Audiovox DPF800 - Digital Photo Frame User manual

DPF800
8"DIGITALPICTURE FRAME
PDF created with FinePrint pdfFactoryPro trial version http://www.fineprint.com

2
A.Introduction
ThankyouforselectingtheDPF800DigitalPictureFrame. Themain
featuresincludea8"Screen(4:3AspectRatio)LiquidCrystalDisplay
(LCD)monitor,a3in1cardreaderandaUSBport.Theunit applies
thelateststateofthe art electronicsandisdesignedforusewithSD/
MMC,MSmemorycardsandUSBmemorydevices.Theunit iscon-
structedtoprovideyearsofreliable,trouble-freeservice.Pleaseread
theentireinstructionmanualsuppliedwith thisproductpriortoopera-
tion.Thedocumentation will assistyou in obtaining the bestequip-
mentperformance.Allmanuals shouldbestoredforlater use.
B. Cautions and Warnings
1. Placement
Topreventfireorelectric shock, donotexposethisappliance to
rain or moisture. Do notplace the seton an unstable cart, stand,
tripod,bracketortabletopreventitfromfalling.Keeptheunitaway
fromstrong magnets, heat sources, direct sunlight, and exces-
sivedust.
2. Installation
Ensure that the DPF800 is usedinaccordancewiththe
instructions andillustrationsprovidedinthismanual.
3. ObjectandLiquid
Donot pushobjects ofanykindintotheunitthroughopenings; do
not spillorspray liquidof any kindonorin thesystem(thismay
resultin afire or electricshock).Do notplace anything heavyon
theunit.Toensure properventilation andproperoperation,never
cover or block the slotsandopeningswith acloth or other
material.
4. Disassembly
Do not attempt to disassemblethe cabinet. Thereis a riskof elec-
tricshock.Contact qualifiedservicepersonnel ifyour systemis in
needof repair.
5. CleaningUnit
When cleaning, makesurethe systemis unplugged fromthepower
source.Do not useliquid cleanersor aerosol cleaners.Use a
clothlightlydampenedwith water forcleaning the exteriorof the
systemonly.
PDF created with FinePrint pdfFactoryPro trial version http://www.fineprint.com

3
C. Contents
1. 1 xDPF800 8 Digital Picture Frame
2. 3 xSnap-On FrameCovers (White, Blackand Wood Grain)
3. 1 xRemote Control w/Battery(CR2025)
4. 1 xUSBAdapter Cable
5. 1 xAC to DC Power Supply
6. 1 xInstructionManual
D. Controls and Indicators
POWER: unit
Presstoturntheonoroff
MENU:
Presstoaccessthemain
MENU
UPCOPYDELETE: // scrollupor
copy/deletea photo Pressto
DOWNROTATE: / Pressto scrolldownor
rotate a photo
NEXT:
Presstoscrollrightorviewthe
nextphoto
PREVRETURN: . / scrollleftPresstoor
viewthepreviousphoto
POWER: Power ON/OFFIndicator LED
Right and LeftSide
TopSide
DC9V
PlugtheACadapter
Snap-On FrameCovers (White, Blackand Wood Grain)
Thesnap-on framecovers are easily removedby hand.Align theIR
sensor with the IR sensor hole on theframe cover to ensure that
the Remote Controlwill operate.
PDF created with FinePrint pdfFactoryPro trial version http://www.fineprint.com

4
E. Remote Control Controls and Indicators
PositioningYourFrame
Keep the frameawayfrom strongmagnets, heat sources,
direct sunlight, or excessive dust.
AdjustableStand
Rotatethestandtopositiontheframe
verticallyorhorizontally.
SOURCE
//
Presstoselectfrom
SDMSMMC
orUSB
inputs
ZOOM
Enlargeanimage
MENU
Presstoaccess
theMainMenu
NEXTRIGHT /
PLAYPAUSEMODE //
DOWNROTATE /
REPEAT
UPCOPYDEL //
CAL/TIME
RemoteControl
PDF created with FinePrint pdfFactoryPro trial version http://www.fineprint.com

5
GeneralSETUPPage
F.SETUP
Press ‘MENU’to display theMain Menu onthescreen.
Main SETUPMenu Screen
1)Usingthecursorbuttonsmove theselectionbox to ‘SETTINGand
pressthe ‘PLAY’button.Thegeneralsetuppage willbedisplayed
on the screen.
PDF created with FinePrint pdfFactoryPro trial version http://www.fineprint.com

