Aukey EP-B80 User manual
User Manual
Bluetooth®Earbuds
English
Deutsch
Français
Español
Italiano
日本語
01~11
12~20
21~29
30~38
39~47
48~54
Contents
- 01 -
Thank you for purchasing the AUKEY EP-B80 Bluetooth®Earbuds. Please
read this user manual carefully and keep it for future reference. If you
need any assistance, please contact our support team with your product
model number and Amazon order number.
Package Contents
Bluetooth®Earbuds
USB-A to C Cable
Three Pairs of Silicone Ear-Tips (S/M/L)
Three Pairs of Foam Ear-Tips (S/M/L)
Specifications
Model
Chipset
Sensitivity
Frequency Range
Impedance
Microphone Type
Microphone Sensitivity
Input
Charging Time
Battery Life
Battery Type
Operating Range
Weight
Technology
Driver (each channel) 1 × 10mm / 0.4” Dynamic Driver and
Balanced Armature
EP-B80
Bluetooth 5.0+EDR, A2DP, AVRCP, HFP, HSP,
aptX, aptX-LL, AAC
QCC3005
95dB ±3dB (at 1kHz)
10Hz – 40kHz
32 ohm ±15%
MEMS (microphone chip)
-42dB ±3dB
DC 5V
1.5 hours
Up to 8 hours
Li-Polymer (2 x 60mAh)
Up to 15m / 49ft
15g / 0.52oz
Carrying Pouch
User Manual
Warranty Card
- 02 -
Product Diagram
Volume + /
Next Track
LED Indicator
Multi-Function
Button
Volume - /
Previous Track
USB-C Charging Input
Microphone
- 03 -
Getting Started
Charging
Fully charge your earbuds before first use. Before charging, make sure the
earbuds are turned off. To charge, simply connect one end of the USB-A
to C cable to a USB charging port and the other end to the input port on
the earbuds. When the green LED indicator light turns off, your earbuds
are fully charged and ready for use. Charging takes around 1.5 hours.
Turning On / Off
Turn On
Turn Off Press and hold the multi-function button. The LED indicator
will light up green for 2 seconds and you'll hear a
descending tone
Press and hold the multi-function button. The LED indicator
will light up white for 2 seconds and you'll hear an
ascending tone
Pairing
Starting with the earbuds powered off:
1.
2.
3.
4.
Notes
●
●
●
●
●
- 04 -
Press and hold the multi-function button until the LED indicator flashes
green and white alternately
Turn on Bluetooth on the device you want to pair with the earbuds
In the list of available devices, find and select “AUKEY EP-B80”
If a code or PIN is required for pairing, enter “0000”
To clear the pairing list, power on the earbuds and then hold volume +
and volume - simultaneously for 5 seconds until the LED indicator lights
up green and white. Once the pairing list is cleared, you’ll hear a tone
and the earbuds will automatically enter pairing mode
The earbuds will automatically shut down after 5 minutes in pairing
mode if no devices are paired
If your paired device is turned off or manually disconnected, the
earbuds LED indicator will flash white twice every 5 seconds and the
earbuds will shut down after 5 minutes
Double-press the multi-function button after turning off Bluetooth on a
connected device to enter pairing mode. The LED indicator will flash
white and green alternately for 3 minutes. If no devices are paired,
the earbuds will enter standby mode
The maximum wireless operating range is 15m (49ft). If you exceed this
range, the earbuds will disconnect from your paired device and you’ll
hear a tone. The connection will be re-established once you re-enter
the wireless range within 5 minutes. The earbuds will automatically
reconnect to the last-paired device. To connect with other devices,
repeat the previous “Pairing” steps
Music and Calls Control
Streaming Audio
Once paired, you can wirelessly stream audio from your device to your
earbuds. Music will automatically pause when you receive an incoming
phone call, and resume once the call has ended.
Making Calls
Once paired with your smartphone, making and answering calls can be
managed via the in-line remote.
Pairing
Starting with the earbuds powered off:
1.
2.
3.
4.
Notes
●
●
●
●
●
- 05 -
Music and Calls Control
Streaming Audio
Once paired, you can wirelessly stream audio from your device to your
earbuds. Music will automatically pause when you receive an incoming
phone call, and resume once the call has ended.
Making Calls
Once paired with your smartphone, making and answering calls can be
managed via the in-line remote.
Answer or end a call
Redial last-called
number
Reject an incoming
call
Switch mic
Play or pause
Adjust volume
Skip to next / previous
track
Press the multi-function button once
Press volume + or -
Press and hold the volume + / - for 2
seconds
Short-press the multi-function button. If there’s a
second incoming call, press the multi-function
button once to answer the second call and
end the first call. Alternatively, press and hold
the multi-function button for 2 seconds to
answer the second call and put the first call on
hold. Then press and hold the multi-function
button for 2 seconds to switch between these
two calls
Double-press the multi-function button when
your device is connected (but not playing
music)
Double-press the multi-function button
During a call, press and hold the volume +
for 2 seconds to switch between the earbuds
and your phone for talking
Use Siri or other voice
assistants
When your device is connected, press and
hold the multi-function button for 2 seconds
and you’ll hear a tone
●
This equipment complies with FCC RF radiation exposure limits set forth
for an uncontrolled environment.
IC Statement
This device complies with Industry Canada licence-exempt RSS standard(s).
Operation is subject to the following two conditions:
1.
2.
Le présent appareil est conforme aux CNR d'Industrie Canada applicables
aux appareils radio exempts de licence. L'exploitation est autorisée aux
deux conditions suivantes:
1.
2.
CE Statement
Max RF power level:
BT classic (2402–2480MHz): 2.1dBm
RF exposure assessment has been performed to prove that this unit will
not generate the harmful EM emission above the reference level as
specified in EC Council Recommendation (1999/519/EC).
CAUTION: RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN INCORRECT
TYPE. DISPOSE OF USED BATTERIES ACCORDING TO THE INSTRUCTIONS.
Excessive sound pressure from earphones and headphones can cause
hearing loss.
