Avalla X-125 User manual

Dehumidiers
X-125 X-150 X-200
Read this manual carefully before use and keep it for future
reference. Failure to do so may result in injury, property
damage and may void the warranty.
avalla.com

02 En
Contents
02 Contents
03 Quick start guide: X-125 and X-150
• Parts guide
• Touch control panel
05 Quick start guide: X-200
• Parts guide
• Touch control panel
07 General operating instructions
• Empty water tank
• Continuous drainage
• Cleaning the air lter
08 Troubleshooting
• Storage
• Disposal
09 Health and safety
• General safety instructions
• Connection to the power supply

03En
Quick start guide: X-125 and X-150
Parts guide
Touch control panel
01. Air outlet
02. Air humidity indicator
03. Touch control panel
04. Air inlet
05. Drainage outlet
06. Water tank
07. Drainage hose
01 03
04
05
06
07
02

04 En
Power: Press to toggle power on/off.
Mode: Press to cycle between operation modes:
• Dehumidier: The unit will stop operation when it has
reached target humidity level and will automatically
resume if humidity rises again.
• Continuous dehumidier: The unit operates unrestricted by
target humidity levels.
• Clothes dryer: Operates at a lower fan speed.
• Aeration: The fan circulates air without dehumidifying
function.
Fan speed: Press to change fan speeds when using
dehumidier and aeration modes:
• Low speed
• High speed
Night mode: Press to toggle the display and lights on/off.
Timer: Pressing timer will cycle 0-24 hours and operates in two
ways:
• When power is off, pressing timer will delay the start-up
time of the machine.
• When power is on, pressing timer will set the time until the
unit shuts down.
Note: Press Timer, Mode or Power button to cancel a set timer.
Note: The timer will stop when the water tank is full and will
resume once emptied.
Humidity setting: Slide your nger to increase / decrease
the target humidity. The display will ash to show the desired
target percentage, then return to show the current humidity.
Defrost light: Illuminates when the unit goes in to self-
defrost mode. The dehumidier will go in to standby. Normal
operation will automatically resume when the compressor has
defrosted.
Tank full: This light shows you when the tank is full and needs
emptying.
Air humidity indicator:
• Blue: Low indoor humidity - below 50%
• Green: Medium indoor humidity - between 51-70%
• Red: High indoor humidity - above 71%
Humidity setting

05En
Quick start guide: X-200
Parts guide
Touch control panel
01. Touch control panel
02. Air humidity indicator
03. Air outlet
04. Air inlet
05. Drainage outlet
06. Water tank
07. Drainage hose
01 03
04
05
06
07
02

06 En
Power: Press to toggle power on/off.
• Power indicator illuminates when on and ashes when in
standby mode.
Mode: Press to cycle between operation modes:
• Dehumidier: The unit will stop operation when it has
reached target humidity level and will automatically
resume if humidity rises again.
• Clothes dryer: Operates at a lower fan speed.
• Aeration: The fan circulates air without dehumidifying
function.
Fan speed: Press to change fan speeds when using
dehumidier and aeration modes:
• Low speed
• High speed
Timer: Adjusts the shut down timer for the unit.
• Press timer button followed by plus / minus buttons to
increase / decrease timer. The timer icon will illuminate.
• Press timer button when display is ashing to disable timer
mode.
Note: The timer will stop when the water tank is full and will
resume once emptied.
Humidity setting:
• Press either plus or minus button to set the target humidity
level. The display will ash to show the desired target
percentage, then return to show the current humidity
which is indicated when the percentage light is on.
• When the room reaches target humidity, the icon will
illuminate.
• Press and hold the plus button for 3 seconds to display
current room temperature.
Defrost light: Illuminates when the unit goes in to self-
defrost mode. The dehumidier will go in to standby. Normal
operation will resume when the compressor has defrosted.
Tank full: This light shows you when the tank is full and needs
emptying.
Air humidity indicator:
• Blue: Low indoor humidity - below 50%
• Green: Medium indoor humidity - between 51-70%
• Red: High indoor humidity - above 71%

07En
General operating instructions
Empty water tank
Continuous drainage
Cleaning the air lter
01. Switch off the
power to the
unit.
02. Remove the
water tank
from the back
and drain.
03. Return the
water tank
and continue
operation.
01. Make sure
power is off.
02. Remove the air
intake cover.
03. Remove the air
lter.
04. Vacuum with
a soft head
attachment.
05. Replace the air
lter then air
intake cover.
The unit can operate for prolonged periods,
bypassing the water tank.
Note: the water tank must be installed or the
machine will not run.
Caution: Automatic ‘water tank full’ shut
down is disabled when using continuous
drainage.
01. Make sure the power is off.
02. Attach the drainage hose to the drainage
outlet.
03. Make sure the end of the drainage hose
leads to a suitable drain where overow is
not a risk.
X-125 and X-150
X-125 and X-150
X-200
X-200
i Check and clean the air lter regularly to maintain maximum air ow .
i The Dehumidier will only operate in temperatures between 5-32oc

