AusClimate AU1000DD User manual

USER MANUAL
Ausclimate Cool Seasons 10L
Desiccant Dehumidifier
Model: AU1000DD
Please read this user manual before operating

IMPORTANT SAFETY INSTRUCTIONS
PLEASE READ ALL INSTRUCTIONS CAREFULLY BEFORE OPERATING.
WARNING - This appliance is intended for use in a domestic or office environment only.
Any other use is not recommended by the manufacturer and may cause fire, electrical
shocks or other injury to person or property.
When using electrical appliances, basic safety precautions should always be followed:
1. Do not operate the unit with a damaged power cord or power plug, or after it malfunctions
or has been dropped or damaged in any way. Seek advice from your reta iler or distributor
for examination and repair.
2. This unit should always be kept in an upright position to avoid any damage. Locate the
unit on a flat stable surface.
3. Check the household voltage to ensure it matches the units rated specification before
operating.
4. Operate this unit in an ambient temperature between 1°C and 40°C.
5. Ensure that the air inlets and outlets are not blocked or covered.
6. Do not place the unit too close to curtains or other furnishings - min 40cm.
7. When using the "LAUNDRY MODE" to speed up the drying of wet clothes in the room,
please keep the clothing at a safe distance from the unit to prevent water from dripping
onto the unit.
8. Never place anything on top of the unit and do not cover with any kind of material while in
use.
9. This product is intended for domestic and office use ONLY and not for commercial,
industrial or outdoor use.
10. To protect against electrical shocks, do not immerse unit, power cord or power plug in
water, or spray with liquids.
11. Never unplug the power cord without pressing the "ON/OFF" key to off first, as this could
damage the unit.
12. Always unplug the unit when not in use or moving location. To disconnect from the power
supply, grip the plug to pull from the power socket. Never pull by the cord.
13. Always empty the water tank before storing the unit away.
14. Close supervision is necessary when any appliance is used near children and pets.
15. Do not run power cord under carpet, or cover the cord with rugs or runners. Arrange the
power cord away from areas where it may be tripped over.
16. Never operate or store the unit in direct sunlight.
17. If authorised by the distributor, repairs may be undertaken by a qualified service
technician. Repairs carried out by unqualified people may cause damage to the unit or
injury to persons or property and void the warranty.
18. Where possible, don’t use an extension power lead as the cable may overheat and cause
a risk of fire. Only use an extension lead after ensuring it is in perfect condition.
19.Do not use the unit without the air filter and make sure that the filter is kept clean to avoid
malfunction and invalidating the warranty.
SAVE AND READ THESE IMPORTANT SAFETY INSTRUCTIONS
1
This appliance is not intended for use by persons (including children) with reduced physical,
sensory or mental capabilities, or lack of experience and knowledge, unless they have been given
supervision or instruction concerning use of the appliance by a person responsible for their safety. Children
should be supervised to ensure that they do not play with the appliance.

FEATURES
(Non) Compressor dehumidifier ~ uses desiccant rotor technology
Environmentally friendly with no harmful gasses & quiet in operation
Moisture removal ~ 10 litres/day (20 C, 60%RH)
Water tank capacity ~ 3.8 litres
Nano-silver embedded in the filter
~ kills bacteria on contact improving the quality of air in your home or office
~ Anti-bacteria Nano-silver embedded in each filter string
~ Over 99% anti-bacteria performance
~ The filter may be cleaned by use of vacuum cleaner
~ The filter may also be washed by water and still retain performance
Laundry mode ~ includes power saving setting for warm
temperatures & turbo setting for winter
Up to 8-hour timer ~ for added convenience
Temperature range for use ~ 1 C - 40 C
Light & portable with carry handle
Removable water bucket with handle
Operating light
Auto restart after power cut
~ Once the power is restored after a power failure,
the appliance will continue to operate at the selected
settings prior to the power failure.
Wide / Spot adjustable louver
~ to provide wide, parallel or spot air flow.
Automatic louver wide range (max 150o
o
)
~ 3-stage automatic air swing to meet your needs.
~ Retractable 50 downward sub-louver for drying
shoes or ground.
leave the clothes
more than 40cm
away
2
Wide blowing Spot blowing

