Overview
V20 SDI to CSI-2 adapter
The V20 features an SDI input and CSI-2 output with 2 lanes, to connect to the CSI-2 camera input and to
emulate the Pi camera (version 1.3). No special driver required. Compatible only with Raspberry Pi.
Tech nic a l det ail s
• emulate Raspberry Pi camera 1.3
• SDI input (MCX): 1080p24, 1080p25, 1080p30
• loop through SDI output (MCX)
• 2 CSI-2 connectors (22 pin connector on top - 15 pin connector on bottom)
• size: 32.5mm x 53.5mm
• mounting: 3 holes with 3.2mm diameter each
•model: 38222-3
•order code: 70504
Power
•p o w e r : 6 V - 1 2 V
V20 top V20 bottom
AUVIDEA GMBH TECHNICAL REFERENCE MANUAL 3
VERSION 1.0 V20 (38222-3)
Pinout description
Power/GPIO (J7)
This is a 6 pin PicoBlade connector with 1.25 mm pitch. MCU UART and SWD programming interface.
JTAG (J6)
This is a 6 pin PicoBlade connector with 1.25 mm pitch. Xilinx cable header
Pin
Function
Description
1
V12.0
6V to 12V power in (1.5W max.)
2
UART2_TX
UART2_TXD (3.3V)
3
UART2_RX
UART2_RXD (3.3V)
4
SWCLK
SWCLK
5
SWDIO
SWDIO
6
GND
Ground
Pin
Function
Description
1
3.3V
3.3V power out
2
TMS
TMS
3
TCK
TCK
4
TDO
TDO
5
TDI
TDI
6
GND
Ground
AUVIDEA GMBH TECHNICAL REFERENCE MANUAL 4
VERSION 1.0 V20 (38222-3)
CSI-2 output (J1)
This is a 22 pin 4 lane CSI-2 connector with 0.5mm pitch (Wuerth 687122149022). To open the connector and to
release the cable just lift the brown lid upwards. This connector has the same pinout as the CSI-2 connector on
the Raspberry Pi compute module carrier board or the Pi Zero. The contacts are on the bottom. Please use a
FPC cable with contacts on the same side.
Pin
Function
Description
1
GND
Ground
2
CSI_D0-
CSI_D0_N
3
CSI_D0+
CSI_D0_P
4
GND
Ground
5
CSI_D1-
CSI_D1_N
6
CSI_D1+
CSI_D1_P
7
GND
Ground
8
CSI_CLK-
CSI_CLK_N
9
CSI_CLK+
CSI_CLK_P
10
GND
Ground
11
CSI_D2-
CSI_D2_N
12
CSI_D2+
CSI_D2_P
13
GND
Ground
14
CSI_D3-
CSI_D3_N
15
CSI_D3+
CSI_D3_P
16
GND
Ground
17
CAM_GPIO
CAM_GPIO (3.3V)
18
CAM_CLK
CAM_CLK (3.3V)
19
GND
Ground
20
SCL
SCL (3.3V)
21
SDA
SDA (3.3V)
22
V3.3
3.3V power (not used)
AUVIDEA GMBH TECHNICAL REFERENCE MANUAL 5
VERSION 1.0 V20 (38222-3)
CSI-2 output (J5)
This is a 15 pin 2 lane CSI-2 connector with 0.5mm pitch (Wuerth 686115148922). To open the connector and to
release the cable just lift the brown lid upwards. The contacts are on the bottom. Please use a FPC cable with
contacts on the same side.
HD-SDI loop through out (J2)
This is a MCX connector (Molex-734151631).
HD-SDI in (J23)
This is a MCX connector (Molex-734151631).
