LAUNCH TECH X-431 PRO3 SE User manual

Version: V1.00.000
Revised date: 11-16-2022

LAUNCH X-431 PRO3 SE User Manual
i
Trademarks
LAUNCH is a registered trademark of LAUNCH TECH CO., LTD. in China and
other countries. All other marks are trademarks or registered trademarks of their
respective holders.
Copyright Information
Copyright © 2021 by LAUNCH TECH CO., LTD. (also called LAUNCH for short).
All rights reserved. No part of this publication may be reproduced, stored in a
retrieval system, or transmitted in any form or by any means, electronic,
mechanical, photocopying and recording or otherwise, without the prior written
permission.
Statement: LAUNCH owns the complete intellectual property rights for the
software used by this product. For any reverse engineering or cracking actions
against the software, LAUNCH will block the use of this product and reserve the
right to pursue their legal liabilities.
Disclaimer of Warranties and Limitation of Liabilities
All information, illustrations, and specifications in this manual are based on the
latest information available at the time of publication.
The right is reserved to make changes at any time without notice. We shall not
be liable for any direct, special, incidental, indirect damages or any economic
consequential damages (including the loss of profits) due to the use of the
document.
Important Safety Precautions
Important: To avoid personal injury, property damage, or accidental damage to
the product, read all of the information in this section before using the product.
 Never collide, throw, or puncture the tool, and avoid falling, extruding and
bending it.
 Do not insert foreign objects into or place heavy objects on your device.
Sensitive components inside might cause damage.
 Do not use the tool in exceptionally cold or hot, dusty, damp or dry
environments.
 In places using the tool may cause interference or generate a potential risk,

LAUNCH X-431 PRO3 SE User Manual
ii
please turn it off.
 This tool is a sealed unit. There are no end-user serviceable parts inside. All
internal repairs must be done by an authorized repair facility or qualified
technician. If there is any inquiry, please contact the dealer.
 Never place the tool into apparatus with strong electromagnetic field.
 Keep the tool far away from magnetic devices because its radiations can
damage the screen and erase the data stored on the tool.
 DANGER: Do not attempt to replace the internal rechargeable lithium battery.
Contact the dealer for factory replacement.
 CAUTION: Please use the included battery and charger. Risk of explosion if
the battery is replaced with an incorrect type.
Precautions on Using this tool
Before using this tool, please read the following safety information carefully.
 Always perform automotive testing in a safe environment.
 If the VCI (Vehicle Communication Interface) device is not in use for a long
period of time, it is suggested to unplug the connector from vehicle’s DLC to
conserve battery power.
 Wear an ANSI-approved eye shield when testing or repairing vehicles.
 The vehicle shall be tested in a well-ventilated work area, as engines produce
various poisonous compounds (hydrocarbon, carbon monoxide, nitrogen
oxides, etc.)
 Do not connect or disconnect any test equipment while the ignition is on or
the engine is running.
 Put blocks in front of the drive wheels and never leave the vehicle unattended
while testing.
 Keep the tool dry, clean, free from oil, water or grease. Use a mild detergent
on a clean cloth to clear the outside of the equipment as necessary.
 Do not drive the vehicle and operate the tool at the same time. Any distraction
may cause an accident.
 Keep clothing, hair, hands, tools, test equipment, etc. away from all moving or
hot engine parts.
 Before starting the engine, put the gear lever in the Neutral position (for

LAUNCH X-431 PRO3 SE User Manual
iii
manual transmission) or in the Park (for automatic transmission) position to
avoid injury.
 To avoid damaging the tool or generating false data, please make sure the
vehicle battery is fully charged and the connection to the vehicle DLC (Data
Link Connector) is clear and secure.
 Automotive batteries contain sulfuric acid that is harmful to skin. In operation,
direct contact with the automotive batteries should be avoided. Keep the
ignition sources away from the battery at all times.
Precautions on Operating Vehicle’s ECU
 Do not disconnect battery or any wiring cables in the vehicle when the ignition
switch is on, as this could avoid damage to the sensors or the ECU.
 Do not place any magnetic objects near the ECU. Disconnect the power
supply to the ECU before performing any welding operations on the vehicle.
 Use extreme caution when performing any operations near the ECU or
sensors. Ground yourself when you disassemble PROM, otherwise ECU and
sensors can be damaged by static electricity.
 When reconnecting the ECU harness connector, be sure it is attached firmly,
otherwise electronic elements, such as ICs inside the ECU, can be damaged.
FCC Statement
Any Changes or modifications not expressly approved by the party responsible
for compliance could void the user’s authority to operate the equipment.
This device complies with part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference,
and (2) this device must accept any interference received, including interference
that may cause undesired operation.
Note: This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation.
This equipment generates, uses, and can radiate radio frequency energy, and if
not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does

