Auto Page RS-610 User manual

RS-610
PROFESSIONAL REMOTE CAR STARTER
&
KEYLESS ENTRY
OPERATIONS MANUAL
THIS PRODUCT IS DESIGNED FOR PROFESSIONAL INSTALLATION ONLY

SYSTEM OPERATIONS
A. 5-BUTTON TRANSMITTER OPERATION
B. ACTIVE LOCK:
1. Press button on the transmitter.
2. The horn will chirp once and parking lights will flash once indicating that
the system is now active. The vehicle doors will lock upon activating
when interfaced with the keyless entry system.
SILENT LOCKING / UNLOCKING: Pressing the + buttons
together on the transmitter will lock or unlock your system, No chirp
sound will be heard, lock / unlock confirmation will be through the
vehicles parking lights only.
C. ACTIVE UNLOCK:
1. Press button on the transmitter.
2. The horn will chirp twice and parking light will flash twice to indicating
that the keyless system is now unlocked. The vehicle doors will un-
lock and dome lights will turn on for 30 seconds.
3. PATHWAY ILLUMINATION (See Alarm Feature “I - 2” Programming):
This feature turns the parking light “ON” for 30 seconds upon a unlock
signal and for 10 seconds upon the lock signal.
Transmitter
Button
System Function Remark
Lock Doors & Arm System
Panic function Press and Hold for 3
seconds
Unlock Doors & Disarm System
-
Two Steps Door Unlock & Disarm
System
Press twice within 3
seconds.
+Silent Arming / Disarming
Channel 2 (Trunk) Timer Control Press and Hold for 2
seconds
- Car Locator
Activate Remote Start or Press and Hold for 1
seconds
Turn Off The Remote Start
Side switching button For 2nd Car
Operation or Garage Door Opener
Press side button first then
press designated button

D. LED DISPLAY:
E. CHIRP INDICATOR:
F. PARKING LIGHTS:
TWO STEPS DOOR UNLOCK: This feature will independently unlock
the driver door only when deactivating the system. Pushing the
button a second time within 3 seconds will unlock the entire vehicle.
G. DEACTIVATING WITHOUT A TRANSMITTER
The Override function may be used if the remote transmitter is lost
or inoperative.
1. Enter the vehicle and turn the ignition switch to ‘ON’ position.
2. Within 10 seconds push and release the valet switch
If starter disable is installed. You can now start and operate the vehicle
normally.
H. VALET MODE:
The valet switch allows you to temporarily bypass all system function,
eliminating the need to hand your transmitter to parking attendants or
garage mechanics. When the system is in valet mode, and remote start
functions are bypassed, however the remote panic feature and remote
door locks will remain operational. To use the valet mode, the system
must first be deactivated either by using you remote transmitter, or by
operating the Manual override sequence.
Enter Valet Mode:
1. From the Unlock condition, turn the ignition to “ON” position.
2. Push and hold valet switch for 2 seconds until the LED turns on. The
LED will remain on as long as the system is in ‘valet mode’.
LED Function
Off Disarmed
Slow flash Armed
On (solid) Valet Mode
Chirp Function
1 Chirp Arm
2 Chirps Disarm
6 Chirps Car Locator
Parking light Function
1 Flash Arm
2 Flashes Disarm
12 Flashes Car Locator
Constant On Under Remote
Start

Exit Valet Mode:
1. Return to normal operation, turn ignition ‘on’.
2. Push and hold valet switch for 2 seconds, The LED will turn off
indicating the system has exited the valet mode.
I. PANIC FUNCTION: (IF CAR HORN IS INSTALLED)
The transmitter can be used as a remote panic switch to manually trig-
ger the vehicle’s horn in case of emergency.
1. Press and hold the button for 3 second. The horn will immediately
sound.
2. During panic mode, the normal function of this transmitter button will
be suspended. The and buttons can be used to lock and un-
lock the doors (if the option is installed), however once the button is
pressed, the vehicle’s starter disable device, (where installed) will be
enabled allowing the vehicle to start.
3. To stop the panic, press and hold the or button on the transmit-
ter again for 3 seconds. Also if any transmitter button other than the
or button is pressed and released, the panic mode will be
turned off immediately.
4. If no buttons are pressed, the panic function will stop automatically in
60 seconds.
J. DOME LIGHT CONVENIENCE DELAY & SUPERVISION
This system is a unique feature, which will turn on your vehicle dome
light as following:
1. Upon unlocking, the interior lights will remain on for 30 seconds.
2. If the vehicle is intruded, the interior light will flash for the same duration
as the siren.
Note: Turning on the ignition switch or activating the system will turn off
the dome light.
K. IGNITION CONTROL DOOR LOCKS. (See Alarm Feature II –
2 Programming).
If the vehicle’s door locks have been interfaced to the security system,
the system will automatically lock the vehicle’s doors when the ignition is
turned “ON” and /or unlock the vehicle’s doors when the ignition is turned
“OFF”.
L. TRUNK RELEASE
Press and hold the button on transmitter for two seconds to remote
control the trunk release or other electric devices.
M. CAR LOCATOR
Press the button twice with 3 seconds to active car locator function.
The horn will chirp 6 times. The parking light will flash 12 times, for you to
easily locate your car.

