Audiovox ACD-30 Programming manual

AA
AA
A
CD-30CD-30
CD-30CD-30
CD-30
DETACHABLEFRONTPANEL
ELECTRONICALLY-TUNEDAM/FM/MPXRADIO
WITHPROGRAMMABLECDPLAYER
ANDQUARTZCLOCK

INDEXINDEX
INDEXINDEX
INDEX
How To Use This Manual .................................................................
Kit Information ..................................................................................
Universal and Import Car Installations ..............................................
Chrysler-Dodge-Plymouth Installations ............................................
Chevrolet-Oldsmobile-Pontiac-Buick-GMC Cadillac-Saturn
Installations ......................................................................
Ford-Lincoln-Mercury Installations ...................................................
Radio Wiring .....................................................................................
Speaker Wiring : 4-Speaker Systems ...............................................
2-Speaker Systems .............................................
Operating Instructions ......................................................................
Setting the Clock ..............................................................................
Specifications ...................................................................................
Troubleshooting ................................................................................
Care and Maintenance .....................................................................
Warranty ...........................................................................................
Page 1
Page 2
Page 3,4
Page 5
Page 6
Page 7
Page 8
Page 9
Page 10
Page 11-15
Page 15
Page 16
Page 17
Page 18
Back Page
11
11
1
HOW TO USE THIS MANUALHOW TO USE THIS MANUAL
HOW TO USE THIS MANUALHOW TO USE THIS MANUAL
HOW TO USE THIS MANUAL
1. Identify the make and year of the car in which you will be installing this sound system.
2. Refer to the Kit Listing and Kit Information sections on page 2 to determine if a kit is required.
3. If a kit is required, follow the directions in Kit Information section.
4. Follow the specific installation instructions for your particular make of car as listed in the index.
1-800-645-7102
8:30AM - 7PM
9AM - 5PM
7:30AM - 6PM
8AM - 4PM
CENTRAL EASTERN
6:30AM - 5PM
7AM - 3PM
MOUNTAIN
5:30AM - 4PM
6AM - 2PM
PACIFIC
MON.-FRI.
SATURDAY
DAY
TIME ZONE
Toll-FreeAssistanceToll-FreeAssistance
Toll-FreeAssistanceToll-FreeAssistance
Toll-FreeAssistance
The installation and wiring connections for this unit are so simple, we doubt you'll need our
help, but, if you do, we're here to help you. Just call our toll-free telephone assistance line
at [phone] during days/hours shown.
Monday-Friday
Saturday
8:30am-7:00pmEastern
9:00am-5:00pmEastern
HELP!

IMPORT CARSIMPORT CARS
IMPORT CARSIMPORT CARS
IMPORT CARS
Due to the wide variety of import cars and the different installations required, this manual does not show
typical installations in these vehicles. However, this sound system can be installed in many import cars
by following the "Universal Installation" section on pages 3 and 4. Check the application chart at your retail
store or call our toll-free "HELP" line for specific information on your particular car.
22
22
2
KIT INFORMATIONKIT INFORMATION
KIT INFORMATIONKIT INFORMATION
KIT INFORMATION
1. The years shown in the Kit Listing below are approximate. Always check the application chart at your
retail store to find information on your specific make, model and year of vehicle. If a kit is required, read
the description on the kit you intend to purchase to make sure it applies to your vehicle. If you have
any doubts or questions, call our toll-free "HELP" line.
2. The kits shown below are Audiovox kits. Your retailer may sell kits made by other manufacturers which
may also be usable to install this radio. Always check the kit application before purchasing it to make
sure it will work with your vehicle.
3. If you believe you need a kit but cannot find a retail store where it is available, call our toll-free "HELP"
line.
KIT LISTINGKIT LISTING
KIT LISTINGKIT LISTING
KIT LISTING
VEHICLE TYPE
Chevrolet-Oldsmobile-Buick-Pontiac-Cadillac-Saturn
1981 and Older ..............................................................
1982 and Newer .............................................................
Chevrolet-GMC Full Size Vans
1988 and Newer ..............................................................
Chevrolet-GMC Full Size Pickups
1988 and Newer ..............................................................
Chrysler-Dodge-Plymouth
U.S. Built 1974 and Newer ..............................................
Imported ..........................................................................
Ford-Lincoln-Mercury
1984 and Older ...............................................................
1985 and Newer ..............................................................
Jeep-Eagle
1984 and Newer ..............................................................
KIT REQUIREMENT/NOTES
Installation Not Possible
AX-93-FCGM
AX-88-CHV
AX-88-CHT
AX-93-FCGM
Refer to In-Store Chart
Installation Not Possible
AX-93-FCGM
Filing of Dash Required
IMPORTS:
Acura-Audi-BMW-Daihatsu-Fiat-Honda-Hyundai
Mercedes-Peugeot-Porsche-Saab-Subaru
Volkswagen-Volvo-Yugo................................................
Datsun-Nissan................................................................
Mazda.............................................................................
Toyota............................................................................
Will Fit Most Years; Some Require
Filing of Dash
Refer to In-Store Chart
Professional Installation Recommended
Professional Installation Recommended
For vehicles not listed or more specific information, refer to the in-store application chart or call our "HELP"
line.