Hereby, Shenzhen AUKEY E Business Co., Ltd.declares that the radio
equipment type (Bluetooth®Headphones, EP-B80) is in compliance with
Directive 2014/53/EU. The full text of the EU declaration of conformity is
available at the following internet address: www.aukey.com.
Notice: This device may be used in each member state of the EU.
Trademark
The Bluetooth®word mark and logos are registered trademarks owned
by Bluetooth SIG, Inc. and any use of such marks by Shenzhen AUKEY E
Business Co., Ltd. is under license. Other trademarks and trade names
are those of their respective owners.
Notice for the US
Changes or modifications not expressly approved by the party responsible
for compliance could void the user’s authority to operate the equipment.
FCC Rules
This device complies with Part 15 of the FCC Rules. Operation is subject
to the following two conditions:
1.
2.
NOTE: This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to Part 15 of the FCC Rules. These
limits are designed to provide reasonable protection against harmful
interference in a residential installation.
This equipment generates, uses, and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However, there is
no guarantee that interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference by one or
more of the following measures:
●
●
●
- 06 -
LED Indicator
White & green flashing alternately
White flashing twice every 5 seconds
White flashing once every 5 seconds
White flashing once every second
Green flashing twice every 5 seconds
Green
Green off (after charging)
Status
Pairing mode
Standby mode / Disconnected
Connected / Playing music
In call
Low battery
Charging
Fully charged
FAQ
The earbuds are on but not connecting to my device
For the earbuds and your device to establish a connection, you need to
put them both in pairing mode. Please follow the instructions in the
“Pairing” section of this manual.
I’ve established a connection with my smartphone but can’t hear any sound
Double-check the volume level on your smartphone and the earbuds.
Some smartphones require you to set up the earbuds as an audio output
device before the audio can be transmitted. If you’re using a music player
or other device, please make sure it supports the A2DP stereo music profile.
The sound isn’t very clear or the caller can’t hear my voice clearly
Adjust the volume on your smartphone and the earbuds. Try getting
closer to your smartphone to rule out the possibility of interference or
wireless range-related issues.
What is the wireless range of the earbuds?
The maximum range is 15m (49ft). However, the actual range will depend on
environmental factors. For optimal performance, keep your devices
connected with the earbuds within a 15ft–40ft range and make sure that
there are no major obstacles (like reinforced steel walls) between the
earbuds and your devices.
My earbuds won’t turn on
Try charging the earbuds for a while. If the earbuds still won’t power on,
please contact our support team at the address below.
Product Care & Use
●
●
Warranty & Customer Support
For questions, support, or warranty claims, contact us at the address below
that corresponds with your region. Please include your Amazon order
number and product model number.
*Please note, AUKEY can only provide after sales service for products purchased directly from
AUKEY. If you have purchased from a different seller, please contact them directly for service
or warranty issues.
Qualcomm®aptX™ is a product of Qualcomm Technologies International,
Ltd. Qualcomm is a trademark of Qualcomm Incorporated, registered in
the United States and other countries, used with permission. aptX is a
trademark of Qualcomm Technologies International, Ltd., registered in
the United States and other countries, used with permission.
●
This equipment complies with FCC RF radiation exposure limits set forth
for an uncontrolled environment.
IC Statement
This device complies with Industry Canada licence-exempt RSS standard(s).
Operation is subject to the following two conditions:
1.
2.
Le présent appareil est conforme aux CNR d'Industrie Canada applicables
aux appareils radio exempts de licence. L'exploitation est autorisée aux
deux conditions suivantes:
1.
2.
CE Statement
Max RF power level:
BT classic (2402–2480MHz): 2.1dBm
RF exposure assessment has been performed to prove that this unit will
not generate the harmful EM emission above the reference level as
specified in EC Council Recommendation (1999/519/EC).
CAUTION: RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN INCORRECT
TYPE. DISPOSE OF USED BATTERIES ACCORDING TO THE INSTRUCTIONS.
Excessive sound pressure from earphones and headphones can cause
hearing loss.
Hereby, Shenzhen AUKEY E Business Co., Ltd.declares that the radio
equipment type (Bluetooth®Headphones, EP-B80) is in compliance with
Directive 2014/53/EU. The full text of the EU declaration of conformity is
available at the following internet address: www.aukey.com.
Notice: This device may be used in each member state of the EU.
Trademark
The Bluetooth®word mark and logos are registered trademarks owned
by Bluetooth SIG, Inc. and any use of such marks by Shenzhen AUKEY E
Business Co., Ltd. is under license. Other trademarks and trade names
are those of their respective owners.
Notice for the US
Changes or modifications not expressly approved by the party responsible
for compliance could void the user’s authority to operate the equipment.
FCC Rules
This device complies with Part 15 of the FCC Rules. Operation is subject
to the following two conditions:
1.
2.
NOTE: This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to Part 15 of the FCC Rules. These
limits are designed to provide reasonable protection against harmful
interference in a residential installation.
This equipment generates, uses, and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However, there is
no guarantee that interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference by one or
more of the following measures:
●
●
●
- 07 -
FAQ
The earbuds are on but not connecting to my device
For the earbuds and your device to establish a connection, you need to
put them both in pairing mode. Please follow the instructions in the
“Pairing” section of this manual.
I’ve established a connection with my smartphone but can’t hear any sound
Double-check the volume level on your smartphone and the earbuds.
Some smartphones require you to set up the earbuds as an audio output
device before the audio can be transmitted. If you’re using a music player
or other device, please make sure it supports the A2DP stereo music profile.
The sound isn’t very clear or the caller can’t hear my voice clearly
Adjust the volume on your smartphone and the earbuds. Try getting
closer to your smartphone to rule out the possibility of interference or
wireless range-related issues.
What is the wireless range of the earbuds?
The maximum range is 15m (49ft). However, the actual range will depend on
environmental factors. For optimal performance, keep your devices
connected with the earbuds within a 15ft–40ft range and make sure that
there are no major obstacles (like reinforced steel walls) between the
earbuds and your devices.
