DISCONNECT DEVICE SHALL BE READILY
OPERABLE
USE THE APPARATUS ONLY IN MODERATE CLIMATES
CAUTION
The symbols shown are internationally recognized symbols that warn about potential hazards of electrical products.
The lightning ash with arrow point in an equilateral triangle means that the unit contains dangerous voltages. The
exclamation point in an equilateral triangle indicates that it is necessary for the user to refer to the users manual.
These symbols warn that there are no user serviceable parts inside the unit. Do not open the unit. Do not attempt to service
the unit yourself. Refer all servicing to qualied personnel. Opening the chassis for any reason will void the manufacturer’s
warranty. Do not get the unit wet. If liquid is spilled on the unit, shut it off immediately and take it to a dealer for service.
Disconnect the unit during storms to prevent damage.

IMEO2 - User manual 07
CAUTION - SERVICING
This product contains no user serviceable parts. Refer all servicing to qualied service personnel. Do
not perform any servicing (unless you are qualied to)
EC DECLARATION OF CONFORMITY
This product conforms to all the essential requirements and further relevant specications described
in following directives: 2014/30/EU (EMC) , 2014/35/EU (LVD) and 2014/53/EU (RED)
WASTE ELECTRICAL AND ELECTRONIC EQUIPMENT (WEEE)
The WEEE marking indicates that this product should not be disposed with regular household waste
at the end of its life cycle. This regulation is created to prevent any possible harm to the environment
or human health.
This product is developed and manufactured with high quality materials and components which can be
recycled and/or reused. Please dispose this product at your local collection point or recycling centre for
electrical and electronic waste. This will make sure that it will be recycled in an environmentally friendly
manner, and will help to protect the environment in which we all live.

IMEO2 - User manual08
Chapter 1
Connections and connectors
CONNECTION STANDARDS
The in- and output connections for AUDAC audio equipment are performed according to international wiring
standards for professional audio equipment
1. 3.5 mm Jack (AUX):
For unbalanced line input connections
2. RCA (COAXIAL):
For coaxial SP/DIF digital input connections
3. TOSLINK (OPTICAL)
For optical SP/DIF digital input connections
3. HDMI ARC:
For HDMI (ARC) input connections
USB
USB-a: For playbacks and updates
Tip:
Ring:
Sleeve:
Tip:
Sleeve:
HDMI Type A (19-pin)
Pinout:
Left
Right
Ground
Signal
Ground
According HDMI specications

IMEO2 - User manual 09
Chapter 2
Overview IMEO2: Front
1) Status indicator LED’s:
These LED’s indicate the current operation status of the
IMEO2.Various color LED’s indicate following statuses:
• Red: Standby mode
• Green: (Blinking) USB / (Illuminated) AUX (3.5 mm jack input)
• Blue: Bluetooth mode
• Orange:(Illuminated) Optical / (Blinking) Coaxial mode
• White: HDMI ARC mode
3) Power button:
The power button allows to switch on and off the unit.
Press to switch the sound bar on. Press and hold to switch
the sound bar off. Repeatedly press (short term) to switch
between the various operation modes
(USB / AUX / BLUETOOTH / OPTICAL / COAXIAL / HDMI
ARC).
2) Remote control (IR) sensor:
The remote control (IR) sensor is located behind the front grill
of the IMEO2. This sensor requires a line-of-sight connection
with the remote control. Make sure this sensor is not covered
or blocked.
4) +/- buttons:
The + / - buttons allow to increase or decrease the volume
level.
1
2
3
4

IMEO2 - User manual010
Overview IMEO2: Rear
5) AC Power inlet connection:
The mains power supply (100-240V AC - 50/60 Hz) has to
be applied to this AC power inlet. The connection is made by
an IEC C8 power connector and the power lead is standard
tted, but can be unplugged for convenient assembly.
6) Coaxial input connection:
The coaxial input connection (RCA) allows connecting the
sound bar to any TV, receiver or other source device with an
coaxial SP/DIF output connection.
7) Optical input connection:
The optical input connection (Toslink) allows connecting the
sound bar to any TV, receiver or other source device with an
optical SP/DIF output connection.
8) USB socket:
The USB connection allows connection to memory devices.
This allows previously stored audio sources to be played
back (MP3, FLAC, WAV).
9) AUX socket:
The AUX input connection (3.5 mm jack) allows connecting
the sound bar to any stereo line-level audio source. It can be a
connection between a portable device such as smartphone,
tablet, laptop or headphone output of any device.
10) HDMI ARC socket:
The HDMI input socket allows connecting the soundbar to
any TV or projector with an HDMI connection supporting
ARC functionality
5 6 7 8 9 10