33
33
3
UNIVERSAL INSTALLATION AND IMPORT CAR INSTALLATIONUNIVERSAL INSTALLATION AND IMPORT CAR INSTALLATION UNIVERSAL INSTALLATION AND IMPORT CAR INSTALLATIONUNIVERSAL INSTALLATION AND IMPORT CAR INSTALLATION
UNIVERSAL INSTALLATION AND IMPORT CAR INSTALLATION
REMOVALTOOLS
RADIO
HELP!
USETEMPLATETOCHECKOPENINGSIZE
ORTOCUTOPENINGINSOLID
DASHBOARDS
UNIVERSAL INSTALLATION AND IMPORT CAR INSTALLATIONUNIVERSAL INSTALLATION AND IMPORT CAR INSTALLATION
UNIVERSAL INSTALLATION AND IMPORT CAR INSTALLATIONUNIVERSAL INSTALLATION AND IMPORT CAR INSTALLATION
UNIVERSAL INSTALLATION AND IMPORT CAR INSTALLATION
This installation is designed for cars, trucks, vans, and boats that have an existing radio opening that is
no larger than the size shown on the template provided (182mm wide x 53mm high). If the opening is
smaller than required, you can use a file to enlarge it to match the template, using theslots on the template
as a guide. If you have no existing radio opening, use the template to accurately cut the required size
as per the slots on the template.
CAUTION: 1. DO NOT CUT OR FILE THE OPENING TO THE OUTER EDGES OF THE TEMPLATE!
2. FOR PROPER OPERATION OF THE CD PLAYER, THE CHASSIS MUST BE WITHIN 20° OF
HORIZONTAL. MAKE SURE THE UNIT IS MOUNTED WITHIN THIS LIMITATION.
1. Inspect the Existing Radio Opening:
A. Use the radio opening template (supplied) to make sure the dashboard opening is the proper size.
If your vehicle does not have an existing opening of this size, it will be necessary to cut or file the
opening to these dimensions.
B. Check that there will be sufficient space behind the dashboard for the radio chassis.
2. PreparetheRadioforinstallation:
A. Carefully check the radio chassis for any shipping screws that are labeled "Remove Before
Installation" and remove them as necessary.
B. Remove the detachable front panel if it is attached to the chassis, as explained in the Operating
Instructions section of this manual.
C. Using the 2 removal tools (supplied), remove the mounting sleeve from the radio chassis as shown
in the diagram below.
3. Mounting the Radio Sleeve:
A. Check the dashboard opening size by sliding the mounting sleeve into it. If the opening is not large
enough, carefully cut or file as necessary until the sleeve easily slides into the opening. Do not
force the sleeve into the opening or cause it to bend or bow.
B. Locate the series of bend tabs along the top, bottom, and sides of the mounting sleeve. With the
sleeve fully inserted in the dashboard opening, bend as many of the tabs outward as necessary
so that the sleeve is firmly secured to the dashboard.
Monday-Friday
Saturday
8:30am-7:00pmEastern
9:00am-5:00pmEastern
1-800-645-7102
REMOVABLEFRONTPANEL
(REFERTOOPERATING
INSTRUCTIONSFORREMOVAL)
MOUNTINGSLEEVE
MOUNTINGANGLELIMITATION
SIDEVIEW
OF
CHASSIS
20°
MAX.
20°
MAX.
FRONT
PANEL

44
44
4
UNIVERSAL INSTALLATION AND IMPORT CAR INSTALLATIONUNIVERSAL INSTALLATION AND IMPORT CAR INSTALLATION UNIVERSAL INSTALLATION AND IMPORT CAR INSTALLATIONUNIVERSAL INSTALLATION AND IMPORT CAR INSTALLATION
UNIVERSAL INSTALLATION AND IMPORT CAR INSTALLATION
UNIVERSAL INSTALLATION AND IMPORT CAR INSTALLATIONUNIVERSAL INSTALLATION AND IMPORT CAR INSTALLATION
UNIVERSAL INSTALLATION AND IMPORT CAR INSTALLATIONUNIVERSAL INSTALLATION AND IMPORT CAR INSTALLATION
UNIVERSAL INSTALLATION AND IMPORT CAR INSTALLATION
4. Wire the Radio to the Vehicle's Wiring:
A. Place radio in front of dashboard opening so that wiring can be brought through the mounting sleeve.
B. Carefully follow the diagrams on pages 8 and 9 to wire the radio, making certain all connections
are secure and insulated with wire nuts or electrical tape to insure proper operation of the unit.
C. After completing the wiring, re-attach the front panel to the chassis and turn the unit on to confirm
operation (ignition switch must be "on"). If unit does not operate, re-check all wiring until problem
is corrected.
D. Once proper operation is achieved, turn off ignition switch, remove front panel, and proceed with
final mounting of the radio.
5. Installing the Radio in the Mounting Sleeve:5. Installing the Radio in the Mounting Sleeve:
5. Installing the Radio in the Mounting Sleeve:5. Installing the Radio in the Mounting Sleeve:
5. Installing the Radio in the Mounting Sleeve:
A. Carefully slide the radio into the mounting sleeve until it is fully seated and the side spring clips snap
in place.
B. Attach one end of the perforated strap (supplied) to the screw stud on the rear of the radio using
the hex nut provided.
C. Fasten the other end of the perforated strap to a secure part of the dashboard either above or below
the radio using the screw and hex nut provided.
CAUTION: The rear of the radio must be supported with the strap to prevent possible damage to the
dashboard from the weight of the radio or improper operation of the radio due to vibration.
D. Re-attach the front panel to the chassis and check operation of the unit by referring to the Operating
Instructions section of this manual.
6. Removing the Radio:
A. Should it be necessary to remove the radio for servicing or other reasons, first remove the
detachable front panel.
B. Remove the rear support strap by taking off the hex nut securing it to the screw stud on the rear
of the chassis.
C. Use the 2 removal tools (supplied) to disengage the side spring clips and pull the radio out of the
mounting sleeve.
PERFORATEDSTRAP
HEXNUT
BENDTABSTOSECURE
SLEEVETODASH
SLIDERADIOINTOSLEEVE
SCREWSTUD
BENDBOTTOM
TABSDOWNWARD
BENDTOP
TABSUPWARD
HEXNUT