My earbuds won’t turn on
Try charging the earbuds for a while. If the earbuds still won’t power on,
please contact our support team at the address below.
Product Care & Use
●
●
Warranty & Customer Support
For questions, support, or warranty claims, contact us at the address below
that corresponds with your region. Please include your Amazon order
number and product model number.
*Please note, AUKEY can only provide after sales service for products purchased directly from
AUKEY. If you have purchased from a different seller, please contact them directly for service
or warranty issues.
Keep away from liquids and extreme heat
Don’t use the earbuds at high volume for extended periods, as this
may cause permanent hearing damage or loss
Qualcomm®aptX™ is a product of Qualcomm Technologies International,
Ltd. Qualcomm is a trademark of Qualcomm Incorporated, registered in
the United States and other countries, used with permission. aptX is a
trademark of Qualcomm Technologies International, Ltd., registered in
the United States and other countries, used with permission.
●
This equipment complies with FCC RF radiation exposure limits set forth
for an uncontrolled environment.
IC Statement
This device complies with Industry Canada licence-exempt RSS standard(s).
Operation is subject to the following two conditions:
1.
2.
Le présent appareil est conforme aux CNR d'Industrie Canada applicables
aux appareils radio exempts de licence. L'exploitation est autorisée aux
deux conditions suivantes:
1.
2.
CE Statement
Max RF power level:
BT classic (2402–2480MHz): 2.1dBm
RF exposure assessment has been performed to prove that this unit will
not generate the harmful EM emission above the reference level as
specified in EC Council Recommendation (1999/519/EC).
CAUTION: RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN INCORRECT
TYPE. DISPOSE OF USED BATTERIES ACCORDING TO THE INSTRUCTIONS.
Excessive sound pressure from earphones and headphones can cause
hearing loss.
Hereby, Shenzhen AUKEY E Business Co., Ltd.declares that the radio
equipment type (Bluetooth®Headphones, EP-B80) is in compliance with
Directive 2014/53/EU. The full text of the EU declaration of conformity is
available at the following internet address: www.aukey.com.
Notice: This device may be used in each member state of the EU.
Trademark
The Bluetooth®word mark and logos are registered trademarks owned
by Bluetooth SIG, Inc. and any use of such marks by Shenzhen AUKEY E
Business Co., Ltd. is under license. Other trademarks and trade names
are those of their respective owners.
Notice for the US
Changes or modifications not expressly approved by the party responsible
for compliance could void the user’s authority to operate the equipment.
FCC Rules
This device complies with Part 15 of the FCC Rules. Operation is subject
to the following two conditions:
1.
2.
NOTE: This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to Part 15 of the FCC Rules. These
limits are designed to provide reasonable protection against harmful
interference in a residential installation.
This equipment generates, uses, and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However, there is
no guarantee that interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference by one or
more of the following measures:
●
●
●
FAQ
The earbuds are on but not connecting to my device
For the earbuds and your device to establish a connection, you need to
put them both in pairing mode. Please follow the instructions in the
“Pairing” section of this manual.
I’ve established a connection with my smartphone but can’t hear any sound
Double-check the volume level on your smartphone and the earbuds.
Some smartphones require you to set up the earbuds as an audio output
device before the audio can be transmitted. If you’re using a music player
or other device, please make sure it supports the A2DP stereo music profile.
The sound isn’t very clear or the caller can’t hear my voice clearly
Adjust the volume on your smartphone and the earbuds. Try getting
closer to your smartphone to rule out the possibility of interference or
wireless range-related issues.
What is the wireless range of the earbuds?
The maximum range is 15m (49ft). However, the actual range will depend on
environmental factors. For optimal performance, keep your devices
connected with the earbuds within a 15ft–40ft range and make sure that
there are no major obstacles (like reinforced steel walls) between the
earbuds and your devices.
My earbuds won’t turn on
Try charging the earbuds for a while. If the earbuds still won’t power on,
please contact our support team at the address below.
Product Care & Use
●
●
Warranty & Customer Support
For questions, support, or warranty claims, contact us at the address below
that corresponds with your region. Please include your Amazon order
number and product model number.
*Please note, AUKEY can only provide after sales service for products purchased directly from
AUKEY. If you have purchased from a different seller, please contact them directly for service
or warranty issues.
- 08 -
This device may not cause harmful interference.
This device must accept any interference received, including interference
that may cause undesired operation.
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that
to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
This device may not cause harmful interference, and
This device must accept any interference received, including interference
that may cause undesired operation.
l'appareil ne doit pas produire de brouillage, et
l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique
subi, même si le brouillage est susceptible d'en compromettre le
fonctionnement.
Qualcomm®aptX™ is a product of Qualcomm Technologies International,
Ltd. Qualcomm is a trademark of Qualcomm Incorporated, registered in
the United States and other countries, used with permission. aptX is a
trademark of Qualcomm Technologies International, Ltd., registered in
the United States and other countries, used with permission.
●
This equipment complies with FCC RF radiation exposure limits set forth
for an uncontrolled environment.
IC Statement
This device complies with Industry Canada licence-exempt RSS standard(s).
Operation is subject to the following two conditions:
1.
2.
Le présent appareil est conforme aux CNR d'Industrie Canada applicables
aux appareils radio exempts de licence. L'exploitation est autorisée aux
deux conditions suivantes:
1.
2.
CE Statement
Max RF power level:
BT classic (2402–2480MHz): 2.1dBm
RF exposure assessment has been performed to prove that this unit will
not generate the harmful EM emission above the reference level as
specified in EC Council Recommendation (1999/519/EC).
CAUTION: RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN INCORRECT
TYPE. DISPOSE OF USED BATTERIES ACCORDING TO THE INSTRUCTIONS.
Excessive sound pressure from earphones and headphones can cause
hearing loss.
Hereby, Shenzhen AUKEY E Business Co., Ltd.declares that the radio
equipment type (Bluetooth®Headphones, EP-B80) is in compliance with
Directive 2014/53/EU. The full text of the EU declaration of conformity is
available at the following internet address: www.aukey.com.
