AutoMeter BVA-200s User manual

>BATTERY TEST
SYSTEM TEST
REVIEW/PRINT
VOLTMETER
�
28
1
2650-1537-00 1/6/11
BVA-200s
Operator’s Manual
Hand Held-Accuracy with a Pulsed 120 Amp Load
The BVA-200s is the ultimate hand-held tester. It is the auto
industry’s answer to portability in a professionally accurate load
tester and system analyzer.
Auto Meter Products Inc.
350 West Center Street
Pleasant Grove, Utah 84062
Service [phone] ext. 223
Toll Free (866) 883-TEST (8378)
Fax [phone]
www.autometertest.com












Auto Meter Products Inc.
413 West Elm Street
Sycamore, IL 60178
Toll Free (866) 883-TEST (8378)
Fax [phone]
www.autometer.com

2
27
NOTES
CONGRATULATIONS!
You have purchased one of Auto Meter's hand-held Electrical System
Analyzers. It is designed to test each component of a vehicle's electrical
charging and starting system with speed and accuracy. If you should
have any questions about your tester, testing procedures, or service see
page 28 for contact information.
BVA 200s
Load Test Capacity..................120 Amp
Battery sizes ...........................100-1600 CCA
Digital Back-Lit Display ..........1" x 2.5" - 4 line x 16 character
Volt Ranges.............................Digital 0-30
Cooling....................................Vented
Leads ......................................Load Amp-2 1/2 ft., 6 Gauge
Size .........................................5 7/8" x 9 1/2" x 1 7/8"
Memory ...................................stores the last 200 tests
Internal Battery........................9 Volt Alkaline
Optional PR-12 .......................Infrared printer and carrying case
Optional AC-24J......................BVA-200s Carrying case only
Optional AC-12 ......................PC Interface adapter cord
Weight.....................................4 lbs.
What to Expect from the BVA-200s:
Immediately recognize a bad battery and perform a complete
charging system analysis.The BVA-200s is a portable full-featured
menu-driven battery tester and charging system analyzer that provides
quick, professional load results using Auto Meter's Pulsed Differential
Load. Quick battery checks will increase charging productivity. The
BVA-200s is user friendly. It tells you what to do. The stator-diode test
automatically indicates open or shorted stator-diodes. It is professionally
accurate. Detailed test results are displayed after each test or can be
reviewed and/or printed from memory.
Caution: The BVA-200s grill may get hot after repeated use. Be sure to
hold the unit from the side grips only. Keep hands away from the grill.

26
3
NOTES TABLE OF CONTENTS
Specications -------------------------------------------------------2
Safety -----------------------------------------------------------------4
Cause of Battery Failure -----------------------------------------4
Controls and Functions-------------------------------------------5
Maintenance --------------------------------------------------------6
Clamp Replacement ----------------------------------------------6
Battery Replacement ---------------------------------------------6
Sections
1. Hook Up --------------------------------------------------------7
2. Battery Test ----------------------------------------------------8
3. System Test-------------------------------------------------- 11
4 Other Menu Items
Review Tests ------------------------------------------- 17
Printer----------------------------------------------------17
Printing Test Results --------------------------------- 18
Voltmeter ------------------------------------------------ 19
Setup-----------------------------------------------------19
Opening Hyper Terminal ---------------------------- 21
Downloading Test Information --------------------- 23
Capturing Information in Microsoft Excel -------24
Warranty Information-------------------------------------------- 25
Contact Information --------------------------------------------- 28
Note: The BVA-200s checks and load tests 6 volt and 12 volt
Batteries and tests the starter and alternator on 12 volt and 24
volt systems. The following examples illustrated are for a 12 volt
system. The BVA-200s automatically identies the appropriate
voltage and displays the menu selection and instructions needed
for that system.