PRODUC SEDT CRIPTION
THE CONTROL PANEL
3
Control panel
Auto-swing louver
Sub-louver
for downward
blowing
Adjustable
blades
Plug
Air filter
Continuous
drain hole
Air outlet
Handle
Water level
indicator
Air inlet
Hand grip
to pull out
the bucket
Bucket
Full
Check
ON/OFF
Wide
Front
Up
8H
4H
2H
Turbo
Saving
High
Low
Auto
TIMER
SWING
DRY
MODE
LAUNDRY
MODE
Louver settings
Control key
Dry Mode key
Power Key
Continuous /
Laundry Mode key
Timer key Timer indicators
Function indicators
Louver setting indicators
Water Full indicator
Indicator lights up when the bucket
is full of water orincorrectly installed.
Check indicator
Indicator lights up when the unit
malfunctions.

UNIT SETUP
Place the unit in an upright position on a stable, flat surface.
Ensure the unit is a safe distance away from a
wall or furniture (see the right graphic).
Keep clothes at a safe distance of 40 cm
from air outlet of the unit to prevent water
dripping into the unit.
Where to position your
dehumidifier?
For best results position the
dehumidifier somewhere central,
such as the middle of the room or
a hallway. Do not position in front
of a radiator or in direct sunlight.
TO OPERATE SAFELY
Do not insert small
objects into the unit
as they may cause
damage or possible
hazard.
Keep suitable distance
space as above
Do not remove water
bucket when running
or water may leak.
Ensure water bucket is fitted
correctly. If the bucket is full
or is not in place, the "FULL"
lights up and the unit stops.
4
Top
min 60cm
Air outlet
min 20cm
(When louver up)
Air inlet
Louver
min 20cm
min 20cm
min 50cm
min 40cm
(When louver
closed)

OPERATING INSTRUCTIONS
ON and OFF
Connect the power plug to the appropriate electrical socket outlet.
Press the ON/OFF button to turn the unit ON.
Press the ON/OFF button again to turn the unit OFF.
Note: In the event of a power failure
Once the power is restored after a power failure, the unit will
continue to operate at the selected settings prior to the power
failure. This includes the drying mode, swing function and time
remaining in timermode.
Note: After turning the appliance OFF
After turning the unit OFF using the ON/OFF button, the fan will
continue to run for a two-minute period. This is a normal procedure
and helps to cool & protect the internal components.
During this two-minute period, DO NOT remove the power plug from
the power socket outlet; wait for the fanto stop running.
AUTO DRY MODE
Press the "AUTO DRY" key for dehumidification (general drying of your home or office).
Note: There may be times when the fan speeds are the same for AUTO and LOW.
AUTO itself is not a fan speed but a target relative humidity set point that uses
either the low or high fan speeds to reach its target of 55-60%RH.
If the relative humidity of the room is close to or within this range, then switching
between LOW and AUTO will make no difference to the fan speed.
AUTO
LOW
HIGH
MODE
AUTO
DESCRIPTION
T
o keep the room at a comfortable relative humidity (RH)
l
evel
The unit automatically keeps room humidity at 55~60%RH
with automatic high or low fan speed.
LOW
To run low fan speed
The unit automatically dehumidifies in low fan speed and
low heater.
HIGH
Super dry mode to prevent damp, condensation & mould
The unit automatically keeps room humidity at 45~50%RH
to achieve quicker and efficient drying.
5
Full
Check
ON/OFF
Wide
Front
Up
8H
4H
2H
Turbo
Saving
High
Low
Auto
TIMER
SWING
DRY
MODE
LAUNDRY
MODE

