USER MANUAL

ii © Copyright Reserved Autonics Co., Ltd.

Preface
© Copyright Reserved Autonics Co., Ltd. iii
Preface
Thank you very much for selecting Autonics products.
Please familiarize yourself with the information contained in the Safety Considerations section
before using this product.
This user manual contains information about the product and its proper use, and should be kept
in a place where it will be easy to access.

User Manual Guide
iv © Copyright Reserved Autonics Co., Ltd.
User Manual Guide
Please familiarize yourself with the information in this manual before using the product.
This manual provides detailed information on the product's features. It does not offer any
guarantee concerning matters beyond the scope of this manual.
This manual may not be edited or reproduced in either part or whole without permission.
A user manual is not provided as part of the product package. Please visit our home-page
(www.autonics.com) to download a copy.
The manual's content may vary depending on changes to the product's software and other
unforeseen developments within Autonics, and is subject to change without prior notice.
Upgrade notice is provided through our homepage.
We contrived to describe this manual more easily and correctly. However, if there are any
corrections or questions, please notify us these on our homepage.

User Manual Symbols
© Copyright Reserved Autonics Co., Ltd. v
User Manual Symbols
Symbol Description
Supplementary information for a particular feature.
Failure to follow instructions can result in serious injury or death.
Failure to follow instructions can lead to a minor injury or product damage.
An example of the concerned feature's use.
※1 Annotation mark.

Safety Considerations
vi © Copyright Reserved Autonics Co., Ltd.
Safety Considerations
Following these safety considerations will ensure the safe and proper use of the product
and help prevent accidents and minimize hazards.
Safety considerations are categorized as Warnings and Cautions, as defined below:
Warning Cases that may cause serious injury or fatal accident if
instructions are not followed.
Caution Cases that may cause minor injury or product damage if
instructions are not followed.
Fail-safe device must be installed when using the unit with machinery that may cause
serious injury or substantial economic loss. (e.g. nuclear power control, medical equipment,
ships, vehicles, railways, aircraft, combustion apparatus, safety equipment, crime/disaster
prevention devices, etc.)
Failure to follow this instruction may result in fire, personal injury, or economic loss.
Use the unit within the rated specifications.
Failure to follow this instruction may result in shortening the life cycle of the product or fire.
Do not connect, repair, or inspect the unit while connected to a power source.
Failure to follow this instruction may result in fire.
Check 'Power Wiring' and 'Serial Interface' before wiring.
Failure to follow this instruction may result in fire.
In preparation for product damage, communication error, or malfunction, install external limit
switch, emergency stop switch, or other protection circuit.
Failure to follow this instruction may result in fire, personal injury, or economic loss.
Since Lithium battery is embedded in the product, do not disassemble or burn the unit.
Failure to follow this instruction may result in fire.
Do not disassemble or modify the unit.
Failure to follow this instruction may result in fire.
Please contact to us for battery replacement.

Safety Considerations
© Copyright Reserved Autonics Co., Ltd. vii
Do not use the unit in the place where flammable/explosive/corrosive gas, humidity, direct
sunlight, radiant heat, vibration, impact, or salinity may be present.
Failure to follow this instruction may result in fire or explosion.
Use dry cloth to clean the unit, and do not use water or organic solvent.
Failure to follow this instruction may result in electric shock or fire.
When connecting the power input, use AWG 23 cable or over and tighten the terminal screw
with a tightening torque of 0.5 to 0.8N.m.
Failure to follow this instruction may result in fire or malfunction due to contact failure.
Keep metal chip, dust, and wire residue from flowing into the unit.
Failure to follow this instruction may result in fire or product damage.
Do not push over 2 point at the same time.
Failure to follow this instruction may result in malfunction.
The above specifications are subject to change and some models may be discontinued
without notice.
Be sure to follow cautions written in the instruction manual, user manual and the
technical descriptions (catalog, homepage).

Cautions during Use
viii © Copyright Reserved Autonics Co., Ltd.
Cautions during Use
Follow instructions in 'Cautions during Use'. Otherwise, it may cause unexpected accidents.
24VDC power supply should be insulated and limited voltage/current or Class 2, SELV
power supply device.
Install a power switch or circuit breaker in the easily accessible place for supplying or
disconnecting the power.
Operate the product after supplying power to the product, input/output equipment, and load.
If operate product before supplying power, it may result in output error or malfunction.
Keep away from high voltage lines or power lines to prevent inductive noise.
Do not use near the equipment which generates strong magnetic force or high frequency
noise.
Make a required space around the unit for radiation of heat, and do not block ventilation
openings.
Do not push the touch panel with a hard and sharp object or push the panel with excessive
force. It may result in fire or malfunction.
When skin is smeared with liquid crystal from the broken LCD, rinse with running water for
over 15 minutes.
If it gets into the eyes, rinse eyes with running water for over 15 minutes and contact a
doctor.
This unit may be used in the following environments.
①Indoors (in the environment condition rated in 'Specifications')
②Altitude max. 2,000m
③Pollution degree 2
④Installation category II

