FieldServer
FS-8700-130 Notifier NCA2-NFS2-3030
Driver Manual
(Supplement to the FieldServer Instruction Manual)
APPLICABILITY & EFFECTIVITY
Effective for all systems manufactured after March 2015

FS-8700-130 Notifier NCA2-NFS2-3030 Manual
Contact Information
Contact Information:
Thank you for purchasing the FieldServer.
Please call us for Technical support of the FieldServer product.
Contact Information:
Sierra Monitor Corporation
1991 Tarob Court
Milpitas, CA 95035
Contact number:
[phone]
[phone]
Email: [e-mail]
Website: www.sierramonitor.com

FS-8700-130 Notifier NCA2-NFS2-3030 Manual
Table of Contents
TABLE OF CONTENTS
Notifier NCA2/NFS2-3030 Description...............................................................................................41
Driver Scope of Supply .......................................................................................................................422.1 Supplied by FieldServer Technologies for this driver.....................................................................4
Hardware Connections........................................................................................................................533.1 Hardware Connection Tips / Hints..................................................................................................6
Data Array Parameters........................................................................................................................74
Configuring the FieldServer as a Notifier NCA2/NFS2-3030 Client ................................................855.1 Panel Status - Memory Mapping ....................................................................................................8
5.2 Client Side Connection Parameters .............................................................................................10
5.3 Client Side Node Parameters.......................................................................................................11
5.4 Client Side Map Descriptor Parameters.......................................................................................12
5.4.1 FieldServer Related Map Descriptor Parameters .................................................................12
5.4.2 Driver Related Map Descriptor Parameters ..........................................................................12
5.4.3 Map Descriptor Example: Standard example........................................................................13
Configuring the FieldServer as a Notifier NCA2/NFS2-3030 Server.............................................146
Appendix A. Useful Information ..............................................................................................................15
Appendix A.1. Node Status .....................................................................................................................15
Appendix A.2. FieldServer Synchronization............................................................................................15
Appendix A.3. Driver Limitations and Exclusions....................................................................................15
Appendix B. Troubleshooting..................................................................................................................16
Appendix B.1. Connection Tips & Hints ..................................................................................................16
Appendix B.2. Networking Tips...............................................................................................................16
Appendix C. Reference.............................................................................................................................17
Appendix C.1. Notifier NCA2/NFS2-3030 Message Types Recognized.................................................17
Appendix C.2. System Trouble Messages..............................................................................................18
Appendix C.3. Error Messages ...............................................................................................................22
LIST OF FIGURES
Figure 1 - Connection Diagram .............................................................................................................................5

FS-8700-130 Notifier NCA2-NFS2-3030 Manual
Page 4 of 23
NOTIFIER NCA2/NFS2-3030 DESCRIPTION1
The NCA2/NFS2-3030 Serial driver allows the FieldServer to record data from Notifier NCA2 or NFS2-
3030 panels over RS-232 as per NFS2-3030/NCA-2 EIA-232 Protocol & Data Formats 53219 Rev A
1/3/2008. There is no active polling by this driver; the communications are one-way through the panel's
printer or CRT port. The FieldServer acts as a Client; receives messages and records the status of a
Panel. The panel MUST output messages in160 characters ASCII format in English.
This driver is not capable of emulating a Notifier NCA2 or NFS2-3030 panel.
The NCA2 controls all the devices (e.g. 3030, 640 panels) connected on the Notifier network. Each Fire
Alarm Panel on Network is considered as a Node. 240 Nodes can exist on one network. NFS2-3030 can
exist on a network or be self-standing.
NCA2 interacts with other Fire Alarm Panels, records the status of the panels and sends the events to
printer and CRT ports. FieldServer captures these events in text form, parses and stores them in Data
Arrays. These Data Arrays can be monitored by third party tools. Since the FieldServer does not actively
poll for data, the accuracy and timeliness of the stored data is limited to the frequency of update
messages that the Notifier Fire Panel issues.
If a networked panel does not send the 'CLEARED' message for latched points via the NCA2 it is not
possible to detect cleared points unless a system reset is done. It is possible to configure the FieldServer
to clear on reset message from NCA2. See Appendix A.2 for more detail.
Please note that the FieldServer can be configured with a large number of points. The point limits
purchased with the FieldServer prevent the entire database from being accessed in any one application.
It is therefore strongly advisable to ensure that only the point addresses of interest are configured, and
that the FieldServer is purchased with the correct point count.
The types of Notifier messages supported by this driver are summarized in Section 5.1. A detailed table
presented in Appendix C.1 shows each type of NCA2/NFS2-3030 message the FieldServer recognizes
and the effect that it has on the status of the points in the Data Array.
Max Nodes Supported
FieldServer Mode
Nodes
Comments
Client
0
This Driver cannot be used as a Client.
Server
1
Each FieldServer port can connect to only 1 Notifier panel port
DRIVER SCOPE OF SUPPLY2
2.1 Supplied by FieldServer Technologies for this driver
FieldServer Technologies PART #
Description
FS-8917-16
Pigtail cable for RJ45 Port
FS-8700-130
Driver Manual