Pin
Function
Description
1
3.3V
3.3V power (not used)
2
SDA
SDA (3.3V)
3
SCL
SCL (3.3V)
4
CAM_CLK
CAM_CLK (3.3V)
5
CAM_GPIO
CAM_GPIO (3.3V)
6
GND
Ground
7
CSI_CLK+
CSI_CLK_P
8
CSI_CLK-
CSI_CLK_N
9
GND
Ground
10
CSI_D1+
CSI_D1_P
11
CSI_D1-
CSI_D1_N
12
GND
Ground
13
CSI_D0+
CSI_D0_P
14
CSI_D0-
CSI_D0_N
15
GND
Ground
Pin
Description
center pin
SDI signal output (75 Ohm)
shielding
pin
Ground
Pin
Description
center pin
SDI signal input (75 Ohm)
shielding
pin
Ground
AUVIDEA GMBH TECHNICAL REFERENCE MANUAL 6
VERSION 1.0 V20 (38222-3)
I2S (J8)
This is a 9 pin Molex PicoBlade connector with 1.25mm pitch. I2S digital audio for future expansion. Currently
not supported.
Pin
Function
Description
1
3.3V
3.3V power
2
MCLK
MCLK (3.3V)
3
BCK
BCK (3.3V)
4
LRCLK
5
DATA0
Data line 0 output (3.3V)
6
DATA1
Data line 1 output (3.3V)
7
DATA2
Data line 2 output (3.3V)
8
DATA3
Data line 3 output (3.3V)
9
GND
Ground
AUVIDEA GMBH TECHNICAL REFERENCE MANUAL 7
VERSION 1.0 V20 (38222-3)
MCU
The V20 micro controller (MCU: STM32F042F6P6) with 32 kByte Flash and 6kByte RAM. At this time the MCU is
not used and not programmed. For future expansion only.
MCU pin description
Pin types:
PP - push/pull output"
OD - open drain output"
Ain - analog input"
AF - alternate function
IO - Input/Output
The power supply to the MCU is supplied by a 3.3V LDO regulator which is always on. So the MCU is powered as
soon as power is applied to the power input on J1. This allows the MCU to manage whether power should be
applied to the carrier board.
The MCU tunnels the console UART interface to the Jetson Nano. Some instructions are intercepted by the MCU
and executed by it. These instructions are not forwarded to the compute module.
MCU Pin
Name
Type
Function
Description
1
PB8/BOOT0
-
-
10k pull down
2
PF0
OD
POWER
1: inactive, 0: press power button
3
PF1
O
POWER
Power enable
4
NRST
-
-
hardware power on reset of MCU (RC circuit)
5
VddA
-
-
analog 3.3V supply (by always on LDO)
6
PA0
PP
LED
0: LED off, 1: LED on (default MCU heartbeat) (D6)
7
PA1
OD
SYS_RST_IN
System reset; open drain 1.8V
8
PA2
AF
UART2_TX
UART 2
9
PA3
AF
UART2_RX
UART 2
10
PA4
AF
SPI1_CS
SPI1_CS
11
PA5
AIN5
SPI1_SCK
SPI1_SCK
12
PA6
AIN6
SPI1_MISO
SPI_MISO
13
PA7
-
SPI1_MOSI
SPI1_MOSI
14
PB1
Ain9
CAM_GPIO
CAM_GPIO
15
GND
-
-
Ground
16
VddA
-
-
digital 3.3V supply (by always on LDO)
17
PA9/PA11
AF
UART_TX
UART_TX to J14 connector (pin 2)
18
PA10/PA12
AF
UART_RX
UART_RX to J14 connector (pin 3)
19
PA13
-
SWDIO
SWD programming interface
20
PA14
-
SWCLK
SWD programming interface
AUVIDEA GMBH TECHNICAL REFERENCE MANUAL 8
VERSION 1.0 V20 (38222-3)
V20 revisions
V20 revision 3 (38222-3)
-cleaned up VCCAUX supply:
-added bead to 3.3V and added 470nF caps
-alternative: 2.5V LDO
- add strapping pull down resistors J92-95 to preset GPIOs to FPGA (on J7)
AUVIDEA GMBH TECHNICAL REFERENCE MANUAL 9
VERSION 1.0 V20 (38222-3)
FAQ
to be added.!
AUVIDEA GMBH TECHNICAL REFERENCE MANUAL 10
VERSION 1.0 V20 (38222-3)
Disclaimer
Thank you for reading this manual. If you have found any typos or errors in this document, please let us know.
This is the preliminary version of this data sheet. Please treat all specifications with caution as there may be
any typos or errors.