6
SLIDESHOW TIME
SLIDEWITHMP3
b).SelectSLIDEWITHMP3 using theDOWNbuttonandthen press
theRIGHTbutton to enterthe submenu.SelectONorOFF.The
ONsettingwill allow anyMP3filetobe played whilethe slide
showis displayed.Thefactory settingis OFF. PressMODE to
confirm the setting.Press the LEFT button to return to themain
menu.
a).SelectSLIDE SHOWTIME using theDOWNbuttonandthen
press theRIGHT button to enter thesubmenu. Select theslide
showdisplaytime foreach photo (3, 5 or 8 seconds). The fac-
tory settingis five seconds. PressMODE to confirm the setting.
Press the LEFT button toreturn to themain menu.
PDF created with FinePrint pdfFactoryPro trial version http://www.fineprint.com

7
c).Select PHOTO MODE usingthe DOWNbutton and thenpress
the RIGHT button to enter the submenu.Select NORMALor
ZOOM.The ZOOM settingwillenlarge thephotoview whendis-
played. The factory settingisNORMAL. PressMODE toconfirm
the setting.PresstheLEFT button to return to the mainmenu.
PHOTO MODE
Note: When setto NORMAL,the entirephoto will displayed on
the screen. If the photo format is not 16:9, then blackbandswill
appear on the screen. This is normal. Press the ZOOMbutton
(Remote Control) to enlarge the photo and use the LEFT and
RIGHTbutton to view thephoto.
d).SelectMATTING using theDOWNbuttonand thenpressRIGHT
buttontoenterthesubmenu.Themattingfeaturedisplaysaframe
around thedisplayed picture.
Mode 1 - Christmas
`Mode 2 - PhotoAlbum(One Page)
Mode 3-Flower Print
Mode4-PhotoAlbum(Two Page)
Mode 5-Vine/Leaf
Mode 6 - Flowers
Mode 7-Frame
Mode 8 - Flowers
Selectthe matting mode desired or OFF. The factorysettingis
OFF. Press MODE to confirm the setting. Press the LEFT but-
ton to return to the mainmenu.
PDF created with FinePrint pdfFactoryPro trial version http://www.fineprint.com

8
FADE OPTION
e).Select theFADE OPTIONusingtheDOWNbutton and then
press the RIGHTbutton toenter the submenu.The fade option
controlsthetransition from one photo to another.
WTWipe from top
WLTWipeleft topdiagonal
TCHTop/Bottom HorizontalCenter
TCVLeft/ Right VerticalCenter
WHHorizontal bars
WVVertical bars
DTCFadebox
FIFOMorphtoanother picture
Press MODEto confirm the setting. Press the LEFT button to
returnto the mainmenu.
MATTING
PDF created with FinePrint pdfFactoryPro trial version http://www.fineprint.com

9
f). SelectDEFAULTusingthe DOWNbutton and then press RIGHT
button to enter the submenu. Select RESET. RESET will return
all ofthe features to thefactorydefault settings.Press MODE to
confirm the setting. Press the LEFT button to return to themain
menu.
DEFAULT
g).SelecttheCLOCKSETUP PAGE using theRIGHT button. Press
MODE to access the submenu.
CLOCK SETUPPAGE
PDF created with FinePrint pdfFactoryPro trial version http://www.fineprint.com

10
h).SelectCLOCKSETTINGusingthe DOWNbutton andthenpress
theRIGHTbuttonto enterthesubmenu.Selectthe hours, min-
utes orAM/PMdisplay.UsingtheUP or DOWNbuttonsset the
hour to the correcttime.Repeat for theminutes and AM/PM.
PressMODE to confirm thesetting.Pressthe LEFT button to
returnto the mainmenu.
CLOCK SETTING
Note: Ifthe frame is unplugged for more than 10 minutes, the clock
and the calendar will have tobe reset.
i).Select ALARMSETTING usingtheDOWNbuttonandthen press
the RIGHT buttonto enter the submenu.Select thehours, min-
utes on the display.Usingthe UP orDOWNbuttonssetthehour
to the correct time. Repeat for the minutesand AM/PM. Press
MODEto confirm the setting. Press theLEFTbutton to return to
the main menu.
ALARMSETTING
PDF created with FinePrint pdfFactoryPro trial version http://www.fineprint.com

11
DATE SETTING
j). SelectDATESETTING usingtheDOWNbuttonandthen press
RIGHTbutton to enter the submenu. Set the month, dayand
yearusingtheUPand DOWNbuttons.PressMODE to confirm
the setting.Press the LEFT button to return to the mainmenu.
k).Select ALARMMODE using the DOWNbutton and thenpress
theRIGHTbutton to enterthe submenu.The alarmcanbeset to
ON orOFF.Press MODE toconfirm the setting. Press the LEFT
button to return to themain menu.
ALARM MODE
PDF created with FinePrint pdfFactoryPro trial version http://www.fineprint.com

