CrimeStopper Cool Start RS-1300DP User manual

RS-1301DP/1303DP/1304DP 1-WAYSYSTEM
RS-1300DP ADD-ONMODULE
DP SERIES (DataPort)
OPERATINGINSTRUCTIONS
**IMPORTANTNOTES:- FORRS-1300DPMODELONLY**
RS-1300DPModelisan add-on/expansion unit, withoutremotesor an antenna thatmustbe controlled byan
existing alarmor keyless entrysystem.The “InfinityRun” feature isnotavailableon an RS-1300DPsystem.Most
ofthe remotestartfeaturescan be controlled through an existing factoryor aftermarketremotekeyless entryor
alarmsystem.Pressing an auxiliarybutton on an Aftermarketsystemor pressing abutton 3timeson aFactory
keyless remotecan activatearemotestartusing the RS-1300DP.Thisisreferred tointhismanualasactivating
the “Green Start input wire”.
*IMPORTANTINFORMATION:Primaryand Optional Features
-PRIMARY: Theseare featuresthatmustbe connected inorder for the systemtooperateproperlyi.e. Remote
Startconnections,Flashing lights,and BrakeReset. For programming,the hood pinand programbutton are
required.
-OPTIONAL: Thesefeaturesare tobe connected onlyifdesired or agreed upon bythe customer and the installing
dealer i.e.Door Locks,TrunkPop,DomeLightIllumination,Horn-Honk,Anti-Grind,etc.Thesefeaturesmayalso
require additionalpartsand/or labor fees.Consultwithyour installer beforehand tobe sure ofwhatisgoing tobe
installed withyour particular system.
TECHNICALSUPPORT:[phone]
Monday-Friday8:00am-4:30pmPacificStd. Time
Web Site: www.crimestopper.com
E-mail: [e-mail]
CRIMESTOPPERSECURITYPRODUCTS, INC.
1770 S. TAPO STREET, SIMIVALLEY, CA. 93063
REV A–10.10.2005
ThisdevicecomplieswithFCC Rulespart15.Operation is
subjecttothe following twoconditions: 1)Thisdevicemaynot
causeinterference,and (2)thisdevicemustacceptany
interferencethatmaybe received,including interferencethat
maycauseundesired operation.The manufacturerisnot
responsiblefora
nyradioorTVinterferencecaused by
unauthorized modification tothisequipment. Suchmodification
couldvoidthe user'sauthoritytooperatethe equipment.

2
TABLEOF CONTENTS
Operation Cautions&Warnings…..…...…………………..….………………………….……………….…………2
Using theRemote Transmitter…..……..…………………………………………………………………….....…….3
StatusLED…………………..…………….…………………………………………………………………….….…….4
Remote EngineControl...........………….…..…………………………………………………………….….….….3-8
Turbo TimerMode……..………….…………………………………………………...……………………….….……9
Convenience and Safety Features……….…………………….………………………………...……………..10-11
TransmitterProgramming...........……………………………………………….………………………….....……..12
2VehicleOperation....…………………………………...……………...……………………..…………….…..……13
Troubleshooting “BeforeYou Call”Section ..…………..…..……………………………………………….14-15
BatteryReplacement..………………………………………...………………………………..…………….….……15
OPERATIONCAUTIONS&WARNINGS
CRIMESTOPPERSECURITYPRODUCTS,INC. and its VENDORS shall notbe liablefor anyaccidentresulting
fromthe useofthisequipment. Thissystemisdesigned tobe professionallyinstalled intoacar or vehicleinwhich
all items,suchasparking brakeand all associated components,door switches,transmission shift linkage,throttle
linkage, and all engine safetyfeatures, are inperfect working condition.
DONOTinstall theRemote EngineStarting Systemon MANUALTRANSMISSIONvehicles. If accidentallyleft
ingear the vehiclecouldbecomeaself-propelled threat tolifeand property.
ITISABSOLUTELYTHEOWNER’SSOLERESPONSIBILITYTO: A)Understand the operation ofthissystem
and itssafetyfeatures.B)Check for proper operation ofthe systemprior toaccepting deliveryofthe vehiclefrom
the installation facility.C)Check and maintainthe condition ofthe vehicleand all itemsrelativetothe proper
operation ofthissystemand itssafetyfeatures.D)Always leavethe doorsand windowsclosed and locked to
protect against accidentsand theft.
DONOTremote startthevehicleinaclosedgarage. Makesure thatthe garage door isopen or there is
adequateventilation.Failure toobservethisrulecouldresultin injuryordeath frompoisonousCarbon Monoxide
fumes

