Auriol Z29962C User manual

Z29962C
Z29962D
RADIO-CONTROLLED
WEATHER STATION
Operation and Safety Notes
FUNK-WETTERSTATION
Bedienungs- und Sicherheitshinweise
VREMENSKA STANICA
Upute za posluživanje i za Vašu sigurnost
ΑΣΥΡΜΑΤΟΣ
ΜΕΤΕΩΡΟΛΟΓΙΚΟΣ ΣΤΑΘΜΟΣ
Υποδείξεις χειρισμού και ασφαλείας
STAŢIE METEO FĂRĂ FIR
Instrucţiuni de utilizare şi de siguranţă
МЕТЕОРОЛОГИЧНА СТАНЦИЯ
С РАДИОВРЪЗКА
Инструкции за обслужване и безопасност
7

GB/CY Operation and Safety Notes Page 6
HR Upute za posluživanje i za
Vašu sigurnost Stranica 26
RO Instrucţiuni de utilizare şi
de siguranţă Pagina 46
BG Инструкции за обслужване
и безопасност Страница 66
GR/CY Υποδείξεις χειρισμού
και ασφαλείας Σελίδα 88
DE/AT / CH Bedienungs- und
Sicherheitshinweise Seite 110

3
TENDENCY
%
COMFORT
IN
OUT
O
C
O
C
DAY D M
s
MAX
MIN
MAX
MIN
YEAR
PM
A
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
Z29962C/ Z29962D

4
B
20
21
22
2324

5
C
25
26
27
2829

6 GB/CY
Proper Use........................................................Page 7
Description of parts ......................................Page 7
Technical Data................................................. Page 8
Scope of Supply .............................................Page 9
Safety
General Safety Information ............................ Page 10
Safety Instructions for Batteries.......................Page 10
Before Initial Use
General information........................................ Page 12
Setting up the external sensor......................... Page 13
Setting up the weather station ........................Page 13
Mounting the product on a wall .............Page 14
Weather station............................................... Page 15
External sensor................................................. Page 15
Setting up the weather station................ Page 15
Operation
Setting the time/ date manually ..................... Page 16
Displaying DST summertime............................ Page 16
Setting the alarm.............................................. Page 17
Switching the alarm on/ off............................ Page 17
Using the snooze function............................... Page 18
Temperature display........................................ Page 18
Humidity display.............................................. Page 18
Setting up the weather forecast function........ Page 18
Weather trend .................................................Page 19
Setting the memory function for
minimum/ maximum levels.............................. Page 20
Displaying the maximum/ minimum levels..... Page 20
Using 12-/ 24-hour format ............................. Page 21
Selecting the language ................................... Page 21
Setting the time zone....................................... Page 22
Changing the batteries.................................... Page 22
Troubleshooting............................................. Page 23
Cleaning and Maintenance ....................... Page 23
Disposal............................................................. Page 24
Declaration of Conformity......................... Page 25

7GB/CY
Radio-controlled weather station
Q
Proper Use
The weather station displays the indoor and outdoor
temperature in Celsius (°C) or Fahrenheit (°F), the
indoor relative humidity in % RH and their maximum
and minimum levels. The weather station also displays
a weather forecast, the time in 12/24-hour format
and the date. It is also equipped with an alarm and
calendar function. The device is not intended for
commercial use.
Q
Description of parts
Weather station
1Weather icon
2Comfort indicator
3Humidity (% RH) (indoor)
4MAX display for indoor/ outdoor temperature
5Indoor temperature
6MIN display for indoor/ outdoor temperature
7Outdoor temperature
8Date (Day/ Month)
9Time
10 ZZ/REGISTER button
11 MEMORY button
12 ADJUST button (for settings)
13 ALARM button
14 CLOCK button
15 -Icon
16
s
-Icon (DST/ summertime)
17 YEAR/ DAY display
18 MAX/ MIN display for humidity
19 Weather trend

