Auriol Z31601A User manual

IAN 91679
RADIO-CONTROLLED WEATHER STATION
RADIO-CONTROLLED
WEATHER STATION
Operation and Safety Notes
BEZDRÁTOVÁ METEORO-
LOGICKÁ STANICE
Pokyny pro obsluhu a bezpečnostní pokyny
BRADIjSKO VODENA
VREMENSKA pOSTAjA
Navodila za upravljanje in varnostna opozorila
METEOSTANICA
Pokyny pre obsluhu a bezpečnostné pokyny
91679_aur_Funk-Wetterstation_Cover_SI_CZ_SK.indd 2 28.06.13 10:18

GB Operation and Safety Notes Page 8
SI Navodila za upravljanje in varnostna opozorila Stran 31
CZ Pokyny pro obsluhu a bezpečnostní pokyny Strana 55
SK Pokyny pre obsluhu a bezpečnostné pokyny Strana 77
91679_aur_Funk-Wetterstation_Cover_SI_CZ_SK.indd 3 28.06.13 10:18

3
A
1 32
13
17
14
18
15
19
16
20
6
6
5
4
91679_aur_Funk-Wetterstation_Content_SI_CZ_SK.indd 3 28.06.13 10:18

4
11
B810911
91679_aur_Funk-Wetterstation_Content_SI_CZ_SK.indd 4 28.06.13 10:18

5
C
21
22
23
24
91679_aur_Funk-Wetterstation_Content_SI_CZ_SK.indd 5 28.06.13 10:18

6
7
12
5
9
D
91679_aur_Funk-Wetterstation_Content_SI_CZ_SK.indd 6 28.06.13 10:18

7
E
2
91679_aur_Funk-Wetterstation_Content_SI_CZ_SK.indd 7 28.06.13 10:18

8 GB
Intended use............................................................................ Page 9
Parts description................................................................... Page 9
Technical Data ........................................................................ Page 10
Scope of delivery.................................................................. Page 10
General safety instructions............................................ Page 11
Battery safety information............................................. Page 12
Start-up ....................................................................................... Page 13
Setting up the devices................................................................. Page 14
Starting the outdoor sensor/changing batteries...................... Page 14
Starting the base station/changing batteries........................... Page 14
The DCF signal (time transmitter) ............................................... Page 15
Information in base mode
The clock field ............................................................................. Page 16
The barometric pressure field..................................................... Page 18
The indoor temperature field...................................................... Page 19
The outdoor temperature field.................................................... Page 20
Settings
Basic settings ............................................................................... Page 22
Temperature alarm...................................................................... Page 24
Activating the temperature alarm............................................... Page 24
Alarm ........................................................................................... Page 25
Accessing stored data ................................................................ Page 26
Manually activating signal reception
Activating DCF signal reception................................................. Page 27
Activating reception from the outdoor sensor ........................... Page 27
Background lighting.................................................................... Page 28
Troubleshooting.................................................................... Page 28
Cleaning and Care ............................................................... Page 29
Disposal...................................................................................... Page 29
Declaration of Conformity.............................................. Page 29
91679_aur_Funk-Wetterstation_Content_SI_CZ_SK.indd 8 28.06.13 10:18

9GB
Radio-controlled weather station
Intended use
This radio-controlled weather station displays the indoor and outdoor
temperature, indoor and outdoor humidity, and barometric pressure. It
features a radio-controlled clock and several alarm functions. The proba-
ble weather trend is calculated based on data collected. The product is
not intended for commercial use.
Parts description
Base station
1Display
2SNOOZE-/LIGHT field
3Keypad
4Base station eyebolt
5Battery compartment cover
6Stand
7Battery compartment
Outdoor sensor
8Signal LED
9Battery compartment cover
10 Outdoor sensor eyebolt
11 Outdoor sensor stand
12 Outdoor sensor battery
compartment
Keypad
13 SET-/HISTORY button
14 UP button
15 DOWN-/ button
16 ALARM-/SET button
17 CH button
18 ALERT button
19 MEM button
20 °C/°F button
Display
21 Clock field
22 Barometric pressure field
23 Indoor temperature field
24 Outdoor temperature field
91679_aur_Funk-Wetterstation_Content_SI_CZ_SK.indd 9 28.06.13 10:18

10 GB
Technical Data
Base station:
Temperature measurement range: 0°C to 50°C
32°F to 122°F
Humidity measurement range: 20% to 95%
Radio-controlled clock: DCF77
Batteries: 2xLR06, 1.5V (size AA)
Barometric pressure
measurement range: 850hPa to 1050hPa
25.1 inHg to 31.1 inHg
Outdoor sensor:
Temperature measurement range: -20°C to +50°C
-4.0°F to + 122°F
Humidity measurement range: 20% to 95%
Data transmission frequency: 433MHz
Wireless range: max. 100m (open area)
Batteries: 2xLR03, 1.5V (size AAA)
Model no.: Z31601A (black), Z31601B (white)
Scope of delivery
1 Weather station
1 Outdoor sensor
2 Batteries, type LR06, 1.5V
2 Batteries, type LR03, 1.5V
1 Set of operating instructions
91679_aur_Funk-Wetterstation_Content_SI_CZ_SK.indd 10 28.06.13 10:18