LAUNCH X-431 PRO3 SE User Manual
iv
cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which
the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
X-431 PRO3 SE (FCC ID: XUJX431PROV5) has been evaluated to meet
general RF exposure requirement.

LAUNCH X-431 PRO3 SE User Manual
v
TABLE OF CONTENTS
1 Introduction ................................................................................................. 1
1.1 Product Profile ........................................................................................ 1
1.2 Components & Controls ......................................................................... 2
1.2.1 Display Tablet .................................................................................. 2
1.2.2 VCI Connector ................................................................................ 4
1.3 Technical Parameters ............................................................................. 6
1.4 Package List ........................................................................................... 7
2 Preparations ................................................................................................ 9
2.1 Charging & Turning On ........................................................................... 9
2.2 Screen Layout ........................................................................................ 9
2.3 Basic Gestures ....................................................................................... 9
2.4 Change System Language ................................................................... 10
2.5 Adjust Brightness ................................................................................. 10
2.6 Set Standby Time ................................................................................. 10
2.7 Network Setup ...................................................................................... 11
3 Initial Use ................................................................................................... 12
3.1 Register & Update ................................................................................ 12
3.2 Job Menu ............................................................................................. 14
3.3 Diagnostics Toolbar .............................................................................. 16
4 Connections .............................................................................................. 17
4.1 Preparation ........................................................................................... 17
4.2 Vehicle Connection............................................................................... 18
4.2.1 OBD II vehicle Connection ............................................................ 18
4.2.2 Non-OBD II vehicle Connection .................................................... 18
5 Diagnosis ................................................................................................... 20
5.1 Intelligent Diagnose .............................................................................. 20
5.2 Local Diagnose ..................................................................................... 23
5.2.1 Health Report (Quick Test) ............................................................ 28

LAUNCH X-431 PRO3 SE User Manual
vi
5.2.2 System Scan ................................................................................. 32
5.2.3 System Selection .......................................................................... 32
5.3 Remote Diagnose ................................................................................. 43
5.3.1 Add Friends ................................................................................... 44
5.3.2 Start Instant Messaging ................................................................. 45
5.3.3 Launch Remote Diagnosis (Device-To-Device) ............................. 46
5.3.4 Launch Remote Diagnosis (Device-To-PC) ................................... 49
5.4 Feedback ............................................................................................. 51
5.5 Diagnostic History................................................................................. 52
6 Service (Reset) Function .......................................................................... 53
6.1 Oil Reset Service .................................................................................. 53
6.2 Electronic Parking Brake Reset ............................................................ 54
6.3 Steering Angle Calibration .................................................................... 54
6.4 ABS Bleeding ....................................................................................... 54
6.5 Tire Pressure Monitor System Reset .................................................... 54
6.6 Gear Learning ...................................................................................... 54
6.7 IMMO Service ....................................................................................... 55
6.8 Injector Coding ..................................................................................... 55
6.9 Battery Maintenance System Reset...................................................... 55
6.10 Diesel Particulate Filter (DPF) Regeneration ...................................... 55
6.11 Electronic Throttle Position Reset ....................................................... 56
6.12 Gearbox Matching .............................................................................. 56
6.13 AFS (Adaptive Front-lighting System) Reset ...................................... 56
6.14 Sunroof Initialization ........................................................................... 56
6.15 Suspension Calibration ....................................................................... 56
6.16 IMMO Programming ........................................................................... 57
7 Software Update ........................................................................................ 58
7.1 Update Diagnostic Software & APP ...................................................... 58
7.2 Update Frequently Used software ........................................................ 59
7.3 Renew Subscription.............................................................................. 59
8 Add-on Modules ........................................................................................ 62