8 GB/CY
20 Hanger
21 Battery compartment
22 Stand
23 Dowel (ø 7 mm)
24 Screw (ø 4.5mm)
External sensor
25 Indicator LED
26 Hanger
27 Battery compartment
28 Dowel (ø 5 mm)
29 Screw (ø 3mm)
Q
Technical Data
Weather station:
Indoor temperature
measuring range: 0 – + 49.9 °C
+ 32 – + 122 °F
The value LL.L appears in the LC display at an
internal temperature of ≤ – 10 °C (14 °F).
The value HH.H appears in the LC display at an
internal temperature of ≥ 50 °C (122 °F).
Temperature
resolution: 0.1 °C
Measuring range
humidity: 30 – 95 %
Resolution
humidity: 1 %
Radio signal: DCF
Battery: 2 x AA 1.5 V (included in
delivery scope)

9GB/CY
External sensor:
Temperature
measuring range: – 20 – + 60 °C
– 4 – + 140 °F
The value LL.L appears in the LC display at an
external temperature of ≤ –50 °C (– 58 °F).
The value HH.H appears in the LC display at an
external temperature of ≥ 70 °C (158 °F).
HF transmission
signal: 433 MHz
HF transmission
range: max. 30 metres in open space
Battery: 2 x AA 1.5 V (included in
delivery scope)
Q
Scope of Supply
Please check the supplied items immediately after
unpacking the device to ensure that there is nothing
missing and that the product and all of its parts are
in perfect condition.
1x radio-controlled weather station
1x external sensor
1x stand (weather station)
4x battery AA 1.5 V
2x dowels (ø 7mm, ø 5mm)
2x screws (ø 4.5mm, ø 3mm)
1x operating manual

10 GB/CY
Safety
YOU SHOULD STORE ALL SAFETY INFORMATION
AND INSTRUCTIONS IN A SAFE PLACE IN CASE
YOU NEED TO REFER TO THEM AGAIN IN THE
FUTURE!
General Safety
Information
WARNING!DANGER TO LIFE! Batteries
can be swallowed, which may represent a danger
to life. If a battery has been swallowed, medical
help is required immediately.
J Children or persons who lack the knowledge or
experience to use the device or whose physical,
sensory or intellectual capacities are limited must
never be allowed to use the device without su-
pervision or instruction by a person responsible
for their safety. Children must never be allowed
to play with the device.
J Please note that the guarantee does not cover
damage caused by incorrect handling, non-
compliance with the operating instructions or
interference with the device by unauthorised
individuals.
Safety Instructions
for Batteries
J Remove the batteries from the device if they are
not going to be used for a prolonged period.

11GB/CY
J CAUTION! DANGER OF EXPLO-
SION! The batteries must never be
recharged!
J When inserting the batteries, ensure the correct
polarity! This is shown in the battery compart-
ments.
J If necessary, clean the batteries and device
contacts before inserting the batteries.
J Remove spent batteries immediately from the
device. There is an increased danger of leaks!
J Batteries must not be disposed of in the normal
domestic waste!
J Every consumer is legally obliged to dispose of
batteries in the proper manner!
J Keep batteries away from children; do not throw
batteries in the fire, short-circuit batteries or take
them apart.
J Always replace all the batteries at once.
J CAUTION! DANGER OF EXPLO-
SION! Use batteries of the same
type only.
J If the above instructions are not complied with,
the batteries may discharge themselves beyond
their end voltage. There is a danger of leaking.
If the batteries have leaked inside your device,
you should remove them immediately in order
to prevent damage to the device!
J Avoid contact with the skin, eyes and mucous
membranes. Any parts of the body coming into
contact with battery acid should be rinsed off
with copious amounts of water and/or a doctor
contacted if necessary!

12 GB/CY
Q
Before Initial Use
Q
General information
m CAUTION! When choosing where to position
the weather station, make sure that it is not
exposed to direct sunlight, vibrations, dust, heat,
cold or moisture. Do not place the weather
station or external sensor near to heat sources,
e.g. radiators, as this may result in damage to
the instruments.
j Do not place the devices near sources of inter-
ference such as television sets, computers, thick
walls, thermopane windows etc. Otherwise the
transmission of radio waves between the devices
may be impaired.
j Please ensure that neighbouring devices are not
operated at the same frequency of 433MHz.
Such devices may cause interference to the
radio connection.
j Do not place the devices next to or on metal
plates. Otherwise the quality of radio wave
transmission may be reduced.
Radio signal (DCF):
The DCF signal (time signal transmitter) is made up
of time pulses transmitted from one of the highest
precision clocks in the world close to Frankfurt/Main
in Germany - it varies by 1 second in 1 million years.
In ideal conditions, your weather station can pick
up this signal over a distance of up to approx.
1,500 km around Frankfurt /Main.

