Auvon SM9126 User manual

USER MANUAL
AUVON®TENS Massager
Relaxation, Anywhere, Anytime
Device Name: TENS & PMS
Model SM9126

1
INCLUDED IN THIS STANDARD
PACKAGE
● AUVON® TENS Massager
● SetofElectrodeWires(1/2Wire)
● USBCable&USBAdapter
● UserManual
● HappyCard
●ElectrodePads
FEATURES
● 2outputwith24modes
● 20levelintensity
● 20minutesdefaulttimer,canadjustablefrom
10-60minutes
● Rechargeablelithiumbattery
● Batteryindicatortoknowwhenneedto
rechargethebattery
● ACadapter110~240V,USBCharger5V
SAFETY PRECAUTIONS AND WARNINGS
DO NOT USE THIS UNIT UNDER THESE
CONDITIONS
Consultwithyourphysicianbeforeusingthisunit.
Theunitmaycauselethalrhythmdisturbances
incertainsusceptibleindividuals.Ifyouhavehad
arecentsurgicalprocedure,thestimulationmay
disruptthehealingprocess.

2
Beforeusingyourunit,inspectthesethings.
1.Cordisnotbroken.
2.Padgelisnotdamaged.
3.Electrodecordconnectionisnotbroken.
4.Unitisintactandworking.
5.Thereisnobatteryleakage.
DO NOT USE ON THESE INDIVIDUALS
● Pregnantwomen
● Donotuseonchildrenorinfantsbecause
thedevicehasnotbeenevaluatedforpediatric
use
● Keepoutofthereachofyoungchildren
becausetheelectrodecordcouldcause
strangulation
● Personsincapableofexpressingtheir
thoughtsorintentions.
● Personsincapableofoperatingtheunitby
themslelves.
● Usewithcautionifyouhaveatendencyto
bleedinternally,suchasfollowinganinjuryor
fracture.
● Ifyouhavesuspectedordiagnosedheart
disease,youshouldfollowprecautions
recommendedbyyourphysician.
● Ifyouhavesuspectedordignosedepilepsy,you
shouldfollowprecautionsrecommendedbyyour
physician

3
● Usecautionifstimulationisappliedoverthe
menstruatinguterus.
NEVER APPLY THE PADS TO THESE
BODY AREAS:
● Thehead,themouth,oranyareaofthe
face.
● Theneckoranyareaofthethroatbecause
thiscouldcauseseveremusclespasms
resultinginclosureoftheairway,difficultyin
breathing,oradverseeffectsonheartrhythmor
bloodpressure.
● Donotuseneartheheart,orongenitalarea.
● Bothsidesofthethoraxsimultaneously
(lateralorfrontandback),oracrossyourchest
becausetheintroductionofelectricalcurrent
maycauserhythmdisturbanceswhichcouldbe
lethal.
● Onthecalvesofbothlegsatthesametime
becausethismaycausecardiacdisturbance.
● Onthebottomofbothfeetatthesametime
becausethismaycausecardiacdisturbance.
Openwoundsorrashesoroverswollen,
red,infectedorinflamedareasorskin
eruptions(suchasvaricoseveins,phlebitis,
thrombophlebitisandthrombosis),orontopof
orclosetocancerouslesions,oroverareasof
skinthatlacknormalsensation.

4
DO NOT USE THIS UNIT DURING
THESE ACTIVITIES
● Wheninbathorshower;
● Whilesleeping;
● Whiledriving,operatingmachinery,orduring
anyactivityinwhichelectricalstimulationcan
putyouatriskofinjury.
PAIN MANAGEMENT WARNINGS
● Ifyouhavehadmedicalorphysical
treatmentforyourpain,consultwithyour
physicianbeforeusingthisunit.
● Ifyourpaindoesnotimprove,becomes
seriouschronicorsevere,orcontinuesformore
thanfiveyears,stopusingtheunitandconsult
withyourphysician.
● Themereexistenceofpainfunctionsasa
veryimportantwarningtellingusthatsomething
iswrong.Therefore,ifyousufferfromany
seriousillness,consultyourphysicianinorder
toconfirmthatitisadvisableforyoutousethis
PowerReliefunit.
PRECAUTIONS REGARDING THE PADS
● Donotmovethepadstoanotherlocation
whiletheunitison.
● Therapywon'tworkwithjustonepad.You
MUSTUSETWOPADSatthesametime.

