Auer Signal mTCR User manual

Explosion-proof telephone connecting relay mTCR
1
Description
The telephone connecting relay type
mTCR is used as a fixed device in
areas that may be at risk due to
explosive gas or dust atmospheres
and which require devices of device
groups II and III of the categories
2G and 2D.
The designated position of normal
use is not mandatory.
The telephone connecting relay type
mTCR is implemented in the follo-
wing ignition protection classes:
Ex e ib mb IIC T4 Gb
Ex tb IIIC T1 35°C Db
IP66
Temperature range
-40°C Ta +70°C
The telephone connecting relay type
mTCR is intended for connection to
analogue telephone networks. It
can be simply installed parallel to a
telephone.
The telephone connecting relay
serves for call signalling through
providing potential-free switching
contacts for the connection of
signalling devices. This means for
example that up to two external
devices (e.g. a horn and a flash
light) can be switched on via call
signal. The call break bypass can
be individually adjusted for one of
the connected devices.
The installation regulations in
accordance with IEC/EN 60079-1 4
as well as the respective national
installation regulations must always
be taken into consideration.
Device strutcture
The telephone connecting relay type
mTCR has an unpainted housing
made of electrostatically conductive
compressed material.
The housing consists of a box-
shaped lower part for receiving the
electronics module. The electronics
module is firmly cast into the lower
part of the housing and cannot be
exchanged.
The cover is pressed onto the lower
part of the housing using four
screws, with a circumferential seal
positioned in between. This forms
the non-intrinsically-safe connection
compartment
.
Intrinsically safe DIP switches
An intrinsically safe 4-pole sliding
switch extends out from the casting
within the device (see device over-
view) for pre-setting the desired
mode of operation.
Designation Type Article no.
Order data
Telephone connecting relay mTCR 410 100 100
mTCR
mTCR 3.1_E

1
2
4
190
178
75
approx. 11 4
approx. 1 08
39
5
2
NOTE:
Excessive tightening compromises
the protection class.
The following is to be considered
when assembling the sealing plug:
1 . Only the sealing plug belonging to
the cable gland (5) may be used.
2. The head side of the sealing plug
must be on the outside (5).
3. The sealing plug (5) is to be
pushed into the cable gland as
far as it will go.
Assembly and installation
Loosen the cover screws (2)and
remove the cover (1)(see device
overview). Insert the lower part into
the opening (3)using four 4 mm
screws with a head diameter of 6
mm to 7 mm and fasten to the wall
or ceiling or onto a plate. If the head
diameter of the screws is too small,
suitable washers of6 mm to 7 mm in
diameter are to be used in addition.
Lead the connection lines through the
screwed cable connectors (KLE) (4)
and connect them to terminals in
accordance with connection diagram.
For the pre-installed cable glands,
only lines are to be used which
have a sheathing diameter Ø of 5.5
mm to 1 3 mm, since otherwise the
IP66 housing protection class is not
ensured.
The tightening torque of these
screwed cable connectors is 3.5 Nm.
The tightening torque of the cover
screws is 1 .2 Nm.
Dimensions
Maintenance
The telephone connecting relay type
mTAR contains no parts that need
maintaining.
Maintenance and servicing
The equipment contains no parts
that need maintaining. The specifica-
tions of EN 60079-1 7 regarding the
regular inspection of explosion pro-
tection are to be adhered to.
Start-up
After it has been connected to the
telephone network, the device is ready
for electrical operation.
Requirements
none
CE symbol
We hereby declare this product is in compliance with the Essential
Health and Safety Requirements of
ATEX Directive 2014/34/EU, EMC Directive 2014/30/EU,
Low Voltage Directive 2014/35/EU and RoHS Directive 2011/65/EU.
The appropriate standards, technical regulations and specifications
you can take from the attached conformity declaration.
External view
Internal view
3

3
Connection diagram
The device complies with the
requirements of the
ATEX direc-
tive 2014/34/EU, the EMC-
directive 2014/30/EU and the low
voltage directive 2014/35/EU.