3
USINGTHEREMOTETRANSMITTER
COOLSTART
#1
REMOTE
VEHICLE2
FLASHLIGHT
START
COOLSTART
#1
#2
#3
LOCK
REMOTE
UNLOCK
VEHICLE2
FLASHLIGHT
START
COOLSTART
#3
#1
#2
#4
LOCK
TRUNK
REMOTE
UNLOCK
VEHICLE2
FLASHLIGHT
START
ForRS-1300DP
The RS1300DPmodeldoesnotinclude remotetransmitters,asitisdesigned forthe expansion ofa“parent”remote
keyless or alarmsystem.
ForRS-1301DP
The transmitter supplied withthissystemhas1button,flashlightand car 2side button.The button configuration is
Factory-setand unchangeable.See Page 11 for additionalinformation on howtouseyour remotetooperatea
second vehicleequipped withan RS-1300 seriessystem.
ForRS-1303DP
The transmitter supplied withthissystemhas3button,flashlightand car 2side button.The button configuration is
Factory-setand unchangeable.See Page 11 for additionalinformation on howtouseyour remotetooperatea
second vehicleequipped withan RS-1300 seriessystem.
ForRS-1304DP
The transmitter supplied withthissystemhas4button, flashlight and car 2side button. The button configuration
isFactory-set and unchangeable. See Page 11 for additionalinformation on howtouseyour remotetooperate
asecond vehicleequipped withan RS-1300 seriessystem.
*NEW FEATURE*BUTTON#3 and #4 (#1 on RS-1301DP)Programmablefor1or2button presses
*Default=1press*
Thesebuttonsare programmablefor one or twobutton pressestoactivatetrunkreleaseremotestart. This
option isselectablebyyour installer.

4
STATUSLED
LEDOperation:(install option)
LEDwill flashwhen remotelylocking your doors.
LEDwill remainsolidinValet Servicemode.
REMOTEENGINECONTROL
REMOTEENGINESTARTING -SUCCESSFULSTART:
1) Press the remotestartbutton for atleast1/2second (*default).(For RS-1300DPmodels,consultyour installer).
2) Parking lightsflashonce, return solid, and the Ignition/Acc circuitsturn on.
3) After afewsecondsthe Starter Motor engages.The parking lightsand Acc circuitswill turn off whilecranking.
4) Engine Startsand Runs. Parking Lightsand Acc turnsbackon, and the doorslock.
5) Engine will remainrunning for programmed run timeuntil resetwithBrakepedal.Ifneeded,the engine can be
turned off withremotetransmitter bypressing and releasing the Startbutton.(For RS-1300DPmodel,activate
the Green Start input wire)
AFTER
IGN
4
STARTER
THEN
FLASH1X
SOLID
SOLID
SEC.
THEREMOTESTARTERBUTTONISPROGRAMMABLEFOR1OR2PRESSES
REMOTEENGINESTARTING -UNSUCCESSFULSTART
Inthe eventthatthe engine doesnotstarton the firstattempt, the systemshutsdownfor afewseconds,then
attemptstorestartthe engine a2nd and 3rd time.For hard starting engines,the unitwill allowastarter cranktimeof
up to13 secondsmaximum.Thisshouldprovide amplecranking timefor difficultstarts,butislimited to13 seconds
tohelpprevent damage tothe starter fromover cranking.
1) If engine startson 2nd or 3rd attempt, see steps4&5aboveof "SuccessfulStart".
2) IfThird attemptfailstostartengine,the systemwill turn off and doorswill remainlocked.NOFURTHER
ATTEMPTSWILL BE MADEAUTOMATICALLY