Table of Contents
© Copyright Reserved Autonics Co., Ltd. ix
Table of Contents
Preface .............................................................................................................................iii
User Manual Guide ......................................................................................................... iv
User Manual Symbols ...................................................................................................... v
Safety Considerations ..................................................................................................... vi
Cautions during Use.......................................................................................................viii
Table of Contents ............................................................................................................ ix
1Overview ....................................................................................................13
1.1 Graphic Panel ....................................................................................................13
1.2 Feature of GP ....................................................................................................14
1.3 Model .................................................................................................................15
1.4 Specification.......................................................................................................15
1.4.1 General specification.................................................................................. 15
1.4.2 Performance specification.......................................................................... 16
1.4.3 GP-S044, GP-057 system setting .............................................................. 17
1.5 Communication..................................................................................................18
1.5.1 Communication interface ........................................................................... 20
1.6 Unit description ..................................................................................................21
1.6.1 GP-S044..................................................................................................... 21
1.6.2 GP-S057..................................................................................................... 21
1.7 Dimensions ........................................................................................................22
1.7.1 GP-S044..................................................................................................... 22
1.7.2 GP-S057..................................................................................................... 23
2Installation .................................................................................................25
2.1 GP installation....................................................................................................25
2.2 Power wiring ......................................................................................................26
2.2.1 Ground wiring ............................................................................................. 27
2.3 Battery replacement...........................................................................................27
3Device Construction .................................................................................29
3.1 Device element ..................................................................................................29
3.2 Device range......................................................................................................29
3.2.1 Bit device range ......................................................................................... 29
3.2.2 Word device range ..................................................................................... 29
4System Organization ................................................................................31
4.1 Connection with controller .................................................................................31
4.1.1 1:1 organization.......................................................................................... 31
4.1.2 1:N organization ......................................................................................... 32
4.1.3 Heterogeneous organization ...................................................................... 33
4.2 Universal organization .......................................................................................33
4.3 Connect with barcode, printer............................................................................34

Table of Contents
x © Copyright Reserved Autonics Co., Ltd.
4.4 Connect with GP Editor .....................................................................................35
4.4.1 GP Editor configuration .............................................................................. 38
5Start up GP.................................................................................................39
5.1 Checking list before supplying power................................................................ 39
5.2 Operation order..................................................................................................40
6System Screen ..........................................................................................41
6.1 Organization of system screen..........................................................................41
6.2 Operation of system screen...............................................................................42
6.3 Device monitor...................................................................................................43
6.4Set Environment ................................................................................................44
6.4.1 Language ................................................................................................... 44
6.4.2 PLC setting................................................................................................. 45
6.4.3 Clock........................................................................................................... 49
6.4.4 Clear USER DATA...................................................................................... 50
6.4.5 Menu call key ............................................................................................. 51
6.4.6 Buzzer ........................................................................................................ 52
6.4.7 Opening time .............................................................................................. 53
6.4.8 Backlight ..................................................................................................... 54
6.4.9 Battery ........................................................................................................ 55
6.4.10 Contrast ...................................................................................................... 56
6.4.11 Latch device ............................................................................................... 56
6.5 Data View...........................................................................................................57
6.5.1 Base screen ............................................................................................... 57
6.5.2 Window screen ........................................................................................... 58
6.5.3 Comment.................................................................................................... 58
6.5.4 Memory size ............................................................................................... 59
6.5.5 Model & Version ......................................................................................... 59
6.6 Set Function.......................................................................................................60
6.6.1 Data transfer............................................................................................... 60
6.6.2 Time switch ................................................................................................ 62
6.6.3 Print out ...................................................................................................... 64
7User Screen ...............................................................................................65
7.1 Screen specification...........................................................................................65
7.2 Screen display object ........................................................................................66
7.3 Screen switching................................................................................................ 67
7.4 Overlap window function ...................................................................................68
7.5 Device connection status display ...................................................................... 70
8System Window.........................................................................................71
8.1 Key pad type......................................................................................................71
8.2 Key pad organization......................................................................................... 72
9Troubleshooting ........................................................................................73
9.1 Error and troubleshooting ..................................................................................73
10 Firmware update........................................................................................75
11 Repair and Check ......................................................................................77

Table of Contents
© Copyright Reserved Autonics Co., Ltd. xi
11.1 Change repair component .................................................................................77
11.1.1 Battery replacement ................................................................................... 77
11.2 Check .................................................................................................................78
11.2.1 General check ............................................................................................ 78
11.2.2 Periodic check ............................................................................................ 78

Table of Contents
xii © Copyright Reserved Autonics Co., Ltd.