55
55
5
CHRYSLER-DODGE-PLYMOUTH INSTALLATIONCHRYSLER-DODGE-PLYMOUTH INSTALLATION CHRYSLER-DODGE-PLYMOUTH INSTALLATIONCHRYSLER-DODGE-PLYMOUTH INSTALLATION
CHRYSLER-DODGE-PLYMOUTH INSTALLATION
CHRYSLER-DODGE-PLYMOUTH INSTALLATIONCHRYSLER-DODGE-PLYMOUTH INSTALLATION
CHRYSLER-DODGE-PLYMOUTH INSTALLATIONCHRYSLER-DODGE-PLYMOUTH INSTALLATION
CHRYSLER-DODGE-PLYMOUTH INSTALLATION
All U.S. Made Cars, Trucks, and Vans Built Since 1974All U.S. Made Cars, Trucks, and Vans Built Since 1974
All U.S. Made Cars, Trucks, and Vans Built Since 1974All U.S. Made Cars, Trucks, and Vans Built Since 1974
All U.S. Made Cars, Trucks, and Vans Built Since 1974
Important-This radio cannot be installed in any U.S. made Chrysler, Dodge, or Plymouth without an
installation kit. Refer to Kit Listings on page 2 for the required kit. Complete kit installation is explained
in the instructions included with the kit.
CAUTION: 1. DO NOT CUT OR FILE THE OPENING TO THE OUTER EDGES OF THE TEMPLATE!
2. FOR PROPER OPERATION OF THE CD PLAYER, THE CHASSIS MUST BE WITHIN 20° OF
HORIZONTAL. MAKE SURE THE UNIT IS MOUNTED WITHIN THIS LIMITATION.
1. Remove Existing Radio:1. Remove Existing Radio:
1. Remove Existing Radio:1. Remove Existing Radio:
1. Remove Existing Radio:
A. Remove existing radio dash trim panel surrounding the radio opening. This panel is usually
secured by screws and/or snap-in clips.
B. Remove the two large screws used to secure radio to the sub-dashboard.
Helpful Hint: If you do not have an existing radio, you will find the radio opening is covered by a
disposable cover plate.
C. Pull the radio forward to access the wiring and antenna cables plugged into the rear of the chassis.
D. Un-plug the wiring harness(es) and antenna cable and remove the radio.
2. Install the New Radio:2. Install the New Radio:
2. Install the New Radio:2. Install the New Radio:
2. Install the New Radio:
A. Following the instructions included with the installation kit, secure the sleeve from the radio to the
mounting plate from the kit as explained on page 3.
B. Install the sleeve/mounting plate assembly to the sub-dashboard as per the instructions with the
installation kit.
C. Replace the dashboard trimpanel.
D. Following the instructions of steps 4 and 5 on page 4, carefully wire the radio and complete
installation into the mounting sleeve.
FACTORYDASHPANEL
RADIO
REMOVALTOOL
MOUNTINGSLEEVE
INSTALLRADIOUSINGSAME
PROCEDUREASEXPLAINED
ONPAGES3AND4
SUB-DASHBOARD(RADIOAREA)
MOUNTINGPLATEFROMKIT
(NOTINCLUDEDWITHRADIO)
IMPORTANT
AMOUNTINGKITISREQUIRED
FORTHISINSTALLATION
HELP!
8:30am-7:00pmEastern
9:00am-5:00pmEastern
Monday-Friday
Saturday
1-800-645-7102
DETACHABLE
FRONTPANEL

66
66
6
CHEVROLET-OLDS-BUICK-PONTIAC-GMC-CADILLAC-SATURN INSTALLATIONCHEVROLET-OLDS-BUICK-PONTIAC-GMC-CADILLAC-SATURN INSTALLATION CHEVROLET-OLDS-BUICK-PONTIAC-GMC-CADILLAC-SATURN INSTALLATIONCHEVROLET-OLDS-BUICK-PONTIAC-GMC-CADILLAC-SATURN INSTALLATION
CHEVROLET-OLDS-BUICK-PONTIAC-GMC-CADILLAC-SATURN INSTALLATION
INSTALLRADIOUSINGSAME
PROCEDUREASEXPLAINED
ONPAGES3AND4
SUB-DASHBOARD
(RADIOAREA)
MOUNTINGPLATEFROMKIT
(NOTINCLUDEDWITHRADIO)
FACTORYDASHPANEL
MOUNTINGSLEEVE
RADIO
DETACHABLEFRONTPANEL
REMOVALTOOLS
IMPORTANT
AMOUNTINGKITISREQUIRED
FORTHISINSTALLATION
CHEVROLET-OLDSMOBILE-BUICK-PONTIAC-GMC-CADILLAC-SATURN INSTALLATIONCHEVROLET-OLDSMOBILE-BUICK-PONTIAC-GMC-CADILLAC-SATURN INSTALLATION
CHEVROLET-OLDSMOBILE-BUICK-PONTIAC-GMC-CADILLAC-SATURN INSTALLATIONCHEVROLET-OLDSMOBILE-BUICK-PONTIAC-GMC-CADILLAC-SATURN INSTALLATION
CHEVROLET-OLDSMOBILE-BUICK-PONTIAC-GMC-CADILLAC-SATURN INSTALLATION
All U.S. Made Cars, Trucks, and Vans Built Since 1982All U.S. Made Cars, Trucks, and Vans Built Since 1982
All U.S. Made Cars, Trucks, and Vans Built Since 1982All U.S. Made Cars, Trucks, and Vans Built Since 1982
All U.S. Made Cars, Trucks, and Vans Built Since 1982
Important-This radio cannot be installed in any "GM" vehicle without an installation kit. Refer to Kit Listings
on page 2 for the required kit. Complete kit installation is explained in the instructions included with kit. This
radio cannot be installed in GM vehicles built before 1982.
CAUTION: 1. DO NOT CUT OR FILE THE OPENING TO THE OUTER EDGES OF THE TEMPLATE!
2. FOR PROPER OPERATION OF THE CD PLAYER, THE CHASSIS MUST BE WITHIN 20° OF
HORIZONTAL. MAKE SURE THE UNIT IS MOUNTED WITHIN THIS LIMITATION.
1. Remove Existing Radio:1. Remove Existing Radio:
1. Remove Existing Radio:1. Remove Existing Radio:
1. Remove Existing Radio:
A. Remove existing radio dash trim panel surrounding the radio opening. This panel is usually secured
by screws and/or snap-in clips.
B. Remove the screws used to secure radio to the sub-dashboard.
Helpful Hint: If you do not have an existing radio, you will find the radio opening is covered by a
disposable cover plate.
C. Pull the radio forward to access the wiring and antenna cables plugged into the rear of the chassis.
D. Un-plug the wiring harness(es) and antenna cable and remove the radio.
2. Install the New Radio:2. Install the New Radio:
2. Install the New Radio:2. Install the New Radio:
2. Install the New Radio:
A. Following the instructions included with the installation kit, secure the sleeve from the radio to the
mounting plate from the kit as explained on page 3.
B. Install the sleeve/mounting plate assembly to the sub-dashboard as per the instructions with the
installation kit.
C. Replace the dashboard trimpanel.
D. Following the instructions of steps 4 and 5 on page 4, carefully wire the radio and complete
installation into the mounting sleeve.

