Audiovox D2017 User manual

D2017
PORTABLE10.2" LCD MONITOR AND DVD PLAYER
PDF created with FinePrint pdfFactoryPro trial version http://www.fineprint.com

2
AnLCDpanel and/or videomonitormaybeinstalled in amotor vehicle
and visible to the driver ifthe LCD panelor videomonitor is used for
vehicle information, system control, rear or side observationor
navigation.If the LCDpanelor video monitor is usedfortelevision
reception, video or DVD play, the LCDpanel or video monitor must be
installedsothat these featureswill onlyfunction when the vehicle is in
park”orwhenthevehicle’s parkingbrake isapplied.
AnLCD panelor video monitor used for television reception, videoor
DVDplay thatoperateswhenthevehicleis ingear or whentheparking
brakeis not appliedmust be installedtothe rearofthe driver’sseat
where itwill notbevisible, directly or indirectly, to theoperator of the
motor vehicle.
Notice:
This Productincorporates copyrightprotection technologythat is pro-
tectedby methodclaims of certain U.S. Patents andotherintellectual
property rights ownedby Macrovision Corporationandother rights own-
ers. Use ofthiscopyright protectiontechnologymust be authorizedby
MacrovisionCorporation,andisintendedforhomeandotherlimitedview-
inguses onlyunless otherwise authorized byMacrovision Corporation.
Reverse engineeringor disassemblyis prohibited.
PDF created with FinePrint pdfFactoryPro trial version http://www.fineprint.com

3
Content
A.Introduction............................................................................ 4
B.Cautionsand Warnings........................................................ 4
C.Contents ............................................................................... 6
D.PoweringandInstallation ..................................................... 6
E. Controls,Indicators andConnectors ................................... 7
F.Loadingand PlayingaDisc.................................................. 8
G. BasicOperation...................................................................... 9
H. Menu....................................................................10
I. Display...................................................................................10
J.PlayingAudio CDS................................................................13
K. PlayingMP3 Discs .......................................................... 14
L.Viewing JPEGfile...........................................................16
M.ConnectingtoOtherElectronic Equipment.......................... 16
N.Setup....................................................................................18
O. Specifications ...................................................................... 21
P.Rechargeable BatteryInstallation andUse......................... 21
Q. Troubleshooting ................................................................. 24
PDF created with FinePrint pdfFactoryPro trial version http://www.fineprint.com

4
A.Introduction
Thank youfor choosing the D2017portableDVD player.The main
featuresinclude a10.2"Wide Screen (16:9AspectRatio)Liquid Crys-
talDisplay (LCD)monitor andaDVD player.The unit appliesthe
latest state ofthe art electronics and isdesigned foruse in vehicles,
hotels,officesoryourhome.Theunitis constructed toprovide years
of reliable,trouble-free service, andiscompact sothatyou can take
it with you anywhere and is designed for quickand easyinstallation.
Please read the entireinstruction manual supplied with thisproduct
prior tousing.The documentation willassist you inusingthesystem
properly to obtainthebest equipment performance.Please save this
manual for later use.
B. Cautions and Warnings
1. Placement
Toprevent fireorelectric shock,donotexpose this appliance to
rainor moisture. Keep the unitawayfrom strong magnets, heat
sources,directsunlight, excessive dust.If the unit is brought di-
rectly from acold toa warmlocation, moisturemay condense in-
side the unit. When the unit is moved from a cold to a warm loca-
tion, wait about one hour before operatingthe unit, or removethe
disc andleave the unit turned on until the moisture evaporates.
2. Installation
Ensure thatthe D2017 portable DVDplayer is used in accordance
with the instructions and illustrations provided in this manual.
3. Objects and Liquids
Do not push objects ofany kindinto the unit throughopenings;
do not spill or sprayliquid ofanykind on or in the system (this
mayresult in a fire or electric shock). Do not place anything
heavy onthe unit. Toensure proper ventilation and proper
PDF created with FinePrint pdfFactoryPro trial version http://www.fineprint.com