4
25
SAFETY
Carefully read all operating instructions before
using the BVA-200s
Wear eye protection when working around
batteries.
Be sure each test is completed before removing
load clamps to prevent arcing and potential
explosion from battery gases. Never remove load
clamps while testing. Keep sparks ames, or
cigarettes away from batteries.
Keep hair, hands, and clothing as well as tester
leads and cords away from moving blades and
belts.
Provide adequate ventilation to remove car
exhaust.
In extremely cold temperatures, check for frozen
electrolytic uid before applying load. Do not attempt to Load Test or charge a battery
under 20 degrees. Allow the battery to warm to room temperature before testing or
charging.
Warning! Never attach the BVA-200s to a battery that is connected to any other
tester or charging unit. Damage may result.
Incorrect Application: Wrong size battery may have inadequate cold
cranking rating for original vehicle specications.
Incorrect Installation: Loose battery hold-downs cause excessive vibration,
which can result in damage to the plates.
Improper Maintenance: Low electrolytic uid and corrosion on battery
connections can greatly reduce battery life and affect battery performance.
Age of Battery: If the date code on the battery indicates it is fairly old, the
failure may be caused by natural causes.
Overcharging: Overcharging caused by a high voltage regulator setting or
incorrect battery charging can cause excessive gasing, heat and water loss.
Undercharging: Undercharging caused by a faulty charging system or
low voltage regulation can cause lead sulfate to gradually build up and
crystallize on the plates greatly reducing the battery’s capacity and ability to
be recharged.
CAUSE OF BATTERY FAILURE
LIMITED WARRANTY
12 MONTHS FROM DATE OF PURCHASE
The manufacturer warrants to the consumer that this product will
be free from defects in material or workmanship for a period of
twelve (12) months from the date of original purchase.
Products that fail within this 12 month warranty period will be
repaired or replaced at the manufacturer's option to the consumer,
when determined by the manufacturer that the product failed due
to defects in material or workmanship. This warranty is limited
to the repair or replacement of parts and the necessary labor
by the manufacturer to effect the repair or replacement of the
product. In no event shall the manufacturer be responsible for
special, incidental or consequential damages or costs incurred
due to the failure of this product.
Improper use, accident, water damage, abuse, unauthorized
repairs or alterations voids this warranty. The manufacturer
disclaims any liability or consequential damages due to breach of
any written or implied warranty on its test equipment.
WARRANTY AND SERVICE INFORMATION
Warranty claims to the manufacturer's service department must
be transportation prepaid and accompanied with dated proof of
purchase. This warranty applies only to the original purchaser
and is non-transferable. Shipper damage incurred during
return shipments is not covered under this warranty. It is the
responsibility of the shipper (the customer returning the Test
Equipment) to package the tester properly to prevent any damage
during return shipment. Repair costs for such damages will be
charged back to shipper (customer returning the Test Equipment).
Protect the product By shipping in original carton or add plenty
of over-pack cushioning such as crumpled up newspaper.

24
5
AUTO METER
BVA 200s
SYSTEM ANALYZER
READY TO CONNECT
CONTROLS AND FUNCTIONS
LCD:
Displays menus and test results.
KEYS:
When each key is pressed, a beep
sounds to assure contact has been
made.
On/Off Key:
This is the manual on/off key.
The display will show “Ready to
Connect!” when the unit is turned on.
Y Enter Key:
This key selects the next menu, the
cursor line item and answers ‘yes’ to
a test progression.
+Up Key:
This key moves the cursor up in
order to select a menu line item and
increments certain displayed values.
-Down Arrow Key:
This key moves the cursor down
in order to select a menu line and
decrements certain displayed values.
N Esc Key:
This key cancels a test or progression. It also returns to the previous menu.
Print Key:
Point the BVA-200s infrared print light towards the Optional PR-12
infrared printer receiver and press the print key. Test results will be
printed.
PC Download Jack:
Adapter cord inserted here.
Infrared Print Light:
When the print button is pressed infrared data
will be transmitted to the printer if pointed in the
appropriate direction (up to 15 ft.).
After the le is loaded you can delete unwanted rows and format
columns as desired. The following are labels for identifying the 8
columns of information.
Est. Output
CAPTURING TEXT
4. Using Microsoft Excel
Make sure menu is displayed as shown in illustration page 20 #3.
Select “Capture Text” in the Transfer Menu.
Type in c:\my documents\download.txt and then select Start.
Press “1” to download. When nished select “Capture Text” again
from the Transfer Menu then select “Stop”.
Launch Microsoft Excel and select “Open File”.
Under "Files of Type" at the bottom of the open le window select
All Files (*.*).
Highlight your download.txt le then select “Open”.
Select "Delimited" and start at row 1 then “Next”
Select "Comma" then “Next”
Under Column Date Format select "General" then “Finish”
Note: For other software applications consult your software manual.