77
77
7
FORD-LINCOLN-MERCURY INSTALLATIONFORD-LINCOLN-MERCURY INSTALLATION
FORD-LINCOLN-MERCURY INSTALLATIONFORD-LINCOLN-MERCURY INSTALLATION
FORD-LINCOLN-MERCURY INSTALLATION
All U.S. Made Cars, Trucks, and Vans Built Since 1985All U.S. Made Cars, Trucks, and Vans Built Since 1985
All U.S. Made Cars, Trucks, and Vans Built Since 1985All U.S. Made Cars, Trucks, and Vans Built Since 1985
All U.S. Made Cars, Trucks, and Vans Built Since 1985
Important-Measure the size of your existing radio opening. If it is no larger than the size shown on the
template provided, you can install the radio as explained on page 3 and 4. If the opening is larger, you
must use a kit. See Kit Listing on page 2. This radio cannot be installed in Ford cars built prior to 1985.
CAUTION: 1. DO NOT CUT OR FILE THE OPENING TO THE OUTER EDGES OF THE TEMPLATE!
2. FOR PROPER OPERATION OF THE CD PLAYER, THE CHASSIS MUST BE WITHIN 20° OF
HORIZONTAL. MAKE SURE THE UNIT IS MOUNTED WITHIN THIS LIMITATION.
1. Remove Existing Radio:1. Remove Existing Radio:
1. Remove Existing Radio:1. Remove Existing Radio:
1. Remove Existing Radio:
A. Remove existing radio dash trim panel surrounding the radio opening. This panel is usually
secured by screws and/or snap-in clips.
B. Remove the screws used to secure radio to the sub-dashboard.
Helpful Hint: If you do not have an existing radio, you will find the radio opening is covered by a
disposable cover plate.
C. Pull the radio forward to access the wiring and antenna cables plugged into the rear of the chassis.
D. Un-plug the wiring harness(es) and antenna cable and remove the radio.
2. Install the New Radio:2. Install the New Radio:
2. Install the New Radio:2. Install the New Radio:
2. Install the New Radio:
A. If a kit is not required, follow the instructions on pages 3 and 4. If a kit is required, follow the
instructions included with the kit and secure the sleeve from the radio to the mounting plate from
the kit as explained on page 3.
B. Install the sleeve/mounting plate assembly to the sub-dashboard as per the instructions with the
installation kit.
C. Replace the dashboard trimpanel.
D. Following the instructions of steps 4 and 5 on page 4, carefully wire the radio and complete
installation into the mounting sleeve.
FORD-LINCOLN-MERCURY INSTALLATIONFORD-LINCOLN-MERCURY INSTALLATION FORD-LINCOLN-MERCURY INSTALLATIONFORD-LINCOLN-MERCURY INSTALLATION
FORD-LINCOLN-MERCURY INSTALLATION
IMPORTANT
AMOUNTINGKITISREQUIRED
FORTHISINSTALLATION
SUB-DASHBOARD
(RADIOAREA)
MOUNTINGPLATEFROMKIT
(NOTINCLUDEDWITHRADIO)
FACTORYDASHPANEL
MOUNTINGSLEEVE
RADIO
REMOVALTOOLS
INSTALLRADIOUSINGSAME
PROCEDUREASEXPLAINED
ONPAGES3AND4
HELP!
Monday-Friday
Saturday
8:30am-7:00pmEastern
9:00am-5:00pmEastern
1-800-645-7102
DETACHABLE
FRONTPANEL

88
88
8
RADIO WIRINGRADIO WIRING
RADIO WIRINGRADIO WIRING
RADIO WIRING
REFERTOPAGE9FORSPEAKERWIRING
RADIO WIRINGRADIO WIRING RADIO WIRINGRADIO WIRING
RADIO WIRING
ANTENNASOCKET
ONREAROFRADIO
POSITIVE (+)TERMINAL
12VOLT BATTERY
CARBATTERY
METALPARTOFDASH
(DRILLHOLEIFNECESSARY)
SCREW
BLACKw/WHITESTRIPE
ORANGEw/WHITESTRIPE
EXISTING
ANTENNA
CABLE
"RADIO"OR
"ACCESSORY"FUSE
ANTENNA AUTOMATIC
ANTENNA
RADIO
CAR
FUSEBLOCK
GREENw/WHITESTRIPE
IMPORTANT
THISWIREMUSTBECONNECTEDASSHOWN
ORRADIOWILLNOTOPERATEPROPERLY
SEEPAGE9FORSPEAKERWIRING
(4PAIRSOFGREYWIRES)
14PINPLUG
MATING14PINSOCKET
PINK
IMPORTANT
THEPINKWIRECANBEUSED
TOREMOTELYACTIVATEAN
AUTOMATICANTENNAORAN
EXTERNALAMPLIFIER(SEE
ANTENNA OR AMPLIFIER
MANUAL)

HELP!
99
99
9
GREY
DRIVER'SSIDE
LEFTFRONTSPEAKER PASSENGER'SSIDE
RIGHTFRONTSPEAKER
DRIVER'SSIDE
LEFTREARSPEAKER
PASSENGER'SSIDE
RIGHTREARSPEAKER
RADIO
GREY
GREYw/YELLOWSTRIPE
GREY
GREY

SPEAKER WIRING - 4 SPEAKER SYSTEMSSPEAKER WIRING - 4 SPEAKER SYSTEMS
SPEAKER WIRING - 4 SPEAKER SYSTEMSSPEAKER WIRING - 4 SPEAKER SYSTEMS
SPEAKER WIRING - 4 SPEAKER SYSTEMS
REFERTOPAGE8
FORRADIOWIRING
SPEAKER WIRINGSPEAKER WIRING SPEAKER WIRINGSPEAKER WIRING
SPEAKER WIRING

WARNING!
NEVERGROUNDNEGATIVESPEAKERLEADSTOCHASSISGROUND.
FAILURETOWIREEXACTLYASSHOWNBELOWWILLCAUSEELECTRICALDAMAGETOTHERADIO.
MATING14PINSOCKET
14PINPLUG
SEEPAGE8FOR RADIO WIRING
(PINK,BLACKw/WHITE,
ORANGEw/WHITEAND
GREENw/WHITE)
RCAJACKS
FORUSEWITH
OPTIONALEXTERNAL
AMPLIFIERS
RED=RIGHTCHANNEL
WHITE=LEFTCHANNEL
GREYw/REDSTRIPE
GREYw/WHITE STRIPE GREYw/BLUESTRIPE
8:30am-7:00pmEastern
9:00am-5:00pmEastern
Monday-Friday
Saturday
1-800-645-7102