5
operation,never cover or blocktheslots and openings with acloth
or other material. It is hazardousto replacethebattery incorrectly.
Replacethebatteryonly with thesame or equivalenttype.In order
to protect the environment, please dispose the batteryproperly.
Do not use the unit in temperatures higher than 95 degrees Fahr-
enheit or 35 degrees Celsius.
4.Disassembly
Donot attempt to disassemblethe unit.Thereisa riskofelectric
shockand/orexposure to LaserRadiation. Contactqualifiedser-
vicepersonnel ifyour system needs repair.
5.Cleaning Unit
Whencleaning,makesurethesystem isunplugged fromthepower
source. Donotuseliquid cleaners or aerosolcleaners. Usea cloth
lightly dampenedwith waterfor cleaningtheexterior ofthe system
only.
6. Discs
Do not use irregularlyshaped discs such asheart orstar-shaped
discs as theymay cause the unittomalfunction.Donotstickpaper,
tapeor glue on the disc. Do not expose thedisc to direct sunlight
or heat sources. Do not touchthe surface ofdisc. Handle thedisc
by itsedge. Cleanthedisc bywipingthedisc from the center out
with acleaning cloth. Removethe disc from the unit and store it in
its case after playing. Some playbackoperationsofdiscs maybe
intentionally fixed bysoftwareproducers. Since this unitplays discs
according to the disc contentsthesoftwareproducers designed,
some playbackfeatures maynot be available. Also refer to the in-
structionssuppliedwiththediscs.
PDF created with FinePrint pdfFactoryPro trial version http://www.fineprint.com

6
7.RegionalCoding
Both the DVD player and DVD discs are coded by region. These
regional codes must match inorder for thedisc toplay.Ifthe
codesdon’t match, the disc won’t play. This unit’s code is region
1. DVDs discs with other regional codes cannot be played in this
unit
C. Contents
1. 1x 10.2’’ LCDMonitor & DVD Player Combo
2. 1 xRemote Control with battery(CR2025)
3.1 x Audio/VideoAdapterCable
4. 1 xAC to DCAdapter
5. 1 xDC Power Adapter
6. 1x Instruction Manual
7. 1 xRechargeable Battery
D. Powering and Installation
1. Powering the system indoors (Refer to Figure 1)
Plug one end of theAC to DC adapterinto the DCinputjackon the
left side ofthe mainunit, then plugthe otherend intothe 110~240V
AC power receptacle.
2. Powering the systemin a car
Plug one end ofthe DC Power adapter into the DC input jackon
theunit, then plug the other end intothe vehiclepower outlet.
Figure1
Note: Unplugthe D2017when not in use.
DC 9V
ONOFF
OUT IN
A/V
U
S
B
PDF created with FinePrint pdfFactoryPro trial version http://www.fineprint.com

7
E. Controls, Indicators and Connectors
1. UnitView (Refer to Figure2)
Figure 2
* Connectingto headphone jacknumber 1 will disable the
internal speakers
1
2
3
4
5
78910
11
12
13
14
15
16
17
18
19
6
1) Release Button ofBattery
2) DC 9V InputJack
3)AVJack
4)AVIn/Out SW
5) USB Port
6)Power On/Ooff SW
7) SD/MMC/MS Slot
8)Power LED
9)Remote Control Sensor
10) Cover Open Switch
11) Charge Indicator
12)Headphone Jack 1*
13)HeadphoneJack 2
14)Volume Control
15) LCD Panel shut off
16) Wide Button
17) Previous/Next/Pause/Stop/Play
18)MenuButton
19) Up/Down/Left/Right/OK Button
PDF created with FinePrint pdfFactoryPro trial version http://www.fineprint.com