5
REMOTEENGINECONTROL
TURNING OFF AREMOTESTARTEDENGINE:
1) Engine isrunning inRemoteStart (Parking lightsON).
2) Press and releasethe remotestart button or doublepress (If option #6 ison). (For RS1300DPmodel,
activateGreen Start input wire.)
3) Engine &parking lightsOFF, Doorsre-lock/re-arm.
ENTERING YOUR REMOTESTARTEDVEHICLE:
1) Withengine running, Unlocksystemwithremote(If equipped) or open door withkey.
2) Enter vehicleand be carefulnot tostep on brakepedal!(RemoteStart Reset)
3) Turn Ignition toON/RUN position, then press brakepedaltoreset the RemoteStarter &Shift out of park.
4) Remotestarter will resetinstantlywhen the brakeispressed.Parking lightswill turn off and the ignition keyis
nowcontrolling your vehicle.
REMOTESTART RUN TIMERESET: DOES NOTAPPLYTO RS-1300DP/1301DP
You can nowreset the engine-run timer toallowfor more running timeafter remotestart hasalreadyoccurred
using the remotecontrol. After asuccessfulremotestart, press boththe Lock&Unlockbuttonstogether for at
least 2seconds. The parking lightswill flash3timesand internalengine timer will reset backtozero minutes.
IDLEDOWNMODE:
Thismode allowsthe unittotakeover operation ofthe parked vehiclewhilethe ignition keyisremoved and you exit
the vehicle.The vehicleisputintoaremoterunning condition before you exitand itwill remainrunning for the
programmed run timeor until you comeback.
Examples:
·You pull up toaconveniencestore for aquick stop,"IdleDown"mode keepsengine running when you exitthe
vehicle,(withkeys inhand) remotelock doorsor armalarm.When you return,unlock,turn ignition ONand drive
away.

6
REMOTEENGINECONTROL
IDLEDOWNMODE-EXITING THEVEHICLE:
1) Withvehicleengine running withkey, press the RemoteStart button for at least one second or twiceif set for
Doublepress (For RS-1300DPmodelactivateGreen remotestart input wire.)
2) Parking Lightswill turn ON.
3) Doorswill unlock, or if brakepedalisbeing depressed, doorswill unlockwhen it isreleased.
4) Turn OFF Ignition and removekey. Engine shouldremainrunning.
5) Exit vehiclethen remotelockdoorsif desired.
6) Engine will remainrunning for programmed run timeor until you return (whichever comesfirst).
IGN
SOLID
OFF
UNLOCK

7
REMOTEENGINECONTROL
INFINITYRUN MODE(NOTAVAILABLEONRS-1300DPMODEL)
Thismode can onlybe activated when "IdleDown"procedure.The InfinityRun mode allowsthe vehicleengine to
remainrunning INDEFINITELYafter the programmed run timeelapses.Thismode will allowthe vehicletobe left
running and unattended without the ignition keyinthe switchpreventing the vehiclefrombeing stolen.Thismode
can be beneficialtolawenforcementor commercialtrucksthatneed toremainrunning unattended for long periods
of time. See next page for Infinitymode steps.
INFINITYRUN MODE–EXITING THEVEHICLE:
1) Withvehicleengine running withthe key,press the RemoteStartbutton for atleast1second,pauseafew
seconds, then press and releasethe remotestart button asecond time.
2) Parking Lightswill start flashing, and doorswill unlock.
3) Turn Ignition switchOFF, removekeyand exit the vehicle. Engine shouldremainrunning.
4) The vehicle’sparking lightswill flashfor the programmed run timeof12,24,or 36,or 48 minutesand then switch
tosolidwhilemotor runsindefinitelyor until fuelsupplyrunsout.
SELECTABLEHOURLYCOLD-STARTMODE(1-4 HOURS)
Thismode allowsthe vehicletobe programmed toself-startevery1,2,3or 4hoursand run for the programmed
run time.Thiscan be helpfulduring extremelycoldconditionswhere engine fluidfreeze-up isaconcern.THE
VEHICLEMUSTBEOUTDOORSORINAWELL VENTILATEDAREA! Oncethismode isset, the unitwill start
atthe programmed hourlyintervaland run for the programmed run time.Toresetthismode,either startthe vehicle
withthe keyor the remotecontrol.

