Auta NEOS Series User manual

NEOS
monitor
EN
Navigation and settings
Mute
Call volume
Call to concierge
Melody selection
Privacy selection
Answer Self-starting
Speaker Opening
Special functions
LCD screen
Microp one

calling and conversation
When a call is received from the entrance panel, the monitor starts ringing for a maximum of 30 seconds. As standard,
it performs 4 rings with intervals of 4 seconds between each of them.
During the call period the image appears on the screen, the user can open directly, pressing the button or establish
a conversation pressing the button The conversation has a maximum of 0 seconds. If you want to continue with
the conversation, activate the keypad and press the button
keypad activation at standby
IN STANDBY, to prevent unwanted presses, the monitor incorporates a security system in which the touch keyboard
remains locked until the push button is pressed.
self-staing
Activating the keypad and by pressings the button the user can establish communication with the PANEL / CCTV
CAMERA that he wishes in the case of more than one is present in the installation.
With each press the system will automatically switch to the next device, showing the image and allowing the
opening of it by pressing the button
calling to concierge
If the monitor is in standby, activating the keypad and by pressing the button , a call will be made to the concierge
unit. If the system does not have a concierge unit installed, the monitor will emit an error beep.
ding dong function
The monitor allows to replace the interior bell of the house, this integrates the two calls (outside panel and house bell)
in a single device. These calls will be dierentiated with dierent melodies and lashes automatically. In order to have
this function, you only have to connect the button of the house bell to the monitor.
image adjustment
The monitor allows adjustment of brightness, colour and contrast levels. When the image appears on the screen, you
must press the button . Each press alternates between the 3 available settings.
To adjust the desired value press the push buttons
melody selection and adjust of the calling volume
If the monitor is in standby, activate the keypad and press . With each press will select a dierent melody and a
dierent calling volume.
There is 4 call melodies and 2 volume levels for each one (MEDIUM and HIGH)
Functioning_1

Bringing people together
auta.es
Functioning_2
external functions
The monitor has 1 push-button that allow auxiliary functions, such as garage doors, lights, irrigation, etc ...
To do this, an Auta auxiliary relay must be connected to the control circuit we want to control.
privacy function
The monitor incorporates a privacy mode in which the ringing tones are muted for a selected time. If the privacy mode
is active, the monitor shows by lashes the selected period of time (1 lash - 2 ours, 2 lashes - 4 ours, 3 lashes -
6 ours, 4 lashes - 8 ours). After the selected period of time inished, the monitor automatically returns to standard
mode. To enable the privacy mode activate the keypad and press the button for 4 seconds ( start to blink), select
the desired period of time by pressing the button . Each press will activate a dierent period of time between the 3
available ones. Validate the selection by pressing the button
ding dong function
The monitor allows to replace the interior bell of the house, this integrates the two calls (outside panel and house bell)
in a single device. These calls will be dierentiated with dierent melodies and lashes automatically. In order to have
this function, you only have to connect the button of the house bell to the monitor.
cctv surveillance function
The monitor allows the control of panels and CCTV cameras automatically. We activate the keypad and then press the
button . Each press on the button will activate a dierent device. To do this, each CCTV camera must be installed
with an Auta digital interface.
