Audiovox D1917 User manual

D1917
PORTABLE 9" LCD MONITOR AND DVDPLAYER
PDF created with FinePrint pdfFactoryPro trial version http://www.fineprint.com

2
AnLCDpanel and/or videomonitor maybeinstalled in amotor
vehicle and visible to thedriver iftheLCDpanelor video monitor
is used for vehicle information, system control, rear or side
observationor navigation. Ifthe LCD panelorvideomonitoris
used fortelevision reception, video or DVD play, theLCDpanel or
video monitor must be installed sothat these featureswill only
function when the vehicleisin park”or when the vehicle’spark-
ing brake isapplied.
AnLCD panel orvideomonitor usedfor television reception, video
or DVD playthat operates when the vehicleisingear or when the
parkingbrake is notappliedmust be installedto therearof the
driver’sseat where it willnot bevisible, directly or indirectly, to the
operatorof themotor vehicle.
Notice:
This Product incorporatescopyrightprotectiontechnologythatis
protectedby methodclaims of certainU.S. Patents andotherintel-
lectual propertyrightsownedbyMacrovisionCorporation and other
rights owners. Use of this copyrightprotection technologymust be
authorizedby Macrovision Corporation, andis intendedforhome
andother limitedviewing uses only unlessotherwise authorizedby
MacrovisionCorporation. Reverseengineering ordisassembly is
prohibited.
PDF created with FinePrint pdfFactoryPro trial version http://www.fineprint.com

3
Content
A.Introduction............................................................................ 4
B.Cautionsand Warnings........................................................ 4
C.Contents ............................................................................... 6
D.Powering andinstallation..................................................... 6
E.Controls, Indicators, andConnectors................................... 7
F.Loading andPlayinga Disc.................................................. 8
G. BasicOperation...................................................................... 9
H. Menu....................................................................10
I. Display................................................................................... 10
J.PlayingAudio CDS................................................................ 13
K. PlayingMP3 Discs .......................................................... 14
L.Connectingto otherElectronicEquipment.......................... 16
M.PlayingJPEGFiles........................................................... .17
N.Setup....................................................................................18
O. Specifications ...................................................................... 21
P.Rechargeable BatteryInstallation andUse......................... 21
Q. Troubleshooting ................................................................. 24
PDF created with FinePrint pdfFactoryPro trial version http://www.fineprint.com

4
A.Introduction
Thank youfor choosing the D1917portableDVD player.The main
features includea 9" Digital Screen (16:9 Aspect Ratio) Liquid Crys-
talDisplay (LCD)monitor anda DVD player. Theunit alsocontains a
3 in 1 card reader and a USB port.The unit is designed for use with
SD/MMC,MS memory cardsandUSBmemorydevices.Theunit
applies thelatest state of theart electronics and is designed for use
inhotels, offices oryour home. The unitisconstructed to provide
yearsofreliable, trouble-freeserviceandis compactsothatyoucan
take itwith youanywhereandisdesigned for quick andeasy installa-
tion. Please readthe entireinstruction manual suppliedwiththis prod-
uctpriorto using.Thedocumentation will assist you inusingthesys-
temproperly to obtain thebest equipment performance. Pleasesave
this manual for later use.
B. Cautions and Warnings
1. Placement
Toprevent fireor electric shock, donot expose this unit to rainor
moisture. Keep the unit away from strong magnets, heat sources,
directsunlight, excessivedust. Ifthe unitis brought directly from a
coldto a warmlocation,moisture maycondense inside the unit.
When you move the unit fromacold toawarm location, waitfor
about one hour before operating the unit, or remove the disc and
leavethe unitturned on until themoistureevaporates.
2. Installation
Ensure thatthe9”portableDVDplayeris usedinaccordancewith
the instructions and illustrations provided in this manual.
3. Caution
Donotpushobjectsof anykindintothe unitthroughopenings;do
not spill or sprayliquid ofanykind on or in the unit (thismay
PDF created with FinePrint pdfFactoryPro trial version http://www.fineprint.com