8
REMOTEENGINECONTROL
SELECTABLEHOURLYCOLD-STARTMODE–EXITING THEVEHICLE:
1) Engine shouldbe running withthe Key.Press the RemoteStartbutton for atleast1second.(For RS-1300DP
model,activateGreen startinputwire.)Lightswill turn on signaling the remotestarthasturned on and doorswill
unlock.
2) Within10 secondspress and releasethe valet/programbutton oncefor eachhourlyincrement(1 time=1hour,
2X=2hours, 3X=every3hours, 4X=every4hours).
3) Parking Lightswill turn when the button ispressed and flashfor eachconsecutivebutton press.
4) Turn Ignition switchOFF, removekeyand exit the vehicle. Engine shouldremainrunning.
5) Onceoutside the vehicle,press and releasethe remotestartbutton toturn off engine.(For RS-1300DPmodel,
activateGreen Startinputwire.)The parking lightswill flashthe number oftimesindicating the hourlyincrement
for confirmation.
6) The vehiclewill startbyitselfatthe selected hourlyincrementuntil driven withkeyor started viathe remote
control.
IGN
PARKINGLIGHTTURNON
OFF
UNLOCK
PRESS FOR1SECOND
OR
DOUBLEPRESS
EACH PRESS IS1HOUR
INCREMENTS, UPTO4
HOURS

9
TURBOTIMERMODE(OPTIONAL)
The optionalTurbo Timer mode allowsthe CoolStartsystemtokeep aTurbo or Turbo Dieselvehiclerunning for 1
to5minutes[selectively]after you removethe key,exitthe vehicle,and lockthe doorsremotely.Thisishandyfor
turbo cool-downwithoutthe need for expensiveturbo timers.Thismode requiresthe useofan extra partcalled a
momentaryswitch/button that isnot included withthe kit. Checkwithyour installer about adding thisfeature.
NOTE: The turbo timer button will alsotrigger aremotestart if it isinadvertentlypressed when the vehicleisnot
running. Pleasenotethiswhen installing the button and choosealocation out of harm’sway.
1) Engine shouldbe running withthe key.
2) Press and holddownthe brakepedal.
3) Press your “Turbo Timer” button 1to5timesfor eachminuteof run timeyou desire. (1 press =1min.)
4) Asyou releasethe brakepedaland your systemwill confirmbyflashing the lightsthe samenumber oftimesthe
button waspressed.
5) Turn Ignition switchOFF,removekeyand exitthe vehicle.Remotelockyour doorsfor safety.The engine
shouldremainrunning for the selected number of minutes.
REMOVE KEY
PRESS TURBO
FLASH1-5X
EXITVEH.
PRESS
AND HOLD
BRAKE
TIMERBUTTON
1-5TIMES
RUNNING
RELEASE
BRAKE
LIGHTS
RUNNING
REMAIN
1-5MIN.