6
23
BATTERY
MAINTENANCE
Both jaws of each clamp
must rmly engage the
battery terminal. The
copper jaw contains the
smaller gauge wire that
reads the voltage and
the silver jaw contains
the larger conducting
wire that draws the
load in each test. Jaw
insulation is necessary
for accurate readings.
Damaged clamps or
loose wires will affect the
readings. Keep clamps
clean and in good repair.
CHECK OFTEN FOR LOOSE JAWS
OR DAMAGED INTERNAL PLASTIC
SHOULDER INSULATORS
BATTERY CLAMP REPLACEMENT
Over time the battery clamps will need to be replaced if any of the
following are indicated:
CCA values seem to be way off.
If there is continuity between the silver and copper jaw.
If there is excessive damage or corrosion to the cables or
clamps.
PROCEDURE
Disconnect the back cover.
Disconnect the two small wires from the PCB.
Remove the large cables from the copper busses.
Carefully pull each wire through the grommets.
Reverse the procedure when installing new clamps.
Caution: With cables pointing down, make sure the red clamp
wires are attached to the left buss and the black clamp is attached
to the right buss. Putting a little mineral spirits on the new cable
ends will help with ease of insertion through the grommets.
BATTERY REPLACEMENT
When the LCD indicates a low internal battery remove the back cover
and replace the battery with a 9 volt Alkaline battery.
IMPORTANT:
Est. Output
DOWNLOAD TEST INFORMATION
3. PC Screen Menu
If the BVA-200s is properly connected to your PC and the LCD
shows "CONNECT ANALYZER TO A PC" the menu should
automatically be displayed in Hyper Terminal.
Press 1 to download the last 200 tests.
To save the information displayed see "Capture text into Microsoft
Excel." See BVA-200s test labels below for identication.
Press 2 to exit.
HyperTerminal
Windows
BVA-200s
Test Labels
From the BVA-200s main menu select DOWNLOAD.
REVIEW/PRINT
VOLT METER
SETUP
>DOWNLOAD
CONNECT ANALYZER
TO A P.C.
9600, N, 8, 1.
‘N’ TO CANCEL.

22
7
1HOOK UP
Press the On/Off button: Connect the clamps as instructed on the LCD.
Note! Take special care when connecting to battery side terminals. If
necessary use a side post adapter to prevent thread damage. When
testing dual post batteries always check the post to which the system is
attached. If a load test is made from a post connection and the alternator
is mounted to side terminals a battery load test can be completed, but
a continuity problem may still be in the side terminals when testing the
alternator.
CONNECTION ERRORS
If the clamps are reversed the Reversed Connection warning
will be displayed on the LCD with an audible beeping.
If one or both of the clamps are not in complete contact
(both the copper and silver jaw) CHECK CONNECTIONS!
will ash on the LCD.
Connect Black
Clamp to Negative
(-) Terminal Connect Red
Clamp to
Positive (+)
Terminal
AUTO METER
BVA 200s
SYSTEM ANALYZER
READY TO CONNECT
>ENTER BATTERY
TEMP 70F
12.50V USE +/-.
‘Y’ TO CONTINUE
OPENING WINDOWS HYPERTERMINAL CONT.
Select le in the Hyper Terminal menu.
Select Properties.
The screen on left will appear.
Click on the Settings tab.
Make sure the “Append Lines Feed to
Incoming Line Ends” is checked.
Click ok on both screens.
Now this screen will appear.
Click on the ASCII Setup button.