5
result in a fireor electric shock). Do not placeanythingheavy on
the unit. To ensure proper ventilation and proper operation, never
coverorblocktheslotsandopenings withaclothorothermaterial.
Keep theunit away fromanopenflamesuch as fire, candle etc.
Replacing the batteryincorrectly ishazardous. Replacethe bat-
teryonly with the same or equivalent type. In ordertoprotect the
environment, pleasedispose the batteryproperly. Do notuse the
unit intemperatures higher than95 degrees Fahrenheit or35 de-
grees Celsius.
4.Disassembly
Do not attempt to disassemble the unit’scase. There is a risk of
electric shock and/orexposure toLaser Radiation.Contact quali-
fied service personnel if your system needs repair.
5.Cleaning Unit
Whencleaning,makesurethesystem isunplugged fromthepower
source. Donotuseliquid cleaners or aerosolcleaners. Usea cloth
lightly dampenedwith waterfor cleaningtheexterior ofthe system
only.
6. Disc
Do not use irregularlyshaped discs such asheart orstar-shaped
discs as theymay cause the unittomalfunction.Donotstickpaper,
tapeor glue on the disc. Do not expose thedisc to direct sunlight
or heat sources. Do not touchthe surface ofdisc. Handle thedisc
by itsedge. Cleanthedisc bywipingthedisc from the center out
with a clean cloth. Remove the disc from the unit and store it in its
case after playing. Some playback operations ofdiscsmaybe in-
tentionallyfixed by software producers. Since this unit plays discs
according to the disc contentsthesoftwareproducers designed,
some playbackfeatures maynot be available. Also referto the
instructionssuppliedwiththediscs.
PDF created with FinePrint pdfFactoryPro trial version http://www.fineprint.com

6
7.RegionalCoding
Both theDVDplayer and disc are coded by region. These
regional codes must match inorder for thedisc toplay.Ifthe
codesdon’t match, the disc won’t play. This unit’s code is region
1. DVD’s with other regional codes cannot be played in thisunit
C. Contents
1. 1 x 9’’ LCDMonitor and DVDPlayer
2. 1 xRemote Control with battery(CR2025)
3.1 x Audio/VideoAdapterCable
4. 1 xAC to DCAdapter
5. 1 xDC Power Adapter
6. 1x Instruction Manual
7. 1 xRechargeable Battery
D. Powering and installation
1. Powering the system indoors (Refer to Figure 1)
Plug one end of theAC to DC adapterinto the DCinputjackon the
left side ofthe mainunit, then plugthe otherend intothe 110~240V
AC power receptacle.
2. Powering the systemin a car
Plugone end of the DC Power adapter into the DC input jackon
theunit, thenplugthe other endinto the vehicle power outlet.
Figure1
Note: Unplugthe the unit from its power source and remove the
rechargeablebatteryif theunitis not goingto be used for a long
time.
PDF created with FinePrint pdfFactoryPro trial version http://www.fineprint.com

7
E. Controls, Indicators, and Connectors
1. UnitView (Refer to Figure2)
Figure 2
11) Charge Indicator
12)Headphone Jack 1*
13)HeadphoneJack 2
14) Volume Up/DownControl
15) Brightness Up/Down Control
16)LCD Panel Shut Off Switch
17) Wide Button
18) Previous/Next/Pause/Stop/Play
19)MenuButton
20) Up/Down/Left/Right/OK Button
1
2
4
5
6
78910
11
12
13
14
15
16
17
18
19
20
1) Battery Release Button
2) DC 9V InputJack
3)AVJack
4)AVIn/Out Switch
5) USB Port
6)Power ON/OFF Switch
7) SD/MMC/MSCard Slot
8)Power LED
9)Remote Control Sensor
10) Cover Open Switch
* Connectingto headphone jacknumber 1 will disable the
internal speakers
PDF created with FinePrint pdfFactoryPro trial version http://www.fineprint.com