10
CONVENIENCEAND SAFETYFEATURES
KEYLESS ENTRY(POWER DOOR LOCK CONTROL, Optional)
Thissystem enables youto remotelylock andunlock thevehicle’s doors (ifequipped withpower locks) viaremote control
for safety andconvenience. Note: This feature may require extra labor and/or parts to install. Press the Lock or Unlock
transmitter buttonas youleave or come near thevehicle. Parkinglights will flashonce for lock andtwice for unlock. If
vehicle is running by the remote start system, the lights will flash, but returnback to solid.
AUTO LOCK/UNLOCK (Improved)
TheAuto Lock feature controlswhether thedoors will automaticallylock/unlock onyourvehiclewhendrivingor withturning
theIgnitionON/OFF. If theAuto Lock feature isturned on,andyoursystem isin“Tach”mode, thenthedoors should
automaticallylock as theengineRPM’s increase (driving). If theAuto Lock feature isturned on,andyoursystem isin
“Smart Tachless” mode, thenthedoors will lock afew seconds after theIgnitionisturned on.WhentheAuto Lock feature is
turned on,thesystem will always unlock thedoors whentheIgnitionisturned off. Withthisfeature turned OFF, thesystem
will not automatically lock or unlock the vehicle. See your installer for programming informationonthis feature.
DOOR LOCK NOTE: If your systemhas been setup with an optional starter kill relay, but you do not have power door locks,
note the following: The lock and unlock buttons on the remote control must still be utilized to operate the Starter disable.
REMOTE PANIC (Optional) DOES NOTS APPLYTO RS-1300DP/1301DP
For personalsafety thisunitnow includes apanicfeature. To soundthevehiclecar horn,press theLock Buttononthe
remote for more than2seconds. Thevehiclehornwill honkalongwithflashingparkinglamps for 1minute. Reset Remote
Panic by pressing either the lock or unlock button. See next sectionfor HornHonk information.
HORN CHIRP/HONK OUTPUT(Optional) DOES NOTS APPLYTO RS-1300DP/1301DP
Thisfeature, ifinstalled, will provide audibleconfirmationchirps from thefactory hornfor lock andunlock. Whenusingthis
feature, pressingtheLock or Unlock buttona2nd time within3seconds or once (programmableoption)will provide ahorn
chirp for audibleconfirmation.Thesystem canalso be programmed to provide 3chirps whenaremote start isrequested
using the remote. Note: Hornhonk/chirp feature may require extra labor and/or parts to install.
TRUNK RELEASE OR DOMELIGHTILLUMINATION (Optional) DOES NOTS APPLYTO RS1300/1/3DP
ThisCoolStart system includes anoutputthat canbe programmed to remotelyrelease afactory electronictrunkor
illuminate theinterior lightwhenyouunlock yourvehiclefor lighted entry at night. If youhave theoptionaltrunkpop
installed, simplypress andrelease theTrunkButton#3 onthetransmitter or ifoption#6isturned onyoumust press Button
# 3 twice within3 seconds, to remotely opentrunk. If your system isprogrammed for Dome Lightillumination,then itwill
work automaticallylightingthedome lightfor 30 seconds whenyouunlock yourvehicleviatheremote. Thedome lightwill
turnoff after 30 seconds, or turningthekey on(whichever comes first). ThetrunkPop or Dome LightIlluminationmay
require extra labor and/or parts to install.