Notice: This device may be used in each member state of the EU.
Trademark
The Bluetooth®word mark and logos are registered trademarks owned
by Bluetooth SIG, Inc. and any use of such marks by Shenzhen AUKEY E
Business Co., Ltd. is under license. Other trademarks and trade names
are those of their respective owners.
Notice for the US
Changes or modifications not expressly approved by the party responsible
for compliance could void the user’s authority to operate the equipment.
FCC Rules
This device complies with Part 15 of the FCC Rules. Operation is subject
to the following two conditions:
1.
2.
NOTE: This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to Part 15 of the FCC Rules. These
limits are designed to provide reasonable protection against harmful
interference in a residential installation.
This equipment generates, uses, and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However, there is
no guarantee that interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference by one or
more of the following measures:
●
●
●
FAQ
The earbuds are on but not connecting to my device
For the earbuds and your device to establish a connection, you need to
put them both in pairing mode. Please follow the instructions in the
“Pairing” section of this manual.
I’ve established a connection with my smartphone but can’t hear any sound
Double-check the volume level on your smartphone and the earbuds.
Some smartphones require you to set up the earbuds as an audio output
device before the audio can be transmitted. If you’re using a music player
or other device, please make sure it supports the A2DP stereo music profile.
The sound isn’t very clear or the caller can’t hear my voice clearly
Adjust the volume on your smartphone and the earbuds. Try getting
closer to your smartphone to rule out the possibility of interference or
wireless range-related issues.
What is the wireless range of the earbuds?
The maximum range is 15m (49ft). However, the actual range will depend on
environmental factors. For optimal performance, keep your devices
connected with the earbuds within a 15ft–40ft range and make sure that
there are no major obstacles (like reinforced steel walls) between the
earbuds and your devices.
My earbuds won’t turn on
Try charging the earbuds for a while. If the earbuds still won’t power on,
please contact our support team at the address below.
Product Care & Use
●
●
Warranty & Customer Support
For questions, support, or warranty claims, contact us at the address below
that corresponds with your region. Please include your Amazon order
number and product model number.
*Please note, AUKEY can only provide after sales service for products purchased directly from
AUKEY. If you have purchased from a different seller, please contact them directly for service
or warranty issues.
- 09 -
This device may not cause harmful interference.
This device must accept any interference received, including interference
that may cause undesired operation.
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that
to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
This device may not cause harmful interference, and
This device must accept any interference received, including interference
that may cause undesired operation.
l'appareil ne doit pas produire de brouillage, et
l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique
subi, même si le brouillage est susceptible d'en compromettre le
fonctionnement.
Qualcomm®aptX™ is a product of Qualcomm Technologies International,
Ltd. Qualcomm is a trademark of Qualcomm Incorporated, registered in
the United States and other countries, used with permission. aptX is a
trademark of Qualcomm Technologies International, Ltd., registered in
the United States and other countries, used with permission.
●
This equipment complies with FCC RF radiation exposure limits set forth
for an uncontrolled environment.
IC Statement
This device complies with Industry Canada licence-exempt RSS standard(s).
Operation is subject to the following two conditions:
1.
2.
Le présent appareil est conforme aux CNR d'Industrie Canada applicables
aux appareils radio exempts de licence. L'exploitation est autorisée aux
deux conditions suivantes:
1.
2.
CE Statement
Max RF power level:
BT classic (2402–2480MHz): 2.1dBm
RF exposure assessment has been performed to prove that this unit will
not generate the harmful EM emission above the reference level as
specified in EC Council Recommendation (1999/519/EC).
CAUTION: RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN INCORRECT
TYPE. DISPOSE OF USED BATTERIES ACCORDING TO THE INSTRUCTIONS.
Excessive sound pressure from earphones and headphones can cause
hearing loss.
Hereby, Shenzhen AUKEY E Business Co., Ltd.declares that the radio
equipment type (Bluetooth®Headphones, EP-B80) is in compliance with
Directive 2014/53/EU. The full text of the EU declaration of conformity is
available at the following internet address: www.aukey.com.
Notice: This device may be used in each member state of the EU.
Trademark
The Bluetooth®word mark and logos are registered trademarks owned
by Bluetooth SIG, Inc. and any use of such marks by Shenzhen AUKEY E
Business Co., Ltd. is under license. Other trademarks and trade names
are those of their respective owners.
Notice for the US
Changes or modifications not expressly approved by the party responsible
for compliance could void the user’s authority to operate the equipment.
FCC Rules
This device complies with Part 15 of the FCC Rules. Operation is subject
to the following two conditions:
1.
2.
NOTE: This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to Part 15 of the FCC Rules. These
limits are designed to provide reasonable protection against harmful
interference in a residential installation.
This equipment generates, uses, and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However, there is
no guarantee that interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference by one or
more of the following measures:
●
●
●
FAQ
The earbuds are on but not connecting to my device
For the earbuds and your device to establish a connection, you need to
put them both in pairing mode. Please follow the instructions in the
“Pairing” section of this manual.
I’ve established a connection with my smartphone but can’t hear any sound
Double-check the volume level on your smartphone and the earbuds.
Some smartphones require you to set up the earbuds as an audio output
device before the audio can be transmitted. If you’re using a music player
or other device, please make sure it supports the A2DP stereo music profile.
The sound isn’t very clear or the caller can’t hear my voice clearly
Adjust the volume on your smartphone and the earbuds. Try getting
closer to your smartphone to rule out the possibility of interference or
wireless range-related issues.
What is the wireless range of the earbuds?
The maximum range is 15m (49ft). However, the actual range will depend on
environmental factors. For optimal performance, keep your devices
connected with the earbuds within a 15ft–40ft range and make sure that
there are no major obstacles (like reinforced steel walls) between the
earbuds and your devices.
My earbuds won’t turn on
Try charging the earbuds for a while. If the earbuds still won’t power on,
please contact our support team at the address below.
Product Care & Use
●
●
Warranty & Customer Support
For questions, support, or warranty claims, contact us at the address below
that corresponds with your region. Please include your Amazon order
number and product model number.