LAUNCH X-431 PRO3 SE User Manual
vii
8.1 ADAS (Calibration) ............................................................................... 62
8.2 BST360 (Battery Tester) ....................................................................... 62
8.3 TPMS ................................................................................................... 62
8.4 Videoscope........................................................................................... 62
8.5 S2-2 Sensorbox .................................................................................... 62
8.6 S2-2 Multimeter .................................................................................... 63
8.7 PROG3 (Immobilizer Programmer)....................................................... 63
9 User Info .................................................................................................... 64
9.1 My Report ............................................................................................. 64
9.2 VCI ....................................................................................................... 64
9.3 VCI Management ................................................................................. 64
9.4 Activate VCI.......................................................................................... 64
9.5 Firmware Fix......................................................................................... 65
9.6 Data Stream Sample ............................................................................ 65
9.7 My Order .............................................................................................. 65
9.8 Subscription Renewal Card .................................................................. 65
9.9 Profile ................................................................................................... 65
9.10 Change password............................................................................... 66
9.11 Settings .............................................................................................. 66
9.11.1 Units ............................................................................................ 66
9.11.2 Shop Information ......................................................................... 66
9.11.3 Printer Set ................................................................................... 67
9.11.4 Orientation ................................................................................... 70
9.11.5 Clear Cache ................................................................................ 70
9.11.6 About ........................................................................................... 70
9.11.7 Diagnostic Software Auto Update ................................................ 70
9.11.8 Device Account Management ...................................................... 70
9.11.9 Login/Logout................................................................................ 72
9.12 Diagnostic Software Clear .................................................................. 72
10 FAQ........................................................................................................... 73

LAUNCH X-431 PRO3 SE User Manual
1
1 Introduction
1.1 Product Profile
It inherits from LAUNCH’s advanced diagnosing technology and is characterized
by covering a wide range of vehicles, featuring powerful functions, and providing
precise test result.
Through the simple Bluetooth communication between VCI (Vehicle
Communication Interface) device and the display tablet, it achieves full car
model and full system vehicle trouble diagnosis, which include Reading DTCs,
Clearing DTCs, Reading Data Stream, Actuation Test and Special Functions.
Moreover, taking advantage of the mobile Internet, it also integrates One-click
Update, Remote Diagnosis and Repair Data, which helps to diagnose vehicle
issues more efficiently, and greatly increase customer’s retention.
It has the following features:
 Intelligent Diagnose: This module allows you to use the VIN information of the
currently identified vehicle to access its data (including vehicle information,
historical diagnostic records) from the cloud server to perform quick test,
eliminating guesswork and step-by-step manual menu selection.
 Local Diagnose: Follow the on-screen prompts to start diagnostic session
step by step.
 Remote Diagnose: This option aims to help repair shops or technicians
launch instant messaging and remote diagnosis, making the repair job getting
fixed faster.
 Service Function: All kinds of common maintenance and reset items including
Oil Reset Service, Electronic Parking Brake Reset, Steering Angle Calibration,
ABS Bleeding, TPMS (Tire Pressure Monitor System) Reset, Gear Learning,
IMMO Service, Injector Coding, Battery Maintenance System, Diesel
Particulate Filter (DPF) Regeneration, Electronic Throttle Position Reset,
Gearbox Matching, AFS (Adaptive Front-lighting System) Reset, Sunroof
Initialization, Suspension Calibration etc.
 One-click Update: Lets you update your diagnostic software online.
 ADAS calibration: Allows you to perform Advanced Driver Assistance System
(ADAS) calibration operations. This function needs to be activated before
normal use and only works with the specific ADAS calibration tool.