8
2.Remote Control (Refer to Figure3)
1)DVD/SD-USB Button
2) DisplayButton
3) Skip-Button
4) Menu Button
5) LeftButton
6)AngleButton
7) Stop Button
8) SetupButton
9)NumericButtons
10) Brightness Decrease Button
11)AudioButton
12) Subtitle Button
13) Up Button
14) Skip+ Button
15) Enter Button
16) Right Button
17) DownButton
18) Play/Pause Button
19) ZoomButton
20)A-B Repeat Button
21) Brightness Increase Button
22) 1-All Repeat Button
F. Loading and Playing a Disc
a.Afterconnectingpowerto the unit, settheDVDplayertoON using
the power switch. The power indicator will light.
b.Openthedisctrayby sliding theOPEN switch inthe directionof
the arrow. Place a disc in the traywith label sidefacingup.
c.Closethe trayby pressingthearea marked PRESS”.Theunitwill
load the discand start playing.
d.Rotate VOLUME controltoadjusttheDVD player’svolume.and
usetheremote controlBRIGHTbuttonto adjust theLCD’sbright-
ness.
e. To stopplaying adisc,pressSTOP.
Figure 3
PDF created with FinePrint pdfFactoryPro trial version http://www.fineprint.com

9
G. Basic Operation
POWER
OPEN
PLAY/PAUSE
STOP
NEXT
PREVIOUS
FORWARD
REVERSE
LEFT/RIGHT/UP/DOWN
ENTER
NUMBERS
MENU
REPEAT
A-B
DISPLAY
SUBTITLE
AUDIO
ZOOM
SETUP
Turnthe uniton/off
Remove/load the disc
Start Play/Execute item or setting
Still Picture
(1 time) Stop and start at thepresent play-
back point
(2 times) Stop playbackand start from be-
ginning of disc
Goto thenextchapter, track or scene
during play back
Gobacktothe previouschapter, track
or scene duringplayback
Scan forward at 2, 4, 8,16 or
32 times speed
Scan backward at 2, 4, 8, 16or
32 times speed
Used forMenu Navigation
Execute item or confirm setting
Select item or setting
Display the mainmenu ofthe disc
Repeat playingtitle, chapter, or track
Repeat a specific portionfrom
point A to pointBof thedisc
Displayinformation (title, chapter,
track, time, etc.).
Selectthesubtitlelanguageorturn iton/off
Selecttheaudio language
Enlargean imageto 2, 3, or 4 times the
original size.
Displaythe setup menuto select and
set itemsand exit the setup menu.
PDF created with FinePrint pdfFactoryPro trial version http://www.fineprint.com

10
H.Menu
A DVD is divided into sections called titlesandchapters. When you
playaDVD’sroot menu of thediscwill appear on the screen of your
TV orMonitor. Thecontentsof themenu varyfrom disc todisc.Press
MENU duringplaybackto display the menu. Some DVDs onlyallow
you to select disc playbackoptionsusingtheDVD root menu.
I. Display
1. PLAYINGTIME AND REMAININGTIME
a. Duringplaybackpress the ‘DISPLAY’button to displaythe cur-
rent Title Number (1), the total Number ofTitles (2), the current
ChapterNumber (3), thetotal Numberof Chapters (4), andthe
elapsed playingtime for the title (5).
Title, Chapter Number, and TimeScreenDisplay
b.Press ‘DISPLAY’repeatedlyto choosethe optionsbelowin
sequence.
TitleElapsed: The elapsedtime ofthe title
Title Remain:The remaining time ofthe title
Chapter Elapsed: The elapsed time ofthe chapter
Chapter Remain: The remainingtime ofthe chapter
Display Off: TheDVD’stimeinformation isremoved fromthedisplay.
Title Elapsed
TitleRemain
Chapter Elapsed
Chapter Remain
DisplayOff
PDF created with FinePrint pdfFactoryPro trial version http://www.fineprint.com

