audeeo TOTALLY RAD AOTOTALR User manual

ITEM: AOTOTALR
QUICK START + INSTRUCTION GUIDE

Welcome to audeeo
Thank you for choosing this product. We are striving
for excellence in both aesthetics and acoustics.
But we could not do this without you.
Let's take sound to new heights together.

TOTALLY RAD
WIRELESS KIDS HEADPHONES

1 Welcome
1.1 What's In The Box
2 Your Wireless Kids Headphones
2.1 Getting To Know Your Headphones
2.2 Control Panel Features
3 Quick Start Guide
3.1 Charging & Powering ON
3.2 Bluetooth Pairing
4 Button Functions
5 All Features & Contents
6 Specifications
7 Troubleshooting
8 Care & Maintenance
9 Warranty & Legal

1Welcome
1.1 What's In The Box
GUIDE BOOKLET WIRELESS KIDS HEADPHONES
QUICKSTART + INSTRUCTION GUIDE
MICRO USB CABLE
AUX IN CABLE

HEAD CUSHION
Silicone cushion for a better
grip on your head
CONTROL PANEL
This is the main area that
controls both microphone
functions, volume, & tracks
EAR CUSHIONS
Soft ear cushions for long
listening
MICROPHONE
Answer calls hands-free
2Your Wireless Kids Headphones
2.1 Getting To Know Your Headphones
A
B
C
D
D
C
A
B
ITEM: AOTOTALR

VOLUME (+) / NEXT TRACK
This button skips to the next track, and
increases volume.
VOLUME (–) / PREVIOUS TRACK
This button goes to the previous track, and
decrease volume.
POWER / PAUSE / PLAY / PHONE BUTTON
- Powers your headphones ON / OFF.
- This multi purpose button pauses / plays
receive calls / hang up calls.
- Use of smartphone assistant:
• Google Assistant™
• Siri®
LED INDICATOR LIGHT
This light will illuminate when the headphones
turns ON / OFF / pairing / connected.
MICRO USB CHARGING PORT
Area to plug-in the micro USB cable to charge
the headphones.
MICROPHONE
Input your voice.
AUX INPUT
This port is used for connecting to devices with
an auxiliary cable.
2Your Indulge Wireless Headphones
2.2 Control Panel Features
A
B
C
D
E
F
G
A
B
C
D
E F G
ITEM: AOTOTALR

3
Quick Start Guide
3.1 Charging & Powering ON
Connect the Micro USB cable (only use the provided cable) to a
computer USB port or a USB wall charger. Plug the other end of the
micro USB cable into the Micro USB charging port (E) located on
the left side of the headphone. While charging the LED indicator
light (D) will turn RED and then turn BLUE when the battery is fully
charged.
Ensure the Headphones are turned o, then Press and hold the
power button for about 3 seconds, to turn the Headphones ON,
until blue light flashes.
1
2
1 21
ITEM: AOTOTALR

BLUETOOTH
audeeo Totally Rad
ITEM: AOTOTALR
3 Quick Start Guide
3.2 Bluetooth Pairing
NOTE: Please refer to the diagram on 2.2
BLUETOOTH
Ensure the Headphones are turned o, then Press and hold the
power button for about 3 seconds, to turn the Headphones ON,
The Headphones will enter Bluetooth pairing mode automatically
and emit a tone as the LED indicator light (D) will flash BLUE and
RED. Make sure your device has Bluetooth enabled.
Ensure Bluetooth is enabled on your smartphone or music device.
Your device will start searching for wireless devices. The
Headphones will appear as “audeeo Totally Rad” in the list of
available Bluetooth devices.
Select “audeeo Totally Rad” The LED will begin to slowly blink blue,
and the Headphones will emit a tone to indicate that is has been
successfully paired with your device.
1
2
3
12 3
audeeo Totally Rad

4Button Functions
1
2
3
4
5
6
7
ANSWER & HANG UP CALLS
When there is an incoming call, short press the Power/Pause/Play/
Phone Button (C) to answer the call, press the Power/Pause/Play/
Phone Button (C) once again to hang up the call.
REJECT CALLS
When there is an incoming call, long press the Power/Pause/Play/
Phone Button (C) for 2 seconds to reject the call.
REDIAL THE LAST NUMBER
Double click the Power/Pause/Play/ Phone Button (C) to call the
last number in the list of call history.
PAUSE & PLAY MUSIC
When music is playing, press the Power/Pause/Play/ Phone Button
(C) once to pause music, press the button once again to play music.
NEXT & LAST TRACK
When playing music, press the Volume (+) / Next Track button (A)
to skip to the next track, press the Volume (–) / Previous Track
button (B) to skip to the previous track.
VOLUME UP & DOWN
When in a call or playing music, press and hold the Volume (+) / Next
Track button (A) once to increase the volume, press and hold the
Volume (–) / Previous Track button (B) once to decrease the volume.
VOICE ASSISTANT
press and hold Power/Pause/Play/ Phone Button (C) for 3 seconds.
ITEM: AOTOTALR