LAUNCH X-431 PRO3 SE User Manual
2
 TPMS: Configures the tool as a professional Tire Pressure Monitoring
System (TPMS) service tool. It needs to work with the TSGUN device (sold
separately) to perform all kinds of various TPMS functions.
 Mall: Enables you to subscribe some extra software or service functions that
are not integrated in the tool online.
 Diagnostic History: This function provides a quick access to the tested
vehicles and users can choose to view the test report or resume from the last
operation, without starting from scratch.
 Feedback: Enables you to submit the vehicle issue to us for analysis and
troubleshooting.
 Vehicle Coverage: Quick dial to view the vehicle models that the tool covers.
 Add-on modules: Optional. BST 360 Battery Tester, S2-2 Sensorbox,
Multimeter and Videoscope etc. are available as add-on modules, extending
the functions of the tool.
1.2 Components & Controls
There are two main components to the diagnostic system:
 Display Tablet – the central processor and monitor for the system (See
Chapter “1.3.1”).
 VCI Device – the device for accessing vehicle data (See Chapter “1.3.2”).
1.2.1 Display Tablet
The tablet acts as the central processing system, which is used to receive and
analyze the live vehicle data from the VCI device and then output the test result.

LAUNCH X-431 PRO3 SE User Manual
3
1
Microphone
2 Type-A USB Port
• Connects to the VCI connector to perform
vehicle diagnosis via the USB cable.
• Connects to compatible add-on modules
(such as Videoscope) or USB storage
devices.
3 Type-C USB Port • Connects to AC outlet for charging.
• Connects to PC for data exchange.
4 POWER Key
In Off mode, press it for 3 seconds to turn the
tablet on.
In On mode:
• Press it once to activate the LCD if the LCD
is off. Press it once to turn off the LCD if the
LCD lights up.
• Press and hold it for 3 seconds to turn it off.
• Press and hold it for 8 seconds to perform
forced shutdown.

LAUNCH X-431 PRO3 SE User Manual
4
5
LCD Screen
Indicates the test result.
6
Speakers
7
Rear
C
amera
8 Adjustable stand Flip it out to any angle and work comfortable at
your desk, or hang it on steering wheel.
1.2.2 VCI Connector
The VCI connector works as a vehicle communication interface device, which is
used to connect to the vehicle’s DLC (Data Link Connector) socket via the
diagnostic cable to read the vehicle data and then send it to the tablet.

LAUNCH X-431 PRO3 SE User Manual
5
1 Power indicator Illuminates red while the VCI is powered up.
2 Vehicle indicator Illuminates green and flashes when the VCI
is communicating with the vehicle.
3 I/O indicator
 Illuminates blue when the VCI is
communicating with the tablet via
Bluetooth.
 Illuminates red when the VCI is connected
to the tablet via USB cable.
4 OBD-15 diagnostic
connector
Connects on vehicle’s OBD II DLC via the
diagnostic cable.
5 USB port Connects the VCI to the tablet to perform
vehicle diagnosis via USB cable.

LAUNCH X-431 PRO3 SE User Manual
6
1.3 Technical Parameters
Display Tablet
Operating system Android
Memory 4GB
Storage 64GB
Screen 10.1 inch capacitive touch screen with a
resolution of 1280 x 800 pixels
Camera Rear-facing 8.0MP camera
Connectivity
 Wi-Fi (802.11a/b/g/n/ac)
 Bluetooth
Working temperature 0℃ ~ 50℃
Storage temperature -20 ~ ℃70℃
VCI Connector (Only for Passenger Vehicle Configuration)
Working voltage 9 ~18V
Power consumption ≤2.0W
Dimension 118.3mm*69.5mm*32mm
Working temperature -10℃ ~ 50℃
Relative humidity 20% ~ 90%
VCI Module (Only for Commercial Vehicle Configuration)
Working voltage DC 9 ~36V
Power consumption ≤ 3W
Communication Via Bluetooth/Wi-Fi

LAUNCH X-431 PRO3 SE User Manual
7
Working temperature 0℃~ 50℃
1.4 Package List
The following packing list is for reference purpose only. For different destinations,
the accessories may vary. For details, please consult from the local dealer or
check the packing list supplied with this tool together.
No.
Item
Descriptions
Q
t.
1 Display tablet Indicates the test result. 1
2 VCI connector A device for accessing vehicle live
data. 1
3 HD15F to HD15F
diagnostic cable
• Connects it to HD15F to OBD II 16
adaptor and the VCI for standard
OBD II diagnostic socket.
• Connects it to non-16pin adaptor
(sold separately) and the VCI for
non-OBD II diagnostic socket.
1
4 HD15F to OBD II
16 adaptor
Connects it to vehicle’s OBD II
diagnostic socket and the diagnostic
cable.
1
5 Password envelope
A piece of paper bearing the product
Serial Number and Activation Code for
product registration.
1
6 Power adaptor Charges the tablet via AC outlet. (Optional)
7 Type-A to Type-C
USB cable
• Connects the diagnostic tool to AC
outlet / PC for charging / data
exchange.
• Connects the VCI connector to the
diagnostic tool to perform vehicle
1

LAUNCH X-431 PRO3 SE User Manual
8
diagnosis.

