Aukey BR-C19 User manual

User Manual
2-in-1Wireless Transmitter & Receiver

Thank you for purchasing the AUKEY BR-C19 2-in-1Wireless Transmitter & Receiver. Please read this user
manual carefully and keep it for future reference. If you need any assistance, please contact our
support team with your product model number and Amazon order number.
Package Contents
2-in-1WirelessTransmitter & Receiver
3.5mm Audio Cable
Micro-USB Charging Cable
User Manual
Warranty Card
Product Diagram
Receiver Mode
Multi-Function Button
Transmitter Mode
LED Indicator
Micro-USB
Charging Port
3.5mm Audio Jack
- 01 -

Specifications
Model
Technology
Frequency Range
Input
Charging Time
Continuous Use Time
Battery Type
Operating Range
Dimensions
Weight
BR-C19
BT 4.1, A2DP, AVRCP
2.4GHz - 2.48GHz
DC 5V
2 hours
12 hours (Receiver Mode) / 13 hours (Transmitter Mode)
Li-Polymer (250mAh)
Up to 10m / 33ft
44 × 44 × 12.4mm / 1.73” × 1.73” × 0.47”
18g / 0.63oz
Getting Started
Please fully charge your product before first use. To charge, connect it to a USB charger or charging
port with the included micro-USB cable. When the red LED indicator turns off, your BR-C19 is fully charged
and ready for use. Charging takes around 2 hours.
- 02 -

Powering On / Off
Power On
Power Off
Choose receiver or transmitter mode before powering on the BR-C19
Press and hold the multi-function button for 2 seconds and the LED
indicator will flash blue twice
Press and hold the multi-function button for 3 seconds and the LED
indicator will flash red twice
Note
● After powering off, please wait for 3 seconds to ensure the BR-C19 is fully powered down before
switching mode
Pairing
Transmitter Mode
1. Choose the transmitter mode. Connect one end of the included 3.5mm audio cable to the 3.5mm
audio jack on the BR-C19, and connect the other end of the cable to your audio output device (TV,
computer, CD player, MP3 player, or other) that doesn’t have wireless function
2. Power on the BR-C19 and it will automatically enter pairing mode (LED indicator flashing blue rapidly).
To manually enter pairing (usually to pair with a different device), double-press the multi-function
button
3. Activate the pairing function of your wireless-compatible audio device (like wireless headphones or
speakers)
4. When the BR-C19 has connected with the wireless audio device, the LED indicator will stay blue
- 03 -
Notes
●In transmitter mode, the BR-C19 will automatically exit pairing mode and go into standby (LED indicator
flashing blue once every second) after 2 minutes if no device is paired
●In transmitter mode, the pairing list of your BR-C19 includes up to 4 paired devices and the BR-C19
will automatically reconnect to the last two successfully paired devices
●When you power off, wait for 3 seconds before switching mode. When you turn on the BR-C19 in
receiver mode, the transmitter mode pairing list will be cleared
Receiver Mode
1. Choose the receiver mode. Connect one end of the included 3.5mm audio cable to the 3.5mm
audio jack on the BR-C19, and connect the other end of the cable to your audio equipment (wired
headphones, speaker, or stereo system). Wired headphones may also be used by directly connecting
their audio cable to the BR-C19
2. Power on the BR-C19 and it will automatically enter pairing mode (LED indicator flashing red and
blue alternately). To manually enter pairing (usually to pair with a different device), double-press the
multi-function button
3. Activate the pairing function of your wireless-compatible audio device (like a smartphone) and select
“AUKEY BR-C19”
4. If a code or pin is required for pairing, enter “0000”
Notes
●In receiver mode, the BR-C19 will automatically shut down after 5 minutes in pairing mode if no
device is paired
● In receiver mode, the pairing list of the BR-C19 includes up to 8 paired devices and the BR-C19 will
automatically reconnect to the last two paired devices
●When you power off, wait for 3 seconds before switching mode. When you turn on the BR-C19 in
transmitter mode, the receiver mode pairing list will be cleared
Simultaneous Connection with Two Devices
In transmitter mode, two connected wireless devices (such as wireless headphones) can receive sound
from the same source (such as a TV) simultaneously. In receiver mode, two wireless devices (such as
phones) can be simultaneously connected to one audio output device (such as a speaker), but sound
can only be received from one source at a time.
1. Follow the instructions in the “Pairing” section to pair the BR-C19 with Device A
2. Once paired, disable the wireless function on Device A and then double-press the multi-function
button to enter pairing mode
3. Activate the wireless function of Device B and connect with “AUKEY BR-C19”
4. Once paired with Device B, reactivate the wireless function on Device A and connect with “AUKEY
BR-C19”
5. If you cannot connect the second device, try double-pressing the multi-function button again
Controls & LED Indicator
Once connected in receiver mode, you can stream music to your receiving devices and play or pause
using the BR-C19.