IMEO2 - User manual 011
Overview IMEO2: Remote control
The IMEO2 includes an IR remote controller, which allows
the operation of it from a distance of 6 meters.
1) Power button:
Switches the sound bar between ON and STANDBY mode.
2) MUTE button:
Toggles the status between Mute music or resume the
sound.
3) Source buttons:
Selects the audio source between the various operation
modes:
AUX / BLUETOOTH / HDMI ARC / OPTICAL / COAXIAL.
4) Playback control buttons:
buttons: allows to increase or decrease the
volume level.
buttons: allows to skip to the previous and next tracks
(only in Bluetooth mode)
button: Allows to play / pause / resume playback
in Bluetooth mode. Press and hold to activate the pairing
function in Bluetooth mode or disconnect the currently paired
Bluetooth device.
5) EQ buttons:
Allows to select a preset sound effect. Various presets are
available for FLAT, MUSIC and SPEECH. The optimal at
conguration is selected when the FLAT preset (default
congured), while low frequencies are added when the
MUSIC preset is selected and low frequencies are reduced
when selected the SPEECH preset. Select the optimal preset
according to your application requirements.
12
5
3
4
USB
// PPAIRAIR
VOL+ / VOL-VOL+ / VOL-

IMEO2 - User manual012
CONNECTION STANDARDS
First time use:
The remote control has a pre-installed lithium CR2025 battery. Remove the protective tab to activate the remote control
bat ter y.
Replace the remote control battery:
The remote control requires a CR2025, 3V Lithium battery.
To replace this battery, follow the steps as below:
• Push the tab on the side of the battery tray towards the tray
• Slide the battery tray out of the remote control
• R e m o v e t h e o l d b a t t e r y . P l a c e a n e w C R 2 0 2 5 b a t t e r y i n t o t h e b a t t e r y t r a y w i t h t h e c o r r e c t p o l a r i t y a s i n d i c a t e d
• Slide the battery tray back into the slot in the remote control
4
3
12
4
CAUTION
If the remote control is operated near other products which generate infrared rays,or if other remote control units also using
infrared rays are near the unit, it may operate incorrectly. Conversely, the other products may operate incorrectly
Precautions Concerning Batteries:
- Then the remote control is not to be used for a long time (more than a month), remove the battery from the
Remote Control to prevent it from leaking.
- If the batteries leak, wipe away the leakage inside the battery compartment and replace the batteries with new
ones.
- Do not use any batteries other than those specied.
- Do not heat or disassemble batteries.
- Never throw them in re or water.
- Do not carry or store batteries with other metallic objects. Doing so could cause batteries to short circuit, leak
or explode.
- Never recharge a battery unless it is conrmed to be a rechargeable type.

IMEO2 - User manual 013
ATTENTION
• Installation must be carried out by qualied personnel only. Incorrect assembly can result in severe personal injury and
property damage (if you intend to install this product yourself, you must check for installations such as electrical wiring
and plumbing that may be buried inside the wall).
• It is the installer’s responsibility to verify that the wall will safely support the total load of the unit and wall brackets.
• Additional tools (not included) are required for the installation.
• Do not over tighten screws.
• Keep this instruction manual for future reference.
Chapter 3
Placement and mounting
The IMEO2 offers possibilities for placement on a leveled surface underneath / in front of the TV, display
or projection surface. An included mounting bracket offers possibilities for secure wall mounting, above or
underneath the TV, display or projection surface.
The special mounting bracket consists of a wall support bar and two xation hooks which comes default assembled to the
sound bar.
Bottom
Wall Mount
Top
Wall Mount
Table
Standing