11GB
General safety instructions
Before using the product, please familiarise
yourself with all of the safety information and in-
structions for use! When passing this product on to
others, please also include all the documents!
This product may be used by children
age 8 years and up, and persons with
reduced physical, sensory or mental capacity
or lacking experience and knowledge, when
supervised or instructed on the safe use of the
product and the associated risks. Children should
not be allowed to play with the appliance.
Cleaning and user maintenance should not be
performed by children without supervision.
Do not use the device if it is damaged.
Do not expose the base station to moisture or
direct sunlight.
91679_aur_Funk-Wetterstation_Content_SI_CZ_SK.indd 11 28.06.13 10:18

12 GB
Battery safety information
DANGER TO LIFE!
Batteries are not intended for children. If acci-
dentally swallowed seek immediate medical at-
tention!
CAUTION! EXPLOSION HAZARD!
Never recharge non-rechargeable
batteries, short-circuit and/or open batteries!
Never throw batteries into fire or water!
Do not exert mechanical loads to batteries!
Risk of battery leakage
In the event of a battery leak, immediately re-
move it from the device to prevent damage!
Avoid contact with the skin, eyes and mucous
membranes! In the event of contact with battery
acid, thoroughly flush the affected area with
plenty of clean water and seek immediate
medical attention!
Only use the same type of batteries! Do not
mix used and new batteries!
91679_aur_Funk-Wetterstation_Content_SI_CZ_SK.indd 12 28.06.13 10:18

13GB
Avoid extreme environmental conditions and
temperatures as they may affect batteries e.g.
above radiators!
Remove the batteries from the device if they
have not been used for a long period!
Risk of equipment damage
Only use the specified battery type!
When inserting the battery ensure the correct
polarity! This is shown in the battery compart-
ment!
If necessary, clean the battery and device
contacts before inserting the battery!
Promptly remove drained batteries from the
product!
Start-up
Note: First insert the batteries in the outdoor sensor, then the weather
station.
91679_aur_Funk-Wetterstation_Content_SI_CZ_SK.indd 13 28.06.13 10:18

14 GB
Setting up the devices
ATTENTION: First start the outdoor sensor, then the base station.
If possible, do not expose the outdoor sensor or base station to di-
rect sunlight.
The base station as well as the outdoor sensor can be hung by the
eyebolt 4or 10 . Or flip out the stand 6or 11 . on either device to
place the device on a horizontal, level surface.
Starting the outdoor sensor/
changing batteries
Open the battery compartment 12 on the back of the outdoor
sensor by sliding the battery cover 9in the direction of the arrow.
When changing batteries first remove the old batteries.
Insert the new batteries, type LR03, in the battery compartment 12 .
Check the polarity of the battery during insertion. This is indicated in
the battery compartment.
Close the battery cover.
The signal LED 8at the front of the outdoor sensor will briefly light
up. The signal LED will then flash about twice a minute, indicating
wireless transmission.
Starting the base station/changing batteries
Open the battery cover 5at the back of the base station by pulling
up on the tab at the bottom of the battery compartment.
When changing batteries first remove the old batteries.
91679_aur_Funk-Wetterstation_Content_SI_CZ_SK.indd 14 28.06.13 10:18

15GB
Insert the new batteries, type LR06, in the battery compartment 7.
Check the polarity of the battery during insertion. This is indicated in
the battery compartment.
Close the battery cover.
The display 1will briefly light up and run a brief check of all dis-
play elements.
The outdoor temperature field 24 will show an animation of the re-
ception symbol , indicating the base station is searching for the
signal from the outdoor sensor.
If no outdoor temperature is displayed after 3 minutes,the base sta-
tion will stop searching. The animation of the reception symbol will
turn off and the outdoor temperature field will show --._ °C and --._ %.
Most likely, the signal cannot be received due to structural factors, re-
inforced concrete walls, the brickwork being too solid, or the
distance between the units. After finding a better location for the
outdoor sensor, reception will need to be restarted.
Press and hold the CH button 17 at the back of the base station for
3 seconds until the reception signal becomes animated again.
The weather station will automatically start receiving the DCF radio
signal, regardless if signal from the outdoor sensor was received or
not. The clock field 21 will show an animated radio tower icon , in-
dicating the receiver for the DCF signal is starting to receive the time.
The DCF signal (time transmitter)
The DCF signal (German time transmission station) consists of time im-
pulses emitted by one of the most accurate clocks in the world, located
near Frankfurt/Main, Germany.
In ideal conditions, your weather station can pick up this signal over a
distance of up to approx. 1500km around Frankfurt/Main.
91679_aur_Funk-Wetterstation_Content_SI_CZ_SK.indd 15 28.06.13 10:18