12
BRIGHTNESSSETTING
m).Select BRIGHTNESS usingthe DOWNbutton and thenpress
theRIGHTbuttontoenterthe submenu. TheBRIGHTNESS can
be changed usingthe LEFT orRIGHTbuttons. The range is
adjustable from-20toa+20.Press MODE toconfirm the setting.
Press the LEFT button toreturn to themain menu.
l).Select the VIDEO SETUP PAGE usingthe RIGHTbutton. Press
MODE to access the submenu.
VIDEOSETUPPAGE
PDF created with FinePrint pdfFactoryPro trial version http://www.fineprint.com

13
CONTRASTSETTING
n).SelectCONTRAST usingthe DOWNbutton and then press the
RIGHTbutton toenter the submenu. The CONTRAST can be
changedusingthe LEFTorRIGHTbuttons.The rangeis adjust-
ablefrom -16 to a+16. Press MODEtoconfirmthe setting.
Press the LEFT button toreturn to themain menu.
o).SelectSATURATION using theDOWNbutton and thenpress
theRIGHT buttonto enterthe submenu. TheSATURATIONcan
be changed usingthe LEFT orRIGHTbuttons. The range is
adjustable from -9 to a +9. Press MODE to confirm the setting.
Press the LEFT button toreturn to themain menu.
SATURATIONSETTING
PDF created with FinePrint pdfFactoryPro trial version http://www.fineprint.com

14
EXITtheSETUPPAGE
q).ToEXITthe Set Up page, select the X icon using the RIGHT
button. Press MODE to confirm the settingand return to the
main menu.
HUESETTING
p).SelectHUE usingthe DOWNbutton andthen press the RIGHT
button toenterthesubmenu. TheHUE canbe changed using
theLEFTor RIGHTbuttons.Therangeisadjustable from -9to
a +9. Press MODE to confirm thesetting.Pressthe LEFT but-
ton to return to the mainmenu.
PDF created with FinePrint pdfFactoryPro trial version http://www.fineprint.com

15
G.Selecting Photos Using the SD/MMC/MS Cardor theUSB
MemoryDevice
1.Insert theSD/MMC/MS CardintotheSD/MMC/MS slot or
connect the USB adapter cable tothe USB memorydevice.
2.Press the MENUbuttonto display the main menu page. Using
theLEFT button highlight thePHOTO icon.
3.Press PLAY/PAUSE/MODE once to enter Slide Showmode.
Thephotos transition displayis based FADE options settings.
4.Press PLAY/PAUSE/MODEagaintoenter pause mode.The
framedisplays a singleimage. You can usethe PREV. and
NEXT buttontoselecta photo.
5.Press PLAY/PAUSE/MODE two times to viewphotos as
thumbnails. The thumbnailimagesappear inatable. Use the
PREV. NEXT, UP and DOWNbuttonto navigatethrough the
thumbnails.
Copying Photosto Your Frame
Tocopy photosfrom a SD/MMC/MS Card or a USB memory
device, set the frame to slide show mode. Select the photo and
press UP/COPY/DELETE button. The frame will prompt you if
you want to copythe photo. Select YES and pressMODE. The
frame can copyapproximately20photosto memory.
Note: You can rotate photos clockwise bypressingROTATE button
when the photois displayed onthe screenin slide show
mode. Rotatedphotosare copied in the rotatedposition.
PDF created with FinePrint pdfFactoryPro trial version http://www.fineprint.com

16
Deleting Photos
To delete photos from your frame’s memory, disconnect the
SD/MMC/MS Card or a USB memorydevicefrom theframe.
Use thePREV. orthe NEXT buttonto locate thephoto you
wish todelete. Whenthe desired photoappears, press the
UP/COPY/DELETE button. The frame will prompt ifyou want
todelete thephoto.Select YES andpress MODE button.The
frame deletes the photo from memory.
Note:The deletefunctiononly deletesphotos from the frame’s
memorynot from a card or a USB memorydevice.
H. Selecting Audio Files Using the SD/MMC/MSCardor the USB
MemoryDevice
1.Insert theSD/MMC/MS CardintotheSD/MMC/MS slot or
connect the USB adapter cable tothe USB memorydevice.
2.Press the MENUbuttonto display the main menu page. Using
the LEFT buttonhighlightthe AUDIO icon.
3.Press PLAY/PAUSE/MODE oncetoenter audio mode.The
audiotracksare displayedon theleftside ofthescreen. Artist
information is displayed on the right ofthescreenwhen
available.UsethePREV., NEXT, UPorDOWNbuttonsto
select the desired track.
4.Press PLAY/PAUSE/MODEtoenter PLAYmode. PressPLAY/
PAUSE/MODE again to enter Pause mode.
PDF created with FinePrint pdfFactoryPro trial version http://www.fineprint.com

