Automotive Diagnostics 10 Series User guide

1
Automotive Diagnostics Start Up Guide
1 Introduction
The Complete User Manual and Operators Guide is available at
www.automotivediagnosticsintl.com please download and read prior to
using the Series 10.
1.1 Product Profile
The Series 10 is a Windows 10 Pro tablet-based vehicle diagnostic system. The Series 10
provides a choice of Bluetooth or wired communication through a VCI connector to the
Series 10 tablet to communicate with the vehicle via the diagnostic port.
Below is a diagram showing how the Series 10 turns on and connects to the vehicle.
1.2 Product Features
• Full diagnostic functionality – Complete capabilities for codes, live data, freeze frame,
functional tests, ECU information, adaptation, matching, and coding for dozens of vehicle
systems
•. Automatic VIN identification – to instantly identify the vehicle under test
• System Detection – detects only the systems that are specific to the vehicle and reads
for errors
• One-Touch Full Vehicle Code Scan & Clear - quickly checks and clears codes for all
available modules on the vehicle
• Record / Playback/Print live data
• Study and compare mode for Live data — real-time data can be compared against
known good measurements
• Service functionalities - Direct Access to the most common required special
Bluetooth
or
USB cable

2
functionalities such as oil service, EPB, ABS&SRS, BCM/SIR setting, DPF regeneration,
throttle body alignment, steering angle sensor calibration, battery configuration, etc.
• Interactive Data Logging sessions and remote control - enable direct contact with
Automotive Diagnostics Technical Support for first-hand bugs troubleshooting.
1.3 Unit Description
This section illustrates external features, ports, and connectors of the scanner.
1.3.1 Windows Tablet
(1) Series 10
1. Scan Button – (Scanning is not available on this device).
2. Lock/Power Button –Turns the device on & off with long press, or locks the screen with
short press
3. Volume Up
4. Volume Down
5. Front-Facing Camera
6. Headset jack
7. HDMI (high-definition multimedia interface) Port
8. Micro USB port
9. USB 2.0 port
10. SIM card tray
11. TF card tray
12. DC/AC power jack

3
1.3.2 Vehicle Communication Interface (Only applies to 12V vehicles)
The vehicle communication interface (VCI) is used to connect to a vehicle’s diagnostic
connector (DLC) via Bluetooth or an OBDII extension cable to read ECU data and send it
to the unit.
1. USB connector port – provides connection between VCI and the tablet via USB cable (if
required)
2. Error indicator- illuminates when error occurs while communicating with the tablet.
3. USB indicator – illuminates when the VCI get connected with the tablet via USB cable.
4. Bluetooth indicator – illuminates when the VCI get connected with the tablet via
Diagnostic cable.
5. Diagnostic Port - provides connection between VCI and the vehicle
Note: If the unit remains switched off or on Standby for a long period of time, it could fail to
turn on. Please charge the tablet for a minimum of 10 minutes and turn on again. Keep
the unit charging until you have enough power.

4
2 Registration and Software Update
Please connect you Series 10 tablet to your Wi-Fi network, click on the
icon to register the unit as well as to update the software.
General Notice
For your own safety and the safety of others, and to prevent damage to the equipment
and vehicles, read this manual thoroughly before operating. The safety messages
presented below and throughout this user’s manual are reminders to the operator to
exercise extreme care when using this device. Always refer to and follow safety messages
and test procedures provided by the vehicle manufacturer. Read, understand, and follow
all safety messages and instructions in the manual.
Safety Precautions and Warnings
To prevent personal injury or damage to vehicles and/or the Series 10, read the full
instruction manual first and observe the following safety precautions at a minimum
whenever working on a vehicle:
Always perform automotive testing in a safe environment. Wear safety eye protection that
meets CE/ANSI standards. Keep clothing, hair, hands, tools, test equipment, etc. away
from all moving or hot engine parts. Operate the vehicle in a well-ventilated work area:
Exhaust gases are poisonous. Put blocks in front of the drive wheels and never leave the
vehicle unattended while running tests.
Use extreme caution when working around the ignition coil, distributor cap, ignition wires
and spark plugs. These components create hazardous voltages when the engine is
running.
Put the transmission in PARK (for automatic transmission) or NEUTRAL (for manual
transmission) and make sure the parking brake is engaged.
Keep a fire extinguisher suitable for gasoline/chemical/ electrical fires nearby. Ignition is
on or the engine is running.
Keep the Series 10 dry, clean, free from oil/water or grease. Use a mild detergent on a
clean cloth to clean the outside of the scan tool, when necessary.
For further information please go to
www.automotivediagnosticsintl.com