FS-8700-130 Notifier NCA2-NFS2-3030 Manual
Page 5 of 23
Figure 1 - Connection Diagram
HARDWARE CONNECTIONS3
The FieldServer is connected to the Notifier NCA2/NFS2-3030 Fire Panel as shown in the following
connection drawing.
Configure the Notifier Panel according to manufacturer’s instructions.
FieldServer
FieldServer Part #
8917-16
Pigtail for RJ45
Port
RJ45
Connection to TB5 Printer
Port.
Notifier NCA2/NFS2-3030
Connect to one of the RS-232
Ports on the FieldServer
P1
CTX CRX REFPTX PRX REF
TB5
Printer CRT
Rx (Brown)
Tx (Orange/White)
Com (Blue/White)
18
Connector Pinouts
TB5 CRT
Function
Receive
Reference
Transmit
Pin
CRX
REF
CTX
TB5 Printer
Function
Receive
Reference
Transmit
Pin
PRX
REF
PTX
RJ-45
Function
Transmit
Com
Receive
Pin
8
4
1
Wire Color
Orange/white
Blue/white
Brown

FS-8700-130 Notifier NCA2-NFS2-3030 Manual
Page 6 of 23
3.1 Hardware Connection Tips / Hints
The FieldServer should preferably be connected to the TB5 Printer port. It is theoretically
possible to connect to the TB5 CRT port, but this has not been fully tested.
The Panel’s port must be enabled and set to 80 Columns Not Supervised.

FS-8700-130 Notifier NCA2-NFS2-3030 Manual
Page 7 of 23
DATA ARRAY PARAMETERS4
Data Arrays are “protocol neutral” data buffers for storage of data to be passed between protocols. It is
necessary to declare the data format of each of the Data Arrays to facilitate correct storage of the relevant
data.
Section Title
Data_Arrays
Column Title
Function
Legal Values
Data_Array_Name
Provide name for Data Array
Up to 15 alphanumeric
characters
Data_Array_Format
Provide data format. Each Data Array can only
take on one format.
FLOAT, BIT, UInt16, SInt16,
Byte, Packed_Byte,
Swapped_Byte
Data_Array_Length
Number of Data Objects. Must be larger than the
data storage area required by the Map
Descriptors for the data being placed in this
array.
1-10, 000
Example 1
// Data Arrays
Data_Arrays
Data_Array_Name
, Data_Format
, Data_Array_Length
DA_SYS_N2
, Sint16
, 508
DA_N2L01D
, BIT
, 1749
DA_N2L01D_T
, Sint16
, 159
DA_N2L01M
, BIT
, 1749
DA_N2L01M_T
, Sint16
, 159
DA_N2_PANEL
, BIT
, 1056
DA_N2_PANEL_T
, Sint16
, 96
DA_N2_BELL_T
, Sint16
, 4

FS-8700-130 Notifier NCA2-NFS2-3030 Manual
Page 8 of 23
CONFIGURING THE FIELDSERVER AS A NOTIFIER NCA2/NFS2-30305CLIENT
The configuration file tells the FieldServer about its interfaces, and the routing of data required. In order
to enable the FieldServer for Notifier NCA2/NFS2-3030 communications, the driver independent
FieldServer buffers need to be declared in the “Data Arrays” section, the destination device addresses
need to be declared in the “Client Side Nodes” section, and the required data from Notifier Panels needs
to be mapped in the “Client Side Map Descriptors” section. Details on how to do this can be found below.
Note that in the tables, * indicates an optional parameter, with the bold legal value being the default.
For a detailed discussion on FieldServer configuration, please refer to the FieldServer Configuration
Manual. The information that follows describes how to expand upon the factory defaults provided in the
configuration files included with the FieldServer (See “.csv” sample files provided with the FieldServer).
This section documents and describes the parameters necessary for configuring the FieldServer to
receive information from a Notifier Panel.
5.1 Panel Status - Memory Mapping
The primary purpose of this driver is to record the status of devices connected to the Notifier panel by
interpreting the text messages sent to the printer or CRT port. Not all messages will be interpreted, as
many messages do not directly pertain to device status, or are not currently supported. The following
subset of event messages is recognized:
Active Events:
FIRE ALARM
SECURITY ALARM (LIFE)
LIFE CRITICAL ALARM
MEDICAL EMERGENCY
SECURITY ALARM
CRITICAL PROCESS
SUPERVISORY
TROUBLE/ FAULT
DISABLED
PREALARM
ACTIVE
ON/ OFF
This Driver divides the memory into various types. Each location in each memory type is assigned an
address. It is therefore possible to map an address to a particular offset in a Data Array and make it
accessible for reading by other connected devices. The address structure is provided in Table 1.
Most of these addresses will only contain binary information to represent an active or inactive state.
Where multiple troubles are associated with a single device the addressed register corresponding to that
device will be incremented as a counter for each trouble message and decremented when a trouble is
cleared. These addresses should preferably be stored in SINT16 format in the Data Array.

