Avalue Technology ECM-945GSE User manual

Part No. E2017381602R
ECM-945GSE
Intel® Atom™ processor N270 3.5” Micro Module with Intel®
945GSE + ICH7-M Chipset
Quick Installation Guide
3rd Ed – 06 November 2009

ECM-945GSE Quick Installation Guide
2 ECM-945GSE Quick Installation Guide
1. Getting Started
1.1 Safety Precautions
Warning!
Always completely disconnect the power cord from your
chassis whenever you work with the hardware. Do not
make connections while the power is on. Sensitive
electronic components can be damaged by sudden power
surges. Only experienced electronics personnel should
open the PC chassis.
Caution!
Always ground yourself to remove any static charge before
touching the CPU card. Modern electronic devices are very
sensitive to static electric charges. As a safety precaution,
use a grounding wrist strap at all times. Place all electronic
components in a static-dissipative surface or static-shielded
bag when they are not in the chassis.
Always note that improper disassembling action could cause damage to the
motherboard. We suggest not removing the heatsink without correct
instructions in any circumstance. If you really have to do this, please contact
us for further support.
1.2 Packing List
Before you begin installing your single board, please make sure that the
following materials have been shipped:
z1 x Intel® 945GSE Micro Module
z1 x Quick Installation Guide for ECM-945GSE
z1 x AUX-021 daughter board
z1 x DVD-ROM contains the followings:
—User’s Manual (this manual in PDF file)
—Ethernet driver and utilities
—VGA drivers and utilities
—Audio drivers and utilities
z1 x Cable set contains the followings:
—1 x IDE HDD cable (44-pin, pitch 2.0mm)
—1 x Audio cable (10pin, 2.0mm pitch)
—1 x USB cable (10P/2.54mm-10P/2.0mm)
—1 x Serial ATA cables (7-pin, standard)
—1 x PS/2 Keyboard & mouse Y cable

Quick Installation Guide
ECM-945GSE Quick Installation Guide
3
2. Hardware
Configuration

ECM-945GSE Quick Installation Guide
4 ECM-945GSE Quick Installation Guide
2.1 Product Overview

Quick Installation Guide
ECM-945GSE Quick Installation Guide
5
2.2 Jumper and Connector List
You can configure your board to match the needs of your application by setting jumpers. A
jumper is the simplest kind of electric switch.
It consists of two metal pins and a small metal clip (often protected by a plastic cover) that
slides over the pins to connect them. To “close” a jumper you connect the pins with the clip.
To “open” a jumper you remove the clip. Sometimes a jumper will have three pins, labeled 1,
2, and 3. In this case, you would connect either two pins.
The jumper settings are schematically depicted in this manual as follows:
A pair of needle-nose pliers may be helpful when working with jumpers.
Connectors on the board are linked to external devices such as hard disk drives, a
keyboard, or floppy drives. In addition, the board has a number of jumpers that allow you to
configure your system to suit your application.
If you have any doubts about the best hardware configuration for your application, contact
your local distributor or sales representative before you make any changes.
The following tables list the function of each of the board’s jumpers and connectors.
Jumpers
Label Function Note
JBAT1 Clear CMOS 3 x 1 header, pitch 2.54mm
JCF CF mode select 3 x 1 header, pitch 2.54mm
PWR_MSEL AT/ATX mode select 2 x 1 header, pitch 2.0mm
PWR_5VSEL Input Power type select 3 x 1 header, pitch 2.54mm