5
● Makesurethecomponentsareconnected
wellandthepadsarefixedonthepartofthe
bodyyouwishtotreatorthetherapymaynot
beeffective.
● Padshouldnottouchanymetalobject,such
asbeltbuckle,necklace,orothermetalworn
underclothing.
● Donotoverlappadsorputpadsontopof
eachother.Itmayweakenorstoptherapy,or
theunitmaystopworking.Gelpadsmayalso
sticktogetherandcausegeltoberemoved
whenseparating.
● Donotsharepadswithanotherperson.This
maycauseaskinirritationorinfection.Pads
areintendedforusebyoneperson.
● Donotleavepadsattachedtotheskinafter
treatment.
● Donotbendorfoldbecausethegelmayget
damagedanditwon'tstickorfunctionproperly.
● Toavoiddamagetotheadhesivesurface
tothepads,putthepadsonlyontheskinor
ontheplasticpadholderprovidedtoavoid
damagetotheadhesivesurfaceofthepads.
● Alwaysplacecleanpadsinaccordancewith
illustrationsprovided.
● Donotapplyointmentoranysolventto
thepadsortoyourskinbecauseitwilldisrupt

6
thepadsfromfunctioningproperly.Theself-
adhesivepadswilladheretoyourskin.
HOW DOES IT WORK?
Scientifictheorysuggeststhatelectrical
stimulationtherapymayworkinseveralways:
1. Thegentleelectricalpulsemovesthroughthe
skintonearlynervestoblockorshutoutthepain
messagefromthesourceofthepaintoreaching
thebrain.
2. Thegentleelectricalpulseincreasesthe
productionofthebody'snaturalpainkiller,such
asendorphins.
3. Furthermore,itisthoughtthattheelectrical
stimulationimprovesbloodcirculationaswell.
Musclescontractandrelaxwiththeflowof
theelectricalstimulation.Withthereplated
contractingandrelaxing,thebloodflowsinand
outandthebloodcirculationimproved.
OPERATING INSTRUCTIONS
1. Connectthepadstothewirebysnapping
themon,thenremovetheprotectivefilm.
Note: addingafewdropsofwateronthepads
willincreasetheirlongevity.
2.Placepadswherethemassagesensations
aredesired. Plugintooneoftheportsonthe

7
device.Foradditionalreliefusethesecondport
andrepeatproceduretoputonanothertwo
pads.Makesurebothpadsontheskinandnot
overlapping.Makesureyourskinisfreefrom
anydirt,oilorlotion.
3. Turnthedeviceonbyslidingtheon/off
switchonthetopoftheunit.Theunitwillbenow
activated.
4.Pressthemodebuttontotrydifferentmodes.
Thenpressthecenterbuttontochoosethe
waveswithinthatselection.
Rememberthestrengthwilldefaulttothelowest
setting byeachmodeselection.
Note:Centerbuttoncanalsobeusedasalock
key.Pressandholditfor3secondstolockthe
screen,3secondsagaintounlockthescreen.
5. Onceyouselectamode,graduallyincrease
theintensitybypressingthe+button;decrease
itbypressing-button.
6.Recommendedapplicationis10-60minutes.
Increase10minutesbyeachsetting.Thetime
remainingisautomaticallycounteddown.Then
theunitwillautomaticallyturnoffaftertime
finish.

8
1
12
13
10
9
8
11
2
3
4
5
6
7
ILLUSTRATIONS OF THE DEVICE AND
ACCESSORIES
*TheAUVON®TENSMassageriswith6Massage
Modes,andtotally24Sub-modeChoices.

9
①Massage Time
②KneadMassage
③CuppingMassage
④DeepTissueMassage
⑤ModeSelection
⑥IntensityDecrease(-)
⑦Time Selection
⑧AcupunctureMassage
⑨TappingMassage
⑩ScrapeingMassage
⑪AdjustableIntensity/Strength(Include20Levels,
eachindicatorbarrepresents2strengthlevels)
⑫IntensityIncrease(+)
⑬Sub-modeChoicesSelectionunder6Massage
Modes
Mode Description:
TENS:Itisbeusedfortemporaryreliefofpain
associatedwithsoreandachingmusclesinthe
shoulder,waist,back,neck,upperextremities(arm),
andlowerextremities(leg)duetostrainfromexercise
ornormalhouseholdworkactivities.
PMS:Itisintendedtobeusedtostimulatehealthy
musclesinordertoimproveandfacilitatemuscle
performance.

10
Icon & Mode Name Description
1
Lateralpalm
kneading
(TENS)
Simulating
Tuinaisa
hands-onbody
treatment which
openstheflow
ofQithrough
themeridians
2
Flatpalm
kneading
(TENS)
3
Crosscutfist
kneading
(TENS)
4
Verticalfist
kneading
(TENS)
5Acupuncture
(TENS) Simulating
acupuncture
providesthe
same sensation
withoutneedles,
byutilizing
electronic
pulsesto
achieve the
sensationof
differentneedle
depths.
6Moxibustion
(TENS)
7
Acupuncture
kneading-1
(PMS)
8
Acupuncture
kneading-2
(TENS)

11
Icon & Mode Name Description
9
Rubbing
reduction
(PMS)
Stimulating
cupping,
relatively
constant
stimulation
contracts
muscles.
10 Tapping
(PMS)
11
Fibrillation
massag-1
(PMS)
12
Fibrillation
massage-2
(TENS)
13
Lifting-
pinching
manipulation
(TENS)
Simulating
tappingis
intendedto
producea
hardthumping
sensation that
massageyour
muscles,which
cangiveyou
aninvigorated
andrevitalized
feeling.
14
Vibrating
manipulation
(TENS)
15
16