*Please note, AUKEY can only provide after sales service for products purchased directly from
AUKEY. If you have purchased from a different seller, please contact them directly for service
or warranty issues.
- 10 -
Qualcomm®aptX™ is a product of Qualcomm Technologies International,
Ltd. Qualcomm is a trademark of Qualcomm Incorporated, registered in
the United States and other countries, used with permission. aptX is a
trademark of Qualcomm Technologies International, Ltd., registered in
the United States and other countries, used with permission.
●
This equipment complies with FCC RF radiation exposure limits set forth
for an uncontrolled environment.
IC Statement
This device complies with Industry Canada licence-exempt RSS standard(s).
Operation is subject to the following two conditions:
1.
2.
Le présent appareil est conforme aux CNR d'Industrie Canada applicables
aux appareils radio exempts de licence. L'exploitation est autorisée aux
deux conditions suivantes:
1.
2.
CE Statement
Max RF power level:
BT classic (2402–2480MHz): 2.1dBm
RF exposure assessment has been performed to prove that this unit will
not generate the harmful EM emission above the reference level as
specified in EC Council Recommendation (1999/519/EC).
CAUTION: RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN INCORRECT
TYPE. DISPOSE OF USED BATTERIES ACCORDING TO THE INSTRUCTIONS.
Excessive sound pressure from earphones and headphones can cause
hearing loss.
Hereby, Shenzhen AUKEY E Business Co., Ltd.declares that the radio
equipment type (Bluetooth®Headphones, EP-B80) is in compliance with
Directive 2014/53/EU. The full text of the EU declaration of conformity is
available at the following internet address: www.aukey.com.
Notice: This device may be used in each member state of the EU.
Trademark
The Bluetooth®word mark and logos are registered trademarks owned
by Bluetooth SIG, Inc. and any use of such marks by Shenzhen AUKEY E
Business Co., Ltd. is under license. Other trademarks and trade names
are those of their respective owners.
Notice for the US
Changes or modifications not expressly approved by the party responsible
for compliance could void the user’s authority to operate the equipment.
FCC Rules
This device complies with Part 15 of the FCC Rules. Operation is subject
to the following two conditions:
1.
2.
NOTE: This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to Part 15 of the FCC Rules. These
limits are designed to provide reasonable protection against harmful
interference in a residential installation.
This equipment generates, uses, and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However, there is
no guarantee that interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference by one or
more of the following measures:
●
●
●
FAQ
The earbuds are on but not connecting to my device
For the earbuds and your device to establish a connection, you need to
put them both in pairing mode. Please follow the instructions in the
“Pairing” section of this manual.
I’ve established a connection with my smartphone but can’t hear any sound
Double-check the volume level on your smartphone and the earbuds.
Some smartphones require you to set up the earbuds as an audio output
device before the audio can be transmitted. If you’re using a music player
or other device, please make sure it supports the A2DP stereo music profile.
The sound isn’t very clear or the caller can’t hear my voice clearly
Adjust the volume on your smartphone and the earbuds. Try getting
closer to your smartphone to rule out the possibility of interference or
wireless range-related issues.
What is the wireless range of the earbuds?
The maximum range is 15m (49ft). However, the actual range will depend on
environmental factors. For optimal performance, keep your devices
connected with the earbuds within a 15ft–40ft range and make sure that
there are no major obstacles (like reinforced steel walls) between the
earbuds and your devices.
My earbuds won’t turn on
Try charging the earbuds for a while. If the earbuds still won’t power on,
please contact our support team at the address below.
Product Care & Use
●
●
Warranty & Customer Support
For questions, support, or warranty claims, contact us at the address below
that corresponds with your region. Please include your Amazon order
number and product model number.
*Please note, AUKEY can only provide after sales service for products purchased directly from
AUKEY. If you have purchased from a different seller, please contact them directly for service
or warranty issues.
- 11 -
Qualcomm®aptX™ is a product of Qualcomm Technologies International,
Ltd. Qualcomm is a trademark of Qualcomm Incorporated, registered in
the United States and other countries, used with permission. aptX is a
trademark of Qualcomm Technologies International, Ltd., registered in
the United States and other countries, used with permission.
1 × 10mm / 0,4” Dynamischer Treiber und
Balanced Armature
Technologie
Treiber (jeder Kanal)
Modell
Chipsatz
Sensibilität
Frequenzbereich
Impedanz
Mikrofontyp
Mikrofonempfindlichkeit
Eingang
Ladedauer
Akkulaufzeit
Akkutyp
Betriebsbereich
Gewicht
EP-B80
Bluetooth 5.0+EDR, A2DP, AVRCP, HFP, HSP,
aptX, aptX-LL, AAC
QCC3005
95dB ±3dB (bei 1kHz)
10Hz – 40kHz
32 ohm ±15%
MEMS (Mikrofonchip)
-42dB ±3dB
5 V (Gleichstrom)
1,5 Stunden
bis zu 8 Stunden
Lithium-Polymer (2 x 60 mAh)
bis zu 15 m
15g
Vielen Dank, dass Sie sich für den EP-B80 Bluetooth®Kopfhörer von AUKEY
entschieden haben. Bitte lesen Sie diese Bedienungsanleitung
aufmerksam durch und bewahren Sie sie für zukünftige Referenz gut auf.
Sollten Sie darüber hinaus Fragen oder Probleme haben, hilft Ihnen unser
freundlicher Kundenservice gerne weiter. Halten Sie Ihre Produktmodell
-Nummer und Amazon-Bestellnummer bereit.
Lieferumfang
Bluetooth®Kopfhörer
USB-A- zu C-Kabel
3 Paare Silikon-Ohreinsätze (S/M/L)
3 Paare Schaumstoff-Ohreinsätze (S/M/L)
Technische Daten
Tragebeutel
Bedienungsanleitung
Garantiekarte
- 12 -
- 13 -
Lautstärke + /
Nächster Titel
LED-Anzeige
Multifunktionstaste
Lautstärke - /
Vorheriger Titel
USB-C-Ladeeingang
Mikrofon
Produktbilder
Pairing
Starten Sie mit Ihrem Kopfhörer ausgeschaltet:
1.