08 En
Troubleshooting
Issue Cause Solution
Unit switches off Automatic
defrosting
Wait for the
defrosting mode to
end.
Defrosting mode
happens frequently
Room temperature
too low
If room is below
18ºC the unit will
require more
frequent defrosting
to maintain correct
operation.
Room humidity
remains high Room too large
Make sure the
room size matches
the operational
requirements of the
dehumidier. Ensure
doors and windows
are closed.
Clothes not drying Room temperature
too low
Make sure the room
is at a temperature
where the unit can
operate correctly
(above 18ºC)
Buzzer sound Water tank full Empty water tank
Disposal
Storage
Do not dispose of electrical appliances in general waste.
Contact your local government for information regarding the
disposal options available. If electrical appliances are disposed
of in landlls or dumps, hazardous substances can leak into the
groundwater and cause a hazard for wildlife and human health.
• If the tank is dirty, wash with warm water only, do not use
chemicals.
• If the unit will not be used for an extended period, completely
drain any water and dry the unit out by leaving the drainage
cap off. Dry the water tank with a cloth or towel. Store in a well
ventilated, dry area.

09En
Health and safety
General safety instructions
Symbols from the unit
This unit uses
a ammable
refrigerant.
If the refrigerant leaks
and encounters re
or heat, it may create
harmful gas and there
is risk of re.
Read the user manual
carefully before
operation.
Service personnel are
required to carefully
read the user manual.
Warning: Do not operate near combustible or explosive materials, heat sources, or
any objects that may block air inlet and outlet. Keep the air inlet and outlet free of
obstacles. Only use in rooms that exceed 4m² in size.
Warning: Do not touch the air inlet or the evaporator surface, located behind the
lter. Doing so could cause injury. Always ensure the lter is completely dry before
reinstalling into the unit.
The following must always be observed for safety
• This appliance is not intended to be used by children. Persons with lack of
experience or knowledge, reduced physical, sensory, or mental capabilities,
can use this appliance if they have been given supervision or instruction
concerning use of the appliance in a safe way and understand the hazards
involved.
• The unit is designed only for use with R-290 propane gas. The refrigerant loop
is sealed, only qualied technicians should perform servicing.
• Never discharge the refrigerant into the atmosphere.
• R-290 propane gas is ammable and heavier than air, it collects rst in low
areas, it can be circulated or dispersed by fans.
• If propane gas is present or even suspected, do not allow untrained personnel
to attempt to nd the cause. R-290 has no odour, the lack of gas smell does
not indicate a lack of escaped gas. Do not allow to get in eyes, on skin, or on
clothing. Do not breathe the vapours or gas.
• •If a leak is detected, immediately evacuate all persons from the area, ventilate
and contact the local re department to advise them that a propane leak has
occurred. Do not let any persons back into the area until the qualied service
technician has advised that it is safe to return.
• Component parts must only be replaced with identical repair parts.
• Any person working on, or breaking into a refrigerant circuit, should hold a
current valid certicate from an industry-accredited assessment authority,
which authorises their competence to handle refrigerants safely in accordance
with an industry, recognised assessment specication.
• If the supply cord is damaged, it must be replaced by the manufacturer, its
service agent, or similarly qualied persons.
• The appliance must be disconnected from its power source during servicing,
cleaning or when not in use. Do not use chemicals to clean the appliance.
Class I
Construction
(Earthed)

10 En
• Always operate the unit from a grounded power outlet of equal voltage,
frequency and rating as indicated on the product identication plate.
• Do not operate with wet hands. Keep the unit away from sources or water,
moisture, or any other liquids.
• Do not leave the unit running unattended. Do not unplug or tilt the unit while
it is in operation.
• Do not unplug by pulling on the power cord.
• Do not use an extension cord.
• Do not put objects on the unit, climb or sit on the unit.
• Do not insert ngers or other objects into the air outlet.
• Do not operate the unit if it is dropped, damaged or showing signs of product
malfunction.
• The unit must be installed in accordance with national wiring regulations.
• Do not use means to accelerate the defrosting process.
• The appliance must be stored in a manner to prevent mechanical damage.
• Do not piece or burn, even after use.
• Compliance with national gas regulations must be observed.
• Do not place in direct sunlight or near objects that may cause mechanical
vibration or shock.
• Position the unit on an even / at surface, away from excessive dust, and always
maintain the unit to ensure that excessive dust does not accumulate anywhere
on the unit.
Failure to abide by any of these warnings could result in a re, explosion,
electric shock, injury, death, and property damage.
Servicing Safety Precautions
Please carefully follow this guidance when undertaking any servicing on
this appliance. Any servicing must be carried out by a suitably qualied and
registered individual.
Prior to beginning work, safety checks are necessary to ensure that the risk of
ignition is minimized. For repair to the refrigerating system, all of the following
precautions must be complied with prior to conducting work.
Work Procedure
Work must be undertaken under a controlled procedure to minimize the risk of a
ammable gas or vapour being present while the work is being performed.
General Work Area
All maintenance staff and others working in the local area must be instructed on
the nature of work being carried out. Work in conned spaces must be avoided.
The area around the workspace must be sectioned off. Ensure that the conditions
within the area have been made safe by control of ammable material.
Checking for Presence of Refrigerant
The area must be checked with an appropriate refrigerant detector prior to
and during work, to ensure the technician is aware of potentially ammable
atmospheres. Ensure that the leak detection equipment being used is suitable for
use with ammable refrigerants, e.g. no sparking, adequately sealed or intrinsically
safe.
Presence of Fire Extinguisher
If any hot work is to be conducted on the refrigeration equipment or any
associated parts, appropriate re extinguishing equipment must be available to
hand. Have a dry powder or CO2 re extinguisher adjacent to the charging area.
No Ignition Sources
No person carrying out work in relation to a refrigeration system which involves
exposing any pipe work that contains or has contained ammable refrigerant

