Audicus Bluetooth Remote User manual

Instruction Manual
Bluetooth Remote
2013 Audicus Inc, All Rights Reserved

Instruction Manual
Bluetooth Remote
2013 Audicus Inc, All Rights Reserved

1

Thank you for choosing Audicus!
We are excited that you’re taking advantage of what our
hearing aids can offer.
Your Bluetooth Remote will enhance the way you interact
with your surroundings and improve your quality of life.
If you have any questions, feel free to contact us at
888 979 6918 or [email protected].
2

Welcome
Introduction 4
Remote Control Overview 5
Transmitter Overview 6
Charging the Remote 7
Volume and Programs 8
Bluetooth Programs 9
Cellphone Pairing 10
iPhone/iPad Pairing 11
Android Cellphone Pairing 12
Content
Making / Receiving Calls 13
Using the Bluetooth Remote 14
Transmitter and TV 15
Bluetooth Integrations 16
Trouble Shooting 17
3

4
1. Remote Controller
2. Transmitter
3. Power Plugs + Traveler Set
4. Cables and Analog Adapter*
1
3 4
*for TV, HiFi, Transmitter, etc.
2
Inside the Mini-Media Box You Will Find…

5
Remote Control
Cellphone Button Bluetooth Scanner
Program Button Volume Buttons
Remote
Power
ON/OFF
Button
Mute
Microphone

Transmitter
6
Audio Input
LED light
(blinking=connecting;
stable=connected)
Transmitter volume
On/Off Switch

Bluetooth Remote
1. Charge the remote for at least 5
hours before initial use.
2. LED light shines solid green
when fully charged.
Transmitter
1. Charge the Transmitter for at
least 5 hours before first use.
2. LED shines red while charging.
3. When the Transmitter is turned
ON, the LED shines blue.
4. LED will flash blue when it’s
searching for a connection with
the Bluetooth remote.
5. LED will be solid blue when
connected to Bluetooth Remote.
Charging the Bluetooth Remote
and Transmitter
7
Fully charged Needs to be charged
Remote OFF
Remote ON
Charging, but
OFF
Charging, but ON
Turning OFF
Turning ON

Volume and Programs (NO Bluetooth)
Your hearing aid is equipped with 4 acoustic programs. If NO remote is paired with
the aid, these programs are as follows:
8
WITHOUT Bluetooth Remote
Program 1
Program 2
Program 3
Program 4
Automatic/Universal
Automatic/Universal + More Volume
Automatic/Universal + Less Volume
Conversations in background noise
You can also change the volume by pressing the “+” or “-” buttons on the Remote
Increase volume
Decrease volume
Acoustic
Programs

Programs (WITH Bluetooth)
9
When the Bluetooth Remote is paired with the hearing aid, you have two acoustic
programs available, in addition to 3 Bluetooth Programs.
When no Bluetooth sources are available, you will only hear 2 programs (1 beep &
5 beeps) when pressing the Program Button: Program 1 and Program 5. Please refer
to the diagram below.
WITH Bluetooth Remote
Program 1
Program 2
Program 3
Program 4
Automatic/Universal
Bluetooth Phone(for cellphones)
Music via Bluetooth/Induction Loop (for mp3, tablets, etc.)
Transmitter (for TV or any non-Bluetooth devices)
Program 5 Speech in noise
Acoustic
Bluetooth
Note: When in a Bluetooth Program, the external device must be connected, otherwise the
remote will not detect them. For example, if your cellphone is not operating, Program 2 will not
be an available program.

10
Please note that you can pair your Bluetooth Remote with your cellphone. The remote relays
information to the hearing aid. Your cellphone must have Bluetooth enabled to successfully pair
with the remote.
1. Remote must be charged at least 5 hours before use. Charger is included with package.
2. Turn on your cellphone’s Bluetooth.
3. Scan for devices.
4. Hold the Telephone button on the remote for 2 seconds; this makes the remote discoverable.
5. RCU Connect should appear on your phone. Select RCU Connect to attempt to connect.
6. Once successful, your cellphone will display “Connected” (note: varies with phone).
7. Pairing does not have to be done more than once on the same phone.
Cellphone Pairing

11
iPhone/iPad Cellphone Pairing
Pairing your iPhone/iPod (for iOS 6.9 and earlier)
1. Be sure to charge Bluetooth remote before use
2. Find the Settings icon; tap it
3. Tap the Bluetooth category, then slide the icon dial to the right
4. Hold the Phone Button on the remote for TWO seconds to make it discoverable
5. The “RCU Connect” should appear under Devices
6. Tap “RCU Connect” to pair

12
Android Cellphone Pairing
Pairing your Android Device
1. Be sure to charge Bluetooth remote before use
2. Find the Wireless Settings icon on your phone; tap it
3. Tap the Bluetooth category, then slide the icon dial to the right
4. Hold the Phone Button on the remote for TWO seconds to make it discoverable
5. The “RCU Connect” should appear after you tap Search for devices
6. Tap “RCU Connect” to pair

Making / Receiving Calls
Once your cellphone and remote have been paired, you can easily receive calls.
When your phone rings, you can press the phone button on the top left to listen to
the conversations through your hearing aids. Your remote will work as the
microphone. You can end the call by pressing the same phone button on the
remote. To reject calls, hold phone button for three seconds.
If you are on your cellphone already, you can easily route the call to your hearing
aids by pressing the Bluetooth Scanner Button (top right).
13
Bluetooth Scanner
Button

Phone Calls
The Bluetooth Remote operates within short distances. For best performance, keep
the remote within 2 feet. Use the lanyard or clip to fix the aid onto your upper body or
place it in your pocket.
Your hearing aid needs to be close to the remote control, primarily for phone calls.
The remote also has a microphone that picks up your voice during a phone call.
Listening to music/sounds via external devices
The same rule applies to devices like the iPad, iPod, and tablets; the remote has to
be close to the hearing aids.
Using the Bluetooth Remote During Calls
14

15
NOTE: Be sure to charge your transmitter at least 2 hours before use.
How to connect the Transmitter to TV
1 2
1. Locate the composite cables in the box received.
2. In the rear of your TV, locate the AUDIO OUT area and connect the composite cables.
3. Connect the female end of the composite cable to the stereo cable.
4. Insert the other male end of the stereo cable into the Audio Input of the Transmitter
5. Use the Bluetooth Scanner Button (top right button) on remote to detect transmitter. Once it
connects, the LED light on transmitter should be stable. Blinking indicates its attempting to pair.
6. See diagram on next page to see the options for more Bluetooth integrations.
3 4 5
Input

Bluetooth Integrations with Transmitter
16
Your aBlue can integrate with many devices. The transmitter allows you to connect any
non-Bluetooth devices with your hearing aid. Use the diagram below to see what
options you have for integrations. If you have questions, contact Audicus for more help.
Non- Transmitter Transmitter

Issue
Possible Cause
Action
I only hear two
beeps when I
press the
program button
•
You have not paired your remote control
with any Bluetooth compatible devices
•
Cellphone is not paired

Pair devices. To make remote
discoverable, hold the Phone Button for
two seconds

Pair your phone with the remote
Remote
control
does not respond
•
Remote is not charged

Connect the remote to the adapter; it is
found inside the original packaging
Can
not hear well
•
Not using volume control

Press “+” button to increase volume or
press “-” to decrease volume
Trouble Shooting
17

Contact Us
18
Audicus, Inc
50 Harrison Street, PH #403
Hoboken, NJ 07030
USA
Tel: [phone]
Email: [e-mail]
www.audicus.com
