Autoenterprise EDISON User manual

«EDISON»
Instruction Manual

INSTRUCTION MANUAL EDISON CHARGING STATION
2
© Copyright
This documentation with all illustrations is the intellectual property of AutoEnterprise
LLC (“AutoEnterprise”). All documentation is provided to the user for personal use only.
This documentation may not be reproduced or provided to others without our written
permission. Any violation of the law will be prosecuted.
AutoEnterprise cannot be held liable for any direct or indirect damages
resulting from the use or operation of the electrical circuits of the
equipment or software described herein. The appliance should only be
used by trained and qualified personnel. Read the instructions carefully
before using the product. In addition, AutoEnterprise reserves the right
to change any product described here without prior notice

INSTRUCTION MANUAL EDISON CHARGING STATION
3
TABLE OF CONTENTS
1. Introduction ................................................................................................................................4
2. Key information ...........................................................................................................................4
2.1 Information about the manual ..............................................................................................4
2.2 Warning signs ...........................................................................................................................4
2.3 Liability and warranty .............................................................................................................5
2.4 Disposal information ...............................................................................................................6
2.5 Manufacturer’s label ...............................................................................................................6
3. Application area, station specifications .................................................................................7
3.1 Application area .......................................................................................................................7
3.2 Technical specifications .........................................................................................................7
3.3 Equipment modifications ......................................................................................................9
3.4 General electrical safety information ..................................................................................9
4. Dimensions, connectivity .......................................................................................................10
4.1 Charger’s dimensions and parameters .............................................................................10
4.2 Transportation ........................................................................................................................12
4.3 Installation ..............................................................................................................................12
4.4 Storage ....................................................................................................................................13
5. Maintenance ..............................................................................................................................15

INSTRUCTION MANUAL EDISON CHARGING STATION
4
1. INTRODUCTION
2. KEY INFORMATION
CHARGING EDISON - is a high quality charging station (hereinafter referred to as «the
station»), which is made using the latest solutions in the field of power electronics and
technology, based on the modern components combined with the microcontroller signal
processing technology, which ensures high efficiency, functionality and reliability of the
charger.
This, together with the software and accessible interfaces, provides a flexible and
productive solution for electric vehicle charging that meets the highest quality standards.
The product is designed to control the energy consumed from a 380V AC three-phase
network or from the 220V AC single-phase network to charge an electric vehicle battery.
The product is equipped with an intelligent microcontroller control system and
communication devices that allow for the exchange of information with the electric vehicle
and set the value of the charge current and voltage, according to the needs of the electric
vehicle in real time.
2.1 INFORMATION ABOUT THE MANUAL
This manual describes how to operate the charger properly and safely. Be sure to follow
the safety instructions given here, as well as any local safety regulations and general safety
instructions.
Before you put the charger into use, make sure that the instructions, the «Safety» paragraph
in particular, have been read through and understood completely. This manual is an integral
part of the station and and should therefore be kept in its immediate vicinity.
2.2 WARNING SYMBOLS
Important safety instructions in this manual are marked with symbols. These safety
instructions must be strictly adhered to. Always pay attention to them and follow the safety
instructions to avoid accidents, personal injury or material damage.
WARNING!
Risk of injury or death
This symbol indicates instructions that must be followed to avoid injury,
trauma or death.

INSTRUCTION MANUAL EDISON CHARGING STATION
5
WARNING!
Risk of material damage
This symbol indicates instructions which, if not followed, may result in
material damage, functional faults and/or machine breakdowns.
WARNING!
Danger - electrical current
This symbol alerts you to potentially dangerous situations involving
electric current. Failure to follow the safety instructions increases the risk
of serious injury or death. Caution should be exercised, especially during
maintenance and repairs.
ATTENTION!
This symbol indicates tips and information that should be adhered to in
order to ensure efficient and reliable operation of the product.
2.3 LIABILITY AND WARRANTY
All information, illustrations, sheets, specifications and diagrams contained in these
operating instructions have been carefully compiled to the current state of the technology
at the time of publication. We are not liable for errors, missing information or any
subsequent damages or consequential damages.
Strict adherence to the safety procedures described in these operating instructions and
special care when using the equipment are essential to prevent and reduce the likelihood of
injury or damage to the equipment. The manufacturer is not responsible for damage and/or
malfunctions caused by non-compliance with the instructions in this manual.
Additionally, the manufacturer will not be liable for any personal injury or material damage,
whether indirect or special, consequential, loss of business profits, business interruption
or loss of business information resulting from the use of the equipment described in this
manual.
Any software included in this equipment must only be used for the purposes for which it
has been provided to the User by the AutoEnterprise for which it is strictly prohibited to
make any changes, conversions or copies (except for any necessary backups).
AutoEnterprise reserves the right to update any information, illustrations, sheets,
specifications and diagrams contained in these operating instructions adherence to
technical developments at any time without prior notice.

