Aukey SK-A6 User manual
User Manual
AudioLink Wireless Speaker
Thank you for purchasing the AUKEY SK-A6 AudioLink Wireless Speaker. Please read this user
manual carefully and keep it for future reference. If you need any assistance, please contact
our support team with your product model number and Amazon order number.
Package Contents
AudioLink Wireless Speaker
Micro-USB Cable
3.5mm Audio Cable
User Manual
Warranty Card
- 01 -
Specifications
Model
Technology
Audio Output Power
Signal-to-Noise Ratio
Input
Charging Time
Play Time
Battery Type
BT Operating Range
IP Rating
Operating Temperature
Dimensions
Weight
SK-A6
BT 4.2, A2DP, AVRCP, HSP, HFP
2 x10W
>70dB
DC 5V 2.1A
3.5 hours
7.5 hours (at 50% volume)
Li-ion (2 x 2600mAh)
Up to 10m / 33ft
IPX5
-20°C- 60°C / -4°F- 140°F
106 x 106 x 80mm / 4.17” × 4.17” × 3.16”
768g / 27.09oz
Power Button Mode Button
Circle Indicator Triangle Indicator
Play/Pause Button
Volume - Volume +
Microphone
- 02 -
Audio Input
Reset Button
Micro-USB Input
Product Diagram
M
- 03 -
Charging
Fully charge this speaker before first use. Connect it to a USB charger or charging port with the
included micro-USB cable to charge. When the red circle indicator turns green, your speaker is
fully charged and ready for use. Charging takes around 3.5 hours.
Powering On / Off
● To power on, press and hold the power button for 2 seconds, and the triangle indicator will
turn blue
● To power off, press and hold the power button for 3 seconds, and the triangle indicator will
turn off
BT Pairing
1. When you turn on the speaker, it will automatically enter pairing mode and the triangle indicator
will flash blue
2. Activate the pairing function on your phone or other compatible device and select “AUKEY
SK-A6”
3. If a code or pin is required for pairing, enter “0000”
4. When successfully paired, the triangle indicator will stay blue
- 04 -
Notes
● The speaker will automatically enter standby mode after 10 minutes in pairing mode if no
devices are paired
● The speaker will automatically turn off after 10 minutes in standby mode
● If your paired device is switchedoff or manually disconnected, the speaker will enter pairing
mode and automatically enter standby mode after 10 minutes
● If the speaker or connected device exceeds the operating range (10m), the speaker will
disconnect. The connection to the last successfully connected device will be re-established
once you re-enter wireless range within 10 minutes. To connect to other devices, repeat the
previous“BT Pairing” steps
Playing Audio via Audio Cable
Connect the SK-A6 to your PC, laptop, or other device with audio output using the included
3.5mm audio cable. Press and hold the power button for 2 seconds to turn on and the triangle
indicator will light up solid white.
Notes
● The speaker will disconnect from your phone or other paired devices when an audio cable is
plugged into the audio input jack. Short-press the mode button or unplug the audio cable to
switch back to BT mode
● When playing audio using the audio input jack, short press the volume + / -to adjust the
volume. Play/pause on the speaker is disabled in audio input mode
● For some computers, you may needto access the audio control panelto manually set the
speaker as the default audio device
Connecting Multiple Speakers
1. Turn on the SK-A6 speaker you want to be the main speaker and connect it with an audio
output device (such as a phone) via BT or audio cable
2. Turn on all other SK-A6 speakers that you want to sync with the main speaker
3. Press and hold the play/pause button on the main speaker for 10 seconds (5 seconds until
circle indicator turnsgreen and another 5 seconds until it is rotating blue)to enter speaker sync
mode
- 05 -
4. Press and hold the play/pause button on a secondary speaker for 5 seconds, and the circle
indicator will flash green
5. Wait amoment for both speakersto sync. Main speaker circle indicator will turn solid blue
and secondary speaker circle indicator will turn solid green when successfully synced
6. To link additional speakers, repeat steps 4 & 5
7. For greater sound coverage and volume, link up to a total of 8 AUKEY SK-A6 speakers
To switch a secondary speaker to main speaker:
1. Press and hold the play/pause button on the main speaker for 5 seconds until triangle button
turns green (main speaker is now a secondary speaker)
2. Press and hold the play/pause button on a secondary speaker for 5 seconds until triangle
button turns blue (secondary speaker is now the main speaker)
Notes
● The maximum operating range between the main speaker and secondary speakers is 30m. If
the secondary speakers exceed this range, they will automatically disconnect
● Speakershave aconnections setupmemoryfunction, and will automatically reconnect to
each other in the previously used configuration when powered on
● Play/pause and calls-control / answering are enabled for the main speaker only
Sound Channel Switch
Each speaker can output both sound channels (stereo) or only left channel or right channel
sound. This feature is available when using more than one speaker. For general sound coverage,
all speakers can be set to stereo. When speakers are located to the left and right of listeners,
each one can be set to match its position so that left and right channel sound are more distinct
and heard from the correct sides.