Note
● After powering off, please wait for 3 seconds to ensure the BR-C19 is fully powered down before
switching mode
Pairing
Transmitter Mode
1. Choose the transmitter mode. Connect one end of the included 3.5mm audio cable to the 3.5mm
audio jack on the BR-C19, and connect the other end of the cable to your audio output device (TV,
computer, CD player, MP3 player, or other) that doesn’t have wireless function
2. Power on the BR-C19 and it will automatically enter pairing mode (LED indicator flashing blue rapidly).
To manually enter pairing (usually to pair with a different device), double-press the multi-function
button
3. Activate the pairing function of your wireless-compatible audio device (like wireless headphones or
speakers)
4. When the BR-C19 has connected with the wireless audio device, the LED indicator will stay blue
Notes
●In transmitter mode, the BR-C19 will automatically exit pairing mode and go into standby (LED indicator
flashing blue once every second) after 2 minutes if no device is paired
●In transmitter mode, the pairing list of your BR-C19 includes up to 4 paired devices and the BR-C19
will automatically reconnect to the last two successfully paired devices
●When you power off, wait for 3 seconds before switching mode. When you turn on the BR-C19 in
receiver mode, the transmitter mode pairing list will be cleared
Receiver Mode
1. Choose the receiver mode. Connect one end of the included 3.5mm audio cable to the 3.5mm
audio jack on the BR-C19, and connect the other end of the cable to your audio equipment (wired
headphones, speaker, or stereo system). Wired headphones may also be used by directly connecting
their audio cable to the BR-C19
2. Power on the BR-C19 and it will automatically enter pairing mode (LED indicator flashing red and
blue alternately). To manually enter pairing (usually to pair with a different device), double-press the
multi-function button
3. Activate the pairing function of your wireless-compatible audio device (like a smartphone) and select
“AUKEY BR-C19”
4. If a code or pin is required for pairing, enter “0000”
- 04 -
Notes
●In receiver mode, the BR-C19 will automatically shut down after 5 minutes in pairing mode if no
device is paired
● In receiver mode, the pairing list of the BR-C19 includes up to 8 paired devices and the BR-C19 will
automatically reconnect to the last two paired devices
●When you power off, wait for 3 seconds before switching mode. When you turn on the BR-C19 in
transmitter mode, the receiver mode pairing list will be cleared
Simultaneous Connection with Two Devices
In transmitter mode, two connected wireless devices (such as wireless headphones) can receive sound
from the same source (such as a TV) simultaneously. In receiver mode, two wireless devices (such as
phones) can be simultaneously connected to one audio output device (such as a speaker), but sound
can only be received from one source at a time.
1. Follow the instructions in the “Pairing” section to pair the BR-C19 with Device A
2. Once paired, disable the wireless function on Device A and then double-press the multi-function
button to enter pairing mode
3. Activate the wireless function of Device B and connect with “AUKEY BR-C19”
4. Once paired with Device B, reactivate the wireless function on Device A and connect with “AUKEY
BR-C19”
5. If you cannot connect the second device, try double-pressing the multi-function button again
Controls & LED Indicator
Once connected in receiver mode, you can stream music to your receiving devices and play or pause
using the BR-C19.