INSTRUCTION MANUAL EDISON CHARGING STATION
6
2.4 DISPOSAL INFORMATION
Do not dispose of the charging station together with household waste!
Electronic devices must be disposed of in accordance with the local
directives for the disposal of electronic and electrical waste. If you have
any further questions, please contact your supplier.
Use suitable tools if you need to disassemble the system. All individual parts must be sorted
by different types of materials and disposed of in accordance with the regional guidelines
for the disposal of electronic and electrical waste.
2.5 MANUFACTURER’S LABEL
The marking on the charging station is located on the GSM modem inside the station and
consists of alphabetic and digital symbols (example: M123456). This number is also listed
on the shipping list.
This information is important for setting up, troubleshooting and ordering spare
parts for the station.
In case of malfunctions in the station operation, you should provide the station number to
the technical support service and follow the instructions of specialists. This will help you to
solve most of the problems remotely and avoid the need to send (transport) the equipment
to eliminate such problems.

INSTRUCTION MANUAL EDISON CHARGING STATION
7
Charging mode under IEC61851-1 Type 1 (SAE J1772), Type 2 (Mennekes)
Nominal input voltage 3-phase 380V
Input voltage deviation
limits, %, max
+-10
Nominal mains frequency 50 Hz
Main ports:
Type 1 (SAE-J1772)
Type 2 (Mennekes)
1, 2 or 3 p.
Output power of 1 connector 10 kWh
Maximum current of the output cable 40 A
Maximum connector voltage 230 V
Cable length 5,5 м
1 or 2 p.
Output power 22 kWh
Maximum cable current 3х32 A
Cable length 5,5 m
3. APPLICATION AREA, STATION SPECIFICATIONS
3.1 APPLICATION AREA
The charger is designed exclusively for charging electric vehicles.
For information about the materials, please contact AutoEnterprise sales
representative or contact the AutoEnterprise technical support team.
The following sections should also be followed as part of the intended use:
• Only charge compatible electric vehicles.
• Failure to follow the instructions for use, maintenance and repair described in these
operating instructions excludes any liability on the part of the manufacturer in the event of
a defect.
• The system must only be operated, maintained and repaired by personnel familiar with
the intended use and hazards!
• Carry out maintenance and repairs according to the specifications in this manual.
• The unit may only be operated with equipment and spare parts supplied or listed in the
spare parts and consumables lists.
• Using the charger in other areas is contrary to its intended purpose. The manufacturer is
not responsible for any damage to the equipment resulting from such use. The user is solely
responsible for any damage resulting from improper use of the system.
3.2 CHARGING STATION SPECIFICATIONS

INSTRUCTION MANUAL EDISON CHARGING STATION
8
Access types
RFID-card
Smartphone app
Chip-tag (extra option)
Delivery contents Charging station, user manual
Charging station dimensions 350х2500х245 mm
Number of vehicles
simultaneously connected to
one Charging Station
3 (maximum package)
Type of installation Pillar mounting
Online device monitoring Yes
Current adjustment Yes
Possibility to manage rates of the station Yes
Single body version Yes
Digital display to indicate the amount of
electricity consumed Yes
User interface management Menu functions are managed via the mobile
app
Enclosure material Steel with anticorrosive coating
Mechanical protection IK10
Case protection class IP54
Power cable entry from below Yes
Weight, kg 70
Ambient temperature -20°C to +45°C
CHARGING STATION FEATURES
The technical characteristics of the station shall be specified in separate specifications and
may differ from those agreed upon by the parties.
Signs, labels and pictograms attached to the station must be visible