IMEO2 - User manual014
1. Attach the wall support bar
The rst step is the mounting of the supplied wall support bar on the desired location on the wall. The support bar has to
be xed to the wall by four screws which need to get tted through the provided slots. The provided slots have an elliptical
shape, allowing the possibility for slightly adjusting the position to make it perfectly level.
Make sure the appropriate fasteners are used, depending on the mounting surface
(brick, concrete, wood, ... )
The cables (depending of the required connections for applications) can be fed through the openings of the wall support
bar, and can be tied to the xation slots using cable ties.
2. Make the connections
After the wall support bar is mounted, the connections shall be made depending of the application requirements. Various
connection accessories such as cables, pigtails and 90° angle parts are included for making the connection possible.
3. Attach the speaker
After the wall support bar is attached and the connections
are made, the soundbar shall be xed to the wall plate. This
is done by sliding the hooks assembled to the soundbar into
the provided slots on the wall support bar and xing them.
4: Fixating the speaker
4.A) TOP security bolt:
This option can be selected in the situation that no object is
placed above the IMEO2. To prevent the IMEO2 from falling,
attach safety screws on top of the xing hooks.
4.B) BOTTOM security bolt:
There is the option of xing the speaker from below when
an object is placed above of the IMEO2. Attach the custom
safety screws at the bottom of the xing hooks.

IMEO2 - User manual 015
Using the HDMI (ARC) socket
The ARC (Audio Return Channel) function allows you to send
audio from your ARC compliant TV to your sound bar through
a single HDMI link. To enjoy the ARC function, please ensure
your TV is both HDMI CEC and ARC compliant and set up
accordingly.
When correctly set up, you can use your TV remote control to
adjust the volume output (VOL +/- and MUTE) of the sound
bar. - Connect the HDMI cable (not included) from unit’s
HDMI (ARC) socket to the HDMI (ARC) socket on your ARC
compliant TV. Then press the remote control to select HDMI
ARC mode.
Using the optical socket
The optical socket allows connection of the sound bar to the
optical output of your TV or receiver. Simply connect using
an optical (Toslink) cable. Remove the protective cap before
connecting.
Using the coaxial socket
The coaxial socket allows connection of the soundbar to the
coaxial output of your TV or receiver. Simply connect using
a 75 Ohm coaxial cable
Chapter 4
Connecting
Your TV must support the HDMI-CEC and ARC and the HDMI-CEC and ARC must be set to On.
The setting method of HDMI-CEC and ARC may differ depending on the TV. For details about ARC
function, please refer to the owner’s manual.
Ensure that you use an HDMI cables that can support the ARC function.
HDMI-CEC will be called different names by various manufacturers – please refer to your owner’s
manual for details on setting up HDMI-CEC and ARC.
SERV ICE ON LY
HDMI AR C
OPTICALCOAXIAL AUXSERV ICE ON LY
HDMI AR C
OPTICALCOAXIAL AUX
NOTE
SERV ICE ON LY
HDMI AR C
OPTICALCOAXIAL AUX
SERV ICE ON LY
HDMI AR C
OPTICALCOAXIAL AUX

IMEO2 - User manual016
Using the optical socket
The optical socket allows connection of the sound bar to the
optical output of your TV or receiver. Simply connect using
an optical (Toslink) cable. Remove the protective cap before
connecting.
SERV ICE ON LY
HDMI AR C
OPTICALCOAXIAL AUX
SERV ICE ON LY
HDMI AR C
OPTICALCOAXIAL AUX
SERV ICE ON LY
HDMI AR C
OPTICALCOAXIAL AUX
A
B
Using Bluetooth
The rst time when your Bluetooth portable device is connected (smartphone, tablet, ...) it needs to get paired. For getting it
paired, the sound bar shall be switched ON and in Bluetooth mode. This can be done using the power button on the side of
the unit, or the remote control. When in Bluetooth mode, the blue LED behind the front grill will blink. Activate the Bluetooth
mode in your portable device and search for devices. The device name ‘AUDAC IMEO2’ will appear on your Bluetooth device
list. If the device can’t be found, press and hold the button on the remote control to be discoverable. The system
will enter in pairing mode and two ‘beeps’ will be heard through the speakers. The Bluetooth indicator (blue LED) will blink
fast. Select ‘AUDAC IMEO2’ from the device list and an ‘uplifting beep’ will be heard through the speakers. The Bluetooth
indicator (blue LED) will illuminate constantly.
BLUETOOTH
The Bluetooth® word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. We are the licensee to use
such marks. Other trademarks and trade names are those of their respective owners
NOTE
The operation range between the sound bar device and the Bluetooth transmitter (smartphone, tablet, ... ) is
approximately 8 meters. (without any object in between)
Before any Bluetooth device is connected, ensure you know its capabilities
Compatibility with all Bluetooth devices is not guaranteed
Any obstacle in between the sound bar and the Bluetooth transmitter can reducethe operational range
If the signal strength is weak, the sound bar will disconnect automatically, but will re-enter pairing mode automatically.
•
•
•
•
•
// PPAIRAIR