11
CONVENIENCEAND SAFETYFEATURES
VALETMODE/ STARTERDISABLEOVERRIDE
Before servicing your vehicleor handing the keysover toaValetwerecommend putting the unitintovaletmode.
The remotestartfunction WILL NOToperatewhen inValetmode.Toenter Valetmode, turn the keytothe ON
position,press and holdProgram/Valetswitchfor 5-6 seconds.The LEDwill turn on solidand the systemisnowin
valet. Performthisprocedure againtoexitofValetmode.The keyless entrywill still function normallywhileinvalet
mode. Inthe event of alost or broken transmitter, performthisstep tooverride the Starter Disable(if installed).
ANTI-GRIND / STARTERDISABLE(Optional, relaynotincluded)
ThisOptionalfeature preventsthe user fromaccidentallygrinding the starter ifthe Ignition keyisturned too far to
the startposition whileengine isalreadyrunning fromthe remotestarter.The Anti-Grind/Starter Disablerequires
the useof an externalrelay. Thissystemmust be programmed toallowthe relaytoworkasastarter disable.
HOODOPENSAFETY(Requires grounding hood pininstallation)
Preventsthe engine being RemoteStarted when hood isopen and will shutOFF the engine ifopened during a
remotestart. Eliminatesriskofinjurytosomeone working under the hood of the vehiclewithaproperlyworking
hood pininstalled.IfRemoteStartbutton ispressed withthe hood open,the lightswill flashonceand the unitwill
not attempt astart.
BRAKEPEDALRESET
Preventsstarting or shutsoff aremotestarted vehiclewhen thiscircuitisactiveor activated.Preventsunauthorized
tampering.Thiscircuitshutsthe systemdownimmediatelywhen brakepedalispressed ifthe keyisnotinignition
and turned tothe ONposition.
OEMALARMINTERFACE
Thisfeatureisdesigned toDisarmand Re-armFactoryequipped securitysystemsinconjunction withremotestartand keyless entry
(ifneeded foryourvehicle).Thisfeaturewill maintainthe originalintegrityand securityofyourvehicle’sfactoryequipped systems
before, during, orafterremotestart.
NOTE: When changing, charging, or jumpstarting the vehicle’sbatterywerecommend removing the mainpower
fuseslocated on the heavy gauge REDwiresnear the remotestart module.

12
TRANSMITTERPROGRAMMING
Note: All transmittercodes must belearnedat timeofprogramming!! Theunitwill learnsup to4different
transmittercodes.
1.Open Hood (If no hood pininstalled withyour system, then you must ground the GrayHood pinwire).
2.Turn keytothe ONposition. (Pinkwire must be connected.)
3.Press Programming button 4times, then after afewsecondsthe unit flashesthe parking lights4times.
4.Press button #1 ofthe transmitter tobe coded.You shouldget2lightflashesindicating the unitiswaiting for a
2nd code,then press button #1 ofasecond transmitter,the unitwill flash3timesindicating itswaiting for the 3rd
code and soon.Ifall 4codesare learned,the unitwill automaticallyexitcode learning mode,otherwiseturn key
off and closehood. See diagrambelow.
IGN
OFF
WAITFOR
4FLASHES
PRESS 4X's
FLASH2, 3, or 4X's
(GRAY WIRE GROUNDED)
IGN
OFF
(FORRS-1301DPPRESS THE STARTBUTTON)
PRESSLOCKBUTTON

13
COOLSTART
VEHICLE #2
Presssidebutton
first,thenyouhave
4secondsto
controlvehicle#2.
2-VEHICLEOPERATION&PROGRAMMING
AsingleRS-1300 SERIES remotecan controltwodifferent vehicleswithRS-1300 SERIES systemsinstalled.
SETUP:
Followthe “Transmitter Programming” stepson the second
vehiclebelow.ProgramCar #2’sexisting remotes,then
quicklypress the Car #2 side button on your remotebefore
pressing the lockbutton on your remotetoprogramittoCar
#2.Onceyour remoteisprogrammed tothe second
vehicle,press the car #2 side button on your remotefirst,
and within3secondspress anyofthe 4function buttonson
your remote.You can keep pressing function buttonsto
controlcar #2 aslong asit iswithinthe 3-second window.
After 3secondshaveelapsed, the remotewill revert back
toCar #1 control.
IGN
OFF
WAITFOR
4FLASHES
PRESS4X's
FLASH2, 3, or4X's
(GRAYWIREGROUNDED)
IGN
OFF
COOLSTART
PRESSVEHICLE
#2SIDEBUTTON PRESSLOCK BUTTON
(WITHIN3SEC.)
(FORRS-1301DPPRESSSTARTBUTTON)