INSTRUCTION MANUAL EDISON CHARGING STATION
9
In emergency situations, the charging station disconnects the input power circuits by means
of differential relays.
The gear control system is powered from the mains via an additional circuit breaker.
The output cable is connected by means of sealing sleeves/cable glands.
The time of initial readiness of the charging station after switching on the voltage is not
more than 1 minute.
The charging station is designed for continuous operation.
Switching the operation modes of the charger is carried out under the control of a
communication microcontroller providing communication with the car.
Relative humidity should not exceed 95% without condensation.
3.3 EQUIPMENT MODIFICATIONS
It is strictly forbidden to change, modify or alter the machine in any way without the explicit
consent of the manufacturer.
All signs, stickers and pictograms attached to the machine must be visible, legible and cannot
be removed. Signs, labels or pictograms that have become damaged or illegible must be
replaced immediately. Please contact AutoEnterprise to coordinate such questions.
3.4 GENERAL ELECTRICAL SAFETY INFORMATION
Follow the safety instructions to avoid injury and material damage when working with the
device.
Failure to follow these instructions can result in injury and damage to or
destruction of the product.
Ignoring the safety recommendations and instructions in this manual will relieve
the manufacturer and his authorized representatives of all liability and claims.
Service and modification of the product wiring circuit should be performed by
disconnecting the input circuits with external disconnecting devices and unplugging the
charger from the electric vehicle. Please note that if there is any voltage is present at the
mains input or at the other terminals of the product, life-threatening voltages may also be
present due to internal connections.

INSTRUCTION MANUAL EDISON CHARGING STATION
10
4. DIMENSIONS, STATION INSTALLATION
4.1 CHARGER’S DIMENSIONS AND PARAMETERS
FRONT VIEW SIDE VIEW
The station is structurally designed as a monoblock mounted on a stand and has the
following control and management bodies:
• Charging station in a casing
• connector «Type 1» (indicated in the order);
• connector « Type 2» (indicated in the order);
• information display - 1 pc.

INSTRUCTION MANUAL EDISON CHARGING STATION
11
Charging station «EDISON»
Socket type Quantity Current,
АMax power, kWh Max voltage, V
Type 1 (SAE J1772) 1 40 10 220
Type 2 (Mennekes) 1 32 22 380
Charging station «EDISON 1»
Socket type Quantity Current,
АMax power, kWh Max voltage, V
Type 1 (SAE J1772) 3 40 20 220
Charging station «EDISON 2»
Socket type Quantity Current,
АMax power, kWh Max voltage, V
Type 1 (SAE J1772) 2 80 20 220
Type 2 (Mennekes) 1 32 22 380
CHARGING STATION SPECIFICATION
CHARGING STATION MODIFICATIONS
Socket and cable type for connecting the station to the electric vehicle:
The charging station is available in the following configurations:

INSTRUCTION MANUAL EDISON CHARGING STATION
12
Charging station «EDISON 4»
Socket type Quantity Current,
АMax power, kWh Max voltage, V
Type 2 (Mennekes) 2 64 44 380
Charging station «EDISON 3»
Socket type Quantity Current,
АMax power, kWh Max voltage, V
Type 1 (SAE J1772) 1 40 10 220
Type 2 (Mennekes) 2 64 44 380
4.3 INSTALLATION
Ensure that all internal components are properly secured after transportation.
Check the connections of wires, loops, connectors. Check the tightening of terminals, bolts,
screws, and switchgear.
4.2 TRANSPORTATION
WARNING
There is a risk of injury from falling parts during transportation, loading or
unloading of the station.
ATTENTION
The charger may be damaged or destroyed if it is mishandled during
transportation.
FOR THIS REASON, THE FOLLOWING SAFETY INSTRUCTIONS MUST BE STRICTLY
ADHERED TO:
Transport the charging station with the utmost care..
Transport the charger as carefully as possible to avoid damaging it..
Protect the charger from damage during transportation by using belts and inserts and leave
sufficient clearance between other objects to be transported.