11En
must use any sources of ignition in such a manner that it may lead to the risk of
re or explosion. All possible ignition sources, including cigarette smoking, should
be kept sufciently far away from the site of installation, repairing, removing and
disposal, during which ammable refrigerant can possibly be released to the
surrounding space. Prior to work taking place, the area around the equipment is
to be surveyed to make sure that there are no ammable hazards or ignition risks.
“No Smoking” signs must be displayed.
Ventilated Area
Ensure that the area is in the open or that it is adequately ventilated before
breaking into the system or conducting any hot work. A degree of ventilation must
continue during the period that the work is carried out. The ventilation should
safely disperse any released refrigerant and preferably expel it externally into the
atmosphere.
Checks to the Refrigeration Equipment
Where electrical components are being changed, they must be t for the purpose
and to the correct specication. At all times the manufacturer’s maintenance
and service guidelines must be followed. If in doubt consult the manufacturer’s
technical department for assistance. The following checks must be applied to
installations using ammable refrigerants:
• The charge size is in accordance with the room size within which the
refrigerant containing parts are installed.
• The ventilation machinery and outlets are operating adequately and are not
obstructed.
• If an indirect refrigerating circuit is being used, the secondary circuit must be
checked for the presence of refrigerant.
• Marking to the equipment continues to be visible and legible. Markings and
signs that are illegible must be corrected.
• Refrigeration pipe or components are installed in a position where they
are unlikely to be exposed to any substance which may corrode refrigerant
containing components, unless the components are constructed of materials
which are inherently resistant to being corroded or are suitably protected
against being corroded.
Checks to Electrical Devices
Repair and maintenance to electrical components must include initial safety
checks and component inspection procedures. If a fault exists that could
compromise safety, then no electrical supply must be connected to the circuit until
it is satisfactorily dealt with. If the fault cannot be corrected immediately but it is
necessary to continue operation, an adequate temporary solution must be used.
This must be reported to the owner of the equipment, so all parties are advised.
Initial safety checks must include:
• Those capacitors are discharged: this must be done in a safe manner to avoid
possibility of sparking.
• That no live electrical components or wiring are exposed while charging,
recovering or purging the system.
• That there is continuity of earth bonding.

12 En
Avalla Ltd. Unit A 73, Common Road, Chandler’s Ford,
Eastleigh, SO53 1HE. United Kingdom
Company no. 13477899
[e-mail]
Caution: Risk of electric shock. Do not open.
• This appliance is supplied with a moulded 3 pin mains plug for your safety.
The value of the fuse tted is marked on the pin face of the plug. Should the
fuse need replacing, ensure the substitute is of the correct rating, approved to
BS1362 and ASTA or BSI Kite marked.
• ASTA: BSI:
• The fuse cover is removable with a small plain slot screwdriver. Ensure the fuse
cover is replaced before attempting to connect the plug to an electrical outlet.
If the cover is missing, a replacement must be obtained or the plug replaced
with a suitable type.
• If a replacement plug is to be tted this must be carried out by a qualied
electrician.
• The damaged or incomplete plug, when cut from the cable should be disabled
to prevent connection to a live electrical outlet.
• This appliance is Class I and is designed for connection to a power supply
matching that detailed on the rating label and compatible with the plug tted.
• If an extension lead is required, use an approved and compatible lead rated for
this appliance. Follow all the instructions supplied with the extension lead.
• Class I :Products with this symbol must have metal parts connected to
electrical earth by an earth conductor. The basic requirement is that no single
failure can result in dangerous voltage becoming exposed so that it might
cause electric shock.
Important: If using an extension lead, follow the instructions that came with your
lead regarding maximum load while cable is wound. If in doubt, ensure that the
entire cable is unwound. Using a coiled extension lead will generate heat which
could melt the lead and cause a re.
Failure to abide by any of these warnings could result in a re, explosion,
electric shock, injury, death, and property damage.
Connection to the power supply