● Short-press volume + and play/pause button simultaneously to switch sound channels
● Stereo – circle indicator flashes white twice
● Left channel – circle indicator flashes blue twice
● Right channel – circle indicator flashes green twice
- 06 -
EQ Modes
The speaker has 2 EQ (equalization) sound modes – enhanced bass and boosted treble.
● Press and hold volume + and volume - simultaneously for 2 seconds to toggle between EQ modes
● Enhanced bass – triangle indicator will flash blue twice
● Boosted treble – triangle indicator will flash green twice
Controls
Instructions
Press and hold volume + / -
Short-press play/pause
Short-press the volume + / - simultaneously
Press and hold the power button for 2 seconds
When connected, press and hold the mode
button for more than two seconds
Short-press mode button
Press and hold mode button for more than two seconds
Double-press mode button
Functions
Adjust volume
Pause / Resume
Check battery level
Enter / Exit standby mode
Disconnect current BT and
enter pairing mode
Answer / End a call
Reject an incoming call
Redial last-called number
Note
●Battery level is displayed as the proportion of the circle indicator lit red
●Standby mode keeps the speaker on (for upto 10 minutes) but saves power by turning off
functions such as BT connection. The speaker will automatically reconnect BT when you exit
standby mode (if connected device BT is still on)
- 07 -
LED Indicators
Triangle Indicator
Circle Indicator
Color
Blue
Blue
Blue
Green
White
Red
Color
White
Blue
Green
Blue
Blue
Green
Green
Red
Red
Red
Activity
Flashes twice
Flashes twice
Flashes twice
Rotating
Stays on
Rotating
Stays on
Flashes
Stays on
Turns green
Status Indicated
Stereo sound
Left channel sound
Right channel sound
Main speaker syncing
Main speaker synced
Secondary speaker syncing
Secondary speaker synced
Low battery
Charging
Fully charged
Activity
Flashing once every second
Stays on
Flashes twice
Flashes twice
Stays on
Stays on
Status Indicated
BT pairing mode / Disconnected
BT connected / Playing music / In call
Enhanced bass EQ mode
Boosted treble EQ mode
Audio input mode
Standby mode
- 08 -
Resetting the Speaker
● To restore to default factory settingsor to clear program errors, use a pin or needle to
carefully press the reset button
Product Care & Use
● Keep away from extreme heat and strong magnetic fields
● Do not use this speaker at high volume for extended periods, as this may cause permanent
hearing damage or loss
Warranty & Customer Support
For questions, support, or warranty claims, contact us at the address below that corresponds
with your region. Please include your Amazon order number and product model number.
*Please note, AUKEY can only provide after sales service for products purchased directly from AUKEY. If you have
purchased from a different seller, please contact them directly for service or warranty issues.
Notice for US
Changes or modifications not expressly approved by the party responsible for compliance
could void the user's authority to operate the equipment. This device complies with Part 15 of
the FCC Rules. Operation is subject to the following two conditions:
1. This device may not cause harmful interference, and
2. This device must accept any interference received, including interference that may cause
undesired operation
- 09 -
FCC Rules
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates uses and can
radiate radio frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the equipment
off and on, the user is encouraged to try to correct the interference by one or more of the following
measures:
● Reorient or relocate the receiving antenna
● Increase the separation between the equipment and receiver
●Connect the equipment into an outlet on acircuit different from that to which the receiver is
connected
● Consult the dealer or an experienced radio/TV technician for help
Caution
Changes or modifications made to this device not expressly approved by AUKEY may void the
FCC authorization to operate this equipment.