16 GB
If the signal is detected the clock display 21 will show the current Central
European Time, date and day of the week. A static radio tower signal
appears. For more details please refer to section Basic settings.
If the attempts to receive a signal fail the base station will stop attempting
to receive a signal after 7 minutes and the radio tower signal will
disappear. For information on how to resolve this issue please refer to
chapter Troubleshooting.
You may reactivate reception by pressing and holding the DOWN-/
button 15 for three seconds until an radio tower signal in the
clock display 21 becomes animated.
You also have the option to set the time manually. For more details
please refer to section Basic settings.
Once the base station has received the signal from the outdoor sensor
and the DCF signal, it enters base mode.
In base mode the base station will display the following information:
Information in base mode
The clock field 21
Time:
The time will be displayed in 24 hour
format according to the default settings.
When selecting 12 hour mode in basic
settings, the time from 12:00 o‘clock in the
afternoon until 11:59 o‘clock at night will show PM (Latin for „post me-
ridiem“ = afternoon) in front of the time.
91679_aur_Funk-Wetterstation_Content_SI_CZ_SK.indd 16 28.06.13 10:18

17GB
During Daylight Saving Time DST will appear at the top between the hour
and minute. This display is only functional when receiving the DCF signal.
Date and day:
To the left of the abbrevia-
tion D (Day) the date of
the current day appears,
and to the left of the abbreviation M (month) the date of the current
month. On the right the abbreviation for the current day of the week ap-
pears. The default language for this abbreviation is German, but can be
changed. Please refer to section Basic settings.
The radio tower symbol:
The radio tower symbol indicates successful reception of the
DCF signal. The weather station synchronises its internal clock
with the time station every night. During synchronisation this sym-
bol will flash. If reception was successful the symbol will be static until the
next reception cycle.
The lunar phase:
The current lunar phase is indicated as follows:
The portion of the moon not illuminated will be dark in the
display.
91679_aur_Funk-Wetterstation_Content_SI_CZ_SK.indd 17 28.06.13 10:18

18 GB
The barometric pressure field 22
Barometric pressure display:
At the top right is the barometric pressure
at the time shown in the HIST field (history).
If LLL (or LL.LL when setting the unit inHg),
the display range is below 850hPa
(25.1 inHg), if HHH (or HH.HH), it is above.
By default the current barometric pressure
(HIST = 0) is shown in the unit mb (millibar)
or hPa (hectopascal). However, the display
can also be set to the uncommon unit inHg
(inch of mercury). Please refer to section Basic settings.
The bar graph shows a graphic of the barometric pressure 0, 1, 2, 3, 6
and 12 hours ago.
The barometric pressure trend:
The trend will appear as rising (or dropping), when the baro-
metric pressure changes by 2 hPa (= 0.06 inHg) or more
within an hour and will maintain the direction for one hour
even without any further change.
The weather forecast:
The weather station calculates a weather forecast for about the next
12 hours based on the barometric pressure trend. Of course this forecast
can‘t compare to that of professional weather services supported by
satellites and high performance computers, but merely provides an ap-
proximate indication of current developments.
Available graphic forecasts are:
91679_aur_Funk-Wetterstation_Content_SI_CZ_SK.indd 18 28.06.13 10:18

19GB
slightly cloudy sunny cloudy rainy snow
The indoor temperature field 23
The indoor temperature:
The indoor temperature measured by the base sta-
tion is displayed with indexing up to a tenth of a
degree. The temperature unit °C (for degrees Cel-
sius) appears at the top right. The temperature unit
can also be set to the now uncommon unit °F (degrees Fahrenheit).
To change to this unit press the °C/F button 20 . If LL.L appears, it is be-
low the measurement range of 0 °C to 50 °C (or 32 °F to 122 °F),
when HH.H appears it is above.
The relative humidity:
This displays the relative humidity to which the base
station is exposed.
The temperature- or humidity trend:
The trend will appear as rising (or dropping), when the tem-
perature changes by 2 °C (= 3.6 °F) or more within an hour
and will maintain the direction for one hour even without any
further change. The humidity trend will respond accordingly with a
change of 2 % in humidity.
91679_aur_Funk-Wetterstation_Content_SI_CZ_SK.indd 19 28.06.13 10:18

20 GB
Indoor climate rating:
Based on the indoor humidity and temperature the weather station will
rate the indoor climate using the following key:
DRY humidity below 40%
COMFORT humidity between 40 and 70%,
and a temperature range between 20 °C–28°C
(68°F–82.4°F).
WET humidity higher than 70%
When the indoor temperature is outside the 20°C–28°C range no in-
door climate rating will appear.
Low battery:
If the battery symbol appears the batteries in the base sta-
tion should be replaced as soon as possible. Please refer to
the instructions in section Starting the base station/changing
batteries.
The outdoor temperature field 23
The outdoor temperature:
The outdoor temperature is displayed with index-
ing up to a tenth of a degree. The temperature
unit °C (for degrees Celsius) appears at the top
right. The temperature unit can also be set to the
now uncommon unit °F (degrees Fahrenheit).
91679_aur_Funk-Wetterstation_Content_SI_CZ_SK.indd 20 28.06.13 10:18