INSTRUCTION MANUAL EDISON CHARGING STATION
13
The power supply (input) cable on the
mains side is de-energized by external
disconnecting devices.
• The mains input has a connection
diagram of 1 or 3 phases with separate
neutral (N) and ground conductors (PE).
• If you connect a 4-wire cable, make
the protective earth connection with a
separate conductor.
To connect the station to the electrical
circuit, connect the input power
cable (the cross-section depends
on the station configuration) to the
corresponding input terminals (L1,
L2, L3, N, PE). The following figure
shows an example of how to connect a
station in the «3xType1» configuration.
If the connection is made with a 4-wire
cable, the external grounding should
be made with a cross section of at
least 6 mm2 marked «PE» in the wiring
compartment. It is strictly forbidden
to supply voltage to the mains input of
the charging station when the ground
is not connected

INSTRUCTION MANUAL EDISON CHARGING STATION
14
In the charging mode, it displays information about the charging power in kW*h and the
percentage of the car battery charge.
The modes and operation of the charging station on the LCD display depend on the
software version and may vary from version to version.
THE FIRST CONNECTION TO BE MADE IS THE GROUND WIRE TO THE GROUND
BUSBAR MARKED «PE». DO NOT SWITCH ON THE CHARGER WITHOUT A CONNECTED
GROUNDING!
Non-compliance with this requirement may result in the energizing the charger body, electric
shock damage to the service personnel and consumers, as well as in a failure of the charger.
To switch on the externally controlled charging station, a SIM card of the mobile network
operator must be installed in the GSM modem.
Next, the power cable must be connected to the AC mains using external switching devices.
The charging station operation modes are presented on the LCD display, which, among other
things, displays the following information: operation modes (ready for charging, car battery
charge), software and firmware version, station number, GSM network status (signal strength,
network status), vehicle authorization process.
AutoEnterprise #1 : Charging
V:2.02.1669 0.5 kW*h M006335 24%
4.4 STORAGE
Store the charger in a sealed container until it is assembled and installed.
Charging station storage conditions:
• The storage area should be dry, free of dust, caustic materials, vapours and combustible materials.
• Store in a storage room with appropriate weather protection.
• Do not expose the charger to impacts..
Storage conditions:
• Storage Temperature: 0 to +40 ° C (32 to 104 ° F)
• Relative humidity: max. 85%
• Avoid extreme temperature fluctuations
• If stored for a long time, check the general condition of all parts and packaging regularly

INSTRUCTION MANUAL EDISON CHARGING STATION
15
5. MAINTENANCE
ATTENTION
• Improper maintenance can result in serious injury or damage to the
station. For this reason, this work may only be performed by authorized,
trained personnel who are familiar with the operating principles of low-
voltage electrical equipment and who strictly comply with all relevant safety
instructions when working with electrical systems.
• It is strictly forbidden to store flammable or explosive liquids near the
charging station.
ATTENTION
Before performing any maintenance work, make sure that the charger is
disconnected from the grid.
INFORMATION
To ensure maximum availability and service life of the system, we
recommend that you keep the inside and the outside of the charger
clean on a regular basis.
In the course of operation the following maintenance works are carried out:
• Visual inspection for overheating of equipment; check, pulling connections;
• Identification of defective parts and assemblies, maintenance and replacement.
Authorized service personnel must disconnect all AC power sources from the charger to reduce the
risk of electric shock before starting any maintenance or cleaning work on the charger or on any
circuits connected to the charger.
Preventive inspection of the charger should be carried out at least once every 3 months. To do this,
the battery charger must be disconnected from live circuits and its housing, contacts and vents must
be thoroughly cleaned of dust and dirt, and the quality of wire fastening must be checked. Screws of
terminal blocks and wire ends must be clamped, the wires must not have damaged insulation
In case of a technical malfunction, please start by recording all station data
(number, software version, etc.) and then call us by phone while you’re
next to the switched on device. If you have any questions or technical
problems, please contact us directly at the above address.

INSTRUCTION MANUAL EDISON CHARGING STATION
16
Name of malfunction,
external manifestation and
additional signs
Probable cause Possible remedy
Loss of communication with
the charging station
Modem failure Replacing the modem or
checking the status of the
SIM card
Bad location of the antenna
that receives GSM signal
Changing the location of
the antenna for the best
reception of the GSM
signal or the replacement
of the antenna (for a more
powerful with a stifter)
Damage to the socket Physical wear and tear,
careless handling of
equipment
Disconnect the device. If the
cable cannot be recovered
-replace it.
Socket malfunction If you can not fix it by
yourself, send it for repairs
LCD charging indicator does
not work (no power supply)
No input voltage Discover the reason for the
lack of voltage.
Other malfunctions The charging station does
not provide the set electric
parameters for the EV
battery charge
Contact the AutoEnterprise
technical support team
TECH SUPPORT
Contacts:
1. You can write an email to tech support using the contact page on our web-site.
2. You can call on numbers listed on the web-site.
AUTOENTERPRISE.UA