HELP!
1010
1010
10
SPEAKER WIRINGSPEAKER WIRING SPEAKER WIRINGSPEAKER WIRING
SPEAKER WIRING
SPEAKER WIRING - 2 SPEAKER SYSTEMSSPEAKER WIRING - 2 SPEAKER SYSTEMS
SPEAKER WIRING - 2 SPEAKER SYSTEMSSPEAKER WIRING - 2 SPEAKER SYSTEMS
SPEAKER WIRING - 2 SPEAKER SYSTEMS
REFERTOPAGE8
FORRADIOWIRING
DRIVER'SSIDE
(LEFT)SPEAKER PASSENGER'SSIDE
(RIGHT)SPEAKER
RADIO
GREYw/WHITE STRIPE GREYw/BLUESTRIPE
GREY GREY
GREY GREY
GREYw/REDSTRIPE


WARNING!
NEVERGROUNDNEGATIVESPEAKERLEADSTOCHASSISGROUND.
FAILURETOWIREEXACTLYASSHOWNBELOWWILLCAUSEELECTRICALDAMAGETOTHERADIO.
MATING14PINSOCKET
14PINPLUG
SEEPAGE8FOR RADIO WIRING
(PINK,BLACKw/WHITE,
ORANGEw/WHITEAND
GREENw/WHITE)
RCAJACKS
SPLICEWIRESASSHOWN.
CAREFULLYINSULATE
SPLICESWITHELECTRICAL
TAPEORWIRENUTS.
SPLICEWIRESASSHOWN.
CAREFULLYINSULATE
SPLICESWITHELECTRICAL
TAPEORWIRENUTS.
GREYw/YELLOWSTRIPE
FORUSEWITH
OPTIONALEXTERNAL
AMPLIFIERS
RED=RIGHTCHANNEL
WHITE=LEFTCHANNEL
8:30am-7:00pmEastern
9:00am-5:00pmEastern
Monday-Friday
Saturday
1-800-645-7102

1111
1111
11
OPERATING INSTRUCTIONSOPERATING INSTRUCTIONS
OPERATING INSTRUCTIONSOPERATING INSTRUCTIONS
OPERATING INSTRUCTIONS
OPERATING INSTRUCTIONSOPERATING INSTRUCTIONS OPERATING INSTRUCTIONSOPERATING INSTRUCTIONS
OPERATING INSTRUCTIONS
1ON-OFF SWITCH/VOLUME CONTROL
Rotate this knob clockwise to turn the radio on.
Continuerotation untilthedesiredvolumelevel
is obtained. Rotate the knob fully counter-
clockwise to turn the unit off.
2LEFT / RIGHT BALANCE CONTROL
(PUSH)
Push this knob inward and rotate it to the left or
right to obtain the desired balance between left
and right speakers. A detent click can be felt at
the center of rotation. The knob will automati-
cally return to the outer position (volume con-
trol) when released.
3FRONT/REAR FADER CONTROL
Rotate this knob to the left or right to fade the
sound between the front and rear speakers in
4 speaker installations. A detent click can be
felt at the center of rotation. When used in
conjunction with the Left/Right Balance Con-
trol 2, you have full 4-way stereo balance
capability. In 2 speaker installations, rotating
the Fader Control will have no effect on the
speaker output.
4TREBLE CONTROL
Rotate this knob clockwise to increase treble
response,counter-clockwisetodecreasetreble
response. A detent click can be felt at the
center of rotation (flat setting).
5BASS CONTROL
Push this knob inward and rotate it clockwise to
increase bass response, counter-clockwise to
decrease bass response. A detent click can be
felt at the center of rotation (flat setting). The
knob will automatically return to the outer posi-
tion (treble control) when released.
6FM/AM BAND SELECTOR
Eachtime this buttonis pressed, theradio band
is changed. The indication “AM”, “FMI”, or
“FMII” will appear on the display panel accord-
ing to your selection.
cr
coclbl
bpbo
cs
br
bn
6cn
12
3
bmbt
bs
8bq 7
cm
9
cq cpbu54

1212
1212
12
OPERATING INSTRUCTIONSOPERATING INSTRUCTIONS OPERATING INSTRUCTIONSOPERATING INSTRUCTIONS
OPERATING INSTRUCTIONS
7MANUAL UP/DOWN TUNING ( / )
AUTOMATIC SEEK TUNING
Eachtime the side ofthisbuttonis pressed,
the radio will tune one frequency step higher.
Similarly, each press of the side of the
button will tune one frequency step lower. To
manually tune in a station, press the button in
the appropriate direction until the desired fre-
quency is reached.
Pressing either side of the button for longer
than 0.5 seconds will activate the Automatic
Seek Tuning function in the selected direction
(as indicated by “UP” or “dO” on the display
panel). The radio will seek the next available
station and stop on that frequency.
8PRE-SET SCAN TUNING (PS)
AUTO-STORE TUNING (AS)
During radio operation, press this button to
scan the 6 stations pre-set into the memories
of the band in use. The unit will stop at each
pre-set station for 5 seconds before continuing
to the next pre-set station (the preset number
on the display panel will flash during Pre-Set
Scan operation). Press the button again to
stop the Pre-Set Scan operation and remain
on the selected frequency.
Pressing the button for longer than 2 seconds
will activate the Auto-Store Tuning, which will
automatically scan the band and enter strong
stations into the pre-set memory positions for
that band (FMI and FMII bands if activated
during FMI band use). If you have already set
the pre-set memories of that band to your
favoritestations, activating the Auto-Storefea-
turewillerase those stations andenterthe new
strong stations. The feature is most useful
when travelling in a new area where you are
not familiar with the local stations.
9STATION PRE-SET MEMORIES
To set any of the 6 pre-set memory buttons,
use the following procedure:
1. Turnthe unit onand select the desiredband.
2. Select the first station to be pre-set using the
Manual or Seek Tuning functions 7.
3. Press the pre-set button in until the number
of that pre-set button appears on the display
panel. Thestationisnowsetintothememory
of that pre-set button and can be re-called
by pressing the button momentarily.
4. Repeat the above procedure for the remain-
ing 5 pre-sets on the band in use and for the
other 2 bands of the unit.
bl LOCAL/DISTANT SELECTOR (LO)
During radio operation, this button is used to
select the “stop sensitivity” in the Automatic
Seek tuning mode. For the Local mode, press
the button so that the “LO” indication appears
onthedisplaypanel. In this mode, the radio will
only stop on strong local stations during Auto-
matic Seek operation. Press the button again
to select the Distant mode (“LO” will disappear
from the display panel), allowing the unit to
stop on a wider range of stations, including
weaker distant ones.
bmFMMONO/STEREOSELECTOR (ST)
During FM radio operation, this button is used
toselectmono or stereo reception of thebroad-
cast signal. Under normal reception condi-
tions, the unit should be left in the stereo mode,
indicated by “ST” on the display panel when a
stereo signal is being received. If the stereo
signal is too noisy for comfortable listening,
presstheMono/Stereoselector button bmto
switch to mono reception.

