audeeo AOJAVE User manual

ITEM: AOJAVE
QUICK START + INSTRUCTION GUIDE

Welcome to audeeo
Thank you for choosing this product. We are striving for
excellence in both aesthetics and acoustics. But we could not
do this without you. Let's take sound to new heights together.

JAVELIN
WIRELESS
EARPHONES

1Welcome
1.1 What's In The Box
2Your Javelin Wireless Earphones
2.1 Geing To Know Your Earphones
2.2 Control Panel Features
3Quick Start Guide
3.1 Charging & Powering ON
3.2 Bluetooth Pairing
4 Buon Functions
5 All Features & Contents
6Specifications
7Troubleshooting
8Care &Maintenance
9Warranty & Legal

JAVELIN WIRELESS EARPHONES
1Welcome
1.1 What's In The Box
GUIDE BOOKLET
MICRO USB CABLE
EARPHONES

ITEM: AOJAVE
2Your Javelin Wireless Earphones
2.1 Geing To Know Your Earphones
A
C
B
D
E
B
D
E
A
C
PERFECT FIT
METAL FINISH
MICROPHONE
FLAT CORD
CONTROL PANEL
ear tips that are
designed for all inner
ears types
Outer alloy for extra
durability
Answer calls
hands-free
Tangle free cable
This is the main area that controls
both microphone functions, volume,
and tracks

JAVELIN WIRELESS EARPHONES
2Your Javelin Wireless Earphones
2.2 Control Panel Features
A
B
C
D
E
C
D
A
B
E
MICRO USB CHARGING PORT
LED INDICATOR LIGHT
VOLUME (+)/ NEXT TRACK
POWER/MODE /PHONE BUTTON
VOLUME (–) / PREVIOUS TRACK
This is the area to plug-in and charge
your earphones
Indicates if the earphones are ON / OFF,
pairing, or charging.
This buon skips to the next track, and
increases volume.
This buon will do the following
- Power on & off
- Pause & play music
- Answer & hand up calls
- Reject calls
- Use of smartphone assistant:
• Google Assistant™
• Siri®
This buon goes to the previous track,
and decrease volume..

ITEM: AOJAVE
3Quick Start Guide
3.1 Charging & Powering ON
Connect the Micro USB cable (only use the provided cable) to a
computer USB port or a USB wall charger. Plug the other end of the
micro USB cable into the Micro USB charging port (C) located on the
left side of the microphone. While charging the LED indicator light (E)
will turn RED and then turn BLUE when the baery is fully charged.
Ensure the earphones are turned off, then press and hold the Power/
Mode/ Phone buon(C) for 3-5 seconds to turn the earphones ON.
The earphones will enter Bluetooth pairing mode automatically and
emit a tone as the LED indicator light (A) will flash BLUE and RED.
NOTE: please refer to the diagram on 2.2
1 21
1
2
3-5s

BLUETOOTH
audeeo Javelin
JAVELIN WIRELESS EARPHONES
3Quick Start Guide
3.2 Bluetooth Pairing
NOTE: pleas e refer to the diagram on 2.2
BLUETOOTH
audeeoJavelin
3
1
1
2
3
2
Ensure the earphones are turned off, then press and hold the Power/
Mode/ Phone buon (B) for 3-5 seconds to turn the earphones ON.
The earphones will enter Bluetooth pairing mode automatically and
emit a tone as the LED indicator light (E) will flash BLUE and RED. Make
sure your device has Bluetooth enabled
Ensure Bluetooth is enabled on your smartphone or music device. Your
device will start searching for wireless devices. The earphones will appear
as “audeeo Javelin” in the list of available Bluetooth devices.
Select “audeeo Javelin” The LED will begin to slowly blink blue, and the
earphones will emit a tone to indicate that is has been successfully paired
with your device.
3-5s

4Buon Functions
ANSWER & HANG UP CALLS
When there is an incoming call, short press the Pause/Play/Phone Buon
(B) to answer the call, press the Pause/Play/Phone Buon (B) once again to
hang up the call.
REJECT CALLS
When there is an incoming call, long press the Pause/Play/Phone Buon (B)
for 2-3 seconds to reject the call.
PAUSE & PLAY MUSIC
When music is playing, press the Pause/Play/Phone Buon (D) once to pause
music, press the buon once again to play music.
NEXT & LAST TRACK
When playing music, press the Volume (+) / Next Track buon (A) once to skip
to the next track, press the Volume (–) / Previous Track buon (D) once to skip
to the previous track.
VOLUME UP & DOWN
When in a call or playing music, hold the Volume (+) / Next Track buon (A)
to increase the volume, hold the Volume (–) / Previous Track buon (D) to
decrease the volume.
SMARTPHONE ASSISTANT
Double press the Pause/Play/Phone Buon (B) to activate voice assistant
(Google Assistant™ or Siri®) on your smartphone.
NOTE: please refer to the diagram on 2.2
1
2
3
4
5
6