11
Audio Language
2. SUBTITLE
Duringdisc playbackpress ‘SUBTITLE’toselectthe subtitle language
youdesire*,withthecurrentSubtitle LanguageNumber(1) andthe
total Number of Subtitle Languages(2)displayed. Ifthere are mul-
tiplelanguagespress ‘SUBTITLE’againto selectanother subtitlelan-
guage.Toturn subtitles OFF,press the ‘SUBTITLE’button until ‘Sub-
titleOff’isdisplayed.TheSubtitledisplay willdisappearautomatically
ifthe ‘SUBTITLE’button is not pressed again within 3 seconds.
*Some DVDsonly allowaccessto this functionthrough theDVDmenu
3. AUDIO
During playbackpress ‘AUDIO’to select theaudio languageyou de-
sire*, with the current Audio Channel Number (1) and the total num-
ber of AudioChannels(2)displayed.PressAUDIOagain to select
anotheraudio language. The audiodisplaywill disappear automati-
callyifthe ‘AUDIO’button is not pressed within for 3 seconds.
*SomeDVDsonly allow accessto this functionthrough theDVD menu.
Subtitle
PDF created with FinePrint pdfFactoryPro trial version http://www.fineprint.com

12
4.ZOOM
During playbackpress ‘ZOOM’mutiple timesto enlarge the picture
by 2X, 3Xor4X.
.
Zoom
5. A-B REPEAT
a. Duringplaybackpress the ‘A-B’buttononce to set the Starting
PointA.
b. Press ‘A-B’asecond time to set the EndingPoint B. The
playerwill repeatedly playthe partbetween PointAand Point B.
c.PressA-Bathird time to cancelA-Brepeat (REPEATOFF)
andresumenormalplayback.
A-B Repeat Starting Point A-BRepeatEnding Point A-B Repeat Cancelled
PDF created with FinePrint pdfFactoryPro trial version http://www.fineprint.com

13
6.REPEAT
a.Duringplaybackpress ‘REPEAT1/ALL’repeatedlytocycle through
therepeat modes.
Chapter: Repeat the current chapter
Title: Repeat the current title
All: Repeat all chapters and titles
Repeat Off: Resume normal playback
J. Playing Audio CDS
When playing an audio CD pressthe DISPLAY button repeatedly on
theremoteto viewtimeinformation.Theoptions belowappear on
screendisplayinsequence toshow youwhatinformationis available
usingthis function.
CD Display Mode
Single Elapsed: The current track playing and theelapsed time ofthat
track will be displayed on the screen.
Single Remain: The current trackplayingand the amount oftime
remaining.
Single Elapsed
SingleRemain
TotalElapsed
TotalRemain
Display Off
Single Elapsed When Playing Audio CDs
PDF created with FinePrint pdfFactoryPro trial version http://www.fineprint.com

14
Total Elapsed: The current track playingand the total time that the
CD hasbeen playing.
Total Remain:The current track playingand the amountoftime
remaining on the CD.
Display Off:The CD time information is removed from the
display.
USING THE1/ALLREPEATFEATURE
Thedefaultmodefor the1/ALLREPEATfeatureis OFF.Pressing 1/All
REPEAT button consecutivelychangesthe repeat options:
•Track-repeats the track that isplaying.
•All-repeats the disc that isplaying.
•Repeat Off
Asyou toggle throughthe options,the repeatoptionchanges. The selected
repeat option willplay untilturnedoff.
NOTE: The A-B Repeat feature functions in the same way for an audio
CD as it doesfor a DVD disc.
K. Playing MP3 Discs
MP3isa format for storingdigital audio.AnaudioCD-quality songis
compressed into theMP3 format with very littleloss ofaudio quality
whiletaking up much less disc space.CD-R/RWdiscs that have
beenencoded in MP3formatare compatible with this system.
Whenan MP3discis insertedintothe unit, themenuscreenappears
automatically.Youcanuse themenuscreentoselect your desired
foldersandsongs orthesystem plays thesongs in theorder they
were burned onto the disc.
1.Press the or buttontochoosea folderfrom thefolder liston
the leftsideof the screen.
2. Press ENTERto select thehighlighted folder. The songs avail-
able under the folder willbe listed.
3.Use or buttontochooseasongfromthe list. PressENTER
to select and begin playback ofthehighlightedsong.
PDF created with FinePrint pdfFactoryPro trial version http://www.fineprint.com

