Audio Technica ATW-F948 User manual

CAUTIONS
●Effectivelycutsunwantedradiowavesformobilephones,etc.andsupportsstableoperationof
awirelesssystem
●Compactandlightweightbodyinstallableanywhere
●Passivemoduleneedingnoexternalpowersource
●Connectabletoallwirelesssystems,regardlessofmanufacturer
●Passespowerthroughtoactiveantennas
Thankyouforpurchasingthisantennafilter.Beforeusingthe
antennafilter,pleasereadthroughtheseoperatinginstructionsto
ensurethatyouwillusetheantennafiltercorrectly.Also,besure
tostoretheoperatinginstructionstogetherwiththewarrantyina
safeplaceforfuturereference.
ATW-F948
946-950MHzBand
DedicatedAntennaFilter(2pcsasoneset)
Warnings
●Donotdisassembleormodifytheantennafilter.
Failuretoobservethisprecautioncouldcauseinjuryduetoelectricshockoraccidentalfire.
●Donotsubjectthedevicetostrongimpact.
Failuretoobservethisprecautioncouldcauseinjuryduetoelectricshockoraccidentalfire.
●Donottouchthedevicewithwethands.
Doingsomightcauseinjuryduetoelectricshock.
●Donotsplashwithwater.
Failuretoobservethisprecautioncouldcauseinjuryduetoelectricshockoraccidentalfire.
●Donotallowflammableitems,metalobjects,liquidorotherforeignmattertogetinsidetheantennafilter.
Failuretoobservethisprecautioncouldcauseinjuryduetoelectricshockoraccidentalfire.
●Donotcoverthedevicewithcloth.
Doingsomightcauseanaccidentalfireduetooverheating.
●Keeptheplasticbagsprovidedwiththeproductoutofreachofsmallchildrenandawayfromflames.
Failuretoobservethisprecautioncouldcauseanaccidentorfire.
●Donotplacethedeviceonunstablesurface.
Theproductmayoverturnandcauseinjuryorbecomedamaged.
●Donotplacethedeviceindirectsunlight,nearheatingapparatusorinhot,humidordustyplaces.
Itmaycauseproductfailureormalfunction.
●Keepantennafilterawayfromfire.
Exposuretofiremightdeformorotherwisedamagetheantennafilter.
●Donotuseanychemicalsuchasthinner,benzeneorcontactprotectionagent.
Doingsomightdeformorotherwisedamagetheantennafilterorotherconnecteddevices.
Caution
●Topreventpossibledamagetothefilter,donotexceed400mAofinputcurrent.
Instructions
Features

Receiver
ATW-R6200
Antenna
ATW-F948
IN
OUT
■Connectionexamples
Booster
Frequencyrange 946-950MHz
Impedance 50Ω
Highfrequencypassageloss  3dB
Maximuminputlevel +10dBm
Connector BNC- J(IN)BNC - P(OUT)
Permissibleambienttemperature-10°Cto+60°C
Recommendedambienttemperature +15°Cto+35°C
Outerdimensions φ15×60mm
Weight Approx.28g
1. ConnecttheantennatotheINsideconnectorofthisproductwithacoaxialcable.
2. ConnecttheOUTsideconnectorofthisproducttoareceiver(ATW-R6200)oraboostercompatible
withthe946-950MHzband,directlyorwithacoaxialcable.
（Specificationsandproductdetailsaresubjecttochangewithoutnotice.）
ANT BANT A
RECEIVER
2
GROUND
LIFT
GROUND
NETWORK
INTERFACE
RECEIVER
1
BALANCED
OUTPUT
BALANCED
OUTPUT
GROUND
LIFT
GROUND
NETWORK
INTERFACE
12V
60mA
12V
60mA
WARNING :
THIS APPARATUS
MUST BE EARTHED.
AC IN POWER
Connections
Specifications
Forfurtherinformationonproductwarrantyandrepairservice,please
contactthedealerwhereyouboughttheproductorvisitourhomepage.
http://www.audio-technica.com/
