SCALE IS 5 DECIBELS PER DIVISION
Polar Pattern
200 Hz
LEGEND
3 kHz
1 kHz
8 kHz
240
180
210
270
300
330
0
150
120
90
30
60
12" or more on axis
100
50 200
LEGEND
Roll-off
10k
5k
1k
500 2k 20k
Frequency in Hertz
Frequency Response
Response in dB
10 dB
• Maximum intelligibility and clean, accurate reproduction for
lecturers, stage and television talent, and worship leaders
•Low-profile design (a mere 5 mm in diameter) is ideal for
applications requiring minimum visibility
• Includes an extensive array of accessories
• Switchable low-frequency roll-off reduces sensitivity to popping
in close vocal use
• Operates on battery or phantom power
The AT898 is designed to be worn as a lavalier or hidden in loose
clothing. For use as a lavalier, attach the microphone about six
inches below the chin. Anticipate movements that may cause the
microphone to rub against or be covered by clothing, and position
the microphone to avoid it.
The included single and double mic holders are interchangeable
with all the bases. To change the holders, simply remove original
holder and snap in the desired one. When using the AT898
in extremely close situations, slip the included open-pore foam
windscreen over the mic to reduce wind noise or “popping.”
CAUTION! To avoid possible injury, use caution when affixing the
AT898 viper clip to clothing. The pins are sharp and may puncture
skin. For best results, ensure that pin ends rest on outside of
clothing.
The AT898 requires 11-52V DC phantom power, or a 1.5V AA
battery for operation. A battery need not be in place for phantom
power operation.
Battery installation: Unscrew the base of the power supply unit and
insert one AA battery into the battery compartment, being certain to
observe battery polarity as marked. Then simply screw the base
shut. Alkaline batteries are recommended for longest life. Remove
the battery during long-term storage.
Output from the power module’s XLRM-type connector is low
impedance (Lo-Z) balanced. The signal appears across Pins 2 and
3; Pin 1 is ground (shield). Output phase is “Pin 2 hot” – positive
acoustic pressure produces positive voltage at Pin 2.
Avoid leaving the microphone in the open sun or in areas where
temperatures exceed 110°F (43° C) for extended periods.
Extremely high humidity should also be avoided.
Audio-Technica U.S., Inc., 1221 Commerce Drive, Stow, Ohio 44224
Audio-
Technica Limited, Old Lane, Leeds LS11 8AG England
www.audio-technica.com
P51642-EN ©2004 Audio-Technica U.S., Inc. Printed in Japan
AT898 SUBMINIATURE CARDIOID CONDENSER MICROPHONE
AT898 SPECIFICATIONS†
ELEMENT Fixed-charge back plate
permanently polarized
condenser
POLAR PATTERN Cardioid
FREQUENCY RESPONSE 200-15,000 Hz
LOW FREQUENCY ROLL-OFF 80 Hz, 12 dB/octave
OPEN CIRCUIT SENSITIVITY –43 dB (7.0 mV) /
(Phantom / Battery) –46 dB (5.0 mV) re 1V at 1 Pa*
IMPEDANCE (Phantom / Battery) 200 ohms / 250 ohms
MAXIMUM INPUT SOUND LEVEL 131 dB / 115 dB SPL,
(Phantom / Battery) 1 kHz at 1% T.H.D.
DYNAMIC RANGE (typical) 100 dB / 84 dB,
(Phantom / Battery) 1 kHz at Max SPL
SIGNAL-TO-NOISE RATIO163 dB, 1 kHz at 1 Pa*
PHANTOM POWER 11-52V DC, 2 mA typical
REQUIREMENTS
BATTERY TYPE 1.5V AA/UM3
BATTERY CURRENT / LIFE 2.0 mA / 1200 hours typical
(alkaline)
SWITCH Flat, roll-off (recessed)
WEIGHT (less cable and accessories)
MICROPHONE 0.03 oz (0.9 g)
POWER MODULE 3.6 oz (102 g)
DIMENSIONS
MICROPHONE 0.91" (23.0 mm) long,
0.21" (5.3 mm) diameter
POWER MODULE 5.71" (145.0 mm) long,
0.83" (21.0 mm) diameter
OUTPUT CONNECTOR Integral 3-pin XLRM-type
(power module)
CABLE 9.8' (3.0 m) long (permanently
attached to microphone), 0.08"
(2.0 mm) diameter, 2-conductor,
shielded cable with TA3F output
connector that mates with TB3M
jack on power module
ACCESSORIES FURNISHED AT8537 power module; AT8439
cable clip; clothing clip base;
viper clip base; magnet clip
base and plate with lanyard;
three single mic holders;
two double mic holders;
two windscreens; battery;
protective carrying case
†In the interest of standards development, A.T
.U.S. offers full details on its test
methods to other industry professionals on request.
*1 Pascal = 10 dynes/cm 2= 10 microbars = 94 dB SPL
1T
ypical, A-weighted, using Audio Precision System One.
Specifications are subject to change without notice.