1313
1313
13
OPERATING INSTRUCTIONSOPERATING INSTRUCTIONS OPERATING INSTRUCTIONSOPERATING INSTRUCTIONS
OPERATING INSTRUCTIONS
bnAUTO-RADIOTUNING(ART)
By pressing this button and activating this
function (indicated by “ART” on the display
panel), the radio will automatically tune to a
strong listenable station if the station it is tuned
to becomes too weak and noisy for clear
reception. This feature is most useful when
traveling in fringe reception areas.
boLIQUID CRYSTAL DISPLAY PANEL
The Liquid Crystal Display (LCD) panel dis-
plays the frequency, time and activated func-
tions.
NOTE: Itis a characteristic ofLCD panels that,
if subjected to cold temperatures for an
extended period of time, they will take
longer to illuminate than under normal
conditions and the visibility of the num-
bers on the display may decrease. The
LCDread-outwillreturn tonormalwhen
the temperature increases to a normal
range.
bpDISCSLOT
With the label surface facing up, gently insert
the disc into the disc slot until the soft-loading
mechanism engages and disc play begins.
The disc-in indication “ “, play arrow “ “,
track number and elapsed time will appear on
the display panel.
NOTE: This unit is designed for play of stan-
dard5"(12cm)CompactDiscs ONLY.
Do not attempt to use 3" (8cm) CD-
Single discs in this unit, either with or
without an adaptor, as damage to the
player and/or disc can occur. Such
damage will not be covered by the
Warranty on this product.
bq TRACK SEARCH ( / )
The Track Search function is used to quickly
access the beginning of a particular track.
Eachtimethe Forward Track Search ( ) side
of the button is pressed, the next higher track
number will be selected as shown on the
display panel. Each time the Backward Track
Search ( ) side of the button is pressed, the
next lower track number will be selected as
shown on the display panel.
brCUE FUNCTION
High-speed audible search to any section of
the disc can be made by the Cue function.
Press and hold the Cue button br to advance
quickly to the desired section. Normal play will
resume when the button is released.
bs REPEAT PLAY SELECTOR (RPT)
Duringdiscplay,pressthis button to repeat the
play of the selected track (“RPT” will appear on
the display panel). Play of the track will con-
tinue to repeat until the button is pressed again
and the “RPT” indication disappears from the
display panel.
bt RANDOM PLAY SELECTOR (RNDM)
During disc play, press this button to play the
tracks on the disc in a random shuffled order
(“RNDM” will appear on the display panel).
The Forward Track Search bq function will
also select tracks in the random order instead
of the normal progression. The Random Play
mode can be cancelled by pressing the button
bt again or activating Repeat Play bsor CD
Scanbufunctions.
buCDSCAN
During disc play, press this button to play the
first 10 seconds of each track on the disc (the
track number will flash on the display panel).
When a desired track is reached, press the CD
Scan button bu again to cancel the function
andplayoftheselectedtrackwillcontinue. CD
Scan mode will also be cancelled by activating
any other CD function selector.

cl PAUSE SELECTOR
During disc play, press this button to tempo-
rarily stop play of the disc (the play arrow “ “
on the display panel will disappear). Press the
button again to resume play of the disc from
the point at which it was stopped.
cmPROGRAMMEMORYSELECTION
Up to 6 tracks can be programmed to be
played in your selected order on this unit. The
following procedure is used to program the
order of track play:
1. Insert the disc into the unit to begin disc
play.
2. UsetheTrackSearchfunction bq toselect
the track to be programmed to play first.
When the track number appears on the
display panel, press the #1 Program
Memorybuttoncmforapproximately2sec-
onds until the track number stops flashing.
3. In a similar manner to programming the first
selection, use the Track Search function
bq toselectthetracktobeprogrammedto
play second and press the #2 Program
Memorybutton cm .
4. Continue the above procedure until all the
desired tracks (up to 6) have been set into
Program Memory buttons #1 through #6.
cnPROGRAMMED PLAY (P-PLAY)
After completing the programming procedure,
play of the tracks in programmed order can be
started by pressing the Programmed Play
button cn.The“P” indication will appear onthe
display panel and the first programmed track
will begin play. To stop Programmed Play and
return to playing the disc in normal order,
pressthe Programmed Playbutton cn again
so that the “P” disappears from the display
panel.
NOTE: Programmed Play memory will be
automatically cleared when the disc is
ejected and removed from the unit or
whentheRe-Setbutton cs ispressed.
1414
1414
14
OPERATING INSTRUCTIONSOPERATING INSTRUCTIONS OPERATING INSTRUCTIONSOPERATING INSTRUCTIONS
OPERATING INSTRUCTIONS
co DISC EJECT ( )
Discplayisstopped,thediscisejectedandthe
unit will change to radio operation by pressing
this button. If the disc is not removed from the
unit and the button is pressed again, the disc
will be re-loaded and begin playing.
cp DISC STANDBY SELECTOR (ST-BY)
During disc play, pressing this button will stop
play of the disc and switch to radio operation
without ejecting the disc. During this time, the
disc-in indication “ “ will remain on the
display panel to show that a disc is still loaded
in the unit and the “ST-BY” indication will flash
to show the unit is in the Standby mode. Press
the Standby button cr again to return to disc
play from the beginning of the track in play at
the time Standby mode was activated.
cqTIME/FREQUENCY DISPLAY
SELECTOR (T/F)
During radio or CD play, press this button to
call the time display on the incorporated quartz
clock. The display will automatically return to
radio frequency or disc track/elapsed time
after 5 seconds.
cr FRONT PANEL RELEASE BUTTON
This button is used to release the mechanism
that holds the front panel to the chassis. To
detach the front panel, press the button so that
the right side of the panel is released. Grasp
the right side of the panel and pull it off of the
chassis. To re-attach the panel, slide the left
side of the panel into the opening on the left
side of the chassis and then press the right
side of the panel into place until the latching
mechanism engages.