8
2.Remote Control (Refer to Figure3)
1) Setup Button
2) UpButton
3) Skip- Button
4) Enter Button
5) Reverse/Left Keypad
6)DownButton
7)Numeric Buttons
8) DisplayButton
9) Zoom Button
10)DVD/SD-USB Button
11) Skip + Button
12) A-B Repeat Button
13) Forward/Right Keypad
14)1/All Repeat Button
15) Stop Button
16)MenuButton
17) Subtitle Button
18)Audio Button
19) Play/Pause Button
F. Loading and Playing a Disc
a. After connectingpower to the unit, power on the DVD player with
the power switch. The power indicator will light.
b.Openthedisctrayby sliding theOPEN switch inthe directionof
the arrow. Place a disc in the traywith label sidefacingup.
c.Closethe trayby pressingthearea marked PRESS”.Theunitwill
load the discand start playing.
d. Rotate VOLUMEto adjust the LCD’sbrightness and the DVD
player’svolume.
e. To stopplaying adisc,pressSTOP.
Figure 3
PDF created with FinePrint pdfFactoryPro trial version http://www.fineprint.com

9
G. Basic Operation
POWER
OPEN
PAUSE
STOP
PLAY
Skip +NEXT
Skip-PREVIOUS
FORWARD
REVERSE
ANGLE
LEFT/RIGHT/UP/DOWN
ENTER
NUMBERS
MENU
REPEAT
A-B
DISPLAY
SUBTITLE
AUDIO
SETUP
WIDE
Turnthe uniton/off
Remove/load the disc
Press topause play and againtore-start play.
Press once to stop and restart at thestop point
Press twice to stop and restart at the
beginning of thedisk
Start Play/Execute item or setting
Goto thenextchapter, track or scene
during play back
Gobacktothe previouschapter, track
or scene duringplayback
Scan forward at 2, 4, 8,16 or
32 times speed
Scan backward at 2, 4, 8, 16or
32 times speed
Changethe viewingangle of the scene
Used forMenu Navigation
Execute item or confirm setting
Select item or setting
Display the mainmenu ofthe disc
Repeat playingtitle, chapter, or track
Repeat a specific portionfrom
pointAto pointBof thedisc
Display information (title, chapter, track,
time, etc.).
Select thesubtitlelanguage andturn it
on/off
Selecttheaudio language
Displaythe setup menuto select and
set items, and exit the setup menu.
On the player only: change between wide
screen and 4:3 picture aspectratio.
PDF created with FinePrint pdfFactoryPro trial version http://www.fineprint.com

10
H.Menu
A DVD is divided into sections called titlesandchapters. When you
play a DVD, the root menu of thedisc will appearon the screenof
your TV orMonitor. The contents ofthe menu varyfrom disc to disc.
Press MENU duringplaybackto display the menu. Some DVDs only
allowyou to select disc playbackoptions using the DVD root menu.
I. Display
1. PLAYINGTIME AND REMAININGTIME
a. Duringplaybackpress the ‘DISPLAY’button to displaythe cur-
rent Title Number (1), the total Number ofTitles (2), the current
ChapterNumber (3), thetotal Numberof Chapters (4), andthe
elapsed playingtime for the title (5).
Title, Chapter Number, and TimeScreenDisplay
b.Pressing‘DISPLAY’repeatedlywillprovide the followingsequen-
tial options below:
TitleElapsed: The elapsedtime ofthe title
Title Remain:The remaining time ofthe title
Chapter Elapsed: The elapsed time ofthe chapter
Chapter Remain: The remainingtime ofthe chapter
Display Off: The DVD’s time information is removed from view.
Title Elapsed
TitleRemain
Chapter Elapsed
Chapter Remain
DisplayOff
PDF created with FinePrint pdfFactoryPro trial version http://www.fineprint.com

11
Audio Language
2. SUBTITLE
Duringdisc playbackpress ‘SUBTITLE’toselectthe subtitle language
youdesire*,withthecurrentSubtitle LanguageNumber(1) andthe
total Number of Subtitle Languages(2)displayed. Ifthere are mul-
tiplelanguagespress ‘SUBTITLE’againto selectanother subtitlelan-
guage.Toturn subtitles OFF,press the ‘SUBTITLE’button until ‘Sub-
titleOff’isdisplayed.TheSubtitledisplay willdisappearautomatically
ifthe ‘SUBTITLE’button is not pressed again within 3 seconds.
*Some DVDsonly allowaccessto this functionthrough theDVDmenu
3. AUDIO
During playbackpress ‘AUDIO’to select theaudio languageyou de-
sire*, with the current Audio Channel Number (1) and the total num-
ber of AudioChannels(2)displayed.PressAUDIOagain to select
anotheraudio language. The audiodisplaywill disappear automati-
callyifthe ‘AUDIO’button is not pressed within for 3 seconds.
* Some DVDsonlyallowaccess to this function through the DVD
menu.
Subtitle
PDF created with FinePrint pdfFactoryPro trial version http://www.fineprint.com