ECM-945GSE Quick Installation Guide
6 ECM-945GSE Quick Installation Guide
Connectors
Label Function Note
CFCARD Compact Flash card connector Type I/II x 1
COM1 Serial port 1 connector D-sub 9-pin, male
CPU_FAN CPU fan connector 3 x 1 wafer, pitch 2.54mm
IDE Primary IDE connector 22x2 header, pitch 2.0mm
J422/485 Serial port 2 in RS422/485 mode 3 x 2 header, pitch 2.0mm
JAUDIO Audio connector 5 x 2 header, pitch 2.0mm
JBKL LCD Inverter Connector 5 x 1 wafer, pitch 2.0mm
JCOM2 Serial port 2 in RS232 mode 5 x 2 header, pitch 2.0mm
JDIO General purpose I/O connector 10 x 2 header, pitch 2.0mm
JDVI DVI connector
JKB/MS PS/2 keyboard & mouse connector 4 x 2 header, pitch 2.0mm
JLPC (Reserved for debug) 5 x 2 header, pitch 2.0mm
JLVDS LVDS connector
JPWRBTN Power button connector
JSPI (Revered for BIOS programming)
JTV TV connector 3 x 2 header, pitch 2.0mm
JUSB2 USB connector 2 & 3 5 x 2 header, pitch 2.0mm
JUSB3 USB connector 4 & 5 5 x 2 header, pitch 2.0mm
JVR LCD backlight brightness adjustment 3 x 1 header, pitch 2.54mm
LED1 HDD & Power indicator
PWR_SB 5VSB connector in ATX 3 x 1 wafer, pitch 2.54mm
PWRCON Power connector 2 x 2 header, pitch 2.0mm
RSTBTN Reset button
SATA1 Serial ATA connector 1
SATA2 Serial ATA connector 2
USB1 USB connector 0 & 1
(Co-lay with KB/MS )
VGA VGA connector D-sub 15-pin, female

Quick Installation Guide
ECM-945GSE Quick Installation Guide
7
2.3 Setting Jumpers & Connectors
2.3.1 AT/ATX mode select (PWR_MSEL)
* Default
PWR_MSEL
AT*
ATX
JPWRBTN
Signal PIN
GND 2
PWR_BT 1
Note: JPWRBTN is available in ATX
mode.
PWR_M
S
EL
JPWRBTN

ECM-945GSE Quick Installation Guide
8 ECM-945GSE Quick Installation Guide
2.3.2 Input Power type select (PWR_5VSEL)
* Default
AT Type *
ATX Type
2.3.3 5VSB Power connector in ATX Type (PWR_SB)
PIN Signal
1PSON#
2GND
35VSB
Note: Connect PWR_SB with cable in
ATX type power-input.

Quick Installation Guide
ECM-945GSE Quick Installation Guide
9
2.3.3.1 Signal Description –AT/ATX mode & Input power type
Input power type Power-ON Mode Description
AT Mode
(PWR_MSEL)
Use AT type power input, and set
the board in AT mode.
AT type
(PWR_5VSEL)
ATX Mode
(PWR_MSEL)
Use AT type power input, and set
the board in ATX mode.
AT Mode
(PWR_MSEL)
Use ATX type power input, and set
the board in AT mode.
ATX type
(PWR_5VSEL)
ATX Mode
(PWR_MSEL)
Use ATX type power input, and set
the board in ATX mode.

ECM-945GSE Quick Installation Guide
10 ECM-945GSE Quick Installation Guide
2.3.4 Clear CMOS (JBAT)
* Default
Protect*
Clear CMOS
2.3.5 CF Mode select (JCF)
* Default
Master*
Slave

Quick Installation Guide
ECM-945GSE Quick Installation Guide
11
2.3.6 Audio connector (JAUDIO)
Signal PIN PIN Signal
LIN-OUT_R 12 LIN-OUT-L
GND 3 4 GND
LIN-IN-R 56 LIN-IN-L
MIC_IN 7 8 MIC_REF
NC 910 NC
2.3.7 CPU Fan connector (CPU_FAN)
Signal PIN
GND 1
+12V 2
FAN_TAC1 3

ECM-945GSE Quick Installation Guide
12 ECM-945GSE Quick Installation Guide
2.3.8 General purpose I/O connector (JDIO1)
Signal PIN PIN Signal
DO_GP20 1 2 DI_GP30
DO_GP21 3 4 DI_GP31
DO_GP22 5 6 DI_GP32
DO_GP23 7 8 DI_GP33
DO_GP24 9 10 DI_GP34
DO_GP25 11 12 DI_GP35
DO_GP26 13 14 DI_GP36
DO_GP27 15 16 DI_GP37
SMB_CLK 17 18 SMB_DATA
GND 19 20 +5V
2.3.9 Serial port 2 connector (JCOM2)
Signal PIN PIN Signal
DCD 1 2 RxD
TxD 3 4 DTR
GND 5 6 DSR
RTS 7 8 CTS
RI 9 10 NC

