AUSTRALIAN MONITOR AMIS ZRM4 User manual

A More Thorough Examination...
The AMIS ZRM4 is an easy to use, yet highly featured 1 RU zone routing mixer.
At a Glance
Australian Monitor
1 RU Zone Routing Mixer
Just some of the ZRM4’s features include...
> 6 universal inputs > +/- 15dB gain trim per input
> 4 balanced outputs > Input 1 has selectable priority
> Individual output assign with LED > Switchable mic/line balanced XLR inputs
indication per input > Bi colour status LED per output
> Bi colour status LED per input > Remote VCA volume control per output
> HPF & 15 VDC Phantom power > On board Pre announce, bell, alert & evac tones
switchable per input
> 2 stage EQ per input
ZRM4
Featuring 6 inputs that can be balanced XLR mic or dual RCA/balanced XLR line level, all available to any combination of 4 zone outputs.
Input one can be designated as a paging input with priority over all other inputs individualy selectable at each zone output. Front panel switches with LED indication provide
for simple routing of each input. Each input has bi colour status LED indication & 2 stage equalization. Each input has an internal gain trim which can provide a further +/-
15dB of gain to allow the perfect set up of input gain no matter what the input signal may be. Phantom power & high pass filters are also supplied per input.
Each balanced XLR zone output also features a dual colour status LED & switchable paging mic priority. Remote VCA’s are also available for each output
allowing for a wall mounted volume control to be installed in remote zones giving a volume range from off to whatever the master level on the
AMIS ZRM4 relevant zone output is set to.
Alert, Evacuation, Bell & Pre announce tones are also provided on board.
The AMIS ZRM4 is a compact yet extremely versatile zone routing
mixer which makes the complex task of multizone
signal routing simple & cost effective.

Dimensions (mm) 44.0h x 482.0w x 188.0d
Weight Net 2.9kg Shipping 4.4kg
Net 6.4lb Shipping 9.7lb
Power Input 20VAC; 600mA max or
24 to 34v DC regulated 600mA max
Sensitivity (input required for 0dBu out)
RCA In -26dBu to +4dBu (39mV to 1.23 V)
XLR Line In -26dBu to +4dBu (39mV to 1.23 V)
XLR Mic In -60dBu to -30dBu (0.78mV to 25mV)
Max Level In >14.1 Vrms (+25dBu)
Max Level Out >15.4 Vrms (+26dBu)
Frequency Response <5Hz to >22kHz
(0dB/-3dB)
THD Less than 0.1%
Noise <90dBu 20Hz-20kHz (all pots centred)
Crosstalk <-65dB @ 1kHz
Phantom Power 15VDC
Architectural and
Engineering Specifications
Engineered and Distributed by AUDIO TELEX COMMUNICATIONS PTY LTD (ABN 78 001 345 482), 149 Beaconsfield Street, Silverwater, Sydney, NSW, 2128 Australia
NSW Tel: [phone] Fax: [phone] VIC Tel: [phone] Fax: [phone] QLD Tel: [phone] Fax: [phone] WA Tel: [phone] Fax: [phone]
SA Tel: [phone] Fax: [phone] NZ Tel: [phone] Fax: [phone] International Enquiries - [email protected] www.australianmonitor.com.au
The zone routing mixer shall be 1 RU, have 6 inputs with RCA & mic/line switchable balanced XLR’s.
Each input will have individual +/- 15 dB gain control, switchable 15VDC phantom power, & high
pass filter. Input 1 will be able to be a dedicated priority input individually switchable at each output.
Two stage EQ will provided for each input & all inputs & outputs will have bi colour status indication.
The unit shall have onboard pre announce, bell Evac & Alert tones & have remote
VCA master controls for each output.
The unit shall be an Australian Monitor ZRM4.