REMOTE START OPERATIONS
WARNINGS:
As with any product that performs automatic functions, there are certain
safety precautions that you must practice and be aware of.
1. Keep the transmitter out of children’s reach.
2. Do not leave anyone in the vehicle while running on remote control.
3. Alert servicing personnel that the vehicle can be started automatically.
4. Do not start the vehicle by remote while it’s in an enclosed area or
garage.
5. Always apply the parking brake and lock the vehicle as you exit the
vehicle.
6. Should the unit malfunction, disconnect the fuse until the problem is
corrected.
7. The use and operations of this system is the sole responsibility of the
operator.
8. Some areas may have local ordinances that prohibit leaving a vehicle
running on public streets.
A. TO REMOTE START THE VEHICLE:
When you want to start your vehicle,
1. Press button on the transmitter for 1 seconds.
2. The parking lights will flash to indicate the remote start received the
signal.
3. The engine will start approximately 5 seconds.
4. Once the engine is running, after a couple of seconds the parking light
will turn on again and climate controls will activate and adjust the
vehicles interior temperature to your preset setting.
5. The vehicle will run for 5 to 30 minute cycle and automatically shut
down.
NOTE:
The Remote Start Unit will not start the vehicle if any one of the following
conditions exists:
1. The hood is opened.
2. The brake pedal is pressed.
3. Move the optional remote start enable toggle switch to OFF position.
(If installed)
4. The gear selector is in any gear other then “PARK” or “NEUTRAL”
B. TO TURN OFF THE REMOTE START:
When the engine is running (by remote start), if you want to stop it,
1. Press button on the transmitter.
2. Move the optional remote start enable toggle switch to OFF position.
(If installed)
3. Press the brake pedal
The vehicle will shut down and turn off the parking light to indicate engine
stopped.

C. TO OVERRIDE VEHICLE FROM REMOTE START CONTROL:
To operate the vehicle while running on the remote start.
1. Insert the ignition key and turn it to “ON” ( not the start) position.
2. Press the brake pedal.
Note: If the brake pedal is pressed before the key is in the ON posi-
tion, the engine will shut down.
D. TEMPORARY STOP FEATURE:
This feature allows the vehicle to remain running after the key has been
removed from the ignition. This feature is useful for occasions when you
wish to exit and lock the vehicle for short periods of time, but would like to
leave the engine running and the climate control on.
1. Before turning off the engine, press the button on the transmitter.
The parking lights will come on and the LED will flash 3 times to
confirm Temporary Stop feature ‘ON’
2. Turn the ignition key to OFF position. (The engine will stay running.)
3. The engine will run until the pre-programmed time elapsed or shut-
down input is received.
E. TIMER START:
This unit can be programmed to start and run the engine every 3 hours.
The engine will run for the programmed run time and then shut down.
IMPORTANT: Timer Start should be used only in open areas, Never start
and run the vehicle in on enclosed space as a garage or carport.
3 hours timer start: This feature is design for an extreme cold climate
usage. The system will auto start the vehicle every 3 hours, to prevent
engine freezing and hard to start.
A MAXIMUM OF SIX CYCLES CAN OCCUR.
ENTER:
1. Press the button to remote start the vehicle. As soon as the vehicle
is running and the parking lights have turned ‘ON’.
2. Imediatley depress the button then press and hold down button
3 seconds. The parking light will flash (3) times. The horn chirps (3) times.
The vehicle is now programmed to start every (3) hours.
3. Press the brake pedal to stop the vehicle running.
Exit the timer start:
Timer start can be exited manually as follows:
1. Repeat the Enter Steps from above.
Or
1. Make sure the remote start system is not operating the engine.
2. Turn the ignition on. The LED and parking light will flash (4) times. The
horn chirps (4) times.