5All Features & Contents
CONTENTS:
• TOTALLY RAD HEADPHONES
• MICRO USB CHARGING CABLE
• AUX IN CABLE
• USER MANUAL
• SUPPORT CARD
MULTI DEVICE:
Will work with any
Bluetooth®device
• Mobile phones
• Computers
• Tablets
EXTENDED TIME:
lithium ion battery with
8hrs of listening time
BUILT-IN MIC:
hands-free talking with
volume control
RECHARGEABLE:
lithium ion battery with
extended listening time
KID SAFE SOUND:
volume limit less than
85dB for safe listening
AUX-IN:
fully compatible with
auxiliary cables
BETTER AUDIO:
enhanced acoustics
treble & bass
8
hrs
<85dB
ITEM: AOTOTALR

BLUETOOTH VERSION 5.0
FREQUENCY RESPONSE 20Hz - 20KHz
DRIVER UNIT 40mm
BATTERY 250mAh Lithium ion
STANDBY TIME Up to 200 hours
WORKING TIME Up to 8 hours
CHARGING TIME Approx 2.5 hours
IMPEDANCE 32Ω
OPERATION RANGE 10meters
5Specifications
SPECIFICATIONS:
NOTE:
Working time depends on volume levels
- Lower volume will prolong your estimated battery life.
- Higher volume will decrease your estimated battery life.
ITEM: AOTOTALR

Troubleshooting
TROUBLESHOOTING:
NO POWER
Recharge your Headphones using
the included micro USB cable.
MUSIC IS NOT PLAYING OVER
BLUETOOTH
Make sure your Bluetooth device
has A2DP profile. Check if both
devices are paired and connected
over Bluetooth. Restart the
Headphones to reconnect your
Bluetooth device.
BLUETOOTH DEVICE WILL NOT
RECONNECT WITH THE
HEADPHONES
Navigate to your Bluetooth
settings menu on your Bluetooh
device, tap "audeeo Totally Rad"
and select "Forget". Now follow
the steps to pair your device
again.
6
ITEM: AOTOTALR

• DO NOT expose the unit to liquid, moisture, or humidity to avoid
damage to the product’s internal circuitry.
• DO NOT use abrasive cleaning solvents to clean the unit.
• DO NOT expose the unit to extremely high or low temperatures as
this will shorten the life of the electronic device, destroy the battery,
and/or distort certain plastic parts.
• DO NOT dispose of the unit in fire as they may explode or combust.
• DO NOT expose the unit to and/or use sharp objects on the
Headphones as this will cause scratches and damage.
• DO NOT attempt to disassemble the unit. In the event that the unit
does not function properly, return it to the store where it was
purchased.
7 Care & Maintenance
DO NOT DISPOSE OF LITHIUM-ION
BATTERIES WITH GENERAL WASTE.
PLEASE RETURN IT TO A BATTERY
RECYCLING COLLECTION POINT.
Li-ion

8Warranty & Legal
The condition of this warranty and our responsibilities under this warranty are as follows:
Supplier’s warranty is non-transferable. This warranty is limited to the original purchaser only.
• You must be able to prove the date of original purchase of the unit with a dated receipt.
• The warranty is not applicable if the product has been subject to physical abuse, improper
installation, modification or repair by unauthorized third party.
• The responsibility of supplier’s products shall be limited to the repair or replacement of the
product as its sole discretion.
• Specifically exempt from any warranty are limited-life consumable components subject to
normal wear and tear such as batteries, decorates and other accessories.
• A supplier will not take any responsibility if the failure of the unit has resulted from accident,
abuse, misuse, or any unauthorized repair, modification or disassemble.
• Modification and repair of the unit should be done by authorized and qualified service
personnel, Center or returned to the manufacturer.
• This warranty give you specific legal rights, and you may also have other rights which vary
under local laws.
The Bluetooth®word mark and logos are registered trademarks owned by
Bluetooth SIG, Inc. and any use of such marks by iHip Europe Ltd is under license.
Other trademarks and trade names are those of their respective owners.
This appliance should not be put into the domestic garbage at the end of its useful
life, but must be disposed of at a central point for recycling of electric and electronic
domestic appliances.
This symbol on appliance, instruction manual and packaging puts your attention to
this important issue. The materials used in this appliance can be recycled. By
recycling used domestic appliances you contribute an important push to the
protection of our environment. Ask your local authorities for information regarding
the point of recollection.
Siri®is a trademark of Apple Inc., registered in the U.S. and other countries. Google
Assistant is a trademark of Google Inc.

Manufactured & Distributed by:
iHip Europe Ltd., Chartwell House,
292-294 Hale Lane, London, UK, HA8 8NP
audeeo™ is a registered trademark of iHip Europe Ltd.
MADE IN CHINA