The conformity with the above
directives is confirmed by the CE
sign.
Directivies
EN 60950
ETSI TBR21
ETSI ETS 30001 9-2-4
IEC/EN 60079-0
IEC/EN 60079-7
IEC/EN 60079-1 1
IEC/EN 60079-1 8
IEC/EN 60079-31
IEC/EN 60529
EN 61 000-4-3
EN 61 000-4-4
EN 61 000-4-5
EN 61 000-4-6
EN 55022
Applied standards
1.Telephone network (not intrinsically safe)
Terminals No. 7 and 8 in accordance with 9 and 1 0
Un = AC 90 V / f = 25 Hz
Um_AC = AC 1 00 V / f = 20 … 68 Hz
Um_DC = DC 66 V
Um = 1 20 Veff
AC and DC voltage parts can be superimposed.
Permissible conductor cross-sections are 0.2 to
4.0 mm rigid or 0.2 to 2.5 mm flexible.
Only 2 or 4-core lines may be used.
2. Potential-free relay contacts (not intrinsically safe)
Terminals No. 1 /3 or No. 4/6
Umax = AC 250 V
Imax = 5 A
Pmax = 1 00 VA
In this case only lines with a core cross-section
of 1 .5 mm to 4 mm may be used.
Or Umax = DC 230 V
Imax = 0.5 A
Pmax = 1 00 W
In this case only lines with a core cross-section
of 0.75 mm to 4 mm may be used.
Or Umax = DC 50 V
Imax = 1 A
In this case only lines with a core cross-
section of 0.75 mm to 4 mm may be used.
Or Umax = DC 30 V
Imax = 5 A
Pmax = 1 00 W
In this case only lines with a core cross-
section of 1 .5 mm to 4 mm may be used.
The terminals no. 2 and 5 according to the
connection diagram may not be used. Only 2
or 4-core lines may be used.
3.The telephone network is securely and galva-
nically isolated from the potential-free relay
contacts.
4.The two potential-free relay contacts are
securely and galvanically isolated from one
another up to a voltage of 440 Veff.
The voltage may not exceed 250 Veff at an
individual relay contact.
Electrical parameters

4
Technical data
Housing
Material Glass-fibre reinforced polyester
Height x width x depth Approx. 75 mm x 1 90 mm x 75 mm
Weight Approx. 1 .1 kg
Normal operating position Any
Environmental conditions
Protection class IP 66 in accordance with EN60529
Operating temperature -40°C Ta 70°C
Transport and
storage temperature -40°C to +70°C in accordance with IEC 60721
Further features
Power supply Call AC voltage from the analogue telephone network.
TNV-3 circuit. U = AC 30 V… 1 00 V
Call impedance M 8 k (@ 30 V… 1 00 V/20… 68 Hz)
Modes of operation Function of relay contact 1 (terminals 1 and 3) adjustable
by means of sliding switches:
Sliding switch 4 = OFF => contact follows the call signal
Sliding switch 4 = ON => contact closes for approx. 1 .5 seconds
Function of relay contact 2 (terminals 4 and 6)adjustable
by means of sliding switches.
The contact always follows the call signal. After the call signal, i.e. in the call
break that follows, the contact remains closed for the duration according to
the following setting (call break bypass).
1 = ON => call break bypass approx. 1 second
2 = ON => call break bypass approx. 2 seconds
3 = ON => call break bypass approx. 3 seconds
1 to 3 = OFF => call break bypass approx. 9 seconds
Combinations are possible:
1 2 3 Call break bypass approx.
ON OFF OFF 1 s
OFF ON OFF 2 s
OFF OFF ON 3 s
OFF ON ON 5 s
ON ON ON 6 s
OFF OFF OFF 9 s
Note:
The smooth functioning in the case of a “double call”, i.e. two short call signals one behind the other, cannot
be guaranteed given the abundance of double call signals worldwide. It is the operator’s responsibilityto test
the function on his system in these cases.