OPERATING INSTRUCTIONS
LAUNDRY MODE
Press the "LAUNDRY MODE" key for drying clothes.
MODE DESCRIPTION
SAVING Suitable for warmer temperatures to save power
The unit automatically provides warm dry air to assist in
clothes drying with low power.
TURBO Suitable in cooler winter temperatures to dry clothes faster
The unit automatically provides heated air to dry clothes
faster with higher power.
AUTO SWING LOUVER
Press the "SWING" Key to select the preferred air louver angle.
UP FRONT
HOLD (LED OFF)
The louver modes are useful for speeding up the drying of washing, wardrobes and
walls because it directs the airflow towards the surface of these areas - water
molecules will be forced out faster.
SAVING TURBO
MODE DESCRIPTION
UP The automatic louver swings in an upward
range of approx. 100 .
0
The automatic louver swings in a front
range of approx. 50 .
0
FRONT
WIDE The automatic louver swings in a wide
range of approx. 150 .
0
HOLD The automatic louver stops swinging when you press
"SWING" key - turns the LED light off.
6
WIDE
TOP
FRONT
WIDE

OPERATING INSTRUCTIONS
WIDE / SPOT ADJUSTABLE LOUVER
Wide blowing
-adjust the blades outwards
for an expanded airflow.
Spot blowing
-adjust the blades inwards
for a spot airflow.
DOWNWARD LOUVER ADJUSTMENT
TIMER MODE
Press the "TIMER MODE” key to select your desired running time (2, 4 or 8 hours).
The unit will automatically switch off at the end of the selected time period.
As the time counts down the LED (4 or 2 hours) lights will indicate the time remaining.
When no "TIMER" is set (the LED light is off), the unit will run continuously unless the
bucket is already full.
4hrs
continuous (LED OFF)
The Timer mode is useful
A sub-louver under the main louver can be moved out for blowing air downward further.
if you want to dry a load of washing in ‘Turbo’ laundry mode
and you know that it will take say, 4 hours and you wish to just run the unit at full
power for that time period.
7
2hrs 8hrs
Pull out Push back
Hold both ends
and pull out
Hold both ends
and push back
Press central
portion downward
Turn central portion
upward

TO EMPTY THE WATER BUCKET
Pull bucket out Lift by the handle Remove the cover Pour the water away
NOTE :
Return the bucket
Clean the water bucket with clean water if needed. Do not
use solvents, abrasive materials or hot water.
Do not remove or damage the float in the bucket, or the unit
The bucket cover must be correctly fitted into position.
The "FULL" LED lights up if the bucket is not correctly fitted
TO DRAIN WATER
You may use 2 methods to remove the collected water: water
bucket or drain hose.
A drain hose with an inner diameter of 12mm is quite suitable for
continuous drainage (1.2M drain hose is included):
1. Use a screwdriver to remove the ‘knockout’ at the back of
the unit. Attach the tubing to the connector through the hole.
2.The drain hose should lead downwards away from the unit,
with no sharp bends to ensure uninterrupted drainage.
8
cannot work correctly.
into position.
Return the cover
and the handle
1. When the water bucket is full, the "FULL" LED lights up and the unit stops within
a few minutes.
2. Do not move the unit or remove the water bucket if the machine is still operating.
Water may leak and cause damage to the unit or cause an electric shock.
3. To remove the water bucket, pull it out by gripping the bottom of the bucket, and
lift carefully.
4. Remove the cover of water bucket first, then pour the water away. Clean the
bucket and return the cover and the bucket to the correct position.