1 Overview
© Copyright Reserved Autonics Co., Ltd. 13
1Overview
1.1 Graphic Panel
Graphic Panel (after referred to as GP) is graphic interface device for monitoring parameters of
controller such as PLC. It is one of human-machine interface (HMI) or man-machine interface
(MMI).
If controller does not have visual interface, it is difficult to find out current value or status of
process. In this case, GP is a practical device.
GP monitors control parameter visually by LCD screen or switches the other screen or
designates variable value by touching touch screen. GP and controller are connected by serial
communication and inter-change mutual information.
The variable for controller is displayed by various methods as tag which is graphic object. For
example, if the physical variable for monitoring is temperature, GP displays temperature as
numeral by numeral input tag, or as trend graph with changes by time. GP screen consists of
these graphic objects combinations.
GP Editor which is dedicated software for user defined screen data in GP helps draw screen or
edit data. After editing screen data such as tag form, arrangement, and attribution, download
these to GP and GP starts to monitor by screen data.

1 Overview
14 © Copyright Reserved Autonics Co., Ltd.
1.2 Feature of GP
Product upgrade by web site
We offer GP firmware, GP Editor, protocol, language and font, various manuals at
www.autonics.com to download conveniently.
Communication between heterogeneous controllers
You can connect other type controller to serial port separately.
GP monitors two different controllers simultaneously and relays communication between
two controllers.
Multi monitoring function
You can connect same type of several controllers.
Supports multilingual
GP supports Korean, English and the other languages are available for the later.
Supports several font
GP supports various bitmap font and vector font. You can select the desired font and use it.
Multi communication port
GP supports several communication port such as RS232C /RS422 serial communication
port, USB HOST USB DEVICE, and Ethernet.
Two serial ports of RS232C / RS422 are designated for the device connecting by software
(PLC, computer, printer, barcode reader, etc). By supported communication type of
connected device, select port to communication.
Monitoring function for controller device
Without designed data, GP menu is available for monitoring connectable controller device.
Print and barcode reader connection
You can print alarm list by connecting printer.
It is able to read barcode by connecting barcode reader.
Touch interface
It is able to input value in controller with touch switch on front screen.
Slim size
It is easy to utilize space with slim size.
Various display function
It is able to display data with various tags.

1 Overview
© Copyright Reserved Autonics Co., Ltd. 15
1.3 Model
Model
Screen
size
Display
unit
Color
Power
supply
Interface
GP-S044-S1D0 4.4inch
STN LCD MONO
(Blue, White) 24VDC
Each one of
RS232C, RS422C
GP-S044-S1D1 Two of RS232C
GP-S057-S1D0 5.7inch
Each one of
RS232C, RS422C
GP-S057-S1D1 Two of RS232C
1.4 Specification
1.4.1 General specification
Model GP-S044 GP-S057
Power supply 24VDCᜡ
Allowable voltage range 90 to 110% of power supply
Power consumption Max. 3.6W (Max)
Serial interface
GP-S0□□-S1D0: Each one of RS232C, RS422C(Asynchronous
method)
GP-S0□□-S1D1: Two of RS232C(Asynchronous method)
Noise immunity The square wave noise (Pulse width 1㎲) by the noise simulator with
±0.5kV
Withstanding voltage 500VAC(50/60Hz) for a minute
Insulated resistance Min. 100MΩ(at 500VDC megger)
Ground 3rd grounding(Max. 100Ω)
Vibra
tion
Mechanical 0.75mm amplitude at frequency of 10 to 55Hz (for a minute) in each of
X, Y, Z directions for an hour
Malfunction 0.5mm amplitude at frequency of 10 to 55Hz (for a minute) in each of
X, Y, Z directions for 10 minutes
Envir
onm
ent
Temperature 0 to 50℃, Storage: -20 to 60℃
Humidity 35 to 85% RH, Storage: 35 to 85% RH
Protection IP65 (front panel, IEC standard)
Accessory Fixing bracket: 4pcs, Rubber waterproof ring, Battery(included)
Approval
Unit weight※1Approx. 413g (Approx. 284g) Approx. 555g (Approx. 376g)
※1 : The weight in parenthesis is only unit weight.
※Environment resistance is rated at no freezing or condensation.