8
21
2BATTERY TEST
You can also select Battery Test from
the main menu and then press (Y
Enter).
Press the (+Up) or (-Down) key
to increment or decrement to the
rated CCA of the battery.
For ease of adjustment the last CCA rating will appear unless you have set
a default CCA rating in the SETUP menu. Press (Y Enter) to continue test.
Note: Enter the approximate battery
temperature in degrees Fahrenheit.
>ENTER RATED CCA
600 USE +/-.
12.50V
‘Y’ TO BEGIN
>ENTER BATTERY
TEMP 70F
USE +/-.
‘Y’ TO CONTINUE
>BATTERY TEST
SYSTEM TEST
REVIEW/PRINT
VOLTMETER
Press N to cancel once the clamps are
connect the test will proceed.
>CONNECT CLAMPS
TO BATTERY.
RED+, BLACK-
‘N’ TO CANCEL
If any of the tests (battery test or system test) are selected and the clamps
are not connected to the battery the following screen will appear.
Note: Most computers are congured with
at least one serial port (identied as COM
1), and some have a second serial port,
usually identied as (COM 2). Check your
computer manual to locate and identify a
serial port connector. Even if you have a
physical COM port you need to make sure
it is working properly before you proceed.
Consult your computer manual. If your
computer serial port is congured for 25
pin you will need to obtain an adapter from
your computer store. If your computer
does not have an available serial port and
you’re planning on using Windows HYPER
Terminal as illustrated below, you will need
to buy and install an adapter card with a
serial port.
The BVA-200s will interface with any basic
(ANSI) terminal emulation software. Most
operating systems contain a program that
will do this. For other operating systems
consult the Manual for that system.
Select Windows “Start”
Then “Programs”
Then “Accessories”
Then “Communications”
Then “Hyper Terminal”
Double Click Hypetrm.exe Application
Type in a name for your connection
Select an icon for future identication
Select OK
Select the COM port number you have previously
identied in step 1.
Select OK and select the following from the pull
down menus:
Bits per second 9600
Data bits 8
Parity None
Stop Bits 1
Flow Control None
Select OK
Using Auto Meter’s optional adapter cord AC-12 insert the stereo plug into the jack on the
BVA-200s, then plug the serial adapter into a free serial port on the rear of your computer.
2. Opening Windows HyperTerminal:
PC INTERFACE
Entry Hints
To change the text or number press the (+)
or (-) keys. If you press N at the beginning
of the screen, no changes will be made. To
make changes, use the (+) and (-) keys then
press Y to save the change. The cursor will
then go to the next character or number. If
you are done making changes but there is
more text keep pressing Y until the cursor is
on a blank space at the end of the lines of
text. Pressing Print saves the text up to the
cursor position. Any text after is deleted.
SETUP cont.
Note: Address and city have a max of 23 characters.
>DO YOU WANT TO
STORE INFO
‘Y’ OR ‘N’
This allows you to enter & save the
following store information which is
included in printouts: Store number,
store address, city, state, zip code and
phone number.

20
9
BATTERY TEST (cont.)
If the reading is below 7.2 Volts you will get the following:
If you answer ‘No” you will later be
asked if the battery has been charged.
Surface charge removed if
detected.
Wait for test results.
TESTING BATTERY
PLEASE WAIT...
Bar at the bottom of the screen will
show the tests progress.
SUMMARY SCREEN
>IS THIS A 6V
BATTERY?
‘N’ OR ‘Y’
REMOVING SURFACE
CHARGE...
PLEASE WAIT...
STARTING STANDRD
BATTERY TEMP 70°F
RATED CCA = 600
‘N’ OR ‘Y’
Conrm that the inputs are
correct. Press “Y” if they
are correct. The test will start.
Press “N” to re-enter battery
type, temp, and rating.
Select the rating from JIS,
DIN, IEC, EN, CA, MCA, CCA
>DEFAULT BATTERY
RATING: CCA
USE +/-.
‘Y’ TO SELECT
>SET DEFAULT CCA
AS: LAST CCA.
USE+/-
Y TO SELECT
You can also select the default rating
to be the last entered CCA value or a
particular amount such as 600 CCA.
>USE TEST RESULT
NORMAL WEAR
USE+/-
Y TO SELECT
PRINT OUT OPTIONS
USE DPC-2010
USE +/-
‘Y’ TO SELECT
Battery test results default to
“Normal Wear”. To change to
“Good” or “Bad” test results only,
use + or - to change setting then
use “y” to select this third test
result option.
Sets which printer to print
to. Use AC-14/PR-12 or DPC-
2010 Print Center.
SETUP cont.