Marking
The type plate of the telephone connecting relay type mTCR is marked as follows :
Type mTCR
BVS 15 ATEX E 028
CE 0408
II 2G Ex e ib mb IIC T4 Gb
II 2D Ex tb IIIC T1 35°C Db
-40°C Ta +70°C
Manufacturing No. xxxx
Article no. xxxx
Inspection: Month / year / inspector
Um = 1 20 V IP66 IK08
WARNING – DO NOT OPEN WHEN LIVE
WARNING – WAIT 5 MINUTES AFTER SWITCHING OFF BEFORE OPENING
Auer Signal GmbH
Perfektastraße 102, A-1230 Vienna

EU-KONFORMITÄTSERKLÄRUNG
EU DECLARATION OF CONFORMITY
DECLARATION UE DE CONFORMITE
DECLARATIÓN DE CONFORMIDAD UE
Hiermit erklären wir, dass das ATEX Produkt aufgrund seiner Konzipierung und Bauart sowie in der von uns in Verkehr gebrachten Ausführung
den grundlegenden Sicherheits- und Gesundheitsanforderungen der genannten Richtlinie entspricht.
Bei einer nicht mit uns abgestimmten Änderung des Produktes, verliert diese Konformitätserklärung Ihre Gültigkeit.
We herewith declare that the ATEX product, based on its development and type as well on the specific design we have placed on the market,
conforms to the Essential Health and Safety Requirements of the mentioned directive.
This declaration shall become invalid if any modification we have not authorised is made to the product.
Nous attestons, par le présent document, que le produit ATEX été conçu et fabriqué, quant au modèle mis en circulation par nos services,
conformément aux exigences fondamentales de sécurité et de santé en vigueur de la ou des directives citées.
En cas de modification du produit non convenue avec nos services, la présente déclaration perd sa validité.
Por la presente declaramos que el producto ATEX satisface por su diseñoy tipo constructivo así como en la versión comercializada por nosotros
los requisitos de seguridad y salud fundamentales y pertinentes de la directiva indicada.
En caso de una modificatión del producto no acordad con nosotros, la presente declaración pierde su validez.
Bezeichnung des Erzeugnisses
Telefonanschaltrelais
Name of product
Telephone connecting relay
Titre Produit
Relias d`accès téléphoneique
Nombre del producto
Relé de conexión de teléfono
Typ / Type / Modèle / Tipo
mTCR
Richtlinie / Directive / Directive / Directiva
Normen / Standards / Normes / Normas
2014/34/EU
Geräte und Schutzsyteme zur bestimmungsgemäßen
Verwendung in explosionsgefährdeten Bereichen
Equipment and protective system intended for use in
potentially explosive atmospheres
Appareils et systéme de protection destinés á étre
utilisés en atmosphéres explosibles
Aparatos y sistemas de proteccón para uso en
atmósferas potenciaömente explosivas
EN 60079-0:2012 + A11:2013
EN 60079-7:2015
EN 60079-11:2012
EN 60079-18:2015
EN 60079-31:2014
Die hier angewandten Normen sind mit dem Normenstand aus der EG-Baumusterprüfbescheinigung verglichen worden. Es gibt
keine Änderungen des anerkannten Standes der Technik in Bezug auf dieses Gerät.
The edition of applied standards here has been compared with the edition in the EC-Type Examination Certificate.
There are no changes in the state of the art apply to this equipment.
Les normes appliquées ont été comparées avec les informations du certificat d’essai de type CE. Aucune modification de l’état de la technique
reconnu n’est à noter concernant cet appareil.
Las normas aplicadas fueron comparadas con las normas vigentes del certificado CE de examen de tipo. No hay cambios del estado
reconocido de la técnica relativos a este aparato.
There are no changes in the state of the art apply to this equipment.
Les normes appliquées ont été comparées avec les informations du certificat d’essai de type CE. Aucune modification de
l’état de la technique reconnu n’est à noter concernant cet appareil.
