AutoAqua SMART ATO SATO-100P User manual

Model
SATO-100P
Manual
SMART ATO
IntelligentAquarium Automation

Controller & Accessories
1
Item
SMART Controller
Power Adapter
DC Refill Pump
Water Tube 2M
Universal Holder
Pictures Description
Sense & Control AUTO TOP OFF (All In One)
Universal Power Supply for Controller
Head : 6.5 feet (200 cm)
Used with DC Refill Pump
Fix the water tube
1
1
22
33
44
5
6
7
5
6
7
Smart Controller
Smart Controller Dry side
Smart Controller Wet side
Power DC Jack
Pump DC Jack
Power (Green Led)
Alarm (Blue Led)
Pump (Red Led)

Installation
1. Clean the surface and mount the controller on the wall of the Tank/Sump.
2. Position the Smart controller higher than the original water level.
3. Connect the DC pump wire into the controller and install the water tubing.
4. Connect the power adapter into an AC socket and the controller will begin initializing.
5. Verify the PUMPING initialization and adjust the water level as you require.
2
Side View
Magnet
SATO-100P
Smart
Controller
ReservoirTank/Sump
DC Refill Pump
Power
Front View
Smart
Controller
Tank/Sump
Wet side Dry side
Mounts to Clear Glass or Acrylic sumps
Max wall thickness: 1/2 inch (12.7mm)
Max distance for sensor: 1 inch (25.4mm)

LED indicator
●Green LED (POWER) :
•Light on : Power on
•Flashing Slowly : Refilling
●Blue LED (ALARM) : Return to normal after Refilling/Pumping
•Flashing slowly with an audible alert : Non-Fill issue.
●Red LED (PUMP) : Need to reset the system
•Light on with a music alert : Water Empty, Bubble noise…
•Flashing quickly with an audible alert : Poor contact of the PUMP
●All LEDs (INITIALIZE) :
• Flashing slowly with an audible alert : Initializing
• Flashing quickly with an audible alert : Initializing fails issue. Need to check mis-alignment
& water level setting(higher than the original water level) of the Smart Controller.
AFS Technology
AFS(Auto Feedback Security) Technology is a dynamic & real-time fail safe protection against
failure. The security time out is triggered by the previous pumping on/off period.
●Over-Fill Alert : Water empty, Micro-bubble …
• Ta : Over-Fill Security Time Out (Minimum : 15s except Ta1)
• T1,T2,T3… : Pumping On Period
●Non-Fill Alert : Mis-alignment, Algae …
• Tb : Non-Fill Security Time Out (Minimum : 24 hrs except Tb1)
• T12,T23,T34… : Pumping Off Period
3
T
1
: Pumping On
Ta1 : No A larm Ta2 > 3T1: Alarm Ta3 > 3T2: Alarm
Tb1 > 48 hrs : Alarm Tb2 > 3T12 : Alarm Tb3 > 3T23 : Alarm
OffOffOffOff
On On On On
T
2
: Pumping On T
3
: Pumping On
T
12
: Pumping OffT
23
: Pumping OffT
34
: Pumping Off

Notice
1. Please read the manual in detail before installation
2. Keep the power adapter dry and away from water to avoid any safety issues.
3. Please clean the sensor every 6 months to prevent non-fill issue.
4. Avoid installing controller in an area with micro bubbles or direct lighting.
5. The “Water Tube Output” must be higher than the “Normal Level” in the Tank/Sump and
“High Level” in the reservoir to avoid a siphon issue.
Holder Exchange Procedure (Rimless Tank Rimed Tank)
4
Pull Out Pull In Finish
Reservoir Tank/Sump
DC Refill Pump
High level
Water tube output
Normal level

Specifications
1. Power Input : 100-240VAC 50-60HZ
2. DC PUMP :
• Head : 6.5 ft (200 cm)
• Flow Rate : 74 gph (280 lph)
3. Mounts to Glass or Acrylic walls
• Max Wall Thickness by Magnet: 1/2 inch (12.7mm)
• Max Distance to Sense: 1 inch (25.4mm)
Warranty Card
Warranty Period
Two years from the purchased date
Place of Purchase Service
Purchased Date
(Store name, phone, email, address)
(Y/M/D)
1. This product is guaranteed for two years from the date of purchased at normal operation.
2. The warranty is not transferable.
3. Any incorrect operation will not be warranted and will result in a repair fee.
4. All warranty repairs are performed by the distributor. Please contact the distributor to obtain a
Return Authorization number when sending a warranted unit.
5. This guarantee is effective at the date listed on your sales receipt.