12
4. A-B REPEAT
a. Duringplaybackpress ‘A-B’to set the StartingPointA.
b. Press ‘A-B’asecond time to set the EndingPoint B. The player
willrepeatedlyplay the part betweenPointA andPoint B.
c. Press A-B a third time to cancelA-B repeat and resume normal
playback.
5. 1/ALLREPEAT
a.Duringplayback press‘1ALL/REPEAT’repeatedly tocycle through
therepeat modes.
Chapter:Repeat the current chapter
Title:Repeat the current title
All:Repeat all chapters and titles
Repeat Off:Resume normal playback
The ‘Chapter’repeat displayis shown below:
A-B Repeat Starting Point A-BRepeatEnding PointA-B Repeat Cancelled
Chapter Repeat
PDF created with FinePrint pdfFactoryPro trial version http://www.fineprint.com

13
J. PlayingAudio CDs
When playing an audio CD pressthe DISPLAY button repeatedly on
theremotetoview timeinformation.Theoptions belowaredisplayed
in the folowingsequence.
CD Display Mode
Single Elapsed:Thecurrenttrackplayingandelapsedplaying time of
that trackis displayed on the screen.
Single Remain:The current trackplayingand theamount of time
leftto playon the track.
SingleElapsed
SingleRemain
Total Elapsed
Total Remain
Display Off
Zoom
6.ZOOM
Duringplayback press ‘ZOOM’to enlarge thepicture by2X, 3X ,4X.
(1) Press ZOOM”one time, the picture will be enlarged 2X.
(2) Press ZOOM”a second time, the picture will be enlarged 3X.
(3) Press ZOOM”a thirdtime, the picture will be enlarged 4X.
(4) Press ZOOM”afourth time, the picture will return to normalsize.
Single Elapsed When Playing Audio CDs
PDF created with FinePrint pdfFactoryPro trial version http://www.fineprint.com

14
Total Elapsed:The current track playingand the totaltime thatthe
CD hasbeen playing.
Total Remain:The current track playingand the amount oftime
remaining on theCD.
Display Off:The CD time information is not displayed.
USING THE1/ALLREPEATFEATURE
Thedefaultmode forthe Repeat feature isOFF.PressingREPEAT
consecutively changes the repeat options:
•Track-repeats the track that isplaying.
•All-repeats the disc that isplaying.
•Repeat Off
Asyou toggle throughthe options,the repeatoptionchanges. The selected
repeat option loops repeatedly until you turn itoff.
K.Playing MP3 Discs
MP3isa format for storingdigital audio.AnaudioCD-quality songis
compressed into theMP3 format with very littleloss ofaudio quality
whiletaking up much less disc space.CD-R/RWdiscs that have
beenencoded in MP3formatare compatible with this system.
Whenan MP3discis insertedintothe unit, themenuscreenappears
automatically.Youcanuse themenuscreentoselect your desired
foldersandsongs orthesystem plays thesongs in theorder they
were burned onto the disc.
PDF created with FinePrint pdfFactoryPro trial version http://www.fineprint.com

15
1.Press the or buttontochoosea folderfrom thefolder liston
the leftsideof the screen.
2. Press ENTERto select thehighlighted folder. The songs avail-
able inthefolder willbe listed.
3.Use the or button to chooseasong fromthelist. Press
ENTERtoselectandbegin playback ofthehighlighted song.
4. Use the( NEXT ) buttonto move to the nextsong. Pressthe
(PREVIOUS) button to move to the beginningof the previous
song.
USINGTHEREPEATFEATURE
Thedefault modefor the Repeat feature isOFF. Pressing REPEAT
consecutively changes the repeat options:
•Repeat One (repeat playback ofa song)
•Repeat Folder (repeatplaybackofa specific folder)
•RepeatOff (normal playback)
As you toggle throughthe options, the repeat mode changes. The
selected repeat mode loops repeatedly until you turn it off.
Note:
”iconinfront ofafilenameindicates that thisisafolder,notan
MP3file.
MP3”iconinfrontofafilenameindicates that thisis aMP3 file.
Note:
Due tothe company’s policy ofconstant improvement and technical re-
finement, the company reservestheright to changeor alter software.
PDF created with FinePrint pdfFactoryPro trial version http://www.fineprint.com