LAUNCH X-431 PRO3 SE User Manual
9
2 Preparations
2.1 Charging & Turning On
1. Use the included power adaptor to charge the tablet.
2. After charging is complete, press the POWER button to turn the tablet on.
The system starts initializing and then enters the home screen.
Note: If the battery remains unused for a long period of time or the battery is
completely discharged, it is normal that the tool will not power on while being charged.
Please charge it for a period of 5 minutes and then turn it on.
Warning: Please use the included power adaptor to charge your tool. No
responsibility can be assumed for any damage or loss caused as a result of using power
adaptors other than the one supplied.
Press [POWER] for 3 seconds, an option menu will pop up on the screen. Tap
Power off to turn the tool off.
2.2 Screen Layout
There are five on-screen buttons available on the bottom of the screen.
Home: Navigates to the Android’s home screen.
Recent App: Views the recently launched applications and running
applications.
VCI Connection: Shows whether the VCI device is properly connected or
not.
Screenshot: Captures the current screen.
Back: Returns to the previous screen.
2.3 Basic Gestures
Single-tap: To select an item or launch a program.

LAUNCH X-431 PRO3 SE User Manual
10
Double-tap: To zoom in so that the text on a webpage appears in a
column that fits your device’s screen.
Long press: Tap and hold on the current interface or area until a
contextual menu pops up on the screen, and then release it.
Slide: To jump to different pages.
Drag: Tap the application icon and drop it to other location.
Spread apart/pinch together: To zoom in manually, place two
fingers on the screen and then spread them apart. To zoom out,
place two fingers apart on the screen and then pinch them together.
2.4 Change System Language
The tool supports multiple system languages. To change the language of the
tool, please do the following:
1. On the home screen, tap Settings -> System -> Language & input ->
Languages.
2. Tap Add a language, and then choose the desired language from the list.
3. Tap and hold the desired language and drag it to the top of the screen and
then release it, the system will change into the target language.
2.5 Adjust Brightness
Note: Reducing the brightness of the screen is helpful to conserve the battery
power.
1. On the home screen, tap Settings -> Display -> Brightness level.
2. Drag the slider to adjust it.
2.6 Set Standby Time
If no activities are made within the defined standby period, the screen will be
locked automatically and the system enters sleep mode to save power.

LAUNCH X-431 PRO3 SE User Manual
11
1. On the home screen, tap Settings -> Display -> Advanced -> Sleep.
2. Choose the desired sleep time.
2.7 Network Setup
The tablet has built-in Wi-Fi that can be used to get online. Once you’re online,
you can register your tool, surf the Internet, get apps, send email, launch the
remote diagnosis, and check for software updates etc.
1. On the home screen, tap Settings -> Network & Internet -> WLAN.
2. Slide the Wi-Fi switch to ON, the tablet starts searching for available wireless
networks.
3. Select a wireless network,
 If the chosen network is open, the tablet will connect automatically.
 If the selected network is encrypted, a network password will need to be
entered.
4. When Connected appears, it indicates the Wi-Fi connection is complete.
Note: When Wi-Fi is not required, this should be disabled to conserve battery
power.

LAUNCH X-431 PRO3 SE User Manual
12
3 Initial Use
For new users, you will need to experience a user registration process before
getting started.
3.1 Register & Update
Follow the steps below to proceed registration and update:
Tap the application icon on the home screen to launch it, and then tap Login to
enter the login interface of diagnosis software.
(If you are a new user, follow A to proceed.)
(If you have registered to be a member, go to B to login the system directly.)
(If you have bound a sub-account to this tool, go to B to login the system.)
(In case you forgot password, refer to D to reset a new password.)
A. If you are a new user, tap New Registration to enter the sign-up page.