1515
1515
15
OPERATING INSTRUCTIONSOPERATING INSTRUCTIONS OPERATING INSTRUCTIONSOPERATING INSTRUCTIONS
OPERATING INSTRUCTIONS
NOTES ON USE OF FRONT PANEL
1. Make sure the front panel is right-side-up
when attaching the panel to the chassis as
it cannot be attached when upside-down.
2. Do not press very hard on the panel to
engage the mechanism when attaching
the panel. No more than light to moderate
pressure should be needed.
3. When detaching the panel, be sure to pull it
off from the right side, and not straight
toward you. Similarly, when attaching the
panel, make sure the left side is engaged
before pressing the right side to lock it into
position. Do not attempt to engage to right
side first or push the panel straight on.
4. When taking the panel with you, pleaseuse
the supplied carrying case to protect it from
dirt and damage.
csRE-SETBUTTON
A Re-Set button is located on the front of the
chassis which must be activated by a pen tip
or other thin object as it is recessed to prevent
accidental engagement. The re-set circuitry
is provided to protect the microprocessor cir-
cuitry and should only be activated under the
following circumstances as it will erase the
time and programmed memories.
1. Upon initial installation after all wiring is
completed.
2. After the position of the frequency step
switch on the bottom of the chassis has
been changed.
3. If there is a malfunction of any of the
switches on the unit or of the CD player,
pressing the Re-set button may clear the
system and return to normal operation.
SETTING THE CLOCKSETTING THE CLOCK
SETTING THE CLOCKSETTING THE CLOCK
SETTING THE CLOCK
1. Turn the radio on so that the frequency is shown on the display panel.
2. Press and hold the Time/Frequency Display Selector cq so that the time indication is shown
on the display panel.
3. While continuing to hold the Time/Frequency Display Selector cq , press the #1 Memory
button 9toadjust the hoursand the #2Memory button 9to adjustthe minutes tothe correct
time.
5. When the correct time is shown on the display panel, release the Time/Frequency Display
selector cq .
FREQUENCY STEP SWITCH
This unit is supplied pre-set at the factory for reception of North American radio stations
(10 KHz. channel spacing on AM/200 KHz. spacing on FM). Use in other areas of the world
may require different channel spacing. A switch on the bottom of the chassis allows
selection of 9 KHz. AM/100 KHz. FM channel spacing. Slide the switch to the appropriate
position using a small screwdriver blade. The Re-Set button cs on the front of the chassis
must then be pressed to activate the change of channel spacing.

1616
1616
16
SPECIFICATIONSSPECIFICATIONS SPECIFICATIONSSPECIFICATIONS
SPECIFICATIONS
SPECIFICATIONSSPECIFICATIONS
SPECIFICATIONSSPECIFICATIONS
SPECIFICATIONS
Size:
Operating Voltage:
Output Power:
Output Wiring:
Output Impedance:
Low-Level Output:
Tuning Range:
Sensitivity:
FM Stereo Separation:
CD Frequency Response:
CD Signal/Noise Ratio:
CD Channel Separation:
CD Dynamic Range:
CD Distortion:
7" W x 2" H x 6-1/4" D
179 mm x 51 mm x 159 mm
12 volts DC, negative ground
50 watts maximum
(25 watts per channel)
Floating-ground type designed for 4 speaker use.
May also be used with 2 speakers.
RCA low-level outputs.
Compatible with 4-8 ohm speakers.
500 mv.
AM: 530-1,720 KHz. (10 KHz. step)
531-1,620 KHz. ( 9 KHz. step)
FM: 87.5-107.9 MHz. (200 KHz. step)
87.5-108.0 MHz. (100 KHz. step)
AM: 20 uv.
FM: 1.5 uv.
30 dB
20-20,000 Hz. ± 2dB
>70 dB
>60 dB
>80 dB
<0.1% T.H.D.
*Specifications are subject to change without notice.

1717
1717
17
TROUBLESHOOTINGTROUBLESHOOTING TROUBLESHOOTINGTROUBLESHOOTING
TROUBLESHOOTING
PROBLEM PROBABLE CAUSE CHECK FOLLOWING
Unit completely inoperative no lights,
no sound
Unit will not keep time or radio station
memory
Noise on both radio and CD
Noise on radio only
Poor FM reception and almost no AM
reception
No sound on one speaker
(both radio and CD)
Poor sound-new unit
CD sound skips
Orange/White stripe wire to +12V ACC. and
Green/White stripe wire to +12V battery
Check fuses in wires listed above and check
car fuse block
Green/White stripe wire is not connected to a
"live" +12V battery source
Check fuse in Green/White stripe wire and at
car's fuse block
Check Black/White stripe wire for proper
grounding
Clean and tighten connection
Consult your local garage mechanic-car may
need tune-up or noise filter
Check that antenna base is grounded. Test
withantennadisconnected.Ifnoise goesaway,
replace antenna
Replace antenna and antenna cable
Check speaker wiring
Test with good speaker
Check balance and fader controls
Check rating of speakers for sufficient power
capacity
Check that speakers are in good
condition
Check that none of the speaker wires are
grounded
Check speaker wiring
Adjust the mounting angle to less than 20°
Make sure disc player is mounted securely
Clean disc if dirty; replace if badly scratched
or defective
Allow condensation to dry, then try again
Incorrect power connection
Blown fuse
Incorrect power connection
Blown fuse
Poor ground
Dirty or corroded battery posts
If problem also existed with previous
radio you removed
Antenna
Antenna
Wiring
Speaker
Control Settings
Speakers or speaker wiring
Installation angle is greater than 20°
Disc player is not installed correctly
Dirty, scratched, or defective disc
Condensation on laser lens
TROUBLESHOOTINGTROUBLESHOOTING
TROUBLESHOOTINGTROUBLESHOOTING
TROUBLESHOOTING