15
4.Use the( NEXT)button to move tothenext song. Press
the (PREVIOUS)buttonto movetothebeginningoftheprevious
song.
USING THE1/ALLREPEATFEATURE
The default mode for the 1/ALLREPEAT featureis OFF. Pressing
1/ALLREPEATconsecutively changes the repeat options:
•Repeat One (repeat playback ofa song)
•Repeat Folder (repeatplaybackofa specific folder)
•RepeatOff (normal playback)
As youtoggle through the options, the repeat option changes. The
selected repeat option will play until turned off.
NOTE: The A-B Repeat feature functions in the samewayfor an au-
dioCD as itdoesfora DVD disc.
NOTE:
”iconinfrontofafilenameindicatesthatthis is afolder, not
anMP3file.
MP3”iconinfrontofafilenameindicates that thisis aMP3 file.
NOTE: Due to the company’spolicyof constant improvement and
technical refinement, thecompanyreservesthe right to change or al-
ter software.
PDF created with FinePrint pdfFactoryPro trial version http://www.fineprint.com

16
Figure4
2. Connecting toa Game or Camcorder (Refer toFigure 4)
a. Position the AV In/Out Switch to In”Position.
b. Connect one end ofthe audio/video cable’s black(1/8”plug)
plugintothe unit’s AV jackusinga standardA/V cable (not supplied),
and connect the otherendto the AUDIO/VIDEOoutput jacks on
your Camcorder or game (white = left audio channel, red= right
audio channel, yellow= video).
Note: Please do notconnectan AVsignal source totheAVjackwhen
theunit isin AVOut”Mode.
L. Viewing JPEG Files
1) Load the JPEG Disc intotray.
2) Select a JPEG file by pressing UP/DOWN”button.
3) You can preview the JPEGfile by pressing PLAY”or ENTER”.
4) Pressingthe Down”button will rotatethe picture clockwise.
5) Pressingthe Up”button will access the main menu.
M. Connecting to other Electronic Equipment
1. Connecting toa TV oranother monitor (Refer to Figure4)
a. PositiontheAVIn/Out Switchto Out”Position.
b.Connectone endofthe audio/videoadaptercable’sblack1/8”plug
into the unit’sAVjack.Using astandardA/Vcable(notsupplied),
connecttheotherend totheAUDIO/VIDEOInputjacksonyourTVor
Monitor (white=left audio channel, red =right audiochannel,
yellow=video).
NOTSUPPLIED
PDF created with FinePrint pdfFactoryPro trial version http://www.fineprint.com

17
3.Headphones
Optionalwiredheadphones maybeusedwiththe unit.Simply plugin
theheadsettoeither Headphone1jack orHeadphone2jack onthe
rightside of theDVD. (Refer toFigure5.)
Figure5
PluggingintoHeadphonejack1disablestheinternalspeakers.
4.SD/MMC/MSCardand ThumbDrive/DigitalCameras
With nodiscintheunit, insert eitheranSD card,ThumbDrive, or digital
camera with JPEGor MP3filesintothe appropriateinput. Press the
DVD/SD-USBbutton the appropriate position.Thenyoucan:
1) Insert anSDCard into theSD Slot onthe frontoftheunit.
2) Insert aThumb Driveintothe USBjackonthe left sideof theunit.
3)Connect theUSB cable (not supplied)fromacameraintotheUSB
port ontheleftsideoftheunit.
**
PDF created with FinePrint pdfFactoryPro trial version http://www.fineprint.com