JAVELIN WIRELESS EARPHONES
5All Features & Contents
RECHARGEABLE:
BUILT-IN MIC: BETTER AUDIO:
VOICE ASSISTANT
ACTIVATED & READY
METAL FINISH:
lithium ion baery with
extended listening time
hands-free talking
with volume control enhanced acoustics treble & bass
Works with your phone’s
digital assistant
aluminum alloy finish
extremely durable
CONTENTS:
• JAVELIN EARPHONES
• MICRO USB CHARGING CABLE
• MANUAL
MULTI DEVICE:
will work with any
Bluetooth® device
• mobile phones
• computers
• tablets

ITEM: AOJAVE
6Specifications
SPECIFICATIONS:
FREQUENCY RESPONSE 20Hz - 20kHz
DRIVER UNIT 10mm
BATTERY 75mAh Lithium Ion
WORKING TIME Up to 5+ hours
CHARGING TIME 1-2 hours
IMPEDANCE 32Ω
OPERATION RANGE 10m
NOTE:
workingtimedependsonvolumelevels
- lower volumewill prolongyour estimated baery life.
-highervolume willdecreaseyourestimated baerylife.

JAVELIN WIRELESS EARPHONES
7Troubleshooting
TROUBLESHOOTING:
NO POWER Recharge your Earphones using the
included micro USB cable.
MUSIC IS NOT PLAYING OVER BLUETOOTH
Make sure your Bluetooth device has
A2DP profile. Check if both devices are
paired and connected over Bluetooth.
Restart the Earphones to reconnect
your Bluetooth device.
BLUETOOTH DEVICE WILL NOT RECONNECT
WITH THE EARPHONES
Navigate to your Bluetooth seings
menu on your Bluetooh device, tap
"audeeo Javelin" and select "Forget".
Now follow the steps to pair your
device again.

ITEM: AOJAVE
8Care & Maintenance
• DO NOT expose the unit to liquid, moisture, or humidity to avoid damage to the
product’s internal circuitry.
• DO NOT use abrasive cleaning solvents to clean the unit.
• DO NOT expose the unit to extremely high or low temperatures as this will shorten the
life of the electronic device, destroy the baery, and/or distort certain plastic parts.
• DO NOT dispose of the unit in fire as they may explode or combust.
• DO NOT expose the unit to and/or use sharp objects on the Earphones as this will
cause scratches and damage.
• DO NOT aempt to disassemble the unit. In the event that the unit does not function
properly, return it to the store where it was purchased.

JAVELIN WIRELESS EARPHONES
9Warranty & Legal
Thecondition of this warranty and our responsibilitiesunder thiswarrantyare as follows:
Supplier’s warrantyisnon-transferable.This warranty is limitedtothe originalpurchaseronly.
•You must be able to provethe dateof original purchase of the unit withadatedreceipt.
• The warranty is notapplicable if theproduct has been subjectto physical abuse, improperinstallation, modification or
repairby unauthorized thirdparty.
•The responsibilityof supplier’sproducts shall be limitedtothe repair or replacement of the product as its sole discretion.
• Specificallyexempt from any warranty arelimited-life consumablecomponents subjectto normal wearand tearsuch as
baeries,decoratesandotheraccessories.
• A supplierwill not take anyresponsibility ifthe failure ofthe unit has resultedfrom accident, abuse, misuse,or any
unauthorizedrepair, modification or disassemble.
• Modificationand repair ofthe unit should be done byauthorized andqualified service personnel,Center orreturned
tothe manufacturer.
•This warrantygiveyouspecific legal rights, and you may also haveother rightswhich vary under local laws.
This appliance shouldnot be putinto the domestic garbage atthe end ofits useful life, but must be
disposedof at a centralpoint for recyclingof electricand electronicdomesticappliances.
The Bluetooth® wordmark and logosare registered trademarksowned byBluetooth SIG, Inc.and any
use of suchmarks by iHipEurope Ltd is underlicense. Other trademarksand trade namesare those
oftheir respectiveowners.
This symbolon appliance, instructionmanual and packagingputs youraention tothis important
issue. Thematerials usedin this appliance canbe recycled. By recycling useddomestic appliances
you contribute an important push to the protection ofour environment. Askyour localauthorities for
informationregardingthe pointof recollection.
Siri®is a trademark of Apple Inc., registeredin the U.S. and other countries.
GoogleAssistant is a trademark of Google Inc.

Manufactured & Distributed by:
iHip Europe Ltd., Chartwell House,
292-294 Hale Lane, London, UK, HA8 8NP
audeeo™ is a registered trademark of iHip Europe Ltd.
MADE IN CHINA