10
19
After the Load Test is completed results similar to one of the following
sample screens will appear.
Battery passes
testing. Return to
service.
Charge battery and place into
service.
Battery did not have a sufcient
charge for a complete Load Test.
Charge required. Charge battery
and test.
Battery passes testing but is
showing normal wear. Battery
should be retested in 3 months.
Battery did not have
sufcient remaining
capacity to pass tests.
Battery should be replaced
immediately.
BATTERY TEST (cont.)
#32 12V BATTERY
GOOD BATTERY.
12.84V CHG 100%
#33 12V BATTERY
BAD BATTERY
12.45V CHG 75%
REPLACE NOW
#34 12V BATTERY
GOOD NEEDS CHARG
12.24V CHG 50%
CK START-CHG SYS
#35 12V BATTERY
CHARGE REQUIRED
12.06V CHG 25%
ADDL TEST REQ’D
#36 12V BATTERY
GOOD BATTERY
12.80V CHG 100%
NORMAL WEAR
Scroll Down to Volt Meter then
select Volt Meter by pressing Y
The following will be displayed.
Note: If the car is running and the clamps are attached to the battery a high ripple
(over 50.0 mv) indicates bad diodes in the alternator.
SETUP
Scroll Down to Setup, Select setup by pressing Y
Select the temperature in Fahrenheit
or Centigrade.
Press (Y Enter)
--VOLT METER--
VOLTS: 12.24V
RIPPLE 00.0mV
>SET TEMPERATURE
SCALE: F.
USE +/-.
‘Y’ TO SELECT
>SET LANGUAGE:
ENGLISH
USE+/-
Y TO SELECT
Choose between English or Spanish
using the + and - keys to change the
language. Press Y to select.
REVIEW/PRINT
>VOLT METER
SETUP
DOWNLOAD
REVIEW/PRINT
VOLT METER
>SETUP
DOWNLOAD
VOLT METER

