4. Configuring VoIP Parameters
Before you can make VoIP calls, you need to register with an
Internet Telephony Service Provider (ITSP) and obtain account
and SIP Proxy server information
1. From the menu pane, click Voice Over IP; the 'Voice
Over IP' page appears in the right pane.
2. Click the Line Settings tab, mark check boxes of lines
that are connected to telephones (clear those not
connected), and then click Apply.
3. Click the Edit icon corresponding to the telephone
lines, and then in the 'Line Settings' page, configure the
parameters with values provided by your ISP.
4. Click the Signaling Protocol tab, and then select the 'Use
SIP Proxy' check box. In the 'Proxy IP Address or Host
Name' field, enter the ITSP's proxy server IP address or
host name. Click OK to complete the VoIP configuration.
To verify successful registration with
server, ensure that the Phone
the Voice over IP tab (System Monitoring menu), the
entry 'SIP Registration' displays "Registered"
configured lines.
5. Pick up the phone receiver (or handset) and listen for a
dial tone; you're now ready to make a VoIP call.
3. Configuring Network Parameters
1. Open a Web browser, and then enter the following URL
address to access the gateway's embedded Web server
graphical user interface: http://mp262.home
2. Select the Web GUI display language and click Continue.
3. Define a new login username / password and click OK.
4. In the 'Quick Setup' page, select and define the Internet
connection type as instructed by your ITSP, and then
click OK. You are now connected to the Internet and can
proceed to configure VoIP parameters for
making and receiving voice-over-IP calls.
If there is no Internet connection, the Web GUI's
Map View page (Home) displays a red icon after
the globe icon. Consult your ITSP for valid connection
The gateway's default wireless (Wi-Fi) network name
(SSID) comprises product name followed by "_" and
the six last characters of the MAC address in capital
letters (secured). For example, if the MAC address is
00:90:8F:2C:64:70, the SSID will be MP262_2C6470
The password is 0<serial number without first two
characters>. For example, if the SN is VT1234567, the
password will be 01234567. The SN is printed on the
rear of the MP-262.