2.
3.
4.
Hinweise
●
●
●
●
●
Erste Schritte
Laden
Laden Sie Ihre Ohrhörer vor der ersten Verwendung vollständig auf. Die
Ohrhörer sollten vordem Laden ausgeschaltet sein. Verbinden Sie daseine
Ende des USB-A- zu C-Kabels mit einem USB-Ladeanschluss und dasandere
Ende mit dem Eingang der Ohrhörer. Sobald die grüne LED-Anzeige weiß
erlischt sind Ihre Ohrhörer vollständig geladen und einsatzbereit. Der
Ladevorgang dauert ungefähr 1,5 Stunden.
Ein-/Ausschalten
Einschalten
Ausschalten
Musikwiedergabe und Anrufsteuerung
Audio-Streaming
Sobald Ihr Gerät gekoppelt ist, können Sie über Ihre Ohrhörer kabellos
Musik oder Audiosignale streamen. Die Musikwiedergabe wird bei einem
eingehenden Anruf automatisch pausiert und nach dem Ende des
Gesprächs wiederaufgenommen.
Telefonieren
Wenn Sie Ihr Smartphone verbunden haben, können Sie über die integrierte
Fernbedienung Anrufe durchführen und annehmen.
- 14 -
Halten Sie die Multifunktionstaste gedrückt, die LED-Anzeige
leuchtet grün für 2 Sekunden auf und Sie hören einen
absteigenden Ton
Halten Sie die Multifunktionstaste gedrückt, die LED-Anzeige
leuchtet weiß für 2 Sekunden auf und Sie hören einen
ansteigenden Ton
Pairing
Starten Sie mit Ihrem Kopfhörer ausgeschaltet:
1.
2.
3.
4.
Hinweise
●
●
●
●
●
Halten Sie die Multifunktionstaste gedrückt, bis die LED-Anzeige weiß
und grün alternativ blinkt
Aktivieren Sie das Bluetooth am Gerät, das Sie mit Ihrem Kopfhörer zu
koppeln wollen
In der Liste von verfügbaren Geräten, finden und wählen Sie „AUKEY
EP-B80“
Wenn ein Code oder Pin für Kopplung erforderlich ist, geben Sie bitte
„0000“ ein
Um die Pairing-Liste zu löschen, schalten Sie die Ohrhörer ein und halten
Sie die Tasten Lautstärke + und Lautstärke - gleichzeitig für 5 Sekunden
gedrückt, bis die LED-Anzeige grün und weiß aufleuchtet. Wenn die
Pairing-Liste gelöscht ist, hören Sie einen Ton und der Pairing-Modus wird
automatisch aktiviert
Die Ohrhörer schalten sich automatisch aus, wenn nach 5 Minuten im
Pairing-Modus kein Gerät verbunden wurde
Wenn Ihr gekoppeltes Gerät ausgeschaltet oder manuell getrennt wird,
blinkt die LED-Anzeige der Ohrhörer alle 5 Sekunden zweimal weiß und die
Ohrhörer schalten sich nach 5 Minuten aus
Drücken Sie die Multifunktionstaste nach dem Ausschalten von
Bluetooth auf einem angeschlossenen Gerät zweimal, um den
Pairing-Modus zu aktivieren. Die LED-Anzeige blinkt dann 3 Minuten lang
abwechselnd weiß und grün. Wird kein Gerät gekoppelt, gehen die
Ohrhörer in den Stand-by-Modus über
Die maximale kabellose Reichweite beträgt 15 m. Bewegen Sie sich
außerhalb dieser Reichweite, wird die Verbindung zwischen den
Ohrhörern und dem gekoppelten Gerät getrennt, wobei zusätzlich ein
Ton zu hören ist. Die Verbindung wird wiederhergestellt, sofern Sie sich
Musikwiedergabe und Anrufsteuerung
Audio-Streaming
Sobald Ihr Gerät gekoppelt ist, können Sie über Ihre Ohrhörer kabellos
Musik oder Audiosignale streamen. Die Musikwiedergabe wird bei einem
eingehenden Anruf automatisch pausiert und nach dem Ende des
Gesprächs wiederaufgenommen.
Telefonieren
Wenn Sie Ihr Smartphone verbunden haben, können Sie über die integrierte
Fernbedienung Anrufe durchführen und annehmen.
- 15 -
innerhalb von 5 Minuten wieder innerhalb der Reichweite befinden. Die
Ohrhörer stellen automatisch zum zuletzt gekoppelten Gerät eine
Verbindung her. Um ein anderes Gerät zu verbinden, müssen Sie die
vorherigen Schritte für das „Pairing“ wiederholen
Pairing
Starten Sie mit Ihrem Kopfhörer ausgeschaltet:
1.
2.
3.
4.