FS-8700-130 Notifier NCA2-NFS2-3030 Manual
Page 9 of 23
Parameter
Addresses
For each SLC loop per Node
Memory Type : Detector ; Module
Fire Alarm
1 –159
Security Life
160 –318
Life Critical
319 –477
Medical Emergency
478 –636
Security Alarm
637 –795
Critical Process
796 –954
Supervisory
955 - 1113
Disabled
1114 –1272
Prealarm
1273 –1431
Active
1432 –1590
ON/OFF
1591 –1749
Memory Type : Detector_Trouble; Module_Trouble
Troubles/Faults
1 –159
Parameter
Addresses
For each Node
Memory Type : Node_Trouble
Troubles/Faults
1 –508
Memory Type : Panel
Panel (Maximum12 Boards and 8 Panel circuits per Board )
Hardware address memory address
Board 1 panel 1 1
Board 1 panel 2 2
Board 2 panel 1 9
-----
-----
Board 12 panel 8 96
)
Fire Alarm
1 –96
Security Life
97 - 192
Life Critical
193 - 288
Medical Emergency
289 - 384
Security Alarm
385 - 480
Critical Process
481 - 576
Supervisory
577 - 672
Disabled
673 - 768
Prealarm
769 - 864
Active
865 - 960
ON/OFF
961 - 1056
Memory Type : Panel_Trouble
Troubles/Faults
1–96
Memory Type : Bell_Trouble
Troubles/Faults
1-4
Table 1 –Memory Mapping Address Structure.

FS-8700-130 Notifier NCA2-NFS2-3030 Manual
Page 10 of 23
5.2 Client Side Connection Parameters
Section Title
Connections
Column Title
Function
Legal Values
Port
Specify which port the device is connected to
the FieldServer
P1-P81
Protocol
Specify protocol used
nfs2-nca; nca2; nfs2-3030
Baud*
Specify baud rate
CRT Port
4800; 9600; 19200; 38400; 57600;
(Vendor limitation)
Printer Port
9600 (Vendor limitation)
Parity*
Specify parity
None (Vendor limitation)
Data_Bits*
Specify data bits
8(Vendor limitation)
Stop_Bits*
Specify stop bits
1(Vendor limitation)
Example
// Client Side Connections
Connections
Port
, Protocol
, Baud
, Stop_Bits
, Parity
P8
, nfs2-nca
, 9600
, 1
, None
1
Not all ports shown are necessarily supported by the hardware. Consult the appropriate Instruction manual for details of the ports
available on specific hardware.

FS-8700-130 Notifier NCA2-NFS2-3030 Manual
Page 11 of 23
5.3 Client Side Node Parameters
Section Title
Nodes
Column Title
Function
Legal Values
Node_Name
Provide name for Node
Up to 32 alphanumeric characters
Node_ID
Station address of any physical
Node on network
1-240. Set unique Id for standalone
Notifer-3030 Panel
Protocol
Specify protocol used
nfs2-nca or nca2 ; nfs2-3030
Port
Specify which port the device is
connected to the FieldServer
P1-P8
Node_Inactivity_Timeout*
Used to monitor the connection to
the panel for inactivity. Should
there be no response from the
panel for the set number of
seconds, the FieldServer will mark
the node offline.2
-, 1-Any value in seconds
(Use a timeout value greater than
how often the panel will issue a query
poll.)
Example
// Client Side Nodes
Nodes
Node_Name
, Node_ID
, Protocol
, Port
, Node_Inactivity_Timeout
Panel_1
, 2
, nfs2-nca
,P8
, 15
2
The Notifier Panel must be configured to supervise the port on which the FieldServer is connected. Only use when port
supervision is enabled on the panel.

FS-8700-130 Notifier NCA2-NFS2-3030 Manual
Page 12 of 23
5.4 Client Side Map Descriptor Parameters
5.4.1 FieldServer Related Map Descriptor Parameters
Column Title
Function
Legal Values
Map_Descriptor_Name
Name of this Map Descriptor
Up to 32 alphanumeric characters
Data_Array_Name
Name of Data Array where data is to
be stored in the FieldServer
One of the Data Array names from
Section 4
Data_Array_Offset
Starting location in Data Array
0 to (Data_Array_Length-1) as
specified in Section 4.
Function
Function of Map Descriptor
Passive
5.4.2 Driver Related Map Descriptor Parameters
Column Title
Function
Legal Values
Node_Name
Name of Node to fetch data from
One of the Node names
specified in Section 5.3
Data_Type
Specify memory area type
Detector
Module
Detector_Trouble
Module_Trouble
Panel
Panel_Trouble
Bell_Trouble
Node_Trouble
Address
Starting address of block
As per Data_type
Detector
Module
1-1749
Detector_Trouble
Module_Trouble
1-159 for point troubles
Panel
1-1056 for Panel circuits
Panel_Trouble
1-96 for Panel troubles
Bell_Trouble
1-4 for Bell circuits
Node_Trouble
1-509 for Node troubles
Length
Length of Map Descriptor
Same as address value
Loop*
Specify Loop number. To capture system level
events specify it as 0 or omit this parameter
-, 0-10, 0
Clear_on_Reset*
Specify whether driver should clear Node(s)
memory area upon receipt of “SYSTEM RESET”
message from Panel.
No, Yes
Clear_on_Normal*
Specify whether driver should clear Node(s)
memory area upon receipt of “SYSTEM NORMAL”
message from Panel.
Yes ,No