18
11
3SYSTEM TEST OVERVIEW
Symptomatic Check before Proceeding:
Check all cables and connections.
Check the battery for corrosion and dirty terminals.
Check starter/solenoid for visual defects.
Check the ignition switch and any magnetic switches for loose or
bad wiring, loose mounting, or connections and sticking contacts.
Check for starter/solenoid noise. The type of noise or the lack
thereof can help in diagnosing the problem.
Does the solenoid click, but the starter does not turn? Does the
starter turn, but not engage the ywheel? Is the starter sluggish?
Note: A remote starter switch can be used to bypass the ignition switch and crank
the engine from under the hood. This way the sounds of the starter can be heard.
Press (N Esc.) to return to main menu. Select System Test then press (Y Enter).
Use the (+Up) and (-Down) to move
cursor to the desired test
SYSTEM TEST
The System Test will test the vehicle battery, starting system, and charging
systems in a quick logical order. Since a bad or discharged battery will greatly
affect the measurements done during the starting system and charging system
test, the BVA-200S will only allow those tests to be done after the battery has
been determined to be good and charged. The Starting Test measures the
amount of current needed to crank the engine and provides the initial information
to diagnose and/or further test the starting system if necessary.
Replace battery with a known
good, fully charged battery
and then rerun the system
test. Pressing 'Y' will return to
the main menu.
Charge the battery and
rerun the system test.
Pressing 'Y' will return to
the main menu.
A battery test as described in Section 2 will be performed rst. If the battery is found
to be bad the following screen will be displayed.
If the battery is good but needs a charge the following screen will be displayed.
REPLACE BATTERY
AND RERUN
SYSTEM TEST
'Y" TO CONTINUE
CHARGE BATTERY
AND RERUN
SYSTEM TEST
'Y" TO CONTINUE
BATTERY TEST
>SYSTEM TEST
REVIEW/PRINT
VOLTMETER
Make sure the Infrared Receiver is
properly set up. (Use DPC-2010)
After a test is made with the BVA-
200s make sure the results are
displayed on the LCD.
Point the BVA-200s in the direction of
the Infrared Receiver (within 15 ft.)
Press the <Print> key and the test
results will be printed.
Wait for the screen to clear before
moving the BVA-200s. It takes a
moment to send all the test data.
Depending upon the test made the
printer will sometimes yield more
information than the LCD.
Wait until the printer stops printing
before you press the BVA-200s print
key again.
IR Receiver
Make sure the Infrared Printer is
properly set up. (Use AC-14/PR-12)
After a test is made with the BVA-200s
make sure the results are displayed on
the LCD.
Point the BVA-200s in the direction of
the Infrared Printer (within 15 ft.)
Press the <Print> key and the test
results will be printed.
Depending upon the test made the
printer will sometimes yield more
information than the LCD.
Wait until the printer stops printing
before you press the BVA-
200s print key again
PRINTING TEST RESULTS

12
17
Wait for instructions before cranking engine.
If the current draw is between 75A & 250A (for gas powered engines) the starting
system is likely good and the following screen will appear
If the current is under 75A a solenoid connection or corrosion problem is likely and the
following screens appear.
SYSTEM TEST OVERVIEW cont
If the battery is good and charged the following screen will be displayed.
>CONTINUING WITH
STARTING SYSTEM
TEST
PREPARING FOR
STARTING TEST
>START ENGINE
'N' TO CANCEL
#40 12V START
CURRENT 200A
STARTING SYSTEM
- PASS -
The BVA-200S will test the starting
system. A bar at the bottom of
the screen will show the tests
progress.
TESTING STARTING,
SYSTEM
PLEASE WAIT ...
Press the (-Down) key to dis-
play the next screen. Press Y or
N to go to the main menu.
#73 12V START
CURRENT 60A
STARTING SYSTEM
- FAILED -
4OTHER MENU ITEMS
REVIEW TESTS
Press (Y Enter) to select
Review/Print.
The last test will be displayed.
Press (N Esc.) to select
previous test. Press (+Up)
or (-Down) key to select the
desired test.
The BVA-200S can print to the in store printer via the DPC-2010
infrared receiver or an optional infrared PR-12/AC-14 printer. From
the setup menu, select printing method use DPC-2010 or use
PR-12/AC-14.
An invisible infrared beam links the BVA-200s to the optional
PR-12/AC-14 or DPC-2010 infrared printer from up to 15 ft away.
No connection cords are needed. For more instructions on how to
operate the printer consult the printer manual.
PRINTER
Scroll Down to Review/Print
Scroll down to about.
Press Y to select.
VOLT METER
SETUP
DOWNLOAD
>ABOUT
ABOUT SCREEN
The about screen shows
the model number. Firm-
ware version 1, tester serial
number, and date.
Press any key to go back to
the menu.
BVA-200S
VERSION 7.4
SER #: 17533
COPYRIGHT 2010
>REVIEW/PRINT
VOLT METER
SETUP
DOWNLOAD
#44 12V CHARGE
PASS REGULATOR
PASS DIODES
PASS OUTPUT
The BVA-200S prepares
for the starting system
test. Bar at the bottom
of the screen will show
the progress.