1 Overview
16 © Copyright Reserved Autonics Co., Ltd.
1.4.2 Performance specification
Display performance
Model
GP-S044
GP-S057
LCD type 4.4inch STN Blue Negative 5.5inch STN Blue Negative
Resolution 240 X 80 dot 320 X 240 dot
Display area 112.8 X 37.6mm 119 X 91mm
Color Mono(Blue, White)
LCD view angle
Within each 30°of top/bottom/right/left
Backlight White LED
Brightness Adjustable by software
Graphic drawing performance
Language※1Korean, English, Japanese, Chinese, Russian, Vietnamese, Portuguese
Text
High resolution display up to
400 characters (Based on 6 X
8 font)
6 X 8, 8 X8 ASCII character,
High quality view of numbers
(width 1 to 8 times, height 0.5
to 5 times)
8 X 16 ASCII character, 16 X
16 regional characters (width 1
to 8 times, height 0.5 to 5
times)
High resolution display up to
1590 characters (Based on 6 X
8)
6 X 8, 8 X8 ASCII character,
High quality view of numbers
(width 1 to 8 times, height 0.5 to
5 times)
8 X 16 ASCII character, 16 X 16
regional characters (width 1 to 8
times, 0.5 to 5 times)
Graphic drawing
memory 512kB
Number of user screen 500 pages
Touch switch width15 X height4 = total 60 width16 x height 12 = total 192
※1: You can add other supported langauges.

1 Overview
© Copyright Reserved Autonics Co., Ltd. 17
1.4.3 GP-S044, GP-057 system setting
Function
Description
MONITORING DEVICE
MONITOR
Monitors connected PLC device and changes the status
SET
ENVIRONMENT
LANGUAGE
Designates system language and character set
PLC SETTING Configures serial port for connecting between Editor and
connected device, printer, barcode reader, or monitor
CLOCK
Designates current time and date
CLEAR USER
DATA
Deletes user data downloaded in GP
MENU CALL KEY
Designates the position for calling system setting menu
BUZZER
Designates using buzzer or not
OPENING
Set time for open screen when supplying power
BACKLIGHT
Set off time for backlight as screensaver
BATTERY Displays battery remaining with percentage (%) and bar
graph
CONTRAST
Adjusts LCD screen contrast
LATCH DEVICE Designates maintaining UW device value by GP battery
during power OFF
DATA VIEW
BASE SCREEN
Displays user-defined base screen title and number
WINDOW
SCREEN
Displays user-defined window screen title and number
COMMENT
Displays downloaded comment list in GP
MEMORY SIZE Displays total memory capacity and available memory
capacity
MODEL &
VERSION Displays current version of GP series and model name.
SET FUNCTION
DATA
TRANSFER
Displays this menu during communicating
(download/upload) between GP and GP Editor
TIME SWITCH
Designates time switch
PRINT OUT Prints out alarm history with printer

1 Overview
18 © Copyright Reserved Autonics Co., Ltd.
1.5 Communication
Depending on PLC model type, connections for PLC are different, therefore refer to ‘G P, L P
user manual for communication’.
Every device such as PLC is able to connect any RS232C or RS422 port.
CH1, CH2 is designates in GP Editor.
(1) Connection of 1 PLC
Connect PLC to a port and one of PC, printer, barcode reader to the other port.
(2) Connection of CH1 and CH2
Connect PLC to GP ports.
It is able to connect even if CH and CH2 are not same type PLC, GP can relay data
exchange between CH1 and CH2 according to configuration.

1 Overview
© Copyright Reserved Autonics Co., Ltd. 19
(3) Connection of plural PLCs
It is able to connect same device type to CH1 and CH2 as up to 32 by each.
In this case, GP can link data between CH1-1 to CH1-n and CH2-1 and CH2-n and it is able
not to use CH1 or CH2.

1 Overview
20 © Copyright Reserved Autonics Co., Ltd.
1.5.1 Communication interface
1.5.1.1 Serial interface
(1) Serial port
Port
Pin
Port
Pin
1 Non-used 1 TXD+
2 RXD 2 RXD+
3 TXD 3 Non-used
4 DTR 4 Non-used
5 SG 5 SG
6 DSR 6 TXD-
7 Non-used 7 RXD-
8 Non-used 8 Non-used
9 Non-used 9 Non-used
(2) Serial port setting
Designate the desired settings for below items at [SET ENVIRONMENT] - [PLC SETTING].
Interface RS232C/RS422
Baudrate 300, 600, 1200, 2400, 4800, 9600, 19200, 38400, 57600, 115200bps
Data length 7, 8 Bit
Stop bit 1, 2 Bit
Parity ODD, EVEN
Flow control XON/XOFF, DSR/DTR, NONE