18
N. Setup
1. GeneralSetup Page
1)Withnodiscinsidethe player,press ‘SETUP’to display theMain screen
ofthe Setup Menu on the screen and General Setup Page”appears.At
the same time, ” ishighlighted. Press ‘SETUP’againto exitthe
Setup Menu.
2) Press the or buttons to select the other menus in general
setuppage.
3) With TV Display”highlighted press the ENTERbutton.
4) Press to enter the submenu.
5) Press the or buttonto select the desired option in the sub
menu and press the ENTER to confirm your selection.
6) Repeat steps 3-5 for other menus.
Note: Press toreturn theprevious menu.
a) TVDisplay
* Normal/PS: Whenthe player outputs signal to a normal TV, a nor-
mal picture is shown on the full screen.
* Normal/LB: When the player outputs signal to a normal TV, a nor-
mal pictureis shownon thescreen withablackstrip atboththetop
andbottom ofthescreen.
*Wide:Whenthe player outputs signalto awide screenTV, a
wide picture is shown on the full screen.
b) Angle Mark
*On: Allows access to the anglefeature ifcontained on the DVD.
*Off: Theunit will not display the angle markfeature.
NOTE: Not all discs contain above features. Theabovefeaturesare
discdependent.
b) Screen Saver
*On:Enables screensaver
*Off:Disables screensaver
*NOTE: The DVD playerwill enter the Screen Savermode after ap-
proximately threeminutesifthe same image remains on the screen.
PDF created with FinePrint pdfFactoryPro trial version http://www.fineprint.com

19
2.Video QualitySetup
1)InSetupmenu, Pressthe or buttonto select Video Quality
Setup”and is highlighted. Press ENTER toenter the video quality
setuppage.
2) Press the or button to select the other options inthe video
qualitysetuppage.
3) Brightness”is highlighted.
4) Press to enter the sub menu.
5) Press the or buttonrepeatedly toadjust theselected option
and press ENTER to confirm your selection.
6) Repeat steps 3-5 for other menus.
NOTE: Press to return the previous menu.
a) Brightness b) Contrast
c) Saturation d) Hue
3.Password
In the Setup menu, Press the or button to select Password
Setup Page”and is highlighted. PressENTERto enter the password
page.
PressENTERtwice to enter thePassword Change Page.Input the Old
Password or the Default Password, the New Password, and Confirmed
the NewPassword. Press ENTER to confirm the change.
NOTE: Thedefault password is 3308.
4.PreferencePage
1) In Setupmenu, Press the or button to select Preference
Page”and is highlighted.Press ENTER toenterthepreference page.
2) Press the or button to select the other options in the preference
page.
3) Pressthe ENTER button, Audio”ishighlighted.
c) Last Memory
*On: The unit will return to the last position on the disc.
*Off: Theunit will not return to the last position on the disc.
Note:TheLast position memoryfunction will only work when the
disctray is OPEN.
PDF created with FinePrint pdfFactoryPro trial version http://www.fineprint.com

20
4) Press to enter the submenu.
5) Press the or button to select the desired option and press
ENTER to confirm your selection.
6) Repeat steps 3-5 for other menus.
Note: Press to return theprevious menu.
a)Audio
b) Subtitle
c) DiscMenu
Note: Language and subtitle selectionis onlyavailablefor discsthat
are recordedin theabovelistedlanguages.Iftheselected language
isnot available,theplayer willplayand displayonthe screenthe
original recordedlanguage containedinthedisc.
d) Parental
Select ‘Parental’usingtheand button,thenpress toenter the
submenu.
Selectthe parental level you desireusingand the button for discs
with lock-out function or multiple ratinglevels. These arelistedfrom the
lowest level (1KID SAFE) to the highest level(8ADULT). Press ENTER
andinput 4 digit password, then press ENTERagain toconfirm the pa-
rental levelsetting.
NOTE: The levelof8Adult isthe factorydefault.
e) Default
Select ‘Default’usingthe and button, then press to enter the
submenu. Press ENTER tomake all of the settings return to the factory
set mode.
NOTE: The parental settingand the password settingare not affected
by the default reset function.
NOTE: TheDefault Password is 3308.This password is alwayseffec-
tive even afteryou haveselected yourownpasswordand changed it. To
avoidthe possibilityofothers usingthe default password to set the
parental level andchange thepassword, you canrecordthis default
passwordin anotherareaand delete itfrom this manual. Somediscs
canbelimited dependingonthe ageofusers whilesomediscs cannot.
PDF created with FinePrint pdfFactoryPro trial version http://www.fineprint.com