17
I. Calendar Function
1.Press the MENUbuttonto display the main menu page. Using
the LEFTbutton highlight the CALENDARicon.
2.Press PLAY/PAUSE/MODE once to enter calendar display
mode.The month andthe year willbedisplayed at the topof
the screen. Usingthe UP or DOWN buttons select the month
andtheyear. Using thePREV. orNEXT button, selecttheday.
J.SPECIFICATIONS
Audio format :MP3
Photo format: JPEG
Panel size: 8inch
Powersource:DC 9V
Powerconsumption:5W
Operatingtemperature: 41~95°F, 5~35°C
Weight :1.68lb 0.76Kg
Dimensions (WxH xD): 10.2 X 8.4 X 1.5 inches
259X 213 X 38mm
Note:Thedate is set in F. Setup, Step J. The above procedure is
forreferenceto view datesinthe future or in the past.
PDF created with FinePrint pdfFactoryPro trial version http://www.fineprint.com

U.S.A.:AUDIOVOX ELECTRONICS CORPORATION, 150 MARCUSBLVD,HAUPPAUGE,NEWYORK 11788
l1-800-645-4994
CANADA : CALL 1-800-645-4994FORLOCATIONOF WARRANTYSTATIONSERVINGYOURAREA
AUDIOVOXELECTRONICSCORP. (the Company)warrants to the original retailpurchaserof
this productthat should thisproduct or any part thereof,under normal use and conditions,
be proven defective inmaterialorworkmanshipwithin90 daysfromthe dateoforiginal
purchase,such defect(s)will berepairedor replaced withreconditioned product (at the
Company's option) without charge for parts and repair labor. A game controller, if supplied,
is similarly warranted for ninety(90) days.
Toobtainrepairorreplacementwithin theterms ofthis Warranty, the product istobe delivered
withproofofwarrantycoverage(e.g. dated bill ofsale), specification of defect(s),
transportation prepaid, tothe Company atthe address shown below.
This Warranty does not extend to the elimination of externally generated staticor noise, to
correction of antenna problems, to costs incurred for installation, removal orreinstallation of
theproduct, ortodamagetodigitalmemory/mediadevices, gaming devices, discs, speakers,
accessories, or electricalsystems.
This Warrantydoesnotapplytoany product or partthereofwhich,inthe opinion ofthe
Company,has suffered or been damaged through alteration, improper installation,mishan-
dling, misuse, neglect, accident, or by removal or defacement of the factory serial number/
barcodelabel(s).THEEXTENTOFTHECOMPANY'SLIABILITYUNDERTHISWARRANTYIS
LIMITEDTOTHEREPAIRORREPLACEMENTPROVIDEDABOVEAND,INNOEVENT,SHALL
THECOMPANY'SLIABILITYEXCEEDTHEPURCHASEPRICEPAIDBYPURCHASERFORTHE
PRODUCT.
This Warranty is in lieuof allother express warranties orliabilities. ANY IMPLIED WARRAN-
TIES,INCLUDINGANYIMPLIEDWARRANTYOFMERCHANTABILITY,SHALLBELIMITEDTO
THE DURATION OFTHIS WRITTEN WARRANTY. ANY ACTION FOR BREACH OF ANY
WARRANTYHEREUNDERINCLUDINGANYIMPLIEDWARRANTYOFMERCHANTABILITY
MUST BE BROUGHTWITHINAPERIODOF 24 MONTHS FROMDATEOFORIGINAL
PURCHASE. INNOCASESHALLTHECOMPANYBELIABLEFORANYCONSEQUENTIALOR
INCIDENTALDAMAGESFORBREACHOFTHISORANYOTHERWARRANTY,EXPRESSOR
IMPLIED, WHATSOEVER.No person or representative is authorized toassumefor the
Company any liabilityother than expressedherein in connection with the sale ofthis product.
Some states do not allowlimitations on howlong an implied warranty lasts or the exclusion
or limitation ofincidentalor consequential damageso theabovelimitationsor exclusions may
not apply to you. This Warranty gives you specific legal rights and you may also haveother
rights whichvary fromstatetostate.
90 DAYLIMITED WARRANTY
Applies to Audiovox Video Products
128-5556G
©2007 Audiovox Electronics Corporation
PDF created with FinePrint pdfFactoryPro trial version http://www.fineprint.com

128-8004
©2007 Audiovox Electronics Corporation
PDF created with FinePrint pdfFactoryPro trial version http://www.fineprint.com