Quick Installation Guide
ECM-945GSE Quick Installation Guide
13
2.3.10 Serial Port 2 in RS-422/485 (J422/485)
Note:
J422/485 is available after modifying the mode
of COM2 in BIOS setting.
Signal PIN PIN Signal
TxD- 1 2 RxD-
TxD+ 3 4 RxD+
+5V 5 6 GND
2.3.11 TV connector (JTV)
Signal PIN PIN Signal
GND 6 5 GND
C 4 3 Y
GND 2 1 CVBS

ECM-945GSE Quick Installation Guide
14 ECM-945GSE Quick Installation Guide
2.3.12 Power Connector (PWRCON)
Signal PIN PIN Signal
VIN 4 1 GND
VIN 3 2 GND
2.3.13 LCD backlight brightness adjustment connector (JVR)
Signal PIN
GND 3
VR 2
+5V 1
Variation Resistor
(Recommended: 4.7KΩ, >1/16W)

Quick Installation Guide
ECM-945GSE Quick Installation Guide
15
2.3.14 LCD Inverter Connector (JBKL)
Signal PIN
+5V 5
VR 4
ENBKL 3
GND 2
+12V 1
Note:
For inverters with adjustable Backlight function, it is possible to control the LCD
brightness through the VR signal controlled by JVR. Please see the JVR section
for detailed circuitry information.
2.3.14.1 Signal Description – LCD Inverter Connector (JBKL)
Signal Signal Description
VR Vadj = 0.75V ~ 4.25V (Recommended: 4.7KΩ, >1/16W)
ENBKL LCD backlight ON/OFF control signal

ECM-945GSE Quick Installation Guide
16 ECM-945GSE Quick Installation Guide
2.3.15 USB Connector 2, 3, 4 &5 (JUSB2, JUSB3)
Signal PIN PIN Signal
+5V 1 2 GND
D2-/D4- 3 4 GND
D2+/D4+ 5 6 D3+/D5+
GND 7 8 D3-/D5-
GND 9 10 +5V
JUSB2 JUSB3

Quick Installation Guide
ECM-945GSE Quick Installation Guide
17
2.3.16 LVDS Connector (JLVDS)
18-bit LVDS
Signal PIN PIN Signal
+5V 2 1 +3.3V
+5V 4 3 +3.3V
I2C_DAT1 6 5 I2C_CLK1
GND 8 7 GND
Txout0 10 9Txout1
Txout0# 12 11 Txout1#
GND 14 13 GND
Txout2 16 15 NC
Txout2# 18 17 NC
GND 20 19 GND
E_Txout0 22 21 E_Txout1
E_Txout0# 24 23 E_Txout1#
GND 26 25 GND
E_Txout22827 NC
E_Txout2# 30 29 NC
GND 32 31 GND
Txclk 34 33 E_Txclk
Txclk# 36 35 E_Txclk#
GND 38 37 GND
+12V 40 39 +12V
24-bit LVDS
Signal PIN PIN Signal
+5V 2 1+3.3V
+5V 4 3 +3.3V
I2C_DAT1 6 5 I2C_CLK1
GND 8 7 GND
Txout0 10 9Txout1
Txout0# 12 11 Txout1#
GND 14 13 GND
Txout2 16 15 Txout3
Txout2# 18 17 Txout3#
GND 20 19 GND
E_Txout0 22 21 E_Txout1
E_Txout0# 24 23 E_Txout1#
GND 26 25 GND
E_Txout2 28 27 E_Txout3
E_Txout2# 30 29 E_Txout3#
GND 32 31 GND
Txclk 34 33 E_Txclk
Txclk# 36 35 E_Txclk#
GND 38 37 GND
+12V 40 39 +12V

