Avante ERGOADJUST DELUX User manual

ERGOADJUST DELUX
ADJUSTABLE BED MANUAL

TABLE OF CONTENTS
Safety ………...……………………………….….….… 1
Introduction ………………...………………..………. 3
Care ……………………………………………...... 4
Features ...…………..………………..………..…….....5
Unpacking Your Base ………………….…..…........... 6
Attaching Castors ...……………………...……...…… 7
Attaching Mattress Bars ……………………………… 8
Hand Control Overview…………………..….…........ 9
Troubleshooting ..………………………..…………..12
Product Guarantee ………..………………….....……14
Notes …………………………………………………..16

SAFETY
ATTENTION: Important Safety Disclaimers
Read all instructions before using
your adjustable base. Save these instructions.
WARNING
Always unplug the base from electrical outlet before servicing any part of
the base. Unplug the base before cleaning. To safely disconnect, ensure
TO REDUCE THE RISK OF SHOCK, FIRE OR INJURY: For optimal safety and
operation, plug the bed base into a surge protector (not included). Ensure to always un-
plug the base from the electrical outlet before servicing or cleaning any part of the base.
Keep the power cord away from heated surfaces. Discontinue use of the bed base and
contact a qualified service centre if it has a damaged cord or plug, if it is not working
properly, or it has been dropped into water. Only use this bed base for its intended use
as described in this manual. Do not use accessories/ attachments that are not recom-
mended by the manufacturer. Improper connection of the equipment can result in the
risk of electrical shock, electrical fire or fault if the plug does not fit your outlet. Contact
a qualified electrician to install a suitable outlet.
PETS AND CHILDREN: Dispose of all packing materials immediately after opening
as it may pose a risk to small children and pets. To avoid injury, it is not advised to al-
low children and small pets to play under the bed. Children should not operate the bed
base without adult supervision.
Page 1

SAFETY
• To reduce the risk of falls on height adjustable bases, the base should
always be in its lowest position for sleeping and resting. The high posi-
tion should only be used for carer’s access to the user, ease of entry
and exit of bed for the user and ease of making the bed.
• A minimum of 2 able and fit adults should be used when lifting or
moving the beds. It is recommended to use trolleys or other lifting/
moving devices where possible.
• Careless use of naked flames, cigarettes or other heat sources could set
fire to this product.
• Do not operate whilst any person is under the base whilst raising/
lowering or adjusting the bed.
• Care should be taken that no body parts are in or near the adjustable
frame while operating.
• Ensure the cabling of the bed is free from the mechanism.
• Don’t run over electrical cables when moving the bed.
• Do not manipulate or conduct electrical maintenance on the motors or
any of the beds electrical components or cables. Any electrical work
must be facilitated by a qualified tradesperson.
WARNING
• Stay clear of moving parts while in motion.
• Before adjusting, make sure children and pets are clear of moving
parts and are not under bed base.
• Do not allow children to operate bed base without adult supervision
Page 2

INTRODUCTION
Congratulations on the purchase of your new
ERGOADJUST DELUX BED!
The ErgoAdjust Delux is Avante’s new advanced adjustable bed that embod-
ies function and comfort. The bed is equipped with full package of function-
alities for mobility and designed to maximize your user experience. ErgoAd-
just Delux is the optimal choice for anyone who seeks independent mobility
and better sleeping experience.
Key Features:
• Hi-Lo Lift Function
• Vibration Massage
• Head Tilt Function
• Under Bed Lighting
• USB Charging Ports
• Wireless Hand Control
• Customizable Preset Positions
• 180kg weight rated
Page 3

CARE
GENERAL CARE INSTRUCTIONS
• Legs and castors should be checked for tightness regularly.
• When transporting - do not over tighten when restraining.
• Do not exceed the maximum weight limit for this bed (180kg
total).
• Always lock castors other than when moving or relocating
the bed.
• Do not jump on or abuse the bed.
• Do not constantly push the buttons on the controller when
not for intended use.
• Use the controller only for adjusting the bed frame for in-
tended use - not for entertainment.
• Lubricate moving parts using a non-corrosive lubricant every
6 months or as required. We recommend the use of INOX.
• Beds should be positioned with clearance from walls and ob-
jects so as not to cause damage.
• Do not rock or tilt the frame.
Page 4