Note
● After powering off, please wait for 3 seconds to ensure the BR-C19 is fully powered down before
switching mode
Pairing
Transmitter Mode
1. Choose the transmitter mode. Connect one end of the included 3.5mm audio cable to the 3.5mm
audio jack on the BR-C19, and connect the other end of the cable to your audio output device (TV,
computer, CD player, MP3 player, or other) that doesn’t have wireless function
2. Power on the BR-C19 and it will automatically enter pairing mode (LED indicator flashing blue rapidly).
To manually enter pairing (usually to pair with a different device), double-press the multi-function
button
3. Activate the pairing function of your wireless-compatible audio device (like wireless headphones or
speakers)
4. When the BR-C19 has connected with the wireless audio device, the LED indicator will stay blue
Notes
●In transmitter mode, the BR-C19 will automatically exit pairing mode and go into standby (LED indicator
flashing blue once every second) after 2 minutes if no device is paired
●In transmitter mode, the pairing list of your BR-C19 includes up to 4 paired devices and the BR-C19
will automatically reconnect to the last two successfully paired devices
●When you power off, wait for 3 seconds before switching mode. When you turn on the BR-C19 in
receiver mode, the transmitter mode pairing list will be cleared
Receiver Mode
1. Choose the receiver mode. Connect one end of the included 3.5mm audio cable to the 3.5mm
audio jack on the BR-C19, and connect the other end of the cable to your audio equipment (wired
headphones, speaker, or stereo system). Wired headphones may also be used by directly connecting
their audio cable to the BR-C19
2. Power on the BR-C19 and it will automatically enter pairing mode (LED indicator flashing red and
blue alternately). To manually enter pairing (usually to pair with a different device), double-press the
multi-function button
3. Activate the pairing function of your wireless-compatible audio device (like a smartphone) and select
“AUKEY BR-C19”
4. If a code or pin is required for pairing, enter “0000”
Notes
●In receiver mode, the BR-C19 will automatically shut down after 5 minutes in pairing mode if no
device is paired
● In receiver mode, the pairing list of the BR-C19 includes up to 8 paired devices and the BR-C19 will
automatically reconnect to the last two paired devices
●When you power off, wait for 3 seconds before switching mode. When you turn on the BR-C19 in
transmitter mode, the receiver mode pairing list will be cleared
Simultaneous Connection with Two Devices
In transmitter mode, two connected wireless devices (such as wireless headphones) can receive sound
from the same source (such as a TV) simultaneously. In receiver mode, two wireless devices (such as
phones) can be simultaneously connected to one audio output device (such as a speaker), but sound
can only be received from one source at a time.
1. Follow the instructions in the “Pairing” section to pair the BR-C19 with Device A
2. Once paired, disable the wireless function on Device A and then double-press the multi-function
button to enter pairing mode
3. Activate the wireless function of Device B and connect with “AUKEY BR-C19”
4. Once paired with Device B, reactivate the wireless function on Device A and connect with “AUKEY
BR-C19”
5. If you cannot connect the second device, try double-pressing the multi-function button again
- 05 -
Controls & LED Indicator
Once connected in receiver mode, you can stream music to your receiving devices and play or pause
using the BR-C19.