1818
1818
18
CARE AND MAINTENANCECARE AND MAINTENANCE CARE AND MAINTENANCECARE AND MAINTENANCE
CARE AND MAINTENANCE
CARE AND MAINTENANCECARE AND MAINTENANCE
CARE AND MAINTENANCECARE AND MAINTENANCE
CARE AND MAINTENANCE
The radio section of your new sound system does not require any maintenance. We recommend you
keep this manual for reference on the many features found in this unit as well as how to set the clock.
The compact disc player section also requires no routine maintenance, but proper understanding of
its use and handling will help you obtain maximum enjoyment of its capabilities. The following points
should be observed:
When cleaning the interior of the vehicle, do not get water or cleaning fluids on the unit.
The CD player is a precision instrument and will not operate properly in extreme hot or cold. In
case of such conditions, wait until the interior temperature of the vehicle reaches a normal
temperature before using the player.
If the temperature inside the player gets too hot, a protective circuit will automatically stop play
of the disc. In this case, allow the unit to cool off before operating the player again.
Never insert anything other than a 5" (12 cm) compact disc into the player as the mechanism
can be damaged by foreign objects.
Do not attempt to use 3" (8 cm) CD-Single discs in this unit, either with or without an adaptor,
as damage to the player and/or disc may occur. Such damage will not be covered by the
Warranty on this product.
When not using the disc player, always remove the compact disc. Do not leave an ejected disc
sitting in the disc slot as this can expose it to sunlight and other causes of damage.
Do not attempt to open the unit chassis. There are no user serviceable parts or adjustments
inside.
When the vehicle warms up during cold weather or under damp conditions, moisture may
condense on the lens of the disc player. Should this occur, the player will not operate properly
until the moisture has evaporated.
The unit is designed with a vibration dampening CD mechanism to minimize interruption of disc
play due to normal vibration in a moving vehicle. When driving on very rough roads, however,
occasional sound skips may occur. This will not scratch or damage the disc and normal play
will resume when the rough conditions cease.
Use only compact discs with the mark.
Fingerprints, dust, and dirt should be carefully wiped off the disc’s playing surface (shiny side)
with a soft cloth.
Wipe in a straight motion from the inside to the outside of the disc.
Never use chemicals such as record sprays, household cleaners or thinner to clean compact
discs. Such chemicals can irreparably damage the disc’s surface.
Discs should be kept in their storage cases when not in use.
Do not expose discs to direct sunlight, high temperatures or high humidity for extended periods.
Do not stick paper, tape, or labels on the disc surfaces nor write on them with any type of marker.
HANDLING COMPACT DISCS
Dirt, dust, scratches, and warpage can cause skips in the playback and deterioration of sound quality.
Please follow these guidelines to take care of your compact discs:

















©1996 Audiovox Corporation Hauppauge, NY 11788 Printed in China
®
12 MONTH LIMITED WARRANTY
Some states do not allow limitations on how long an implied warranty lasts or the exclusion or limitation of incidental
or consequential damage so the above limitations or exclusions may not apply to you. This Warranty gives you
specific legal rights and you may also have other rights which vary from state to state.
This Warranty is in lieu of all other express warranties or liabilities. ANY IMPLIED WARRANTIES, INCLUDING ANY
IMPLIED WARRANTY OF MERCHANTABILITY, SHALL BE LIMITED TO THE DURATION OF THIS WRITTEN
WARRANTY. ANY ACTION FOR BREACH OF ANY WARRANTY HEREUNDER INCLUDING ANY IMPLIED
WARRANTY OF MERCHANTABILITY MUST BE BROUGHT WITHIN A PERIOD OF 30 MONTHS FROM DATE
OF ORIGINAL PURCHASE. IN NO CASE SHALL THE COMPANY BE LIABLE FOR ANY CONSEQUENTIAL OR
INCIDENTAL DAMAGES FOR BREACH OF THIS OR ANY OTHER WARRANTY, EXPRESS OR IMPLIED,
WHATSOEVER. No person or representative is authorized to assume for the Company any liability other than
expressed herein in connection with the sale of this product.
This Warranty does not extend to the elimination of car static or motor noise, to correction of antenna problems, to
costs incurred for installation, removal, or reinstallation of the product, or damage to tapes, compact discs, speakers,
accessories, or vehicle electrical systems.
This Warranty does not apply to any product or part thereof which, in the opinion of the Company, has suffered or
been damaged through alteration, improper installation, mishandling, misuse, neglect, accident, or by removal or
defacement of the factory serial number/bar code label(s). THE EXTENT OF THE COMPANY'S LIABILITY UNDER
THIS WARRANTY IS LIMITED TO THE REPAIR OR REPLACEMENT PROVIDED ABOVE AND, IN NO EVENT,
SHALL THE COMPANY'S LIABILITY EXCEED THE PURCHASE PRICE PAID BY PURCHASER FOR THE
PRODUCT.
Applies to In-dash radios, radio/tape player and radio/CD player combinations, and CD Changers.
AUDIOVOX CORPORATION (the Company) warrants to the original retail purchaser of this product that should this
product or any part thereof, under normal use and conditions, be proven defective in material or workmanship within
12 months from the date of original purchase, such defect(s) will be repaired or replaced with new or reconditioned
product (at the Company's option) without charge for parts and repair labor.
To obtain repair or replacement within the terms of this Warranty, the product is to be delivered with proof of warranty
coverage (e.g. dated bill of sale), specification of defect(s), transportation prepaid, to an approved warranty station.
For the location of the nearest warranty station to you, call toll-free to our control office:
CANADA: CALL 1-800-645-4994 FOR LOCATION OF WARRANTY STATION SERVING YOUR AREA
IN U.S.A. 1-800-243-1311
IN CANADA 1-800-645-4994
Form No. 128-4123D
AUSTRALIA: AUDIOVOX PACIFIC PTY LTD., DOYLE AVENUE, UNANDERRA, NSW 2526  [phone]
NEW ZEALAND: AUDIOVOX PACIFIC PTY LTD., UNIT B, 6 HENDERSON PLACE, PENROSE, AUCKLAND [phone]
U.S.A. : AUDIOVOX CORPORATION, 150 MARCUS BLVD., HAUPPAUGE, NEW YORK 11788 [phone]
Form No. 128-4572B