FEATURES
PRODUCT FEATURES
• Stylish modern living design
• Adjustable head and foot parts
• Head tilt function supporting neck
muscles
• Massage Function
• Wired multifunction remote control
• USB charging ports
• Underbed lighting
FRAME DESIGN FEATURES
• Whisper quiet, low voltage, DC lift
system provides smooth and efficient
operation.
• Long lasting steel support.
• Superior steel foundation.
• Powder coated steel.
• Designed to lift up to 180kg total
weigh
• Gravity fall motors.
• Can suit any adjustable bed mattress.
• Wall aligned technology.
Raised Position with
Head and Foot Up
Head Tilt Function
Page 5

UNPACKING YOUR BASE
Page 6
1. Open the carton box & remove the protective plastic.
2. Locate box of parts, remove
zip ties.
3. Locate hand controller,
remove zip tie and protective
plastic.

ASSEMBLING
(CASTORS)
Page 7
1. Turn your Ergo on its side.
2. Locate your four castors from the box of parts; before screwing in,
ensure all castors are in a locked position.
3. Screw in your castors into each hole in the corners of the bed as
shown below.

ASSEMBLING
(MATTRESS BARS)
Page 8
1. Turn your Ergo back to a flat position, with castors now attached.
2. Locate the mattress bars; attach each mattress bar as shown below.

HAND CONTROL OVERVIEW
To turn on hand control, firstly ensure the remote is plugged into the con-
trol box underneath the bed. The remote should look like the one to the
right. The remote keys have backlight for assisting operation at night.
Please note—to transfer between saved positions, return the bed to
FLAT position FIRST, before selecting next position.
Pairing Button
Zero Gravity
Position
Anti-Snore
Position
Memory Position
Underbed Light
Head Up Head Down
Foot Up Foot Down
Flat Position
Raise Bed Height
Lower Bed Height
Massage Time
Switch
Head Massage
Foot Massage
Head Tilt Up Head Tilt Down
Turn Massage
On and Off
Page 9
Massage Type
Switch ERGOADJUST DELUX
HAND CONTROL

STEPS OF REPROGRAMMING
PRESET POSITION
1. Adjust the bed into desired posi-
tion.
2. Choose the pre-set position that
you would like to change ( Zero
Gravity or Anti Snore).
3. Press and hold the chosen pre-set
button and the flat position button
simultaneously for 5 seconds, until
the backlight start flashing, then
the current position of the bed is
now saved as a custom position un-
der the pre-set button.
SET UP MEMORY POSITION
1. Adjust the bed into desired position.
2. Press and hold “Memory” button and the flat position button simultane-
ously for 5 seconds, until the backlight start flashing, then the current po-
sition of the bed is now saved as a Memory position
PRESS AND HOLD
TO CHANGE PRESET POSITIONS
PRESS AND
HOLD
TO SET UP
MEMORY
POSITION
ERGOADJUST DELUX
HAND CONTROL
REPROGRAMMING HAND
CONTROL POSITIONS
Page 10

SYNCING
BASES
To Sync TWO bases to ONE remote
Requires Link Cable
1. Insert link cable end into each control box on the separate bases you wish to sync.
2. Once completed, either remote will then operate both bases.
To Sync ONE base ONLY
1. Fit 2 AAA Batteries to the hand con-
trol.
2. Connect power to the transformer.
3. Pressing the Pair button on the control
box twice quickly( the blue pairing light
will turn on).
4. Press and hold the pair button on re-
mote control for 3 seconds, the back-
light will start flashing. The blue pairing
LED light on the control box will turn
green to indicate that pairing is com-
plete. If not successful , repeat the above
steps.
PRESS AND HOLD
ERGOADJUST DELUX
HAND CONTROL
Page 11

TROUBLESHOOTING
Below are a list of possible problems & their solutions should the ad-
justable base fail to operate properly
PROBLEMS SOLUTIONS
The base does not respond when
the remote is used.
Remote LED illuminates and
appears to be normal.
Perform any or all of the following:
• Check that the power cord is plugged
into a working & grounded electrical
outlet.
• Check that the light on the transformer
is on.
• Check the home’s circuit breaker & fus-
es.
• Unplug the power cord from the outlet.
After one minute, plug it back in . Press
any button on the remote.
The remote does not work
or does not light up.
• Check the remote LED light is lighting
up when pressed. If not, please replace
2*1.5V AAA batteries.
Base stutters while in motion. • Clear any clutter or obstructions under
& around the adjustable base. Radio fre-
quency interference from other remotes or
electronic devises may affect normal oper-
ation.
• Assure the keys on remote are being
pressed firmly down when operating
the Head & Foot buttons.
Page 12