16
13
If the current is over 250A, the system will need more information to determine if
the starter is good. The next screen will ask what type of engine you are testing.
SYSTEM TEST OVERVIEW cont
WHAT TYPE ENGINE
ARE YOU TESTING
USE +/- DIESEL
'Y' .TO CONTINUE
HOW MANY CYLINDERS
DOES ENGINE HAVE
USE +/- 4
'Y' TO CONTINUE
Use the +/- key to choose between gas
and diesel.
If the engine is diesel the system will
need to know the number of cylinders
the engine has. Use the +/- key to
choose either 4, 6 or 8.
Trustworthy advice for what to do next.
The chart on page 14 shows the current limits for the different engine types. If
the starter is likely to have a problem the following screens will appear.
#74 12V STARTING
CURRENT 680A
STARTING SYSTEM
- FAILED -
CK CABLES
CK CONNECTIONS
CK SHORT/GROUND
CK SOLENOID
CK SOLENOID
CK CABLES
CK CONNECTIONS
CK FOR CORROSION
Press the (-Down) key to display the
next screen. Press the (+Up) key to
move to the previous screen
IF ALL CK GOOD
RECOMMEND BENCH
TESTING STARTER
NOTE 1: If the LCD reads "FAIL OUTPUT" it is recommended you run the test
again with the engine at fast idle (2,000 RPM or more.)
If Measured Output is displayed
the output may be low for some
systems.
SYSTEM TEST OVERVIEW cont.
#43 12V CHARGE
FAIL REG LOW
FAIL DIODES
FAIL OUTPUT <30A

14
15
If manufacturer's specications are not available the chart below can be used as
a general guideline. The amounts are in Amps.
There are a few points to consider in testing a starting system on a diesel engine.
The BVA-200S is designed to recognize any signicant amount of draw; this
includes glow plugs in small diesel engines. In heavy-duty applications consider
computer and accessory draw.
• Make sure you start the engine quickly. The engine should be warm.
• Turn the ignition on and allow the glow plugs to heat up and click off before you
run the Starting Test.
• Repeat the test in different ways and compare results.
If the results are out of specication do the following:
After the starting system test the following screen will be displayed.
• Inspect the connectors for excessive voltage drop.
• Repair or replace any defective cables or connectors.
• Retest the system.
SYSTEM TEST OVERVIEW cont
>CONTINUING WITH
CHARGING SYSTEM
TEST
If still out of specications: High Amp reading may indicate engine is out of time
or a faulty starter. Some possible causes are shorted windings, bent armature,
broken housing or bad bearings.
STARTING CURRENT DRAW AND DIESEL ENGINES
IF ALL CK GOOD
RECOMMEND BENCH
TESTING STARTER
Use the (+ Up) and (-
Down) keys to scroll
through the screens.
Press Y or N to go to
the main menu.
650A
SYSTEM TEST OVERVIEW cont.
This test measures the output of the charging systems under
load conditions. This information provides the basis for fur-
ther charging system tests. It also detects the presence of an
open or shorted diode that causes an output loss of several
amps and can cause the failure of other diodes.
Symptomatic Check before Proceeding:
Battery should be in good condition and charged before testing the
Charging System.
Check warning light indications.
Check belt condition and tension.
Check all cables and connections.
Check the battery for corrosion and dirty terminals.
Does the battery have a low state of charge? (See section 2 and 3)
Make sure all electrical items are off.
Check for Alternator noise.
Allow the charging test to nish.
Test result will appear. The following are examples.
Alternator has GOOD
regulation and GOOD
output.
High Regulation will damage the
system. High Regulation is likely due
to a faulty alternator and/or voltage
regulator.
Bar at the bottom of the screen will
show the tests progress.
The BVA-200S will allow the voltage
to stabilize before starting the test
bar at the bottom of the screen that
shows the test progress. Be patient,
it can take up to 30 seconds for the
voltage to stabilize.
#43 12V CHARGE
PASS REGULATOR
PASS DIODES
PASS OUTPUT
#43 12V CHARGE
FAIL REG HIGH
PASS DIODES
TESTING CHARGING
PLEASE WAIT…
ALLOW VOLTAGE
TO STABILIZE
14.43