Las normas aplicadas fueron comparadas con las normas vigentes del certificado CE de examen de tipo. No hay cambios
del estado reconocido de la técnica relativos a este aparato.
EG Baumusterprüfbescheinigung
EC-type-examination certificate
Attestation examen CE
Certificado de examen CE
BVS 15 ATEX E 028
Benannte Stelle für die Bescheinigung
Notified body of the certificate
Organisme notifié de l` attestation
Organismo encargodo del certificado
DEKRA EXAM GmbH
Fachstelle für Sicherheit elektrischer Betriebsmittel –BVS
Carl-Beyling-Haus
Dinnendahlstraße 9
D-44809 Bochum
Benannte Stelle für die Überwachung
Notified body of the inspection
Organisme notifié de contróle
Organismo encargodo del examen
Kennummer
Inspection number / Numéro d`identificatio /
Número de examen
TÜV AUSTRIA SERVICES GMBH
Deutschstraße 10
A-1230 Wien
0408
Hersteller / Anschrift
Manufacturer / Factory address
Fabricant / fabricante
Auer Signal GmbH
Perfektastr. 102
A-1230 Wien
Geschäftsführer: Mag. Christian Auer
Managing director / Direction / Gérant / Gerente: (Name, Vorname / name, prename / nom, prénom / apellido y nombre)
Wien ____________ 15.05.2018 ______________________
(Ort / place / lieu / población) (Datum / date / date / fecha ) (Unterschrift / signature / signature / Firma)

Warnings and safety instructions
This device is an explosion-proof telephone connecting relay specially for operation in a hazardous industrial
environment. The following warnings and safety instructions are to be considered:
1 . The device serves for call signalling at analogue telephone connections through providing potential-
free switching contacts for connecting signalling devices. It is not intended for use in safety-related
applications.
2. The device is constructed in protection class II and may only be connected and operated at the
prescribed voltage. A correct connection is to be ensured. The connection line is to be installed in such a
way that there is no risk of stumbling.
3. The device may only be operated under the ambient conditions indicated (see chapter “description”).
Adverse ambient conditions, such as too high or too low an ambient temperature, are not permissible
since these encourage the failure of electronic components.
4. It is to be ensured that the device, the connection cable etc. are not damaged. If damaged, operating the
device is not permissible.
5. When operating the device, the legal and commercial regulations, the accident prevention regulations and
the electrical codes are to be taken into consideration.
6. In the case of repairs, only original spare parts are permissible, which must be exchanged in a technically
correct manner. Other replacement parts may lead to damage and to the warranty expiring.
7. The device must be de-energised for it to be opened.
8. After switching off, wait 5 minutes before opening.
9. When open, no dust may get into the device.
1 0. The cover seal necessary for the tightness of the housing as well as the collar at the lower part of the
housing may not be damaged during assembly and disassembly.
1 1 . When reconditioning the equipment for use in dust, the reconditioned parts should undergo another
routine check test.
1 2. Changes to the product which serve for technical advancement may be made without being announced
beforehand.
1 3. If using a 4 core installation cable (NYM- J4x 1 ,5 mm2) and the 5 A load each of both relays at an environ-
mental temperature of +70 °C a temperature of +74 °C will be achieved at the cable inlet.
It has to be made sure, that a suitable installation cable will be chosen.
1 4. The manufacturer assumes no liability for the connection being correct!
If the aforementioned points are not adhered to, the explosion protection of the device is no longer ensured
and the device then puts the life of the operator in danger and can cause an explosive atmosphere to be
ignited.
1 5. The connection and the installation of the device have to be carried out by an instructed specialist in
accordance with the prescribed installation regulations and taking the indicated ignition protection class
into consideration.
Subject to alterations or errors
Auer Signal GmbH
Perfektastr. 102 Phone [phone] http://www.auersignal.com
A-1230 Wien Telefax (0043) 1 815 99 51 e-mail: offi[email protected]
