audeeo CURIO LUXE Manual

ITEM: AOCURIO
QUICK START + INSTRUCTION GUIDE

Welcome to audeeo
Thank you for choosing this product. We are striving for
excellence in both aesthetics and acoustics. But we could not do
this without you. Let's take sound to new heights together.

CURIO LUXE
WIRELESS HEADPHONES

1Welcome
1.1 What's In The Box
2Your Curio Wireless Headphones
2.1 Getting To Know Your Headphones
3Quick Start Guide
3.1 Charging & Powering ON
3.2 Bluetooth Pairing
4 Button Functions
5 All Features & Contents
6Specifications
7Troubleshooting
8Care &Maintenance
9Warranty & Legal

CURIO WIRELESS HEADPHONES
1Welcome
1.1 What's In The Box
GUIDE BOOKLET
MICRO USB CABLE
AUXILIARY CABLE
HEADPHONES

ITEM: AOCURIO
2Your Curio Wireless Headphones
2.1 Getting To Know Your Headphones
A
A B
C
D E F
C
B
D
FOLDABLE HINGES
ON-EAR CUSHIONS
NEXT/VOLUME (+) BUTTON
INSIDE TOP HEAD CUSHION
Located on both the left &
right side of the headphones
for better storage.
Comfortable, breathable
leather for long listening.
Press the button once to
skip to the next track. Hold
the button to increase the
volume.
Lightweight comfortable
silicone that rests the head-
phones on your head.

ITEM: AOCURIO
G H I J
EPOWER/PLAY/PAUSE/PHONE BUTTON
Hold the button 3 seconds to power on your headphones, hold the button 5
seconds to power o your headphones.
Press the button once to pause or play a song.
When receiving a call press the button once to answer the call, press the button
once again to hang up the call.
When receiving a call press and hold the button for 2 seconds to reject the call.
Double press the button to call the last number in the list of call history.
Hold the button for 1-2 seconds until you hear the “beep” prompt to activate
Voice Assistant ( Google Assistant™ or Siri® ) on your smartphone.
F
G
H
I
J
BACK/VOLUME (−) BUTTON
LED INDICATOR LIGHT
AUXILIARY/AUDIO SLOT
MICRO USB
CHARGING PORT
BUILT-IN MICROPHONE
Press the button once to skip to the previous track. Hold the button to decrease
the volume.
Light will indicate if the headphones are on/o, pairing, and charging.
Insert 3.5mm jack cable.
Area to plug-in the micro
USB cable to charge the
headphones.
Hands-free talking.

ITEM: AOCURIO
3Quick Start Guide
3.1 Charging & Powering ON
Connect the Micro USB cable to a computer USB port.
Plug the other end of the micro USB cable into your Wireless Headphones.
The red LED light will illuminate while the headphones are charging. When
the battery is fully charged, the LED light will turn o automatically.
Disconnect the headphones at this point. The headphones will then be
ready for use. When the battery is low, your headphones will issue a warning
tone. When this happens, charge your headphones.
NOTE: please refer to the diagram on 2.2
1
2
3

CURIO WIRELESS HEADPHONES
3Quick Start Guide
3.2 Bluetooth Pairing
NOTE: please refer to the diagram on 2.2
1
2
3
Ensure the Headphones are turned o, then press POWER/PLAY/PAUSE/
PHONE Button (E) to turn the headphones ON. The headphones will enter
Bluetooth pairing mode automatically and the LED indicator light (G) will flash
BLUE and RED. Make sure your device has Bluetooth enabled.
Ensure Bluetooth is enabled on your smartphone or music device. Your
device will start searching for wireless devices. The Headphones will appear as
“audeeo Curio LUXE” in the list of available Bluetooth devices.
Select “audeeo Curio LUXE” The LED will begin to slowly blink blue, and the
Headphones will emit a tone to indicate that is has been successfully paired
with your device.
CONNECT
audeeo Curio LUXE

4Button Functions
ANSWER & HANG UP CALLS
When there is an incoming call, short press the Pause/Play/Phone Button
(E) to answer the call, press the Pause/Play/Phone Button (E) once again to
hang up the call.
REJECT CALLS
When there is an incoming call, long press the Pause/Play/Phone Button (E)
for 2-3 seconds to reject the call.
REDIAL LAST NUMBER
Double press the Power/Pause/Play/Phone Button (E) to call the last
number in the list of call history.
PAUSE & PLAY MUSIC
When music is playing, press the Power/Pause/Play/Phone Button (E) once
to pause music, press the button once again to play music.
NEXT & LAST TRACK
When playing music, press the Volume (+) / Next Track button (D) once to skip
to the next track, press the Volume (–) / Previous Track button (F) once to skip
to the previous track.
VOLUME UP & DOWN
When in a call or playing music, hold the Volume (+) / Next Track button (D)
to increase the volume, hold the Volume (–) / Previous Track button (F) to
decrease the volume.
NOTE: please refer to the diagram on 2.2
1
2
3
4
5
6