MAINTENANCE
Cleaning the unit
1. Turn off the unit, wait for the fan to stop and unplug from the power socket.
2. Clean the surface with a soft damp cloth.
3. Dry thoroughly with a towel after cleaning.
4. To avoid damage, do not wash or splash the unit with water, or let water
drip into the air inlet or airoutlet.
Cleaning the nano-silver air filter
If the nano-silver air filter is covered with dust, the airflow and general performance
of the unit may be affected. Check and clean the filter every 2 weeks or as required.
1. Turn off the unit and remove the filter from the unit.
2. Clean the filter with a vacuum cleaner.
3. You may also wash the filter with water and still retain bacterial protection.
4. Replace the filter in position.
Before placing into storage
1. Turn off the unit, wait for it to stop and unplug from the power socket.
2. Clean and dry the bucket, as well as the filter and the rest of the unit.
3. Ensure the unit is fully drained of water.
4. Cover the unit to prevent it from gathering dust.
5. Store upright in a cool dry place.
6. Do not expose to direct sunlight.
9

TROUBLE-SHOOTING
Check the following before contacting technical support:
Problem Cause Solution
The unit does not
operate.
The power is not connected. Insert power plug into the power socket.
Power cord or power plug may be
damaged.
Inspect power cord and power plug for
damage. If damaged, do not use - contact
the retailer or distributor for advice.
The device does
not dehumidify.
The water container is full. Empty the water from the container.
The water bucket has not been
replaced correctly.
Return the water bucket into the correct
position.
The air filter is clogged. Clean the air filter.
The temperature in the room where
the dehumidifier is operating is too
low.
The machine does not dehumidify below
1°C. Note: at such low temperatures, the
moisture in the room will be very low
anyway.
The relative humidity in the room
where the dehumidifier is operating is
too low.
The unit dries down to the target
relative humidity, then goes into ‘fan
only’ mode until the relative humidity
goes above the set point again.
The unit is not
drying quickly
enough.
The unit may have already reduced the
humidity in the room to one of the
targets of 55-60%.
Set the DRY MODE to ‘High’, which
may further reduce the humidity to
40-45% Relative Humidity.
The unit works,
but reduces the
relative humidity
insufficiently /
there is little
water in the water
tank.
The room/house is too large. This
dehumidifier can dry to about a medium
3 or 4 bedroom house.
We recommend using a dehumidifier
with a greater capacity, or ‘compressor’
dehumidifier.
There are too many sources of
moisture: showers, washing, clothes-
drying and cooking all puts moisture
into the air. Un-flued gas heating can
also add too much moisture into the air
for a dehumidifier to remove.
We recommend using a dehumidifier
with a greater capacity, or ‘compressor’
dehumidifier.
Consider using a different heat source to
an un-flued gas heater.
The air filter is blocked - the reduced
air flow is effecting performance.
Clean the air filter.
Unit is blowing
out warm air. Air is passed over a heating element
within the unit, prior to being blown
into the room. This is part of the
dehumidification process.
This is normal, a dehumidifier is not an
air cooler.
The unit is
noisy.
The air filter is blocked or the unit is
on an uneven surface.
Clean the filter and or put the unit on a
flat surface. A dehumidifier will also be
noisier on wooden floors than carpet.
The fan still runs
after I have
turned the unit
off.
The fan is cooling the internal heater. This is normal. The fan will run for
about 2 minutes after you press the
power button off. Wait for the fan to
stop, then turn the unit off at the wall.
The “Check” LED
is illuminated.
The unit may not be working properly
. Clean the filter and leave to stand for 20
minutes. Ensure that the dehumidifier is
not in front of a hot radiator. If the
problem remains, then please contact
the distributor.
There is an odour
coming from the
unit.
The zeolite desiccant material may be
returning various household odours
back into the room during the
dehumidification process.
This odour is not harmful to humans or
pets. It
will not last long and is not a sign
of a fault.
10

11
SPECIFICATIONS
Model AU1000DD
Power supply AC 220-240V, 50Hz
Power input Low 410watts / High 720watts
Dehumidifying capacity 10 litres/day (20°C@60%RH)
Recommended room size 50m2 or 125m3
Capacity water container 3.8 litres
Operating range 1 – 40°C
Dimensions (w x d x h) W462 x D217 x H525mm
Noise levels Low 45, High 52 dBA
Power control Easy soft touch
Desiccant Zeolite
Drain hose 1.2M provided
Net weight 8.2kgs
For all after-sales enquiries and warranty details please visit our website
for contact information, or call 1800 122 100