IMEO2 - User manual 017
Chapter 5
Additional information
In projects with public system access such as classrooms or conference rooms, it can be desirable to lock it in a specic
operation (input) mode or disable specic functions, to avoid users changing the input signal.
Lock input:
To lock the sound bar in a specic input function (disable the operation mode selection), turn the unit ON and switch to the
desired audio source (e.g. AUX input). Press and hold the ‘AUX’ button (or other selected function) on the remote control
for about 5 seconds to enable the lock. All status indicator LED’s will blink now simultaneous and the input selection will be
locked. (the input can’t be changed by the user). Press and hold the selected function button again for about 5 seconds to
disable the lock. All status indicator LED’s will blink again simultaneous and the lock will be disabled.
Disable Bluetooth:
To disable the Bluetooth function, make sure the unit is in standby mode and press and hold the BT button on the remote
control for about 5 seconds. The blue Bluetooth indicator LED will blink and the Bluetooth function will be disabled.
Press and hold the BT button again for about 5 seconds in standby mode to enable the Bluetooth function again. The blue
Bluetooth indicator LED will blink and the Bluetooth function will be enabled again.
Disable auto standby:
To disable the auto standby function, make sure the unit is in standby mode and press and hold the power button on the
remote control for about 5 seconds. The green indicator LED will ash 3 times and the auto standby function will be disabled.
To enable the auto standby function, make sure the unit is in standby mode and press and hold the power button on the
remote control for about 5 seconds. The red indicator LED will ash 3 times and the auto standby function will be disabled.
Disable volume control on main unit:
To disable the volume control on the main unit, make sure the unit is in standby mode and press and hold ”VOL+” and “VOL-”
buttons on main unit. The blue indicator LED will ash 2 times and the volume control will be disabled.
To enable the volume control on the main unit, make sure the unit is in standby mode and press and hold ”VOL+” and “VOL-”
buttons on main unit. The blue indicator LED will ash 4 times and the volume control will be enabled.
Before updating the IMEO2, the new software must be obtained. This software can be found at https://
audac.eu/software. The downloaded files, ending in .bfu, must be copied exactly to a USB stick.
Before the update can be carried out, the IMEO2 has to be switched to USB mode. The USB stick can be inserted
into the USB port and the update will start automatically. All the lights will be on during the update process.
When the update is completed the IMEO2 will automatically enter standby mode. The IMEO2 is now updated.
DISABLE / ENABLE SPECIFIC FUNCTIONS
UPDATE

IMEO2 - User manual018
In installations with multiple IMEO2’s installed throughout the building, it can be desirable to assign custom Bluetooth ID’s to
distinguish them from each other. Typical applications are hotels, conference rooms, schools, ... The hotel mode function in
the rmware offers a solution for these applications.
Using the hotel mode, the Bluetooth ID can be adjusted to ‘AUDAC - IMEO2 + xxxx’ where ‘xxxx’ is a 4-digit number,
representing the room number, class number, meeting room number, ...
Additionally, a function is implemented to dene a specic wake-up source, allowing the IMEO2 to always turn-on with the
same input source selected, no matter which input source was selected before power-down.
To enable hotel mode, follow below steps:
Disable auto standby:
Switch IMEO2 to standby mode (upper RED LED illuminated)
Press code ‘6280’ on remote control to enable hotel mode. (see image as below)
(6280 = COAXIAL – BT – PAIR – VOL-)
The Green LED will start to blink (others are continuously illuminated)
Enter the rst number of the 4-digit ID (see image as below)
The Blue LED will start to blink (others are continuously illuminated)
Enter the second number of the 4-digit ID (see image as below)
Repeat for numbers 3 and 4
After the 4 digits of the Bluetooth ID are entered, the upper (standby) LED will start to blink.
Now the wake-up input source can be selected with the last digit:
1: AUX
3: HDMI ARC
0: No specic wake up source
HOTEL MODE
•
•
•
•
•
•
•
•
•
•
The BT name will now be changed to e.g. ‘AUDAC IMEO2 – 1234’ (in
case 1234 was entered) To exit the hotel mode function, press code
‘0826’ on remote control to enable hotel mode.
1
4
1
4
7
2
5
8
0
3
6
9