20hrs
CURIO WIRELESS HEADPHONES
5All Features & Contents
FOLDABLE
COMPACT DESIGN:
EXTENDED TIME: AUX-IN:
COMFORTABLE:
Smaller on-ear design enables
the headphones to fold and
collapse for easy carrying.
lithium ion battery with
20hrs of listening time
fully compatible with
auxiliary cables
lightweight with soft
cushion ear-cups
CONTENTS:
• CURIO HEADPHONES
• MICRO USB CHARGING CABLE
• AUXILIARY CABLE
• MANUAL
MULTI DEVICE:
will work with any
Bluetooth®device
• mobile phones
• computers
• tablets
BUILT-IN MIC:
hands-free talking
with volume control
BETTER AUDIO:
enhanced acoustics
treble & bass

ITEM: AOCURIO
6Specifications
SPECIFICATIONS:
BLUETOOTH VERSION 5.0
BLUETOOTH FREQUENCY 2.402-2.480GHz
FREQUENCY RESPONSE 20Hz - 20KHz
DRIVER UNIT 40mm
BATTERY 300mAh built-in Li-ion
Polymer battery
WORKING TIME Up to 20 hours
CHARGING TIME 2hours
IMPEDANCE 32Ω
OPERATION RANGE 10m
NOTE:
working time depends on volume levels
- lower volume will prolong your estimated battery life.
- higher volume will decrease your estimated battery life.

CURIO WIRELESS HEADPHONES
7Troubleshooting
TROUBLESHOOTING:
NO POWER Recharge your Headphones using
the included micro USB cable.
MUSIC IS NOT PLAYING OVER
BLUETOOTH
Make sure your Bluetooth device
has A2DP profile. Check if both de-
vices are paired and connected over
Bluetooth. Restart the Headphones
to reconnect your Bluetooth device.
BLUETOOTH DEVICE WILL
NOT RECONNECT WITH THE
HEADPHONES
Navigate to your Bluetooth settings
menu on your Bluetooh device, tap
"audeeo Curio" and select "Forget".
Now follow the steps to pair your
device again.

ITEM: AOCURIO
8Care & Maintenance
• DO NOT expose the unit to liquid, moisture, or humidity to avoid
damage to the product’s internal circuitry.
• DO NOT use abrasive cleaning solvents to clean the unit.
• DO NOT expose the unit to extremely high or low temperatures as
this will shorten the life of the electronic device, destroy the battery,
and/or distort certain plastic parts.
• DO NOT dispose of the unit in fire as they may explode or combust.
• DO NOT expose the unit to and/or use sharp objects on the Head-
phones as this will cause scratches and damage.
• DO NOT attempt to disassemble the unit. In the event that the unit
does not function properly, return it to the store where it was purchased.

CURIO WIRELESS HEADPHONES
9Warranty & Legal
The condition of this warranty and our responsibilities under this warranty are as follows:
Supplier’s warranty is non-transferable. This warranty is limited to the original purchaser only.
• You must be able to prove the date of original purchase of the unit with a dated receipt.
• The warranty is not applicable if the product has been subject to physical abuse, improper
installation, modification or repair by unauthorized third party.
• The responsibility of supplier’s products shall be limited to the repair or replacement of the
product as its sole discretion.
• Specifically exempt from any warranty are limited-life consumable components subject to
normal wear and tear such as batteries, decorates and other accessories.
• A supplier will not take any responsibility if the failure of the unit has resulted from accident,
abuse, misuse, or any unauthorized repair, modification or disassemble.
• Modification and repair of the unit should be done by authorized and qualified service
personnel, Center or returned to the manufacturer.
• This warranty give you specific legal rights, and you may also have other rights which vary
under local laws.
This appliance should not be put into the domestic garbage at the end of its
useful life, but must be disposed of at a central point for recycling of electric and
electronic domestic appliances.
The Bluetooth® word mark and logos are registered trademarks owned by Blue-
tooth SIG, Inc. and any use of such marks by Audeeo Innovations Ltd. is under
license. Other trademarks and trade names are those of their respective owners.
This symbol on appliance, instruction manual and packaging puts your attention
to this important issue. The materials used in this appliance can be recycled. By
recycling used domestic appliances you contribute an important push to the pro-
tection of our environment. Ask your local authorities for information regarding
the point of recollection.
Siri® is a trademark of Apple Inc., registered in the U.S. and other countries.
Google Assistant™ is a trademark of Google Inc.

Manufactured & Distributed by:
Audeeo Innovations Ltd., Chartwell House,
292-294 Hale Lane, London, UK, HA8 8NPHA8 8NP
audeeo™ is a registered trademark of Audeeo Innovations Ltd.
MADE IN CHINA