13GB/CY
Q
Setting up the external sensor
Inserting the batteries:
j Remove the battery compartment cover from
the back of the external sensor.
j Insert two 1.5 V batteries (AA) (included) in
the battery compartment 27.
Note: make sure that the polarity is correct. This
is indicated inside the battery compartment 27
(see Fig. C).
– The external sensor is now ready for operation
and the indicator LED 25 will flash.
j Close the battery compartment cover.
Q
Setting up the weather station
Inserting the batteries:
j Open the battery compartment cover on the
back of the weather station.
j Place two 1.5 V batteries (AA) (included) in
the battery compartment 21.
Note: take care that the polarity is correct. This
is indicated inside the battery compartment 21
(see Fig. B).
j Close the battery compartment cover.
As soon as the batteries have been inserted, the
LCD indicates the indoor temperature 5and the
humidity 3. The weather station starts to receive
the signal from the external sensor. When it has
successfully received the external sensor signal, the
outdoor temperature 7appears on the LCD after
around 1 minute.
Note: do not alter the position of the weather station
when it is picking up the signal, as this can interfere
with reception.

14 GB/CY
The weather station starts to pick up the radio signal
after it has successfully received the external sensor
signal. This process can take up to 7 minutes and is
indicated on the LCD by the flashing icon 15.
Once the DCF radio signal has been picked up
successfully, the icon 15 is displayed constantly
on the LCD.
If synchronisation with the atomic clock is not possible
during setup, change the position of the weather
station (e.g. to next to a window).
j If the weather station does not work properly, you
can restart it by pressing the ADJUST button 12.
Reception may be seriously restricted by certain
obstacles (e.g. concrete walls) or sources of inter-
ference (e.g. other electrical devices).
If interference with reception of the radio signal con-
tinues, you can also set the time and date manually
(see “Setting the time/date manually”).
Q
Mounting the product on a wall
Note: You will require an electric drill and a cross-
head screwdriver for this step.
m CAUTION! DANGER TO LIFE, RISK OF
INJURY AND MATERIAL DAMAGE! Read
the operating and safety instructions for your drill
carefully.
WARNING!DANGER TO LIFE! Take care
that you do not hit electricity, gas or water lines when
you drill into the wall. If necessary, check with a pipe
and cable detector before drilling.

15GB/CY
Q
Weather station
j Mark the position of the hole (ø approx. 7 mm)
on the wall.
j Drill the hole with an electric drill.
j Insert the dowel 23 into the drilled hole.
j Using a crosshead screwdriver, screw the
screw 24 into the dowel 23.
j Hang the weather station by placing the hanger
20 on the screw 24.
Q
External sensor
j Mark the position of the hole (ø approx. 5 mm)
on the wall.
j Drill the hole with an electric drill.
j Insert the dowel 28 into the drilled hole.
j Using a crosshead screwdriver, screw the
screw 29 into the dowel 28.
j Hang the external sensor by placing the
hanger 26 on the screw 29.
Note: Choose a sheltered position for the external
sensor, not directly near the weather station (e.g.
separated by a wall). Ensure that the external sensor
does not come into contact with water or direct
sunlight. Electronic devices may adversely affect
the wireless signal reception.
Q
Setting up the weather station
j Place the stand 22 on the underside of the
weather station.

16 GB/CY
Q
Operation
Reception of the DCF radio signal may be disrupted
or interrupted at the location of the weather station.
In this case you are able to set the instrument
manually.
Q
Setting the time/date manually
1. Press and hold the CLOCK button 14 for approx.
3 seconds. The hours on the time display 9
begin to flash.
2. Press the ADJUST button 12 to set the required
number.
Tip: keep the ADJUST button 12 pressed for
faster time setting. You can also use this option
for the subsequent settings.
If no button is pressed in the space of approx.
30 seconds, the LCD automatically returns to
the standard display.
3. Press the CLOCK button 14 to confirm your
entry. The minutes on the time display 9start
to flash.
4. Repeat steps 2 and 3 to set the minutes, seconds,
year 17 and date 8(month and day).
Note: the seconds display can only be reset
to 00.
5. The LCD returns to the standard display after
you have made the settings.
Q
Displaying DST summertime
Summertime is automatically displayed on the LCD
by the
s
icon 16. The DCF radio signal indicates
to the clock whether or not it is summertime.