FS-8700-130 Notifier NCA2-NFS2-3030 Manual
Page 13 of 23
5.4.3 Map Descriptor Example: Standard example
This shows the standard Map Descriptor setup for one Node with 1 loop and all 159 modules and 159 detectors installed. This Node also has all
boards, panel and bell circuits
//
// Client Side Map Descriptor
//
Map_Descriptors
Map_Descriptor_Name
, Data_Array_Name
, Data_Array_Offset
, Function
, Node_Name
, Loop
, Data_Type
, Address
, Length
SMD_N2_Troubles
, DA_SYS_N2
, 0
, Passive
, NODE2
, -
, Node_Trouble
, 1
, 508
SMD_N2_PANEL
, DA_N2_PANEL
, 0
, Passive
, NODE2
, -
, Panel
, 1
, 1056
SMD_N2_PANEL_T
, DA_N2_PANEL_T
, 0
, Passive
, NODE2
, -
, Panel_Trouble
, 1
, 96
SMD_N2_BELL_T
, DA_N2_BELL_T
, 0
, Passive
, NODE2
, -
, Bell_Trouble
, 1
, 4
SMD_N2L01D
, DA_N2L01D
, 0
, Passive
, NODE2
, 1
, Detector
, 1
, 1749
SMD_N2L01D_T
, DA_N2L01D_T
, 0
, Passive
, NODE2
, 1
, Detector_Trouble
, 1
, 159
SMD_N2L01M
, DA_N2L01M
, 0
, Passive
, NODE2
, 1
, Module
, 1
, 1749
SMD_N2L01M_T
, DA_N2L01M_T
, 0
, Passive
, NODE2
, 1
, Module_Trouble
, 1
, 159
Select the array
for data storage
Identify the Loop id for
which this Map
Descriptor will store
data
All Map Descriptors are
Passive; waiting for a
message from the Notifier
panel.
Specify
Data
Type
Specify range,
starting address
and length
For Node, Panel and
Bell mapping, the
Loop parameter is
not applicable
Node
Events
Loop 1
Events

FS-8700-130 Notifier NCA2-NFS2-3030 Manual
Page 14 of 23
CONFIGURING THE FIELDSERVER AS A NOTIFIER NCA2/NFS2-30306SERVER
This driver cannot be configured as a Server.

FS-8700-130 Notifier NCA2-NFS2-3030 Manual
Page 15 of 23
Appendix A. USEFUL INFORMATION
Appendix A.1. Node Status
Data for any particular Node is valid while that Node is online and the system is synchronized.
Integrity of data for any Node will be lost if the Node goes offline or if synchronism between the
FieldServer and the NCA2 Panel is lost.
Node status offline/online (1/0) is stored in the 502nd address. It is important to read the Node
status before reading any information about the Node.
Node status data integrity itself depends upon system synchronization.
Appendix A.2. FieldServer Synchronization
There is currently no method of auto-synchronizing the FieldServer's Data Arrays with the Notifier
NCA2/NFS2-3030 panel because there is no method for polling the panel through the printer or CRT port.
Synchronization of the two devices can be achieved manually pressing the “System Reset” button on the
panel while the FieldServer is connected and running. All current events will be re-sent to the
FieldServer.
Appendix A.3. Driver Limitations and Exclusions
Zone information will not be recorded.
To synchronize the FieldServer with the panel, connect the running FieldServer and press the
“System Reset” button on the panel. All current events will be re-sent to the FieldServer.
The port must be enabled on the unit and set to 80 columns with NO supervision
All data related to non-event driven reports will not be recorded by the FieldServer
This driver was written as a subset of NFS2-3030/NCA-2 EIA-232 Protocol & Data Formats
53219 Rev A 1/3/2008. Any changes or additions by Notifier will not be reflected in this driver
unless specifically revised.
This driver will not record information about zone status that is incorporated with point status
messages.
There can only be one panel connected to any given FieldServer port.
This driver records data as presented to the printer/CRT port by the Notifier panel, and can only
be as accurate as this data.
The driver cannot send messages to the Notifier panel.
Driver will clear any data on “System Normal” only if this data is previously set by driver and is not
yet cleared by “Cleared” message and is configured to Clear_on_Normal. By default
Clear_on_Normal is “yes”.
Driver will clear any Node data on “System RESET” only if this data is previously set by driver
and is not yet cleared by “Cleared” message and is configured to Clear_on_Reset. By default
Clear_on_Reset is “no”.

FS-8700-130 Notifier NCA2-NFS2-3030 Manual
Page 16 of 23
Appendix B. TROUBLESHOOTING
Appendix B.1. Connection Tips & Hints
Communication errors will be experienced if the port is disabled at the panel. Please check the
Notifier Manuals on how to enable the panel port connected to the FieldServer and ensure that it
is set to 80 columns NO supervision.
If connecting the Panel to one of the FieldServer RS-232 ports causes the FieldServer to reboot,
then an Optical Isolator is required to balance ground potential problems.
Appendix B.2. Networking Tips
By default FieldServer does not take any action on receiving a “SYSTEM RESET”. Normally
when a Node initiates “SYSTEM RESET” by pressing the “RESET” button on the Panel, the panel
sends an individual “CLEAR” message for every point, it clears in its memory area. The
FieldServer therefore waits for the “CLEAR” message to clear a specific bit in its memory for a
particular Node or for the “SYSTEM NORMAL” message to clear all bits in its memory for every
Node. Use Clear_on_Reset parameter if required.
It may be advisable to configure the Notifier panel to suppress less important “Supervisory” or
“Trouble” messages which could prevent the generation of “SYSTEM NORMAL” messages.
Consult Notifier for this configuration or recommendation.
Ensure that every Node is working with a printer or HyperTerminal, before calling FieldServer for
Support.