Hinweise
●
●
●
●
●
Halten Sie die Multifunktionstaste gedrückt, bis die LED-Anzeige weiß
und grün alternativ blinkt
Aktivieren Sie das Bluetooth am Gerät, das Sie mit Ihrem Kopfhörer zu
koppeln wollen
In der Liste von verfügbaren Geräten, finden und wählen Sie „AUKEY
EP-B80“
Wenn ein Code oder Pin für Kopplung erforderlich ist, geben Sie bitte
„0000“ ein
Um die Pairing-Liste zu löschen, schalten Sie die Ohrhörer ein und halten
Sie die Tasten Lautstärke + und Lautstärke - gleichzeitig für 5 Sekunden
gedrückt, bis die LED-Anzeige grün und weiß aufleuchtet. Wenn die
Pairing-Liste gelöscht ist, hören Sie einen Ton und der Pairing-Modus wird
automatisch aktiviert
Die Ohrhörer schalten sich automatisch aus, wenn nach 5 Minuten im
Pairing-Modus kein Gerät verbunden wurde
Wenn Ihr gekoppeltes Gerät ausgeschaltet oder manuell getrennt wird,
blinkt die LED-Anzeige der Ohrhörer alle 5 Sekunden zweimal weiß und die
Ohrhörer schalten sich nach 5 Minuten aus
Drücken Sie die Multifunktionstaste nach dem Ausschalten von
Bluetooth auf einem angeschlossenen Gerät zweimal, um den
Pairing-Modus zu aktivieren. Die LED-Anzeige blinkt dann 3 Minuten lang
abwechselnd weiß und grün. Wird kein Gerät gekoppelt, gehen die
Ohrhörer in den Stand-by-Modus über
Die maximale kabellose Reichweite beträgt 15 m. Bewegen Sie sich
außerhalb dieser Reichweite, wird die Verbindung zwischen den
Ohrhörern und dem gekoppelten Gerät getrennt, wobei zusätzlich ein
Ton zu hören ist. Die Verbindung wird wiederhergestellt, sofern Sie sich
Musikwiedergabe und Anrufsteuerung
Audio-Streaming
Sobald Ihr Gerät gekoppelt ist, können Sie über Ihre Ohrhörer kabellos
Musik oder Audiosignale streamen. Die Musikwiedergabe wird bei einem
eingehenden Anruf automatisch pausiert und nach dem Ende des
Gesprächs wiederaufgenommen.
Telefonieren
Wenn Sie Ihr Smartphone verbunden haben, können Sie über die integrierte
Fernbedienung Anrufe durchführen und annehmen.
Play oder Pause
Lautstärkeregulierung
Zum nächsten oder
vorherigen Titel wechseln Lautstärke + oder - 2 Sekunden
gedrückt halten
Multifunktionstaste einmal drücken
Lautstärke + oder - drücken
- 16 -
innerhalb von 5 Minuten wieder innerhalb der Reichweite befinden. Die
Ohrhörer stellen automatisch zum zuletzt gekoppelten Gerät eine
Verbindung her. Um ein anderes Gerät zu verbinden, müssen Sie die
vorherigen Schritte für das „Pairing“ wiederholen
ACHTUNG: BEI VERWENDUNG EINES FALSCHEN BATTERIETYPS BESTEHTEXPLO-
SIONSGEFAHR. GEBRAUCHTE BATTERIEN SIND LAUT DEN ANWEISUNGEN ZU
ENTSORGEN. Ein überhöhter Schalldruck von Ohrhörern und Kopfhörern
kann zu Gehörverlust führen.
Shenzhen AUKEY E Business Co., Ltd. Erklärt hiermit, dass der Funkgerätetyp
(Bluetooth Kopfhörer, EP-B80) die EU-Richtlinie 2014/53/EU erfüllt. Der
vollständige Text der EU-Konformitätserklärung ist auf folgender Website
verfügbar: www.aukey.com.
Hinweis: Dieses Gerät darf in jedem EU-Mitgliedsstaat verwendet werden.
Meine Ohrhörer lassen sich nicht einschalten
Laden Sie die Ohrhörer für eine gewisse Zeit. Falls die Ohrhörer sich
dann immer noch nicht einschalten lassen, wenden Sie sich über die
untengenannte Adresse an unseren Kundenservice.
Produktpflege & Verwendung
●
●
Garantie & Kundenservice
Bei Fragen, Unterstützungen oder Garantieansprüchen kontaktieren Sie
unsbitte unter der jeweiligen Adresse, die Ihrer Region entspricht. Bitte
gebenSie Ihre Amazon-Bestellnummer und die Produktmodellnummer an.
*Wichtiger Hinweis: AUKEY bietet nur für die Produkte einen Kundenservice an, die direkt bei
AUKEY erworben wurden. Sollten Sie Ihr Produkt bei einem anderen Händler gekauft haben,
kontaktieren Sie bitte dessen Kundendienst bezüglich Fragen oder Garantieansprüchen.
CE-Erklärung
Max. HF-Leistungspegel:
BT classic (2402–2480 MHz): 2,1 dBm
Die HF-Expositionsbewertung wurde zum Beweis dafür durchgeführt,
dass dieses Gerät keine schädlichen EM-Emissionen jenseits des Referenzpe-
gels der Empfehlung des Rates erzeugt (1999/519/EG).
FAQ
Die Ohrhörer sind an, aber nicht mit meinem Gerät verbunden
Damit zwischen den Ohrhörern und Ihrem Gerät eine Verbindung hergestellt
werden kann, müssen Sie bei beiden den Pairing-Modus aktivieren. Folgen
Sie den Anweisungen im Abschnitt „Pairing“ dieser Bedienungsanleitung.
Ich habe eine Verbindung zu meinem Smartphone hergestellt, höre
aber keinen Ton
Überprüfen Sie die Lautstärke an Ihrem Smartphone und an den Ohrhörern. Bei
einigen Smartphones ist es erforderlich, dass die Ohrhörer als Audioausgangs-
gerät festgelegt werden, bevor Audiosignale darüber übertragen werden
können. Wenn Sie einen Musik-Player oder ein anderes Gerät verwenden,
stellen Sie sicher, dass das Stereomusikprofil A2DP unterstützt wird.
Der Klang ist nicht besonders klar oder der Anrufer kann mich nicht
deutlich hören
Passen Sie die Lautstärke an Ihrem Smartphone und an den Ohrhörern an.
Halten Sie sich so nah wie möglich an Ihrem Smartphone auf, damit
Interferenzen und Reichweiten probleme auszuschließen sind.
Wie groß ist die kabellose Reichweite der Ohrhörer?
Die maximale Reichweite beträgt 15 m. Die tatsächliche Reichweite
hängt jedoch von Umweltfaktoren ab. Für optimale Leistung sollten Sie sich in
einer Reichweite von 5– 12 m von Ihrem Gerät aufhalten und sicherstellen,
dass sich keine massiven Hindernisse (wie verstärkte Stahlwände) zwischen
den Ohrhörern und Ihrem Gerät befinden.