17GB/CY
Q
Setting the alarm
j Press and hold the ALARM button 13 for approx.
3 seconds.
Note: if you have already set an alarm, the
set alarm time is displayed on the LCD together
with AL. Otherwise 0:00 and AL are displayed.
j Press the ALARM button 13 briefly. The hours
start to flash.
j Press the ADJUST button 12 to set the required
number.
j Press the ALARM button 13 to confirm your
entry. The minutes start to flash.
j Press the ADJUST button 12 to set the required
number.
j Press the ALARM button, 13 to confirm your
entry.
j The LCD returns to the standard display (Time 9).
Q
Switching the alarm on/off
j Press and hold the ALARM button 13 for approx.
3 seconds. The set alarm time appears on the LCD.
j Press the ADJUST button 12 to switch the alarm
on or off.
Note: when the alarm is switched on, is
displayed above AL.
Note: if no button is pressed within a space of
approx. 30 seconds, the LCD automatically
returns to the standard display.
j The alarm rings for approx. 2 minutes as soon as
the set alarm time is reached. The alarm signal
is switched off automatically after 2 minutes.
Press one of the buttons, MEMORY 11,
ADJUST 12, ALARM 13 or CLOCK 14, to
switch the alarm signal off within this time.
Note: the alarm rings every day at the set time.

18 GB/CY
Q
Using the snooze function
j Press the ZZ/REGISTER button 10 when the
alarm is ringing to activate the snooze function.
j The alarm signal silences and the ZZdisplay
flashes. The alarm signal sounds again after an
interval of 5 minutes.
Note: the alarm rings every day at the set time.
Q
Temperature display
The LCD indicates both the current indoor 5and
outdoor temperature 7.
j Press and hold the ADJUST button 12 for approx.
3 seconds. The °C display starts to flash.
j Press the ADJUST button 12 to switch between
the °C and °F temperature scales.
j Press the MEMORY button 11 to confirm your
entry.
Q
Humidity display
The current humidity 3is displayed on the LCD.
The comfort indicator 2divides the humidity into
three categories.
The displays have the following meaning:
WET = humidity 3> 70 %
COMFORT = humidity 340 – 70 %,
DRY = humidity 3< 40 %
Q
Setting up the weather
forecast function
Note: please also listen to the weather forecast from
your local weather service. If there are discrepancies
between the instrument and your local weather service,
please go by the local weather service forecast.

19GB/CY
j Press and hold the ADJUST button 12 for approx.
3 seconds. The °C or °F display starts to flash.
j Press the CLOCK button 14. The weather icon 1
starts to flash.
j Press the ADJUST button 12 to set the current
weather conditions.
The following weather icons are available:
cloudy
partly cloudy
sunny
rainy
Note: please ensure that you set the current
weather conditions correctly; otherwise the dis-
played weather forecast will not be accurate.
j Press the MEMORY button 11 to confirm your
entry.
Note: if no button is pressed in a space of
approx. 30 seconds, the LCD returns to the
standard display.
Q
Weather trend
The weather station has a weather trend display 19.
The displays have the following meaning:
= the weather is deteriorating
= no change in the weather

20 GB/CY
= the weather is improving
Q
Setting the memory function
for minimum/maximum levels
j Press and hold the ADJUST button 12 for approx.
3 seconds. Either the °C or °F display starts to
flash.
j Press the CLOCK button 14 twice. - - starts to
flash.
j Press the ADJUST button 12 to set the required
memory interval.
The following intervals are available:
- - = general minimum/maximum levels
1d = daily minimum/ maximum levels
7d = weekly minimum/maximum levels
j Press the MEMORY button 11 to confirm your
entry.
Note: if no button is pressed in a space of
approx. 30 seconds, the LCD returns to the
standard display.
Q
Displaying the maximum/
minimum levels
Note: depending on the memory interval setting,
the LCD displays either the general, daily or weekly
minimum/ maximum levels.
j Press the MEMORY button 11 once to display
the maximum 4and minimum 6levels for
the indoor temperature (IN) and the maximum
levels for humidity 3.
j Press the MEMORY button 11 again to display
the maximum 4and minimum 6levels for the
outdoor temperature (OUT) and the minimum
levels for the humidity 3.