IMEO2 - User manual 019
Technical specications
Inputs Type Stereo unbalanced line (AUX)
Connectors 3.5mm jack connector
Sensitivity 500 mV
Type Coaxial SP/DIF digital input
Connectors RCA
Type Optical SP/DIF digital input
Connectors Toslink
Type HDMI ARC
Connectors HDMI 19-pin
Type USB
Connectors USB-A
Output power 2 x 15 Watt RMS (Left & Right)
30 Watt RMS (Subwoofer)
Frequency response 40 Hz - 20 kHz
THD+N 1% (1 kHz, 1W)
Bluetooth Version V3.0
Max power Tx <7 dBm
Frequency band 2402 MHz- 2480 MHz
Remote control Distance 6m
Angle 30°
Battery type CR2025
Power consumption Standby 0.5 Watt
Nominal 30 Watt
Power supply 220 - 240 v AC / 50 - 60 Hz
Dimensions (WxHxD) 1000 x 60 x 113 mm
Weight 3.6 Kg
Packaging Carton box
Shipping weight & volume 4.5 Kg - 0.022 Cbm
Accesoiries included Remote control (IR)
3.5 mm audio cable
3.5 mm audio pigtail
90° HDMI angle adapter
Wall mounting bracket
User manual

Caution:

ThisdevicecomplieswithPart15oftheFCCrulesandIndustryCanadalicense‐exemptRSS
standard(s).Operationissubjecttothefollowingtwoconditions:(1)thisdevicemaynotcause
harmfulinterference,and(2)thisdevicemustacceptanyinterferencereceived,including
interferencethatmaycauseundesiredoperation.

ThemanufacturerisnotresponsibleforanyradioorTVinterferencecausedbyunauthorized
modificationsorchangetothisequipment.Suchmodificationsorchangecouldvoidtheuser’s
authoritytooperatetheequipment.
Thisradiotransmitter(identifythedevicebycertificationnumberormodelnumberifCategoryII)
hasbeenapprovedbyIndustryCanadatooperatewiththeantennatypeslistedbelowwiththe
maximumpermissiblegainindicated.Antennatypesnotincludedinthislist,havingagaingreater
thanthemaximumgainindicatedforthattype,arestrictlyprohibitedforusewiththisdevice.

ThisequipmenthasbeentestedandfoundtocomplywiththelimitsforaClassBdigitaldevice,
pursuanttopart15oftheFCCRules.Theselimitsaredesignedtoprovidereasonableprotection
againstharmfulinterferenceinaresidentialinstallation.Thisequipmentgenerates,usesandcan
radiateradiofrequencyenergyand,ifnotinstalledandusedinaccordancewiththeinstructions,
maycauseharmfulinterferencetoradiocommunications.However,thereisnoguaranteethat
interferencewillnotoccurinaparticularinstallation.Ifthisequipmentdoescauseharmful
interferencetoradioortelevisionreception,whichcanbedeterminedbyturningtheequipment
offandon,theuserisencouragedtotrytocorrecttheinterferencebyoneormoreofthe
followingmeasures:
‐‐Reorientorrelocatethereceivingantenna.
‐‐Increasetheseparationbetweentheequipmentandreceiver.
‐‐Connecttheequipmentintoanoutletonacircuitdifferentfromthattowhichthereceiveris
connected.
‐‐Consultthedealeroranexperiencedradio/TVtechnicianforhelp.

ThedevicehasbeenevaluatedtomeetgeneralRFexposurerequirement.

TomaintaincompliancewithFCC’sRFexposureguidelines,thisequipmentshouldbe
installedandoperatedwithaminimumdistanceof20cmbetweentheradiatorandyour
body.