Note
● After powering off, please wait for 3 seconds to ensure the BR-C19 is fully powered down before
switching mode
Pairing
Transmitter Mode
1. Choose the transmitter mode. Connect one end of the included 3.5mm audio cable to the 3.5mm
audio jack on the BR-C19, and connect the other end of the cable to your audio output device (TV,
computer, CD player, MP3 player, or other) that doesn’t have wireless function
2. Power on the BR-C19 and it will automatically enter pairing mode (LED indicator flashing blue rapidly).
To manually enter pairing (usually to pair with a different device), double-press the multi-function
button
3. Activate the pairing function of your wireless-compatible audio device (like wireless headphones or
speakers)
4. When the BR-C19 has connected with the wireless audio device, the LED indicator will stay blue
Notes
●In transmitter mode, the BR-C19 will automatically exit pairing mode and go into standby (LED indicator
flashing blue once every second) after 2 minutes if no device is paired
●In transmitter mode, the pairing list of your BR-C19 includes up to 4 paired devices and the BR-C19
will automatically reconnect to the last two successfully paired devices
●When you power off, wait for 3 seconds before switching mode. When you turn on the BR-C19 in
receiver mode, the transmitter mode pairing list will be cleared
Receiver Mode
1. Choose the receiver mode. Connect one end of the included 3.5mm audio cable to the 3.5mm
audio jack on the BR-C19, and connect the other end of the cable to your audio equipment (wired
headphones, speaker, or stereo system). Wired headphones may also be used by directly connecting
their audio cable to the BR-C19
2. Power on the BR-C19 and it will automatically enter pairing mode (LED indicator flashing red and
blue alternately). To manually enter pairing (usually to pair with a different device), double-press the
multi-function button
3. Activate the pairing function of your wireless-compatible audio device (like a smartphone) and select
“AUKEY BR-C19”
4. If a code or pin is required for pairing, enter “0000”
Notes
●In receiver mode, the BR-C19 will automatically shut down after 5 minutes in pairing mode if no
device is paired
● In receiver mode, the pairing list of the BR-C19 includes up to 8 paired devices and the BR-C19 will
automatically reconnect to the last two paired devices
●When you power off, wait for 3 seconds before switching mode. When you turn on the BR-C19 in
transmitter mode, the receiver mode pairing list will be cleared
Simultaneous Connection with Two Devices
In transmitter mode, two connected wireless devices (such as wireless headphones) can receive sound
from the same source (such as a TV) simultaneously. In receiver mode, two wireless devices (such as
phones) can be simultaneously connected to one audio output device (such as a speaker), but sound
can only be received from one source at a time.
1. Follow the instructions in the “Pairing” section to pair the BR-C19 with Device A
2. Once paired, disable the wireless function on Device A and then double-press the multi-function
button to enter pairing mode
3. Activate the wireless function of Device B and connect with “AUKEY BR-C19”
4. Once paired with Device B, reactivate the wireless function on Device A and connect with “AUKEY
BR-C19”
5. If you cannot connect the second device, try double-pressing the multi-function button again
Controls & LED Indicator
Once connected in receiver mode, you can stream music to your receiving devices and play or pause
using the BR-C19.
Play / Pause Press the multi-function button once
LED Indicator
Blue
Blue flashing rapidly
Blue & red flashing alternately
Blue flashing once every second
Blue flashing twice every 3 seconds
Red flashing
Red
Red turns off (after charging)
Status
Connected
Transmitter pairing mode
Receiver pairing mode
Transmitter disconnected or in standby
Receiver disconnected
Low battery
Charging
Fully charged
Product Care & Use
●Please keep away from liquids and extreme heat
●Do not use headphones or speakers at high volume for extended periods, as this may cause permanent
hearing damage or loss
- 06 -
Warranty & Customer Support
For questions, support, or warranty claims, contact us at the address below that corresponds with your
region. Please include your Amazon order number and product model number.
Amazon US orders: [email protected]
Amazon EU orders: support[email protected]
Amazon CA orders: support[email protected]
Amazon JP orders: [email protected]
*Please note, AUKEY can only provide after sales service for products purchased directly from AUKEY. If you have
purchased from a different seller, please contact them directly for service or warranty issues.

Product Care & Use
●Please keep away from liquids and extreme heat
●Do not use headphones or speakers at high volume for extended periods, as this may cause permanent
hearing damage or loss
Warranty & Customer Support
For questions, support, or warranty claims, contact us at the address below that corresponds with your
region. Please include your Amazon order number and product model number.
Amazon US orders: [email protected]
Amazon EU orders: [email protected]
Amazon CA orders: [email protected]
Amazon JP orders: [email protected]
*Please note, AUKEY can only provide after sales service for products purchased directly from AUKEY. If you have
purchased from a different seller, please contact them directly for service or warranty issues.
- 07 -