16
L. Connecting to other Electronic Equipment
1. Connecting to a TV or another monitor( Refer to Figure 4)
a. Set theAVIn/OutSwitch to the Out”Position.
b.Connectoneendoftheaudio/videocable’sblack (1/8”plug)plug
intotheunit’sDVD AVjackandconnecttheother endtotheAUDIO
INPUT jacksonyourTVorMonitor usingtheAVadapter cable (white
= leftaudiochannel, red =right audio channel, yellow = video).
Figure4
2.Connecting to a Game or Camcorder (Refer to Figure 4)
a. Set the AVIn/Out Switch to the In”Position.
b.Connectoneendoftheaudio/videocable’sblack (1/8”plug)plug
intothe unit’sDVD AVjackand connectthe otherend totheAUDIO
Outputjacks onyour Camcorderor other DVDusingtheAVadapter
cable (white= left audio channel, red = right audio channel, yellow=
video).
Note: Do not connect anAV signal source with theAV jackwhenthe
AVIn/Out Switchis set tothe Out”position.
3.Headphones
Optionalwiredheadphones maybeusedwiththe unit.Simply plugin
theheadphonestoeitherHeadphone1jack*orHeadphone2jackon
therightsideofthe DVD.(RefertoFigure5.)
NOTSUPPLIED NOTSUPPLIED
PDF created with FinePrint pdfFactoryPro trial version http://www.fineprint.com

17
*PluggingintoHeadphonejack1disablestheinternalspeakers.
4. SD/MMC/MS Cardand Thumb Drive/Digital Cameras
Withno disc in the unit, insert eitheran SD/MMC/MScard,Thumb Drive,
or digital camera withJPEGor MP3filesinto theappropriate input.
1)Insert anSD/MMC/MSCard intotheSD/MMC/MS Slotonthe front of
theunit.
2) Insert aThumb Drive into theUSB jackontheleft sideof theunit.
3)Connect theUSB cable (not supplied)fromacameraintotheUSB
port ontheleftsideoftheunit.
4) Press theDVD/SD-USB button. Choose the folder you desire by us-
ingthe UP”and DOWN”buttons.
Design and Specifications are subject to change for product
improvement without notice.
M. Playing JPEG Files
1)Load the JPEG Disc intotray.
2)TheDVDplayerwilldisplayafolder andtheJPEGScontained within
the folderinathumbnail view.Choose the pictureyou desirebyusing
the UP”and DOWN”buttons.
3)You can viewthe JPEG file you selectedbypressing
PLAY”or ENTER”buttons.
4)Pressingthe DOWN”button rotates the picture 90 degrees
clockwise.
5)Pressingthe UP”Key willreturn to the JPEG menu.
6)When previewingthe file, pressingSUBTITLE”, AUDIO”or
AB”,aniconwillappearonthe display indicatingthattheseoptions
arenotavailable.
Figure 5
**
PDF created with FinePrint pdfFactoryPro trial version http://www.fineprint.com