FS-8700-130 Notifier NCA2-NFS2-3030 Manual
Page 17 of 23
Appendix C. REFERENCE
Appendix C.1. Notifier NCA2/NFS2-3030 Message Types Recognized
Event Keyword
Clearing Event
Notes
FIRE ALARM
CLEARED FIRE
ALARM
states: {1,0}
SECURITY
ALARM (LIFE)
CLEARED
SECURITY ALARM
(LIFE)
states: {1,0}
LIFE CRITICAL
ALARM
CLEARED LIFE
CRITICAL ALARM
states: {1,0}
MEDICAL
EMERGENCY
CLEARED
MEDICAL
EMERGENCY
states: {1,0}
SECURITY
ALARM
CLEARED
SECURITY ALARM
states: {1,0}
CRITICAL
PROCESS
CRITICAL
PROCESS
states: {1,0}
SUPERVISORY
CLEARED
SUPERVISORY
states: {1,0}
TROUBLE/
FAULT
CLEARED
TROUBLE/ FAULT
States: [counter}
DISABLED
CLEARED
DISABLED
states: {1,0}
PREALARM
CLEARED
PREALARM
states: {1,0}
ACTIVE
CLEARED ACTIVE
states: {1,0}
ON/ OFF
OFF
states: {1,0}
SYSTEM
NORMAL
Resets all addresses in all memory areas but only if data is
previously set by driver and is not yet cleared by “Cleared”
message and is configured to Clear_on_Normal. By default
Clear_on_Normal is “yes”.
SYSTEM RESET
Resets all addresses in all memory areas for a given Node
but only if data is previously set by driver and is not yet
cleared by “Cleared” message and is configured to
Clear_on_Reset. By default Clear_on_Reset is ‘no’.

FS-8700-130 Notifier NCA2-NFS2-3030 Manual
Page 18 of 23
Appendix C.2. System Trouble Messages
The following table lists the system troubles theoretically recognized by this driver –only a selection have
been tested.
System Trouble
Address
System Trouble
Address
GROUND FAULT LOOP 1
1
STYLE 4 SHORT A L6
255
GROUND FAULT LOOP 2
2
STYLE 4 SHORT B L6
256
GROUND FAULT LOOP 3
3
STYLE 4 SHORT A L7
257
GROUND FAULT LOOP 4
4
STYLE 4 SHORT B L7
258
GROUND FAULT LOOP 5
5
STYLE 4 SHORT A L8
259
GROUND FAULT LOOP 6
6
STYLE 4 SHORT B L8
260
GROUND FAULT LOOP 7
7
STYLE 4 SHORT A L9
261
GROUND FAULT LOOP 8
8
STYLE 4 SHORT B L9
262
GROUND FAULT LOOP 9
9
STYLE 4 SHORT A L10
263
GROUND FAULT LOOP 10
10
STYLE 4 SHORT B L10
264
GROUND FAULT PORT A
11
GENERAL PS FAULT
265
GROUND FAULT PORT B
12
INSTALLATION ERROR OR CPU/AVPS-24 FAULT
266
GROUND FAULT
13
INSTALLATION ERROR OR CPU/AVPS-24 FAULT
267
STYLE 6 NEG LOOP 1
14
INSTALLATION ERROR OR CPU/AVPS-24 FAULT
268
STYLE 6 NEG LOOP 2
15
EARTH FAULT DETECTED IN WIRING OR SYSTE
269
STYLE 6 NEG LOOP 3
16
EARTH FAULT DETECTED IN WIRING OR SYSTE
270
STYLE 6 NEG LOOP 4
17