14
TROUBLESHOOTING:“BEFOREYOUCALL”SECTION
UNITWILL NOTATTEMPTASTART(KEYLESS ENTRYSTILL FUNCTIONSNORMALLY):
The unitisinValetmode.Turn Ignition ON,press and holdvalet/programming button for 6secondsthen turn key
off. Unitisnowoutofvaletmode and shouldperformaremotestart. IfoptionalLEDindicator isinstalled,then it
will be on solidwhen inValet and OFF when out of Valet.
UNITFLASHES LIGHTSONCEAND WILL NOTATTEMPTASTART:
The unit sensesafault at the Brake(Purplewire isactive) or the Hood isOPEN(Graywire grounded). Thisisa
safetyfeature ofthe unit. Checkinstallation for faultsand makesure hood isclosed and latched and brakewire is
not active. Makesure hood isingood condition and isdepressed when hood isclosed.
NO RESPONSE FROMREMOTETRANSMITTERS:(4 Parts)
1.Checkfor proper power/ground wiring connectionsat module.
2.CheckAntenna Moduleconnection. The antenna moduleincluded withthissystemmust be plugged in.
3.Transmittersmayneed tobe programmed tothe unit. See transmitter programming stepson Page 10.
4.Checktransmitter Batteriesand replaceif necessary.
UNITCRANKSVEHICLEBUTENGINENEVERSTARTS:(2 parts)
1.Inextremecoldor severe weather conditions,the unitmaytakemore than the firstattempttostartthe vehicle.
The remotestart unit will makeup to3attemptstostart the engine.
2.Insomevehicles,there maybe aFactoryanti-theft systemthatwill notallowthe engine torun withoutthe keyin
the ignition.Thesesystemsmayinclude FactorySecurityModules,GMPasskey®/Passlock®,and RF
Transponder systems(Ford P.A.T.S.®).Manylate1990’sthrough 2005 vehiclesinclude sometype ofAnti-Theft
systemwhichmayrequire abypass module.Checkwithyour installer tomakesure thatthe bypass device(if
equipped) isfunctioning properly.
SYSTEMISUNSUCCESSFULATREMOTESTARTDURING EXTREMECOLDCONDITIONS:
Pleasebe aware thatduring sub-freezing conditionsyour remotestarter maytakemore thatone attempttostart, or
itmaynotsuccessfullystartthe vehicleafter 3attempts.During theseconditionsthe vehiclemaynotproperlystart
even using the key, therefore trying tostart bythe remotewouldalsobe unsuccessful.

15
TROUBLESHOOTING:“BEFOREYOUCALL”SECTION
VEHICLESTARTSBUT“CHECK ENGINE”LIGHTCOMES ONORENGINERUNSBADLY:(2 parts)
1.Many1995-UPGeneralMotorscars/trucksrequire asecondaryignition circuit for the Transmission computer
and other on board systems.Ifthe vehicleisstarted withoutthiswire energized,there maybe a“CheckEngine”
or “ServiceEngine Soon” lighton the dash.Thismaycausedamage ifthe vehicleisdriven inthiscondition.
Checkwithinstaller tosee if thiscircuit ispresent and hasbeen properlyconnected tothe system.
2.Insomecases[commonlyNissan vehicles], an additional“Start”(Cranking) circuitisrequired for the vehicleto
run properly.The RS-1300 SERIES systemincludesawire thatcan be used for thisStarter #2 circuit. Check
withyour installer for details.
BATTERYREPLACEMENT
To replace thebattery: Simplyremovethe screwson backofthe transmitter and open the case.Removethe
batteryand replace. The replacement batteryfor all transmittersisGP23A.
GP23A
+-
BATTERY
REMOVESCREWS

www.crimestopper.com
[e-mail]
Phone [phone]
FAX [phone]
©2005 CrimestopperSecurityProducts
ONLINETECHNICALSUPPORT
www.crimestopper.com