- 17 -
LED-Anzeige
Blinkt abwechselnd weiß und grün
Blinkt alle 5 sekunden zweimal weiß
Blinkt alle 5 sekunden einmal weiß
Blinkt einmal pro sekunde weiß
Blinkt alle 5 sekunden zweimal grün
Grün
Grün erlischt (nach dem ladevorgang)
Status
Pairing-modus
Stand-by-modus/nicht verbunden
Verbunden/musikwiedergabe
Anruf
Niedriger akkustand
Wird geladen
Vollständig geladen
Anrufe annehmen
und beenden
Zuletzt gewählte
Nummer erneut
wählen
Eingehenden
Anruf ablehnen
Mikrofonwechsel
Drücken Sie die Multifunktionstaste einmal.
Geht ein zweiter Anruf ein, drücken Sie die
Multifunktionstaste einmal, um den zweiten
Anruf anzunehmen und das erste Gespräch zu
beenden; oder halten Sie die Multifunktion-
staste 2 Sekunden lang gedrückt, um den zweiten
Anruf anzunehmen und das erste Gespräch zu
halten
Drücken Sie die Multifunktionstaste zweimal,
wenn Ihr Gerät verbunden ist (nicht während
der Musikwiedergabe)
Drücken Sie die Multifunktionstaste zweimal
Halten Sie während eines Telefongesprächs die
Taste Lautstärke + 2 Sekunden lang gedrückt,
um zwischen den Ohrhörern und Ihrem Smartphone
zu wechseln
Nutzung von
Siri oder anderen
Sprachassistenten
Wenn Ihr Gerät verbunden ist, halten Sie 2
Sekunden lang die Multifunktionstaste gedrückt,
bis Sie einen Ton hören
ACHTUNG: BEI VERWENDUNG EINES FALSCHEN BATTERIETYPS BESTEHTEXPLO-
SIONSGEFAHR. GEBRAUCHTE BATTERIEN SIND LAUT DEN ANWEISUNGEN ZU
ENTSORGEN. Ein überhöhter Schalldruck von Ohrhörern und Kopfhörern
kann zu Gehörverlust führen.
Shenzhen AUKEY E Business Co., Ltd. Erklärt hiermit, dass der Funkgerätetyp
(Bluetooth Kopfhörer, EP-B80) die EU-Richtlinie 2014/53/EU erfüllt. Der
vollständige Text der EU-Konformitätserklärung ist auf folgender Website
verfügbar: www.aukey.com.
Hinweis: Dieses Gerät darf in jedem EU-Mitgliedsstaat verwendet werden.
Meine Ohrhörer lassen sich nicht einschalten
Laden Sie die Ohrhörer für eine gewisse Zeit. Falls die Ohrhörer sich
dann immer noch nicht einschalten lassen, wenden Sie sich über die
untengenannte Adresse an unseren Kundenservice.
Produktpflege & Verwendung
●
●
Garantie & Kundenservice
Bei Fragen, Unterstützungen oder Garantieansprüchen kontaktieren Sie
unsbitte unter der jeweiligen Adresse, die Ihrer Region entspricht. Bitte
gebenSie Ihre Amazon-Bestellnummer und die Produktmodellnummer an.
*Wichtiger Hinweis: AUKEY bietet nur für die Produkte einen Kundenservice an, die direkt bei
AUKEY erworben wurden. Sollten Sie Ihr Produkt bei einem anderen Händler gekauft haben,
kontaktieren Sie bitte dessen Kundendienst bezüglich Fragen oder Garantieansprüchen.
CE-Erklärung
Max. HF-Leistungspegel:
BT classic (2402–2480 MHz): 2,1 dBm
Die HF-Expositionsbewertung wurde zum Beweis dafür durchgeführt,
dass dieses Gerät keine schädlichen EM-Emissionen jenseits des Referenzpe-
gels der Empfehlung des Rates erzeugt (1999/519/EG).
FAQ
Die Ohrhörer sind an, aber nicht mit meinem Gerät verbunden
Damit zwischen den Ohrhörern und Ihrem Gerät eine Verbindung hergestellt
werden kann, müssen Sie bei beiden den Pairing-Modus aktivieren. Folgen
Sie den Anweisungen im Abschnitt „Pairing“ dieser Bedienungsanleitung.
Ich habe eine Verbindung zu meinem Smartphone hergestellt, höre
aber keinen Ton
Überprüfen Sie die Lautstärke an Ihrem Smartphone und an den Ohrhörern. Bei
einigen Smartphones ist es erforderlich, dass die Ohrhörer als Audioausgangs-
gerät festgelegt werden, bevor Audiosignale darüber übertragen werden
können. Wenn Sie einen Musik-Player oder ein anderes Gerät verwenden,
stellen Sie sicher, dass das Stereomusikprofil A2DP unterstützt wird.
Der Klang ist nicht besonders klar oder der Anrufer kann mich nicht
deutlich hören
Passen Sie die Lautstärke an Ihrem Smartphone und an den Ohrhörern an.
Halten Sie sich so nah wie möglich an Ihrem Smartphone auf, damit
Interferenzen und Reichweiten probleme auszuschließen sind.
Wie groß ist die kabellose Reichweite der Ohrhörer?
Die maximale Reichweite beträgt 15 m. Die tatsächliche Reichweite
hängt jedoch von Umweltfaktoren ab. Für optimale Leistung sollten Sie sich in
einer Reichweite von 5– 12 m von Ihrem Gerät aufhalten und sicherstellen,
dass sich keine massiven Hindernisse (wie verstärkte Stahlwände) zwischen
den Ohrhörern und Ihrem Gerät befinden.
- 18 -
Table of contents
Languages:
Other Aukey Headphones manuals
Aukey
Aukey EP-B40 User manual
Aukey
Aukey EP-T32 User manual
Aukey
Aukey EP-B33 User manual
Aukey
Aukey EP-T10 User manual
Aukey
Aukey Wearbuds AI-W20 User manual
Aukey
Aukey AUKEY-EP-T31 User manual
Aukey
Aukey EP-B60 User manual
Aukey
Aukey EP-T1 User manual
Aukey
Aukey EP-T21S User manual
Aukey
Aukey AUKEY-EP-T31 User manual