12
Icon & Mode Name Description
17
Thai
massage
(PMS)
Simulating
Shiatsu,it
isatypeof
alternative
medicine
consistingof
fingerand
palmpressure,
stretches,and
other massage
techniques.
18
Shiatsu
(TENS)19
20
21 Scrapeing
(PMS)
Itisasimilar
feelinglike
scrapingthe
skinwitha
smoothedged
instrumentfor
relaxation.
22
Sensitive
parts
massage
mode
(TENS)
23
24

13
RECOMMEND MASSAGE POINTS
LOWERBACK
Modes
1,4,5,6,7,10,11,12,15,16
SCIATIC
Modes1,2,3,4,5,8
DELTOID
Modes2,3,,19,20,23,24
Attachonepadinfrontand
oneinbackofthemuscle.
UPPERARM&THIGH
Modes1,2,3,4,5,6,7,15,16
Attachbothpadsoneither
sideoftheareawithpain
WAIST/SHOULDER
Modes
1,4,5,6,7,10,11,12,14,15,16

14
KNEE
Modes1,2,3,4,5,6,7,10
Attachbothpadsabovethe
kneeoraboveandbelowoint
withpain.
CALF
Modes1,2,3,4,5,6,7,8,14,15
Attachbothpadsonthecalf/
legwhereyoufeelpain.(Do
notplaceelectrodepads
simultaneouslytothecalves
ofbothlegs.)
ANKLE/FOOT
Modes1,2,14,15
Attachpadsperthe
illustration,ontheleft/onthe
outsideofyourankle/foot
forpain.
Attachthepadsper
illustrationontheright/onthe
othersideofyourankle/foot.
*Theresistanceofskinvariesfromdifferent
locations.IfyouusethetwoportsofAUVONTENS
Massageratthesametimewhileintwodifferent
locations,therewillbeinconsistenciesinthe
strength.Thisisanormalphenomenon.

15
If this Happens...
Pad gel does not stick to skin.
Possible causes... Try this solution...
1.Haveyouremoved
thetransparentfilmfrom
thepad?
1.Peelofffilmonthe
adhesivesurfaceofpads.
2.Isthepadwet?orIs
yourskintoowet?
2.Drythepad.Ordrythe
skin.
3.Thepadgelmaybe
damaged. 3.Repalcethepad.
4.Istheretoomuch
haironyourskin?
4.Shavetheimmediate
areaforproperpad
adhesion.
5.Areyouusingpad
duringperspiring? 5.Drythepadstuckarea.
6.Havethepadsbeen
washedtoolongand/or
toofrequently?
6.Leavethepadinfreezer
forovernight.
7.Werethepads
storedunderhigh
temperature,high
humidity,ordirect
sunlight?
7.Replacebothpads.
TROUBLE SHOOTING

16
If this Happens...
Power cut off during use.
Possible causes... Try this solution...
1.Arethepowerweak? 1.Rechargeyourdevice.
2.Isthecordbroken? 2.Replacecord.
If this Happens...
The intensity is not felt or very weak intensity
level.
Possible causes... Try this solution...
1.Areyouusingonly
1pad?
1.Puttheotherpadonyour
skin.Youmustuseboth
padsfortherapytowork.
2.Haveyouremoved
thetransparentfilm
fromthepad?
2.Peelofffilmonthe
adhesivesurfaceofpads.
3.Arethepads
stackedtogetherordo
padsoverlap?
3.Checkplacementofpads.
Refertopadplacement
guide.
4.Isthecordproperly
connectdtotheunit?
4.Connectcordplug
correctlyintothejackat
bottomofthisunit
5.Istheintensity
settinggettingweak? 5.Pressthe“+”button.
6.Isthegeldamaged? 6.Replacepad.

17
If this Happens...
The skin turns red or the skin feels irritated.
Possible causes... Try this solution...
1.Istheadhesive
surfaceofpadsdirty
ordry?
1.Washadhesivesurface
ofpadssoftlywithyour
fingertipsforabout3
secondsunderslow
runningwater.
2.Istherapytimetoo
long?
2.Uselessthan25
minutes.
3.Arethetwopads
attachedproperlyto
thebody?
3.RefertothePad
PlacementGuideand
attachcorrectly.
4.Isthepadsurface
wornout?
4.Replacebothpadsat
thesametime.
If this Happens...
Only one side of the output can work properly.
Possible causes... Try this solution...
1.Oneofthelead
wiresdefective ContactAUVON
CustomerServieto
resolvetheconcern.
2.DefectiveTENSunit.

18
TENS Pads Holder
features
Wide
compatibility
forpatchesin
differentsizes.
Theshapeofsalientpointdesigned
speciallytolessendamagetothe
patches.
Highquality
ABSmaterialto
makesureyour
usesafely.

19
Instruction
Sticktheelectrodepatcheson
theholdertoavoidgettingdust.
Windthethreadaroundtheholder
foreasyuseasthepictureshown.
Step 1
Step 2
MAINTENANCE AND CARE
l.Whenyouarefinishedusingthedevice,turnitoff
andtakeoffthepads.Storetheunitinacool,dry
placeuntilnextuse.