ECM-945GSE Quick Installation Guide
18 ECM-945GSE Quick Installation Guide
2.3.17 DVI connector (JDVI)
Signal PIN PIN Signal
+5V 21 TDC0#
GND 4 3 TDC0
NC 65 NC
NC 8 7 NC
HPDET 10 9 TDC1#
DDC_DAT 12 11 TDC1
DDC_CLK 14 13 GND
GND 16 15 GND
TLC# 18 17 TDC2#
TLC 20 19 TDC2
2.3.18 Keyboard & mouse connector (JKB/MS)
Signal PIN PIN Signal
7 NC
MCK 6 5 MDT
VDD 4 3 GND
KCK 2 1 KDT

Quick Installation Guide
ECM-945GSE Quick Installation Guide
19
2.4 Audio / USB Daughter Board User’s Guide
2.4.1 Jumper and Connector Layout
2.4.2 Jumper and Connector List
Jumpers
Label Function Note
JP6
Line out / Speaker out select
(The speaker out function is only
available in combine used of main board)
1-3, 2-4 Speaker out
3-5, 4-6 Line out (Default)
Connectors
Label Function Note
CN1, CN2 USB connector
CN3 TV out connector (Optional) RCA connector
CN4 Line out connector Phone Jack
CN5 Line in connector Phone Jack
CN6 Mic in connector Phone Jack
JP1 2.54mm USB connector 5 x 2 header, pitch 2.54mm
JP2 2.54mm USB connector 5 x 2 header, pitch 2.54mm
JP3 Audio connector 5 x 2 header, pitch 2.0mm
JP4 2.0mm USB connector 5 x 2 header, pitch 2.0mm
JP5 2.0mm USB connector 5 x 2 header, pitch 2.0mm
JP7 TV / Audio connector (Optional) 8 x 2 header, pitch 2.54mm
JP8 TV out connector

ECM-945GSE Quick Installation Guide
20 ECM-945GSE Quick Installation Guide
2.4.3 Setting Jumper and Connector
Line out/Speaker out Select(JP6) 2.54mm USB Connector (JP1)
Line Out*
*Default
Speaker Out
Signal PIN PIN Signal
SPR1 1 2 SPL1
OUT_R 3 4 OUT_L
OUTR 5 6 OUTL
TV-out Connector (JP8)
Signal PIN PIN Signal
COMP 1 2 TVGND
Signal PIN PIN Signal
+5V 1 2 GND
D1- 3 4 GND
D1+ 5 6 D2+
GND 7 8 D2-
GND 9 10 +5V
Note: Wrong USB cable
configuration with your USB devices might
cause your USB devices damaged.
2.54mm USB Connector (JP2) Audio Connector (JP3)
Signal PIN PIN Signal
+5V 1 2 GND
D3- 3 4 GND
D3+ 5 6 D4+
GND 7 8 D4-
GND 9 10 +5V
2CH
Signal PIN PIN Signal
Line out R 1 2 Line out L
GND 3 4 GND
Line in R 5 6 Line in L
Mic In 7 8 Mic Bais
SPK R 9 10 SPK L
Note:
Select 2 CH or 5.1CH by driver AP.
5.1 CH
Signal PIN PIN Signal
Line out R 1 2 Line out L
GND 3 4 GND
Surround R 5 6 Surround L
Center 7 8 Subwoofer-out
SPK R 9 10 SPK L
2.0mm USB Connector
(JP4)
2.0mm USB Connector (JP5) TV / Audio Connector (JP7)
ignal PIN PIN Signal
+5V 1 2 GND
D3- 3 4 GND
D3+ 5 6 D4+
GND 7 8 D4-
GND 9 10 +5V
Signal PIN PIN Signal
+5V 1 2 GND
D1- 3 4 GND
D1+ 5 6 D2+
GND 7 8 D2-
GND 910 +5V
Signal PIN PIN Signal
Mic In 1 2 Mic Bais
GND 3 4 GND
Line out L 5 6 Line out R
SPK L 7 8 SPK R
Line in L 9 10 Line in R
GND 11 12 NC
TVGND 13 14 NC
TVGND 15 16 COMP