F. SHUT-DOWN INPUT FOR REMOTE STARTER:
If any of the following conditions exist while the system is operating, the
engine will not start or will shut down immediately:
1. The hood is opened.
2. The brake pedal is pressed.
3. Move the optional remote start enable toggle switch to OFF position. (If
installed)
4. Engine is over-revved. {“Tachometer checking type” only}
5. The pre-programmed run time (5 /10 / 20 / 30 minutes) has elapsed.
6. Transmitter button is pressed.
7. The vehicle refused to start running after {3} unsuccessful attempts.
G. DISABLING THE REMOTE START SYSTEM: (If installed)
This feature allows your system’s remote start unit to be temporarily dis-
abled to prevent the vehicle from being remote started accidentally. This
feature is useful if the vehicle is being serviced or stored in an enclosed
area. To disable the remote start, move the optional remote start enable
toggle switch to the OFF position.

NOTES

LIMITED LIFETIME WARRANTY PROVISIONS
( U.S. and Continental U.S. Only)
1. AutoPage, Inc. WARRANTS that this new unit has been thoroughly inspected
and tested at the factory prior to delivery. Your AutoPage equipment is guar-
anteed for “life” to the original purchaser/user of the equipment under the
following conditions: If the product proves defective (according to AutoPage’s
testing) within the first year, the defective unit may be exchanged or repaired
free of charge. “Proof of Purchase” (dated sales receipt) must accompany all
warranty returns; otherwise, your return will be rejected and sent back.
After one (1) year, the purchaser should ship the unit prepaid to AutoPage
with a money order in the amount of $20.00 to cover shipping and handling
charges. Note: The enclosed Warranty Card may be required to receive
warranty services.
2. This WARRANTY will be considered void if the equipment has been misused,
neglected, improperly serviced, altered, dropped or damaged by water, con-
trary to the AutoPage OPERATIONS MANUAL. Or, if used with accessories
not approved by AutoPage, which may have contributed to the defect.
3. The purchaser’s remedies under this WARRANTY shall be limited to the re-
pair or replacement of electronic components only. THE FOLLOWING IS
NOT COVERED: Damages or deterioration to cases, batteries, covers and
cabinets; the cost of repairs, replacement and labor of which shall be borne
by the purchaser even if occurring during the WARRANTY period.
4. Any equipment or parts which are claimed to be defective under this WAR-
RANTY must be sent to the AutoPage Service center with “proof of purchase”
at the purchaser’s expense prior to such return, a Return Authorization Num-
ber should be obtained. AutoPage will return the equipment, charges pre-
paid. Warranty Service can be provided through the dealer where the equip-
ment is originally purchased.
5. Any unexpired WARRANTY shall be applicable to equipment and parts in the
possession of the original purchaser only.
6. THIS WARRANTY IS IN LIEU OF ANY AND ALL OTHER WARRANTIES,
EXPRESSED OR IMPLIED, INCLUDING BUT NOT LIMITED TO ANY WAR-
RANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PUR-
POSE.
7. AutoPage shall not be liable, under the foregoing WARRANTIES or other-
wise, for: Any personal injury of any kind to the purchaser, its employees or
agents or anyone else whomsoever resulting directly or indirectly from the
use or presence of the equipment or parts; Consequential damages of any
kind; Any inability of the purchaser to use the equipment.

This WARRANTY CARD is for your record. However, AutoPage reserves the right to
request you to submit this WARRANTY CARD which must have complete information
to receive warranty service. Please keep this card in a secured place.
AUTOPAGE WARRANTY SERVICE CARD
Model: _______________
Serial # _______________
CUSTOMER TO COMPLETE DEALER TO COMPLETE
Mr/Mrs/Ms
_______________________________ ________________________________
Your Name (Please Print) Company Name
_______________________________ ________________________________
Address Dealer’s Address
_______________________________ ________________________________
City, State, Zip Code City, State, Zip Code
_______________________________ ________________________________
Telephone Number Dealer’s Telephone Number
_______________________________ ________________________________
Year / Make / Model of Vehicle Date of Installation / Purchase
________________________________
Dealer’s Signature
“Proof of Purchase” which includes the store name and date of purchase must
accompany all warranty returns.
It is the purchaser’s responsibility to keep this card for any future warranty service.
AutoPage Inc.
1815 West 205th Street
Torrance, CA 90501
310-618-2002

1815 W. 205th Street Suite #101 Torrance, CA 90501
Tel: [phone] or [phone]
www.autopageusa.com