TROUBLESHOOTING
PROBLEMS SOLUTIONS
Massage motor/s seem ex-
cessively loud during opera-
tion.
• Hard surface flooring may cause added vi-
bration. Place carpet pieces or rubber furni-
ture cups under each leg or caster of the
bed.
• Check that the bed is not in direct contact
with a wall, or other object that may cause
vibration or noise.
• If adjustable base is installed on top of a
bed frame, check that the massage motors
are not causing the bed frame (or compo-
nents) to vibrate or rattle.
• If a headboard is utilized, please check that
the attachment hardware is tightened firmly.
USB and/ or under bed
lighting.
• Check to see if the cable has been pulled
out from control box. If so, plug back in.
• For USB, try using alternative devices and/
or cables. Please note: Generic cables may
not work and you may be required to utilise
genuine cables manufactured by your devic-
es company. The USB port is a SLOW charg-
ing port and will not support Fast Charge.
If you have followed the instructions outlined in this manual, and your problem
is persisting, please contact the retailer you originally purchased your bed from
or Avante Australia for further assistance.
Page 13

PRODUCT GUARANTEE
Congratulations on your purchase. Avante Australia is an Interna-
tional Brand that uses technology, production facilities and teams
with over 20 years’ experience.
Our goods come with guarantees that cannot be excluded under the Aus-
tralian Consumer Law. You are entitled to a replacement or refund for a
major failure and for compensation for any other reasonably foreseeable
loss or damage. You are also entitled to have the goods repaired or replaced
if the goods fail to be of acceptable quality and the failure does not amount
to a major failure.
Avante Australia proudly provides a full guarantee (10 years applies to
frame, structure & electric motors only. All other electronic components &
upholstery are covered for 2 years) please refer to our website for details
against faulty workmanship and/or faulty materials. During the guarantee
period, if the company is satisfied there is a genuine fault, it will repair or
replace the product at its option.
THE GUARANTEE DOES NOT EXTEND TO THE FOLLOWING:
• Fabric (including stains, soiling, burns and normal wear).
• Items upon inspection that are deemed unsanitary.
• Normal wear and tear, or damage caused by abuse.
• Clearance bedding sold in ‘as is’ condition.
• Failure to comply with manufacturer care and maintenance instruc-
tions.
IN ORDER FOR THIS GUARANTEE TO BE VALID YOU MUST:
• Be the original purchaser.
• Provide a copy of the original store receipt.
• Not misuse the product (refer to care and maintenance and safety sec-
tions).
Page 14

PRODUCT GUARANTEE
PLEASE TAKE CARE OF YOUR ERGOADJUST DELUX BED BY
TAKING THE FOLLOWING PRECAUTIONS:
• Legs and castors should be checked for tightness regularly.
• When transporting - do not over tighten when restraining.
• Maximum recommended weight limits; on a High Low Lift bed
180kg.
• Always lock castors other than when moving or relocating the bed.
• Do not jump on or abuse the bed.
• Do not constantly push the buttons on the controller when not for in-
tended use.
• Use the controller only for adjusting the bed frame for intended use -
not for entertainment.
• Lubricate moving parts using a non-corrosive lubricant every 6
months or as required. We recommend the use of INOX.
• Beds should be positioned with clearance from walls and objects so as
not to cause damage.
We will not cover damage caused by neglect, mistreatment or general wear and
tear of the bed. Regular maintenance is required.
MAKING A CLAIM
To make a claim under this Guarantee please contact your bedding retailer
who will initiate the claim process with us. If this cannot be done, please
contact Avante Australia Pty Ltd directly via the details on the back of this
manual.
Avante Australia will require photos of Mattress and Base support system
to be sent at the time of a claim being made. For details of how to take ac-
ceptable photos please contact Avante Australia (contact details on back
page).
Page 15

NOTES
Page 16

NOTES
Page 17

Avante Australia Pty Ltd
Unit 2, 29-71 Saltwater Circuit
Narangba, QLD 4504
Phone: [phone]
Fax: [phone]
www.avanteaustralia.com.au