EARTH FAULT DETECTED IN WIRING OR SYSTE
271
STYLE 6 NEG LOOP 5
18
COMM FAULT LOOP INTERFACE BOARD 1
272
STYLE 6 NEG LOOP 6
19
COMM FAULT LOOP INTERFACE BOARD 2
273
STYLE 6 NEG LOOP 7
20
COMM FAULT LOOP INTERFACE BOARD 3
274
STYLE 6 NEG LOOP 8
21
COMM FAULT LOOP INTERFACE BOARD 4
275
STYLE 6 NEG LOOP 9
22
COMM FAULT LOOP INTERFACE BOARD 5
276
STYLE 6 NEG LOOP 10
23
COMM FAULT LOOP INTERFACE BOARD 6
277
STYLE 6 POS LOOP 1
24
COMM FAULT LOOP INTERFACE BOARD 7
278
STYLE 6 POS LOOP 2
25
COMM FAULT LOOP INTERFACE BOARD 8
279
STYLE 6 POS LOOP 3
26
COMM FAULT LOOP INTERFACE BOARD 9
280
STYLE 6 POS LOOP 4
27
COMM FAULT LOOP INTERFACE BOARD 10
281
STYLE 6 POS LOOP 5
28
CATASTROPHIC ISIB COMMUNICATIONS FAULT
282
STYLE 6 POS LOOP 6
29
MEMORY PATTERN FAULT. SERVICE REQUIRED
283
STYLE 6 POS LOOP 7
30
CATASTROPHIC CPU BOARD COMM FAULT
284
STYLE 6 POS LOOP 8
31
UPLOAD/DOWNLOAD COMMUNICATIONS FAULT
285
STYLE 6 POS LOOP 9
32
STYLE \6\" WIRING OR LOOP #1 ABNORMAL"
286
STYLE 6 POS LOOP 10
33
STYLE \4\" WIRING OR LOOP #1 ABNORMAL"
287
STYLE 6 SHORT L1
34
STYLE \6\" WIRING OR LOOP #2 ABNORMAL"
288
STYLE 6 SHORT L2
35
STYLE \4\" WIRING OR LOOP #2 ABNORMAL"
289
STYLE 6 SHORT L3
36
STYLE \6\" WIRING OR LOOP #3 ABNORMAL"
290
STYLE 6 SHORT L4
37
STYLE \4\" WIRING OR LOOP #3 ABNORMAL"
291
STYLE 6 SHORT L5
38
STYLE \6\" WIRING OR LOOP #4 ABNORMAL"
292
STYLE 6 SHORT L6
39
STYLE \4\" WIRING OR LOOP #4 ABNORMAL"
293
STYLE 6 SHORT L7
40
STYLE \6\" WIRING OR LOOP #5 ABNORMAL"
294
STYLE 6 SHORT L8
41
STYLE \4\" WIRING OR LOOP #5 ABNORMAL"
295
STYLE 6 SHORT L9
42
STYLE \6\" WIRING OR LOOP #6 ABNORMAL"
296
STYLE 6 SHORT L10
43
STYLE \4\" WIRING OR LOOP #6 ABNORMAL"
297
STYLE 6 RING 1
44
STYLE \6\" WIRING OR LOOP #7 ABNORMAL"
298
STYLE 6 ON LOOP 1
45
STYLE \4\" WIRING OR LOOP #7 ABNORMAL"
299
STYLE 6 ON LOOP 2
46
STYLE \6\" WIRING OR LOOP #8 ABNORMAL"
300
STYLE 6 ON LOOP 3
47
STYLE \4\" WIRING OR LOOP #8 ABNORMAL"
301
STYLE 6
48
STYLE \6\" WIRING OR LOOP #9 ABNORMAL"
302
ANNUN 1 TROUBLE
49
STYLE \4\" WIRING OR LOOP #9 ABNORMAL"
303
ANNUN 2 TROUBLE
50
STYLE \6\" WIRING OR LOOP #10 ABNORMAL"
304
ANNUN 3 TROUBLE
51
STYLE \4\" WIRING OR LOOP #10 ABNORMAL"
305
ANNUN 4 TROUBLE
52
UNPROGRAMMED DEVICE ON LOOP 1
306
ANNUN 5 TROUBLE
53
UNPROGRAMMED DEVICE ON LOOP 2
307
ANNUN 6 TROUBLE
54
UNPROGRAMMED DEVICE ON LOOP 3
308