18
N.Setup
1. GeneralSetup Page
1)With no discinsidethe player,press‘SETUP’todisplaythe Main screen
ofthe Setup Menuon the screen and General Setup Page”appearsand
” ishighlighted.Press ‘SETUP’againto exittheSetupMenu.
2) Press the ENTERbutton, TV Display”ishighlighted.
3) Press the or button to select the other menus in general setup
page.
4) Press to enter the submenu.
5) Press the or button to select the sub menu and press the
ENTER to confirm your selection.
6) Repeat steps 3-5 for other menus.
Note: Press toreturn theprevious menu.
a) TVDisplay
Normal/PS:When the player outputssignal toa normal TV,anormal
picture is shown on the full screen.
Normal/LB: When the player outputs signal toa normalTV, a normal
picture is shownon the screen with ablackstrip at both thetop and
bottom ofthe screen.
Wide: When the player outputssignal toa wide screen TV, awide
picture is shown on the full screen.
b) Angle Mark
On:Thescreen will showthe anglemark icon. (Ifanangle optionis
available).
Off: The screen will not displaytheangle mark.
c) Screen Saver
On: Enablesscreensaver.
Note: TheDVD playerwillenterthe Screen Saver mode after ap-
proximately fiveminutes ifthe same imageremains on thescreen.
Off: Disables screen saver.
d) Last Memory
On: The unit willreturnto the last position on the disc when the tray
is opened or the AV In/Out switch position is changed.
Off: The unit will not return to the last position on the disc.
PDF created with FinePrint pdfFactoryPro trial version http://www.fineprint.com

19
2.Video QualitySetup
1)InSetupmenu,pressthe or buttontoselect VideoQuality
Setup”and is highlighted. Press ENTER toenter the video quality
setuppage.
2) Press the ENTER button, Brightness”is highlighted.
3) Press the or button to select theother menus in video quality
setuppage.
4) Press to enter the sub menu.
5) Press the or button to adjust the quantityand press the
ENTER to confirm your selection.
6) Repeat steps 3-5 for other menus.
Note: Press to returntheprevious menu.
a)Brightness b) Contrast
c) Saturation d) Hue
3.Password
In Setup menu, pressthe or button toselect Password Setup
Page”and is highlighted. Press ENTER to enter the password page.
PressENTERtwice to enter thePassword Change Page.Input the Old
Password or the DefaultPassword, the NewPassword, and Confirm
the NewPassword. Press ENTER to confirm the change.
Note: The default password is 3308.
4.PreferencePage
1)InSetupmenu, pressthe or buttontoselect PreferencePage”and
is highlighted. Press ENTER to enterthe preference page.
2) Press the ENTER button, Audio”is highlighted.
3)Press the or button to select the other menus inpreference page.
4) Press to enterthesubmenu.
5)Press the or button toselectthe submenuandpressthe ENTER
to confirmyour selection.
6) Repeat steps 3-5 for other menus.
Note: Press to return theprevious menu.
Note:The Last Memoryposition function will onlywork when the
disc trayisopened.
PDF created with FinePrint pdfFactoryPro trial version http://www.fineprint.com

20
a) Audio:Selects the audiolanguageyou desire. Use theUP or
DOWN buttons to select another audio language.
b) Subtitle: Selects the subtitlelanguageyou desire. Use the UP or
DOWN buttons to select another subtitle language. To turn subtitles
OFF use the UP or DOWNbutton and select OFF.
c) DISC MENU: Selects the menu language you desire. Use the UP
or DOWN buttons to select another menu language.
Note: Languageselection for the audio,subtitle and discmenu is only
available for discs thatare recorded indifferentlanguages. If the
selected language isnotavailable, theplayer willplay anddisplay on
the screen the language that wasoriginallyrecorded on thedisc.
d) Parental
Select ‘Parental’usingtheand button,then pressRIGHTtoenter
the submenu. Select the parental level youdesire usingand the
button fordiscswithlock-out functionormultipleratinglevels.These are
listedfromthelowest level(1KIDSAFE) tothe highest level(8ADULT).
Press ENTER andinput 4 digit password, then pressENTER againto
confirm the parentallevel setting.
Note: Thelevelof 8 Adult isthefactorydefault.
e) Default
Select ‘Default’using the and button,then press to enterthe
submenu. Press ENTER to makethe settingsreturn to the factoryset
mode.
Note: The parentalsettingis notaffectedby thedefaultreset function.
Note: The Default Password is 3308.This passwordisalways effective
even after you haveselectedyour ownpassword andchanged it. To
avoidthe possibilityofothers usingthe default password to set the
parental levelandchangethe password,youcanrecord thisdefaultpass-
wordinanother areaanddeleteitfrom thismanual.Somediscscanbe
limited dependingon the age ofusers while some discs cannot.
PDF created with FinePrint pdfFactoryPro trial version http://www.fineprint.com