FS-8700-130 Notifier NCA2-NFS2-3030 Manual
Page 19 of 23
System Trouble
Address
System Trouble
Address
ANNUN 7 TROUBLE
55
UNPROGRAMMED DEVICE ON LOOP 4
309
ANNUN 8 TROUBLE
56
UNPROGRAMMED DEVICE ON LOOP 5
310
ANNUN 9 TROUBLE
57
UNPROGRAMMED DEVICE ON LOOP 6
311
ANNUN 10 TROUBLE
58
UNPROGRAMMED DEVICE ON LOOP 7
312
ANNUN 11 TROUBLE
59
UNPROGRAMMED DEVICE ON LOOP 8
313
ANNUN 12 TROUBLE
60
UNPROGRAMMED DEVICE ON LOOP 9
314
ANNUN 13 TROUBLE
61
UNPROGRAMMED DEVICE ON LOOP 10
315
ANNUN 14 TROUBLE
62
IR ENABLED ON LOOP 1
316
ANNUN 15 TROUBLE
63
IR ENABLED ON LOOP 2
317
ANNUN 16 TROUBLE
64
IR ENABLED ON LOOP 3
318
ANNUN 17 TROUBLE
65
IR ENABLED ON LOOP 4
319
ANNUN 18 TROUBLE
66
IR ENABLED ON LOOP 5
320
ANNUN 19 TROUBLE
67
IR ENABLED ON LOOP 6
321
ANNUN 20 TROUBLE
68
IR ENABLED ON LOOP 7
322
ANNUN 21 TROUBLE
69
IR ENABLED ON LOOP 8
323
ANNUN 22 TROUBLE
70
IR ENABLED ON LOOP 9
324
ANNUN 23 TROUBLE
71
IR ENABLED ON LOOP 10
325
ANNUN 24 TROUBLE
72
TX/RX ERROR ABOVE LIMIT ON LOOP 1
326
ANNUN 25 TROUBLE
73
TX/RX ERROR ABOVE LIMIT ON LOOP 2
327
ANNUN 26 TROUBLE
74
TX/RX ERROR ABOVE LIMIT ON LOOP 3
328
ANNUN 27 TROUBLE
75
TX/RX ERROR ABOVE LIMIT ON LOOP 4
329
ANNUN 28 TROUBLE
76
TX/RX ERROR ABOVE LIMIT ON LOOP 5
330
ANNUN 29 TROUBLE
77
TX/RX ERROR ABOVE LIMIT ON LOOP 6
331
ANNUN 30 TROUBLE
78
TX/RX ERROR ABOVE LIMIT ON LOOP 7
332
ANNUN 31 TROUBLE
79
TX/RX ERROR ABOVE LIMIT ON LOOP 8
333
ANNUN 32 TROUBLE
80
TX/RX ERROR ABOVE LIMIT ON LOOP 9
334
REMOTE DISPLAY 1 TROUBLE
81
TX/RX ERROR ABOVE LIMIT ON LOOP 10
335
REMOTE DISPLAY 2 TROUBLE
82
TOO MANY DEVICES ON LOOP 1
336
REMOTE DISPLAY 3 TROUBLE
83
TOO MANY DEVICES ON LOOP 2
337
REMOTE DISPLAY 4 TROUBLE
84
TOO MANY DEVICES ON LOOP 3
338
REMOTE DISPLAY 5 TROUBLE
85
TOO MANY DEVICES ON LOOP 4
339
REMOTE DISPLAY 6 TROUBLE
86
TOO MANY DEVICES ON LOOP 5
340
REMOTE DISPLAY 7 TROUBLE
87
TOO MANY DEVICES ON LOOP 6
341
REMOTE DISPLAY 8 TROUBLE
88
TOO MANY DEVICES ON LOOP 7
342
REMOTE DISPLAY 9 TROUBLE
89
TOO MANY DEVICES ON LOOP 8
343
REMOTE DISPLAY 10 TROUBLE
90
TOO MANY DEVICES ON LOOP 9
344
REMOTE DISPLAY 11 TROUBLE
91
TOO MANY DEVICES ON LOOP 10
345
REMOTE DISPLAY 12 TROUBLE
92
MISMATCHED LOOP TYPE ON LOOP 1
346
REMOTE DISPLAY 13 TROUBLE
93
MISMATCHED LOOP TYPE ON LOOP 2
347
REMOTE DISPLAY 14 TROUBLE
94
MISMATCHED LOOP TYPE ON LOOP 3
348
REMOTE DISPLAY 15 TROUBLE
95
MISMATCHED LOOP TYPE ON LOOP 4
349
REMOTE DISPLAY 16 TROUBLE
96
MISMATCHED LOOP TYPE ON LOOP 5
350
REMOTE DISPLAY 17 TROUBLE
97
MISMATCHED LOOP TYPE ON LOOP 6
351
REMOTE DISPLAY 18 TROUBLE
98
MISMATCHED LOOP TYPE ON LOOP 7
352
REMOTE DISPLAY 19 TROUBLE
99
MISMATCHED LOOP TYPE ON LOOP 8
353
REMOTE DISPLAY 20 TROUBLE
100
MISMATCHED LOOP TYPE ON LOOP 9
354
REMOTE DISPLAY 21 TROUBLE
101
MISMATCHED LOOP TYPE ON LOOP 10
355
REMOTE DISPLAY 22 TROUBLE
102
MAPPING IN PROGRESS LOOP 1
356
REMOTE DISPLAY 23 TROUBLE
103
MAPPING IN PROGRESS LOOP 2
357
REMOTE DISPLAY 24 TROUBLE
104
MAPPING IN PROGRESS LOOP 3
358
REMOTE DISPLAY 25 TROUBLE
105
MAPPING IN PROGRESS LOOP 4
359
REMOTE DISPLAY 26 TROUBLE
106
MAPPING IN PROGRESS LOOP 5
360
REMOTE DISPLAY 27 TROUBLE
107
MAPPING IN PROGRESS LOOP 6
361
REMOTE DISPLAY 28 TROUBLE
108
MAPPING IN PROGRESS LOOP 7
362
REMOTE DISPLAY 29 TROUBLE
109
MAPPING IN PROGRESS LOOP 8
363
REMOTE DISPLAY 30 TROUBLE
110
MAPPING IN PROGRESS LOOP 9
364
REMOTE DISPLAY 31 TROUBLE
111
MAPPING IN PROGRESS LOOP 10
365
REMOTE DISPLAY 32 TROUBLE
112
LIB #1 SCB RECEIVE ERROR
366
ANALOG OUTPUT 1 TROUBLE
113
LIB #2 SCB RECEIVE ERROR
367
ANALOG OUTPUT 2 TROUBLE
114
LIB #3 SCB RECEIVE ERROR
368

FS-8700-130 Notifier NCA2-NFS2-3030 Manual
Page 20 of 23
System Trouble
Address
System Trouble
Address
ANALOG OUTPUT 3 TROUBLE
115
LIB #4 SCB RECEIVE ERROR
369
ANALOG OUTPUT 4 TROUBLE
116
LIB #5 SCB RECEIVE ERROR
370
AUXILIARY TROUBLE
117
LIB #6 SCB RECEIVE ERROR
371
UDACT TROUBLE
118
LIB #7 SCB RECEIVE ERROR
372
AVPS. TROUBLE
119
LIB #8 SCB RECEIVE ERROR
373
MASTER BOX TROUBLE
120
LIB #9 SCB RECEIVE ERROR
374
AUXIN TROUBLE
121
LIB #10 SCB RECEIVE ERROR
375
DIGIN TROUBLE
122
LIB #1 SCB ACKNOWLEDGE ERROR
376
FFT TROUBLE
123
LIB #2 SCB ACKNOWLEDGE ERROR
377
REMOTE MIC TROUBLE
124
LIB #4 SCB ACKNOWLEDGE ERROR
378
LOCAL MIC TROUBLE
125
LIB #5 SCB ACKNOWLEDGE ERROR
379
LOCAL PHONE TROUBLE
126
LIB #6 SCB ACKNOWLEDGE ERROR
380
POWER SUPPLY TROUBLE
127
LIB #7 ACKNOWLEDGE ERROR
381
FIM TROUBLE - FIELD INTERFACE
MODULE
128
LIB #8 SCB ACKNOWLEDGE ERROR
382
LIM TROUBLE - LOOP INTERFACE
MODULE
129
LIB #9 SCB ACKNOWLEDGE ERROR
383
NIM TROUBLE - NETWORK INTERFACE
MODULE
130
LIB #10 SCB ACKNOWLEDGE ERROR
384
SYSTEM TROUBLE DEFAULT MESSAGE
131
LIB #1 NIB COMMUNICATION ERROR
385
TROUBLE
132
LIB #2 NIB COMMUNICATION ERROR
386
ANNUN 1 NO ANSWER
133
LIB #3 NIB COMMUNICATION ERROR
387
ANNUN 2 NO ANSWER
134
LIB #4 NIB COMMUNICATION ERROR
388
ANNUN 3 NO ANSWER
135
LIB #5 NIB COMMUNICATION ERROR
389
ANNUN 4 NO ANSWER
136
LIB #6 NIB COMMUNICATION ERROR
390
ANNUN 5 NO ANSWER
137
LIB #7 NIB COMMUNICATION ERROR
391
ANNUN 6 NO ANSWER
138
LIB #8 NIB COMMUNICATION ERROR
392
ANNUN 7 NO ANSWER
139
LIB #9 COMMUNICATION ERROR
393
ANNUN 8 NO ANSWER
140
LIB #10 NIB COMMUNICATION ERROR
394
ANNUN 9 NO ANSWER
141
LIB #1 NIB M/S PROGRAMMING ERROR
395
ANNUN 10 NO ANSWER
142
LIB #2 NIB M/S PROGRAMMING ERROR
396
ANNUN 11 NO ANSWER
143
LIB #3 NIB M/S PROGRAMMING ERROR
397
ANNUN 12 NO ANSWER
144
LIB #4 NIB M/S PROGRAMMING ERROR
398
ANNUN 13 NO ANSWER
145
LIB #5 NIB M/S PROGRAMMING ERROR
399
ANNUN 14 NO ANSWER
146
LIB #6 NIB M/S PROGRAMMING ERROR
400
ANNUN 15 NO ANSWER
147
LIB #7 NIB M/S PROGRAMMING ERROR
401
ANNUN 16 NO ANSWER
148
LIB #8 NIB M/S PROGRAMMING ERROR
402
ANNUN 17 NO ANSWER
149
LIB #9 NIB M/S PROGRAMMING ERROR
403
ANNUN 18 NO ANSWER
150
LIB #10 NIB M/S PROGRAMMING ERROR
404
ANNUN 19 NO ANSWER
151
INTERNAL RAM ERROR
405
ANNUN 20 NO ANSWER
152
EXTERNAL RAM ERROR
406
ANNUN 21 NO ANSWER
153
CPU EXTERNAL RAM TEST ERROR
407
ANNUN 22 NO ANSWER
154
CATASTROPHIC CUP NONVOLATILE RAM
408
ANNUN 23 NO ANSWER
155
DIB EXTERNAL RAM TEST ERROR
409
ANNUN 24 NO ANSWER
156
CATASTROPHIC DIA NONVOLATILE RAM
410
ANNUN 25 NO ANSWER
157
EPROM ERROR
411
ANNUN 26 NO ANSWER
158
PRINTER SUPERVISORY PATH IS INTERRUPTED
412
ANNUN 27 NO ANSWER
159
PRINTER SUPERVISORY
413
ANNUN 28 NO ANSWER
160
PRINTER COVER OPEN
414
ANNUN 29 NO ANSWER
161
PRINTER PAPER OUT
415
ANNUN 30 NO ANSWER
162
PRINTER BUFFER FULL OR OUT OF PAPER
416
ANNUN 31 NO ANSWER
163
AUX PRINTER BUFFER FULL OR OUT OF PAPER
417
ANNUN 32 NO ANSWER
164
PRINTER OFF LINE
418
REMOTE DISPLAY 1 NO ANSWER
165
PRINT QUEUE FULL
419
REMOTE DISPLAY 2 NO ANSWER
166
FACP PRINT BUFFER FULL
420
REMOTE DISPLAY 3 NO ANSWER
167
CORRUPT LOGIC EQUAT
421
REMOTE DISPLAY 4 NO ANSWER
168
PROGRAM CORRUPTED
422
REMOTE DISPLAY 5 NO ANSWER
169
DATABASE CORRUPTED
423
REMOTE DISPLAY 6 NO ANSWER
170
AUDIO LIBRARY CORRUPTED
424
REMOTE DISPLAY 7 NO ANSWER
171
LCD80 SUPERVISORY
425
